MITSUBISHI MIRAGE 2015 6.G Owners Manual

Bluetooth® 2.0 interface (if so equipped) 5-100 Features and controls
5
5. The voice guide will say “Importing the contact list from the mobile phonebook.This may take several minutes to com- plete. Would you li
ke to continue?”
Answer “Yes,” transferring to the mobilephonebook the phonebook stored in the cellular phone will start. Answer “No,” the system will return tothe main menu.
6. When the transfer is complete, the voice guide will say “Import complete” andthen the system will return to the main menu.
N00566301092
MODEL: MMC FCC ID: CB2MDGMY10IC: 279B-MDGMY10 Your Bluetooth
® 2.0 interface operates on a
radio frequency subject to Federal Communi- cations Commission (FCC)
Rules (For vehi-
cles sold in U.S.A.
) and Industry Canada
Rules (For vehicles so
ld in Canada). This
device complies with Part 15 of the FCCRules and RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions:  This device may not
cause harmful inter-
ference.  This device must ac
cept any interference
received, including interference that maycause undesired operation.
The term “IC:” before
the radio certification
number only signifies th
at Industry Canada
technical specifications were met. The antenna used for this transmitter must not be co-located or operating in conjunctionwith any other antenna
or transmitter. End-
users and installers must be provided with installation instructions
and transmitter oper-
ating conditions for sa
tisfying RF exposure
compliance. FCC Notice: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 ofthe FCC Rules. These limits are designed to provide reasonable prot
ection against harmful
interference in a residential installation.This equipment generate
s, use and can radiate
radio frequency energy a
nd, if not installed
and used in accordance with the instructions,may cause harmful interf
erence to radio com-
munications. However, there is no guarantee that interfer-ence will not occur in a particular installation. If this equipment does
cause harmful interfer-
ence to radio or tele
vision reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.
NOTE
 The transfer may take some time to complete depending on the number of contacts.  If the Bluetooth
® 2.0 interface could not be
connected to the Bluetooth
® compatible cel-
lular phone, the voice gui
de will sa
y “Unable
to transfer contact list from phone” and thenthe system will return to the main menu.  If you press the HANG-UP button or press and hold the SPEECH button during the data transfer, the transfer will be cancelled and the system will return to the main menu.  If an error occurs during the data transfer, all transfer will be canc
elled and the voice guide
will say “Unable to complete the phonebook import” and then the system will return to the main menu.  If there are no contacts in the phonebook, the voice guide will say
“There are no contacts
on the connected phone.”
General information

CAUTION Changes or modifica
tions made to this
equipment not expressly approved by the manufacturer may void the FCC authoriza- tion to operate this equipment.
BK0212400US.book 100 ページ ２０１４年４月１日　火曜日　午後２時２１分

USB input terminal (if so equipped)
Features and controls 5-101
5
 Connect the equipment into an outlet on a circuit different from that to which thereceiver is connected.  Consult the dealer or an experienced radio/TV technician for help.
ICES Notice: This Class B digital apparatus complies with Canadian ICES-003.
N00566401080 N00566701083
You can connect your USB memory device or iPod
* to play music files stored in the USB
memory device or iPod.The following explains
how to connect and
remove a USB memory device or iPod.
* : “iPod” is a registered trademark of Apple Inc. in the United Stat
es and other countries.
N00566800104
1. Park your vehicle in a safe place and turn the ignition switch to the “OFF” position or put the operati
on mode in OFF.
2. Open the glove compartment and remove the connector cable (A, B) from clips (C). 3. Connect a commercially available USB connector cable (D) to the USB memory device (E).
Enrollment commands

USB input terminal
(if so
equipped)
How to connect a USB memory device

To connect

4. Connect the commercially available USB connector cable (D) to the vehicle’s con-nector cable (B). Be sure to hold the terminal part (A) of the connector cable as shown in the illus-tration. 5. Fix the connector cable (A, B) on the clips.
BK0212400US.book 101 ページ ２０１４年４月１日　火曜日　午後２時２１分

USB input terminal (if so equipped) 5-102 Features and controls
5
1. Turn the ignition switch to the “OFF” position or put the operation mode in OFF. 2. Remove the commercially available USBconnector cable (D). Be sure to hold the terminal part (A) of the connector cable as
shown in the illus-
tration.
3. Fix the connector cable on the clips and close the glove compartment.
N00566900091
1. Park your vehicle in
a safe place and turn
the ignition switch to the “OFF” position or put the operation mode in OFF. 2. Open the glove compartment and removethe connector cable (A, B) from clips (C).
3. Connect the Dock connector (D) to the iPod (E).
WA R N I N G An open glove comp
artment door can
cause a serious injury or death to the frontpassenger in an accident, even if the pas-senger is wearing his/
her seat be
lt. Always
keep the glove comp
artment door closed
when driving.NOTE
 Do not connect the US
B memory device to
the vehicle’s connector cable directly. The USB memory devi
ce may be damaged.
 When closing the glove compartment, be careful not to trap the connector cable andUSB memory device.
To r e m o v e

How to connect an iPod

To connect

NOTE
 Use a genuine Dock connector from Apple Inc. On vehicles equipped
with Mitsubishi Multi
Entertainment System (MMES), refer to theseparate “Mitsubishi Multi Entertainment System owner’s manual”
for details of con-
nection.
BK0212400US.book 102 ページ ２０１４年４月１日　火曜日　午後２時２１分

USB input terminal (if so equipped)
Features and controls 5-103
5
4. Connect the Dock connector (D) to the connector cable (B).Be sure to hold the terminal part (A) of the connector cable as shown in the illus- tration.5. Fix the connector cable (A, B) on the clips.
1. Turn the ignition switch to the “OFF” position or put th
e operation mode in
OFF. 2. Remove the Dock connector (D).Be sure to hold the terminal part (A) of the connector cable as
shown in the illus-
tration. 3. Fix the connector cable on the clips and close the glove compartment.
N00567001067
For details about the
types of connectable
devices and supported fi
le specifications,
refer to the separa
te owner's manual.
For details about the
types of connectable
devices and supported fi
le specifications,
refer to the fo
llowing section.
N00567101143
Devices of the following types can be con- nected.
WA R N I N G An open glove compartment door can cause a serious injury or death to the front passenger in an accident, even if the pas-senger is wearing his/her seat belt. Always keep the glove comp
artment door closed
when driving. NOTE
 When closing the glove compartment, be careful not to trap th
e connector cable and
iPod.
To r e m o v e

Types of connectable devices and supported file specifica-tions

For vehicles equipped with Mitsubishi Multi Entertainment System (MMES) Except for vehicles equipped with Mit- subishi Multi Entertainment System (MMES)Device types

Model name
Condition
USB memory device
Storage capacity of 256 Mbytes or more
iPod
*
fifth gen- eration
F/W Ver.1.3 or later
BK0212400US.book 103 ページ ２０１４年４月１日　火曜日　午後２時２１分

USB input terminal (if so equipped) 5-104 Features and controls
5
On vehicles equipped with the Bluetooth
®
2.0 interface, for thes
e connectable device
types, “iPod
*,” “iPod classic
*,” “iPod
nano
*,” “iPod touch
*” and “iPhone
*,” refer
to the following website: [For vehicles sold in U.S.A.]You can access the Mitsubishi Motors North America website. [For vehicles sold in Canada]You can access the Mi
tsubishi Motors web-
site. Please read and agree to the “Warning about Links to the Web Sites of Other Com-panies”. The websites
mentioned above may
connect you to websites
other than the Mit-
subishi Motors website.
http://www.mitsubishi-motors.com/en/prod- ucts/index.html * : “iPod,” “iPod classic,” “iPod nano,” “iPod touch” and “iPhone” are registered trade- marks of Apple Inc. in the United States and other countries.
iPod clas- sic
*
80GB/180 GB
F/W Ver.1.1.2 or later
120GB
F/W Ver.2.0.1 or later
160GB (late 2009)
F/W Ver.2.0.4 or later
iPod nano
*
first gener- ation
F/W Ver.1.3.1 or later
second generation
F/W Ver.1.1.3 or later
third gen- eration
F/W Ver.1.1.3 or later
fourth generation
F/W Ver.1.0.4 or later
fifth gen- eration
F/W Ver.1.0.2 or later
sixth gen- eration
F/W Ver.1.0 or later
iPod touch
*
first gener- ation
F/W Ver.3.1.3 or later
second generation
F/W Ver.4.2.1 or later
third gen- eration
F/W Ver.4.3.1 or later
fourth generation
F/W Ver.4.3.1 or later
Model name
Condition
iPhone
*
iPhone
F/W Ver.3.1.3 or later
iPhone 3G
F/W Ver.4.2.1 or later
iPhone 3GS
F/W Ver.4.3.1 or later
iPhone 4
F/W Ver.4.3.1 or later
iPhone 4S
F/W Ver.5.0.1 or later
Models other than USB memory devices and iPods
Digital audio player supporting mass storage class
Model name
Condition
NOTE
 Depending on the type of the USB memory device or other devi
ce connected, the con-
nected device may not
function properly or
the available functi
ons may be limited.
 It is recommended to use an iPod with firm- ware updated to th
e latest version.
 You can charge your
iPod by connecting it to
the USB input terminal
when the ignition
switch or the operati
on mode is in ON or
ACC.  Do not keep your US
B memory device or
iPod in your vehicle.  It is recommended that you back up the files in case of
data damage.
 Do not connect to the USB input terminal any device (hard disk, card reader, memory reader, etc.) other than the connectabledevices specified in the previous section. The device and/or data
may be damaged. If
any of these devices
was connected by mis-
take, remove it afte
r turning the ignition
switch to the “OFF” position or putting the operation mode in OFF.
BK0212400US.book 104 ページ ２０１４年４月１日　火曜日　午後２時２１分

Sun visors
Features and controls 5-105
5
N00567200020
You can play music files of the following specifications that are saved in a USB mem- ory device or other
device supporting mass
storage class. When
you connect your iPod,
playable file specif
ications depend on the
connected iPod.
N00524600353
Pull the sun visor downward (1) to reduce front glare while driving. To reduce side glare, turn the visor to the side (2). A vanity mirror is fitted to the back of the sun visor.
Cards can be slipped into the holder (A) on the sun visor.
File specifications

Item
Condition
File format MP3, WMA, AAC Maximum number of levels (including the root)
Level 8
Number of folders 700 Number of files 65,535
Sun visors Vanity mirror
Card holder
BK0212400US.book 105 ページ ２０１４年４月１日　火曜日　午後２時２１分

12 V power outlets 5-106 Features and controls
5
N00525000615
Accessories can be ope
rated while the igni-
tion switch or the opera
tion mode is in ON or
ACC. To use a “plug-in” type
accessory, open the
cover, and insert the
plug in the power outlet.
N00525300575
N00525800235
1- ( ) The light illuminates regardless of whether a door or the liftgate is open or closed.2- (•) Delayed off function The light illuminates when a door or theliftgate is opened. It goes off approxi- mately 30 seconds after the door or lift- gate is closed.However, the light goes off immediately with all doors and the liftgate closed in the following cases:• When the ignition switch is turned to the “ON” position or the operation mode is put in ON.• When the power door lock function is used to lock the vehicle.
12 V power outlets
CAUTION Be sure to use a “plug-in” type accessory operating at 12 V and at 120 W or less. Also be aware that
using electronic equip-
ment with the engine
off may run the battery
down. When the power outlet is not in use, be sure to close the power outlet
cover. This will pre-
vent the power out
let from becoming
clogged and short circuiting.
Interior lights
NOTE
 Be aware that leaving the light illuminated with the engine off may run the batterydown. Never leave the vehi
cle without checking
that the light is off.1- Cargo room light
 P.5-107
2- Dome light
 P.5-106
Dome light
BK0212400US.book 106 ページ ２０１４年４月１日　火曜日　午後２時２１分

Storage spaces
Features and controls 5-107
5
• When the remote control transmitter of the keyless entry system or the F.A.S.T.-key is used to lock the vehicle. • When the door lock/unlock switch or liftgate switch is pressed to lock thevehicle while carrying the F.A.S.T.-key. Auto cut-out function If the light is left switched on with theignition switch is in the “OFF” or “ACC” position or the operation mode is in OFF or ACC, and a door or the liftgate is opened, it goes off automatically after approximately 30 minutes.The light will illuminate again after it automatically goes off in the following cases:• When the ignition switch is turned to the “ON” position or the operation mode is put in ON.• When the keyless entry system or the F.A.S.T.-key is operated. • When all doors and the liftgate areclosed.
3- ( ) The light goes off regardless of whether a door or the liftgate is open or closed.
N00526100176
The light illuminates when the liftgate is opened, and goes out when the liftgate isclosed.
N00526400528
NOTE
 When the key was used to start the engine: if the key is removed while the doors and lift- gate are closed, the li
ght is illuminated and
after approximately 30
seconds it goes off.
When the F.A.S.T.-key was used to start the engine: if the operation
mode is put in OFF
while the doors and lift
gate are closed, the
light illuminates and
after approximately 30
seconds it goes off.  The time until the light
goes off (delayed off)
can be adjusted. See your authorized Mitsubishi Motors dealer for details.  The auto cut-out func
tion cannot be
operated
when the dome light switch is in the “ ” position. Also, this function can
be deactivated. See
your authorized Mitsubish
i Motors dealer for
details.
Cargo room light
NOTE
Storage spaces
CAUTION Never leave lighters,
carbonated drink cans,
or spectacles in the cabin when parking the vehicle in hot suns
hine. The cabin will
become extremely hot,
so lighters and other
flammable items may catch fire and unopened drink cans (i
ncluding beer cans)
may rupture. The heat may also deform orcrack plastic spectacle
lenses and other spec-
tacle parts that are made of plastic. Keep the lids of storage spaces closed while driving the vehicle. A li
d or the contents of a
storage space could otherwise cause injuriesduring a sudden stop.NOTE
 Do not leave valuables
in any storage space
when leaving the vehicle.
BK0212400US.book 107 ページ ２０１４年４月１日　火曜日　午後２時２１分

Cup holders 5-108 Features and controls
5
N00551500275
To open, pull the lever (A).
N00527301433
The cup holder is designed for holding cups or drink-cans secu
rely in its holes.
The cup holder is located in front of the floor console.
N00537000175 N00502800065
Glove compartment
WA R N I N G An open glove comp
artment door can
cause a serious injury or death to the frontpassenger in an accident, even if the pas- senger is wearing his/
her seat be
lt. Always
keep the glove comp
artment door closed
when driving.NOTE
 The USB input terminal (if so equipped) is located in the glove compartment. Fordetails, refer to “USB input terminal” on page 5-101.
Cup holders
NOTE
 Plastic bottles may sometimes not fit securely depending on the shape of the bot- tle. Plastic bottles could fall if driving isdone while a plastic bot
tle is not securely
placed, so check that plastic bottles are placed securely or
use the bottle holder.
For the front seat
CAUTIONDo not drink beverages while driving your vehicle.This is distracting a
nd could cause an acci-
dent.
For the rear seat Bottle holders
CAUTION Drink beverages while
driving your vehicle
is distracting and ca
n cause an accident.
Vibration and shaking while driving may cause beverages to spill.
Be very careful, as
spilling hot beverage
s could cause burns.
BK0212400US.book 108 ページ ２０１４年４月１日　火曜日　午後２時２１分

Rear shelf panel (if so equipped)
Features and controls 5-109
5
There are bottle holders located on the front doors.
N00528200096
1. Insert the concave portion (A) on the underside of the rear shelf panel into the inside protruding portion (B) of the rearpillar.
2. Hang the strap (C) of the rear shelf panel on the hook (D).
Follow this procedure
in reverse to remove.
N00574700014
Convenience hook is lo
cated on the seatback
of the passenger’s seat.
NOTE
 Do not store cup or drink can in the bottle holder.  Make sure all lids are tightly closed when storing beverages that
are in plastic bottles,
etc.  Some beverages may not
be stored, depend-
ing on the size and shape of the plastic bot-tles, etc.
Rear shelf panel
(if so equipped)
CAUTION Do not place luggage or other items on the rear shelf panel. Any it
ems on the rear shelf
panel would obstruct
your rearward view,
and they could fly forward and cause injuries or other mishap in the event of hard braking.
To install

CAUTION Lightly push the rear shelf panel to make sure that the concave portion (A) is setfirmly in the protruding portion (B) of theliftgate. If the rear shelf panel is not securely locked in place, it could unhook while driv- ing and cause injuries.
To remove

Convenience hook
BK0212400US.book 109 ページ ２０１４年４月１日　火曜日　午後２時２１分
