MITSUBISHI MIRAGE 2018 (in English) User Guide

10SMARTPHONE LINK DISPLAY AUDIO (SDA) (IF EQUIPPED)
SETTING THE CLOCK
TO CHANGE THE CLOCK ON ON YOUR SMARTPHONE DISPL AY AUDIO (SDA)
1. From the Home screen, touch Setup
2. From the Setup screen, touch Clock
You can now adjust the time and date.
SMARTPHONE LINK DISPLAY AUDIO (SDA) (IF EQUIPPED)
A
F
G
H
I
JB
C
D
E
A - CD Slot
B - Power & Volume Knob
C - EJECT Button (Eject CD)
D - SEEK Button (Selects next station or track)
E - TRACK (Selects previous station or track)
F - Tune and Illumination Knob (Radio Station)
G - HOME Button (Return to initial display)
H - RADIO (FM1, FM2, AM)
I - Touch Screen Display
J - RESET (Reboot and clear all presets)

11
ACCESSING APPLE CARPLAY™ACCESSING ANDROID AUTO™
1. Make sure your iPhone® has iOS7.1 or later and that you are using a genuine
Apple Lightning® to USB cable.
2. Connect the Apple Lightning
® to USB cable to your phone and to the vehicle’s
USB port in the Center Console.
3. Apple CarPlay will automatically connect. To use the iPhone with CarPlay even
while locked, choose “Allow” on your iPhone’s screen after the first connection.
4. You can now operate Siri by pressing and holding the Steering Wheel Audio
Speech button until prompted on the screen. 1.
You must download the Android Auto app from the Google Play Store. This
process may take up to a couple of minutes.
2. Connect your manufacturers phone cable from your phone and into the vehicles
USB port located in the Center Console.
3. Follow your phone’s on screen instruction until you are connected to Android
Auto. You can press the Speech button on the Steering Wheel Audio Controls to
activate voice operation.
Apple CarPlay, iPhone, Siri and Lightning are trademarks of Apple Inc., \
registered in the U.S. and other Countries. Android, Android Auto, Googl\
e Play and other marks are trademarks of Google Inc.
SMARTPHONE LINK DISPLAY AUDIO (SDA) (IF EQUIPPED)

12
Q: Is my phone compatible with the factory Mitsubishi Bluetooth® Hands Free System?
A: Check the list of compatible phones, www.mitsubishicars.com/owners to see if the phone is Bluetooth® supported.
Q: How do I use Bluetooth
® Audio?
A: Please refer to your Owner’s Manual for instructions.
Q: Why does my Anti-Lock Braking System (ABS) make a noise?
A: Each time your vehicle is started and driven a short distance, you will hear the sound of the ABS motor operating from the right front eng\
ine
compartment. This is the normal sound the Anti-Lock Braking System makes when performing a self check.
Q: Why does the Audio System take so long to upload my music from my audio music device?
A: The Mitsubishi system can read multiple device structures in order to catalog the music files for easy playing and listening. Depending on the amount
of music you have on your device, this may take a few minutes.
Q: How can I play music from my portable music player through the stereo system in my vehicle when equipped with the Bluetooth
® Phone System?
A: Once your device is paired to the Bluetooth® Phone System, you can stream music from your device to your vehicle’\
s sound system. No wires or cords.
Your music stops and restarts at the same song when you exit and when you re-enter the vehicle. Voice commands are not available.
Q: My Mirage has a 12V accessory outlet. What devices can I plug in to it?
A: This outlet is protected with a 15 amp fuse. Always check the current draw rating of any device prior to use in the vehicle. If the devi\
ce is rated above
10 amps, this could lead to circuit overload and the electrical fuse opening (no current flow).
Q: How can I get the MPG stated on the window sticker?
A: Vehicle driving styles will greatly affect MPG. Avoid sudden starts from a stop and let the vehicle coast to a traffic light. Both of these styles will
increase mileage and reduce brake lining wear.
• Vehicles are designed to achieve the best fuel mileage when they are driven at the speed limits on the freeway. Avoid driving over 6\
5 mph.
• Under inflated tires will increase rolling resistance and will reduce fuel mileage. Check tire pressure frequently to increase miles per \
gallon.
Proper tire pressure also ensures optimum tire performance (including tire wear.)
Q: Why does my check engine light come on after I put gas in my car?
A: There are many reasons why your check engine light may illuminate. Before calling your dealership, make sure the fuel cap is fully eng\
aged and you
have heard three clicks when tightening it. After checking and hearing three clicks and the light is still on, contact your dealership.
Q: How do I use the emergency key when the FAST-key battery or vehicle battery is run down?
A: If your Mirage is equipped with a Start/Stop Engine switch and the door does not open, take the key out from the fob and unlock the fron\
t passenger
door manually. Put the key back into the fob and insert it into the slot provided below the Climate Control Switches. Starting the engine and\
charging
the operation mode should now be possible. Remove the FAST-key from the key slot after starting the engine or charging the operation mod\
e.
FAQ’S

PLEASE PLACE COPIES OF THE FOLLOWING ITEMS IN THE POCKET BELOW:
1. Pre-Delivery Inspection Form (Customer Copy)
2. Triple Diamond Delivery Checklist (Customer Copy)
3. Salesperson or Key Dealership Contact’s Business Card
A CENTURY OF BIG IDEAS IN
TWO SUBCOMPACT VEHICLES
For 100 years, Mitsubishi has been a pioneer in the automotive industry, incorporating visionary design with technology ahead of its time. Our \
drivers are more than just
car enthusiasts––they share our conspicuously bold imagination and\
have the confidence to adhere to their convictions and follow their own paths in life. The Mirage
and its more robust sibling the Mirage G4 sedan are two subcompact model\
s that embody the adventure our drivers seek out. Not just kindred spirits––they both offer
the top fuel-efficiency ratings in their respective classes, so even the\
most remote road trip destinations are within reach. Inside, you’ll find the kind of high-tech features
you want when you’re checking places off your bucket list. And in kee\
ping with our century-long legacy of offering affordably priced vehicles––while being backed by one
of the industry’s leading powertrain warranties––they’re two of the best values\
on the market today. The Mirage and Mirage G4––two seriously big ideas.
