brake pedal to center shoes, and check pedal travel. Rotate brake drum
to verify free movement.
STOPLIGHT SWITCH
Loosen lock nut, and adjust switch-to-pedal arm clearance to
.02-.04" (.5-1.0 mm). Tighten lock nut. DO NOT depress master cylinder
push rod during stoplight switch adjustment.
TESTING
POWER BRAKE UNIT
Check Valve Inspection
Remove vacuum hose from power brake unit. Remove check valve
from hose (if possible). Using a vacuum pump, ensure airflow is in
direction of intake manifold only.
System Check
1) Run engine for 2 minutes, and shut it off. Depress brake
pedal several times with normal pressure. If pedal height gradually
becomes higher with successive applications, power brake unit is okay.
If pedal height remains steady, power brake unit is faulty.
2) With engine stopped, depress brake pedal repeatedly until
it's height no longer falls. Hold brake pedal down, and start engine.
If pedal moves downward slightly, power brake unit is okay. If pedal
height does not change, power brake unit is faulty.
3) With engine running, press and hold brake pedal and shut
off engine. Hold brake pedal for 30 seconds. Brake pedal height should
not change. If pedal height falls, power brake unit is faulty.
LOAD-SENSING PROPORTIONING VALVE (LSPV) (PICKUP & RAM-50)
1) Before diagnosing Load-Sensing Proportioning Valve (LSPV)\
,
ensure all other brake components are operating properly. When all
other brake system components are determined to be okay, perform LSPV
test beginning with next step.
2) Ensure unladen vehicle is on level ground. Ensure lever is
not contacting stopper bolt. See Fig. 1.
3) When lever is pushed toward valve, distance from LSPV
lever hole and support hole must be 6.97-7.09 in. (177-180 mm). If
measured distance is not within specification, loosen support bolt.
Adjust support until measured distance is within specification.
4) After measured distance is within specification, connect
pressure gauges to input and output ports of LSPV. See Fig. 4. Bleed
brake system. See BLEEDING BRAKE SYSTEM .
Fig. 4: Connecting Pressure Gauges to LSPV (Pickup & Ram-50)
Courtesy of Mitsubishi Motor Sales of America.
Page 212 of 1333
5) Remove the LSPV load-sensing spring. Slowly depress the
brake pedal. Check the readings on the pressure gauges. Refer to the
LSPV PRESSURE SPECIFICATIONS table.
6) Install LSPV load-sensing spring. Load weight into rear of
vehicle until measured spring length distance is 7.0" (178 mm) with
lever slightly pressed in. See Fig. 1.
7) Slowly depress brake pedal. Check readings on pressure
gauges. See LSPV PRESSURE SPECIFICATIONS table. If fluid pressure is
not within specification, ensure all other brake system components are
okay. If other components are okay, replace LSPV assembly.
LSPV PRESSURE SPECIFICATIONS (PICKUP & RAM-50)
\
\
\
\
\
\
Application Inlet Pressure Outlet Pressure
psi (kg/cm) psi (kg/cm)
Load-Sensing Spring
Removed ........... 853 (60) ......... 242-327 (17-23)
Installed ........ 1991 (140) .... ( 1) 299-583 (21-40)
( 1) - On vehicles with 2WD and heavy-duty suspension,
outlet pressure is 526-697 psi (37-49 kg/cm
). \
\
\
\
\
\
PROPORTIONING VALVE (NON-LOAD-SENSING) (MONTERO)
Pressure Test
1) Connect pressure gauges to input and output ports of the
proportioning valve. See Fig. 5. Bleed brake hydraulic system. Refer
to BLEEDING BRAKE SYSTEM .
2) Slowly depress brake pedal. Check readings on pressure
gauges. See the PROPORTIONING VALVE PRESSURE SPECIFICATIONS table. If
fluid pressures are not within specification, replace proportioning
valve.
Fig. 5: Connecting Pressure Gauges to Proportioning Valve (Typical)
Courtesy of Mitsubishi Motor Sales of America.
PROPORTIONING VALVE PRESSURE SPECIFICATIONS (MONTERO)
\
\
\
\
\
\
Page 213 of 1333
Inlet Pressure Outlet Pressure
Application psi (kg/cm) psi (kg/cm)
2.6L
Test 1 ............ 853 (59) ......... 473-526 (33-37)
Test 2 ........... 1280 (88) ......... 672-757 (46-52)
3.0L
2-Door Model
Test 1 .......... 853 (59) ......... 473-526 (33-37)
Test 2 ......... 1565 (108) ........ 768-865 (54-60)
4-Door Model
Test 1 .......... 597 (41) ......... 569-626 (39-43)
Test 2 ......... 1377 (95) ......... 843-928 (58-64)
( 1) - Maximum side-to-side pressure differential
is 57 psi (4kg/cm
). \
\
\
\
\
\
REMOVAL & INSTALLATION
FRONT BRAKE PADS
CAUTION: DO NOT remove or contaminate special grease coating on lock
pins.
Removal
1) Raise and support vehicle. Remove front wheel(s). Remove
lower lock pin or sleeve bolt. See Fig. 6. Lift caliper body upward.
2) Support caliper using wire. Remove shim(s), shim holder
(if equipped), anti-squeak shim and pad assembly from support
mounting. Remove pad clips.
Installation
If installing new pads, compress piston to bottom of bore.
Install retaining clips, pad assembly, shim(s), shim holder (if
equipped) and anti-squeak shim onto support mounting.
Fig. 6: Exploded View of Front Disc Brake Assembly (Typical)
Courtesy of Chrysler Motors.
FRONT BRAKE CALIPER
Page 214 of 1333
![MITSUBISHI MONTERO 1991 Service Manual Removal
1) Raise and support vehicle. Remove front wheel(s). Separat\
e
rubber flex hose from hydraulic line at brake hose mount, located on
strut housing. Secure end of hydraulic li](/img/19/57332/w960_57332-213.png "MITSUBISHI MONTERO 1991 Service Manual Removal
1) Raise and support vehicle. Remove front wheel(s). Separat\
e
rubber flex hose from hydraulic line at brake hose mount, located on
strut housing. Secure end of hydraulic li")
Removal
1) Raise and support vehicle. Remove front wheel(s). Separat\
e
rubber flex hose from hydraulic line at brake hose mount, located on
strut housing. Secure end of hydraulic line to prevent spillage of
brake fluid.
2) Remove hose clip from brake hose mount. Disconnect brake
hose from caliper. Remove upper and lower caliper-to-steering knuckle
bolts. Lift caliper body upward. Remove caliper.
Installation
To install, reverse removal procedure. Tighten bolts to
specification. See the TORQUE SPECIFICATIONS table. Bleed brake
system. See BLEEDING BRAKE SYSTEM .
FRONT BRAKE ROTOR
Removal (Montero, Pickup 4WD & Ram-50 4WD)
Raise and support vehicle. Remove and support brake calipers.
Place hub in free-wheeling position. Remove drive hub cover using an
oil filter wrench and protective cloth. Remove snap ring, shim and
free-wheeling hub from drive axle. See Fig. 7. Remove lock washer.
Remove lock nut using Lock Nut Wrench (MB990954). Remove front hub
assembly.
Fig. 7: Exploded View of Front Brake Assembly (4WD)
Courtesy of Mitsubishi Motor Sales of America.
Installation
1) Install front hub assembly. Install and tighten lock nut
to 94-145 ft. lbs. (127-197 N.m), and then loosen and retighten to 18
ft. lbs. (24 N.m). Loosen lock nut 30-40 degrees. Reverse removal
procedure for remaining components. After installation is complete,
check drive axle end play. Adjust end play if not .002" (.05 mm) or
less. Rotate drive axle forward and rearward until maximum end play is
obtained.
2) If adjusting axle shaft end play, use proper shim to
obtain desired end play. Shim is located behind snap ring on end of
drive axle. Install shim, and recheck axle end play.
Removal (Pickup 2WD & Ram-50 2WD)
Raise and support vehicle. Remove front caliper. Remove hub
(dust) cap, cotter pin and nut. Remove washer and outer wheel bearing.\
Remove front hub assembly. Remove bolts attaching rotor to front hub,
and separate assemblies.
Page 215 of 1333
Installation
To install, reverse removal procedure. Tighten wheel bearings
to 22 ft. lbs. (30 N.m). Loosen nut, and then retighten to 72 INCH
lbs. (8 N.m). Install cotter pin. If pin does not align, loosen nut up\
to a maximum of 30 degrees.
REAR BRAKE DRUM & SHOES
Removal
1) Raise and support vehicle. Remove wheel and brake drum.
Remove shoe return spring and brake shoe adjuster. See Fig. 8. Remove
adjusting spring, shoe retaining spring and shoe hold-down pins.
2) Remove shoe and lining assembly with parking brake lever.
Remove cable from parking lever. Remove parking brake lever snap ring,
and disengage lever from brake shoe.
Fig. 8: Exploded View of Rear Brake Assembly
Courtesy of Mitsubishi Motor Sales of America.
Installation
1) To install, reverse removal procedure. Apply Lubriplate to
backing plate bosses, adjuster assembly threads and parking brake
lever pin.
2) Set adjustment assembly so brake shoes lightly contact
brake drum. Depress brake pedal to center shoes, and check pedal
travel. Rotate brake drum to ensure free movement.
WHEEL CYLINDERS
Removal & Installation
Raise and support vehicle. Remove rear brake drum and shoes.
See REAR BRAKE DRUM & SHOES under REMOVAL & INSTALLATION. Remove wheel
cylinder and seal assembly. To install, reverse removal procedure.
Bleed brakes.
MASTER CYLINDER
Removal
Drain brake fluid from master cylinder. Remove sensor
connector (if equipped). Disconnect brake lines from master cylinder,
and install plugs to prevent brake fluid spillage. Remove master
cylinder from booster unit and separate reservoirs from housing (if
necessary).
Installation
To install, reverse removal procedure. Before installation,
check and adjust clearance between back of master cylinder piston and
power brake push rod. Refer to MASTER CYLINDER PUSH ROD under
ADJUSTMENTS. After installation, adjust the brake pedal height. Refer
to BRAKE PEDAL HEIGHT & FREE PLAY under ADJUSTMENTS. Bleed brake
system. See BLEEDING BRAKE SYSTEM .
Page 216 of 1333
POWER BRAKE UNIT CHECK VALVE
NOTE: To test check valve before removal, stop engine, and apply
service brake to ensure air flows only toward intake
manifold.
Removal & Installation
Loosen hose clamps, and remove check valve. Before
installation, coat both ends of check valve with sealant, and install
valve with arrow (identification mark) pointing toward intake
manifold. Install check valve clamp, and secure hose clamps.
POWER BRAKE UNIT
Removal
Remove brake master cylinder. Disconnect vacuum hose from
power brake unit. Disconnect clevis pin attaching brake pedal to power
brake unit push rod. From inside vehicle, remove 4 nuts attaching
power brake unit to firewall. Remove power brake unit.
Installation
To install, reverse removal procedure. Install master
cylinder. Bleed brake system if necessary.
REAR AXLE BEARINGS & OIL SEAL
Removal (Montero)
1) With drum removed, disconnect brake line from wheel
cylinder. Disconnect bearing case from axle housing end. Remove brake
backing plate, bearing case and axle shaft as an assembly. If axle
shaft binds, use slide hammer with puller to remove.
2) Remove "O" ring and shims for preloading wheel bearing (if\
equipped). Retain shims for reassembly. To remove oil seal, use slide
hammer and hook.
3) To remove wheel bearing, straighten lock washer tabs. See
Fig. 9 . Remove lock nut using spanner wrench. Remove lock washer.
Install lock nut 3 turns on axle shaft. Install Puller (MB990787-01)
to remove axle shaft from bearing case. Rotate nuts with equal force
to remove axle shaft. Remove bearing outer race using a hammer and
drift.
Fig. 9: Removing Rear Axle Bearing (Montero)
Courtesy of Mitsubishi Motor Sales of America.
Installation
1) Apply Multipurpose Grease (SAE J310) to oil seal. Install\
Page 217 of 1333
oil seal using seal driver. Apply grease to outside circumference of
bearing outer race. Apply grease to lip of oil seal and to roller
surfaces of bearing inner race.
2) Press bearing onto axle shaft. Install rear brake assembly
and bearing case. Pack bearing case and axle threads with grease.
Install lock washer (tab aligned with axle slot) and lock nut (chamfe\
r
toward lock washer). Tighten lock nut to 130-159 ft. lbs. (176-216 N.
m).
3) Bend tabs on lock washer into slots of lock nut. Apply
grease to oil seal area of rear axle housing. Adjust clearance between
bearing case and rear axle by inserting .04" (1.0 mm) shim and "O"
ring into left rear axle housing.
4) Apply semi-drying sealant to mating surface of bearing
case. Install left axle shaft into rear housing. Tighten nuts
diagonally to 36-43 ft. lbs. (49-58 N.m).
5) Install right axle shaft without shims and "O" ring.
Temporarily tighten to about 53 INCH lbs. (6 N.m). Using a feeler
gauge, measure clearance between bearing case and rear axle housing.
6) Remove right axle shaft. Install shims to equal bearing
case-to-axle housing clearance plus .002-.008" (.05-.20 mm). Install
"O" ring to right rear axle housing. Apply sealant to mating surfaces
of bearing case and shim. See Fig. 10.
7) Install axle into housing, tightening nuts diagonally to
36-43 ft. lbs. (50-58 N.m). Check axle shaft for .002-.008" (.05-.20
mm) end play using dial indicator.
Fig. 10: Applying Sealant (Montero, Pickup & Ram-50)
Courtesy of Mitsubishi Motor Sales of America.
Removal (Pickup & Ram-50)
1) With drum removed, disconnect brake line from wheel
Page 218 of 1333
cylinder. Disconnect parking brake cable end, and remove cable
attaching bolts. Remove brake backing plate, bearing case and axle
shaft as an assembly. If axle shaft binds, use slide hammer with
puller to remove.
2) Remove shims, "O" ring and snap ring. Retain shims for
reassembly. Secure axle shaft assembly in a vise, and remove one
retainer bolt from backing plate. Push bearing case completely to side
of dust cover. Place adhesive tape around edge of bearing case at
retainer bolt hole to prevent damage.
3) Secure axle shaft, and grind retainer ring until retainer
ring wall thickness is .04-.06" (1.0-1.5 mm) on axle shaft side and
retainer ring wall thickness is .08" (2.0 mm) on bearing side. See
Fig. 11.
CAUTION: DO NOT damage bearing case or axle shaft when grinding or
chiseling retainer ring.
4) Change angle of grind, and remove remaining .08" (2.0 mm)\
of retainer ring wall on bearing side. See Fig. 11. Using a chisel,
cut retainer ring, and remove. DO NOT damage axle shaft.
Fig. 11: Grinding Bearing Retainer Ring (Pickup & Ram-50)
Courtesy of Mitsubishi Motor Sales of America.
5) Install Puller (MB990787-01) to remove bearing case from
axle shaft. Rotate nuts with equal force to remove wheel bearing.
Page 219 of 1333
Remove bearing outer race using a hammer and drift. Remove oil seal
from axle housing using a slide hammer and hook.
Installation
1) Apply Multipurpose Grease (SAE J310) to oil seal. Install\
oil seal using seal driver. Apply grease to outside circumference of
oil seal lip. Install backing plate and bearing case. Apply grease to
oil seal.
2) Press new oil seal into bearing case until it is flush
with face of bearing case. Apply grease to lip of oil seal and to
external surfaces of bearing outer race. Press bearing outer race into
bearing case.
3) Apply grease to roller surfaces of bearing inner race.
Install rear brake assembly and bearing case. Pack bearing case and
axle threads with grease. Install new retainer ring.
4) Adjust clearance between bearing case and rear axle by
inserting .04" (1.0 mm) shim and "O" ring into left rear axle housing.\
Apply semi-drying sealant to mating surface of bearing case. Install
left axle shaft into rear housing. Tighten nuts diagonally to 36-43
ft. lbs. (50-58 N.m).
5) Install right axle shaft without shims and "O" ring.
Temporarily tighten to about 53 INCH lbs. (6 N.m). Using a feeler
gauge, measure clearance between bearing case and rear axle housing.
6) Remove right axle shaft. Install shims to equal bearing
case-to-axle housing clearance plus .002-.008" (.05-.20 mm). Install
"O" ring to right rear axle housing. Apply sealant to mating surface
of bearing case. See Fig. 10.
7) Install axle into housing, tightening nuts diagonally to
36-43 ft. lbs. (49-58 N.m). Check axle shaft for .002-.008" (.05-.20
mm) end play using dial indicator.
OVERHAUL
NOTE: For exploded views of front disc brake caliper, see Fig. 12.
For exploded view of master cylinder, see Fig. 13.
Fig. 12: Exploded View of Front Disc Brake Caliper (Typical)
Courtesy of Mitsubishi Motor Sales of America.
Page 220 of 1333
![MITSUBISHI MONTERO 1991 Service Manual Fig. 13: Exploded View of Master Cylinder (Typical)
Courtesy of Mitsubishi Motor Sales of America.
DISC BRAKE SPECIFICATIONS
DISC BRAKE SPECIFICATIONS TABLE \](/img/19/57332/w960_57332-219.png "MITSUBISHI MONTERO 1991 Service Manual Fig. 13: Exploded View of Master Cylinder (Typical)
Courtesy of Mitsubishi Motor Sales of America.
DISC BRAKE SPECIFICATIONS
DISC BRAKE SPECIFICATIONS TABLE \")
Fig. 13: Exploded View of Master Cylinder (Typical)
Courtesy of Mitsubishi Motor Sales of America.
DISC BRAKE SPECIFICATIONS
DISC BRAKE SPECIFICATIONS TABLE \
\
\
\
\
\
Application In. (mm)
Disc Diameter
Montero
2.6L ...................................... 10.2 (259)
3.0L ...................................... 10.9 (277)
Pickup & Ram-50
2WD ....................................... 10.2 (259)
4WD ....................................... 10.9 (277)
Lateral Runout ................................ .006 (.15)
Parallelism .......................................... ( 1)
Original Thickness .............................. .87 (22)
Master Cylinder Diameter .................... .938 (23.83)
Minimum Refinish Thickness .................... .80 (20.4)
Discard Thickness ............................. .78 (19.8)
( 1) - Information is not available.
\
\
\
\
\
\
DRUM BRAKE SPECIFICATIONS
DRUM BRAKE SPECIFICATIONS TABLE \
\
\
\
\
\
Application In. (mm)
Drum Diameter ................................. 10.0 (254)
Drum Width ........................................... ( 1)
Master Cylinder Diameter .................... .938 (23.83)
