Engine specifications 11-4 Specifications
11
GVWR: maximum total weight (load) limit specified for the vehicle GAWR: maximum weight (load) limit sp
ecified for the front or rear axle
Seating capacity: the maxi
mum number of occupants
N01147700514
N01147800296
Battery is a 12 volt type.
Gross axle weight rating
Front 1,609 lb (730 kg)Rear 1,477 lb (670 kg)
Vehicle capacity weight 827 lb (375 kg)Seating capacity 5 personsEngine specifications Engine model
3A92
Engine displacement
72.8 CID (1,193 cm
3)
No. of cylinders and cy
linder arrangement Inline-3
Bore
2.95 in (75.0 mm)
Stroke
3.54 in (90.0 mm)
Compression ratio
10.5:1
Thermostat valve opening temperature 189 °F (87 °C)Spark plugs
NGK LZFR5BI-11
Spark plug gap .040 to .043 in (1.0 to 1.1 mm)Firing order
1-3-2
Item
M/T
CVT
Battery
55D23L (356CCA/99RC)
BK0212400US.book 4 ページ 2014年4月1日 火曜日 午後2時21分
Page 292 of 300
Tires and wheels
Specifications 11-5
11
N01147900747
PCD: Pitch Circle Diameter (installation holes)
N01148002130
Tires and wheels Tire 165/65R14Wheel
Size 14 x 4 1/2JPCD 3.93 in (100 mm)Offset 1.81 in (46 mm)
NOTE
Contact an authorized Mitsubishi Motors dealer for details on the combination used on your vehicle. These tires satisfy ve
hicle loading conditions
described in this owner’s manual.
Capacity
Item
Capacity
Lubricants
Fuel (approximate)
9.2 gal (35 L) Refer to “Fue
l selection” on page 3-2
Engine oil
Oil pan 2.9 qt (2.8 L) Engine
oils displaying the ILSAC
certification mark (“star-
burst” symbol) on the container. If these oils are not available, an API classification SN or higher can be used.
Oil filter .21 qt (0.2 L)
Manual transaxle 1.7 qt (1.6 L)
Mitsubishi Motors Genuine
NEW MULTI GEAR OIL ECO
API classification GL-4 SAE 75W-80
Continuously variable transm
ission (CVT) 7.4 qt (7.0 L)
Refer to “Continuously variable
transmission (CVT) fluid” on
page 9-9.
Brake As required Conforming to Brake fluid DOT3 or DOT4Hood lock release mechanism and
safety catch As required Multipurpo
se type grease NLGI Grade 2
Engine coolant {Includes .53 qt (0.5 L) in reserve tank}
M/T 4.2 qt (4.0 L)
Mitsubishi Motors Genuine S
uper Long Life Coolant Premium
or equivalent
*
CVT 4.8 qt (4.6 L)
BK0212400US.book 5 ページ 2014年4月1日 火曜日 午後2時21分
Page 293 of 300
Capacity 11-6 Specifications
11
* : similar high quality ethylene
glycol based non-silicate, non-
amine, non-nitrate and non-borate
coolant with long life hybrid
organic acid tech-
nologyWasher fluid 2.6 qt (2.5 L) —Refrigerant (air conditioning)
Refer to the “Air con- ditioning label” on
page 11-2.
HFC-134a
Item
Capacity
Lubricants
BK0212400US.book 6 ページ 2014年4月1日 火曜日 午後2時21分
Page 294 of 300
Alphabetical index
12-1
12
A
Accessory (installation)
.........................
3-5
Active stability control (ASC)
..............
5-49
Air bag
..............................................
4-21
Air cleaner filter
...................................
9-8
Air conditioning
Automatic air conditioning
..............
7-11
Important air condi
tioning operating tips
..
7-17 Manual air conditioning
....................
7-7
Air purifier
.........................................
7-18
Aluminum wheels
...............................
9-35
Antenna
Roof antenna
..................................
7-41
Anti-lock braking system
.....................
5-46
Assist grip
........................................
5-110
Audio
AM/FM electronically
tuned radio with
CD player
....................................
7-18
Error codes
.....................................
7-38
Handling of compact discs
...............
7-40
Automatic air conditioning
..................
7-11
B
Back-up light
Bulb capacity
.................................
9-26
Ball joint, steering li
nkage seals and drive
shaft boots
.......................................
9-21
Battery
..............................................
9-10
Charging system warning light
........
5-73
Checking battery
electrolyte level
....
9-10
Disconnection and connection
.........
9-11
During cold weather
.......................
9-11
Specification
..................................
11-4
Bluetooth® 2.0 interface
.....................
5-81
Bottle holders
....................................
5-108
Brake
Fluid
.............................................
11-5
Brake assist system
.............................
5-46
Braking
...............................................
6-5
Anti-lock braking system
................
5-46
Hose
.............................................
9-20
Pad wear alarm
..............................
5-45
Parking brake
.................................
5-31
Pedal
.............................................
5-44
Pedal free play
...............................
9-18
Power brakes
.................................
5-44
Service brake
.................................
5-44
Warning lights
...............................
5-72
Break-in recommendations
....................
5-2
Bulb capacity
.....................................
9-26
C
California Perchl
orate Materials
Requirements
.....................................
3-7
Capacities
..........................................
11-5
Card holder
......................................
5-105
Cargo loads
........................................
6-10
Cargo room light
Bulb capacity
.................................
9-27
Catalytic converter
................................
9-3
Certification label
...............................
11-3
Charging system warning light
.............
5-73
Child restraint systems
........................
4-14
Child safety locks for rear door
............
5-27
Cleaning
Inside of your vehicle
......................
9-32
Outside of your vehicle
...................
9-33
Clutch
Pedal free play
................................
9-18
Consumer information
.........................
10-2
Continuously variable transmission (CVT)
...
5-39 Fluid
.......................................
9-9
, 11-5
Selector lever operation
...................
5-40
Selector lever positions
....................
5-41
Convenience hook
.............................
5-109
Coolant (engine)
..........................
9-7
, 11-5
Cruise control
.....................................
5-52
Cup holders
......................................
5-108
