TORQUE CONVERTERS
TORQUE CONVERTER INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Converter clutch lock-up
operation is faulty .... A ............ Require replacement.
Cover shell damaged,
affecting performance .. A ............ Require replacement.
Does not meet stall speed
specification .......... B ............ Require replacement.
End play exceeds
specifications ......... B ............ Require replacement.
Hub broken .............. A ............ Require replacement.
Hub cracked ............. A ............ Require replacement.
Internal component
failure ................ A ............ Require replacement.
Leaking ................. A .. Require repair or replacement.
Pilot broken ............ A ............ Require replacement.
Pilot worn, affecting
performance ............ A ............ Require replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
Weights missing ......... C ............ Require replacement.
\
\
\
\
\
\
\
TRANSAXLE MOUNTS
See MOUNTS (ENGINE, TRANSAXLE AND TRANSMISSION) .
TRANSDUCERS (TRANSMISSION)
See SENSORS.
TRANSMISSION COOLERS
TRANSMISSION COOLER INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Air flow obstruction .... A ................. Require repair.
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A .. Require repair or replacement
of hardware.
Connection leaking ...... A .. Require repair or replacement.
Contaminated ............ A .. Require repair or replacement.
Corroded ................ 1 .. Suggest repair or replacement.
Fins damaged, affecting
Page 452 of 1501
![MITSUBISHI MONTERO 1998 Workshop Manual VENT INSPECTION \
\
\
\
\
\
\
Condition Code](/img/19/57333/w960_57333-451.png "MITSUBISHI MONTERO 1998 Workshop Manual VENT INSPECTION \
\
\
\
\
\
\
Condition Code")
VENT INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Broken .................. A ............ Require replacement.
Missing ................. C ............ Require replacement.
Plugged ................. A ........... (1) Require repair or
replacement.
( 1) - A plugged vent may force fluid past the seal.
\
\
\
\
\
\
\
VIBRATION DAMPERS
VIBRATION DAMPER INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Broken .................. A ............ Require replacement.
Missing ................. C ............ Require replacement.
Out of position ......... B .. Require repair or replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
\
\
\
\
\
\
\
WHEEL ATTACHMENT HARDWARE
NOTE: For conditions noted below, also check conditions of
wheel stud holes.
CAUTION: Proper lug nut torque is essential. Follow recommended
torque specifications and tightening sequence. DO NOT
lubricate threads unless specified by the vehicle
manufacturer.
WHEEL ATTACHMENT HARDWARE INSPECTION
\
\
\
\
\
\
\
Condition Code Procedure
Bent .................... A ............ Require replacement.
Broken .................. A ........ ( 1) Require replacement.
Loose ................... B ... Require repair or replacement
of affected component.
Lug nut installed
backward ............... B .. Require repair or replacement.
Lug nut mating surface
dished ................. A ..... Require replacement of nut.
Lug nut mating type
incorrect .............. B ..... Require replacement of nut.
Lug nut rounded ......... A . ( 2) Require replacement of nut.
Lug nut seized .......... A . ( 2) Require replacement of nut.
Stud incorrect .......... B .... Require replacement of stud.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
( 1) - Some manufacturers require replacement of all studs on
that wheel if two or more studs or nuts on the same wheel
are broken or missing.
( 2) - Only required if removing wheel.
\
\
\
\
\
\
\
Page 551 of 1501
NOTE: Always refer to appropriate engine overhaul article in the
ENGINES section for complete overhaul procedures and
specifications for the vehicle being repaired.
REMOVAL
Remove intake and exhaust manifolds and valve cover. Cylinder
head and camshaft carrier bolts (if equipped), should be removed only
when the engine is cold. On many aluminum cylinder heads, removal
while hot will cause cylinder head warpage. Mark rocker arm or
overhead cam components for location.
Remove rocker arm components or overhead cam components.
Components must be installed in original location. Individual design
rocker arms may utilize shafts, ball-type pedestal mounts or no rocker
arms. For all design types, wire components together and identify
according to the corresponding valve. Remove cylinder head bolts.
Note length and location. Some applications require cylinder head
bolts be removed in proper sequence to prevent cylinder head damage.
See Fig. 1 . Remove cylinder head.
Fig. 1: Typical Cylinder Head Tightening or Loosening Sequence
This Graphic For General Information Only
INSTALLATION
Ensure all surfaces and head bolts are clean. Check that head
bolt holes of cylinder block are clean and dry to prevent block damage
when bolts are tightened. Clean threads with tap to ensure accurate
bolt torque.
Install head gasket on cylinder block. Some manufacturer's
may recommend sealant be applied to head gasket prior to installation.
Note that all holes are aligned. Some gasket applications may be
marked so certain area faces upward. Install cylinder head using care
not to damage head gasket. Ensure cylinder head is fully seated on
cylinder block.
Some applications require head bolts be coated with sealant
prior to installation. This is done if head bolts are exposed to water
passages. Some applications require head bolts be coated with light
coat of engine oil.
Page 575 of 1501
CYLINDER BLOCK
* PLEASE READ THIS FIRST *
NOTE: Always refer to appropriate engine overhaul article in the
ENGINES section for complete overhaul procedures and
specifications for the vehicle being repaired.
BLOCK CLEANING
Only cast cylinder blocks should be hot tank cleaned.
Aluminum cylinder blocks should be cleaned using cold tank method.
Cylinder block is cleaned in order to remove carbon deposits, gasket
residue and water jacket scale. Remove oil galley plugs, freeze plugs
and cam bearings prior to block cleaning.
BLOCK INSPECTION
Visually inspect the block. Check suspected areas for cracks
using the Dye Penetrant inspection method. Block may be checked for
cracks using the Magnaflux method.
Cracks are most commonly found at the bottom of the
cylinders, the main bearing saddles, near expansion plugs and between
the cylinders and water jackets. Inspect lifter bores for damage.
Inspect all head bolt holes for damaged threads. Threads should be
cleaned using tap to ensure proper head bolt torque. Consult machine
shop concerning possible welding and machining (if required).
CYLINDER BORE INSPECTION
Inspect the bore for scuffing or roughness. Cylinder bore
is dimensionally checked for out-of-round and taper using dial bore
gauge. For determining out-of-round, measure cylinder parallel and
perpendicular to the block centerline. Difference in the 2 readings
is the bore out-of-round. Cylinder bore must be checked at top, middle
and bottom of piston travel area.
Bore taper is obtained by measuring bore at the top and
bottom. If wear has exceeded allowable limits, block must be honed
or bored to next available oversize piston dimension.
CYLINDER HONING
Cylinder must be properly honed to allow new piston rings to
properly seat. Cross-hatching at correct angle and depth is critical
to lubrication of cylinder walls and pistons.
A flexible drive hone and power drill are commonly used.
Drive hone must be lubricated during operation. Mix equal parts of
kerosene and SAE 20w engine oil for lubrication.
Apply lubrication to cylinder wall. Operate cylinder hone
from top to bottom of cylinder using even strokes to produce 45 degree
cross-hatch pattern on the cylinder wall. DO NOT allow cylinder hone
to extend below cylinder during operation.
Recheck bore dimension after final honing. Wash cylinder
wall with hot soapy water to remove abrasive particles. Blow dry with
compressed air. Coat cleaned cylinder walls with lubricating oil.
DECK WARPAGE
Check deck for damage or warped head sealing surface. Place
a straightedge across gasket surface of the deck. Using feeler gauge,
measure clearance at center of straightedge. Measure across width and
Page 591 of 1501
SUPER CHARGERS
SWITCHES
THERMAL VACUUM VALVES
THERMOSTATIC AIR DOOR ASSEMBLIES
THERMOSTATS AND HOUSINGS
THROTTLE BODIES
THROTTLE CABLES
THROTTLE LINKAGES AND CABLES
THROTTLE POSITION SENSORS
THROTTLE POSITION SWITCHES
TIMING BELT SPROCKETS
TIMING BELTS
TORQUE STRUTS
TRANSMISSION RANGE SWITCHES
TUBE CLAMPS
TUBE CONNECTORS
TUBE COUPLERS
TUBES
TURBO CHARGERS
VACUUM CONNECTIONS
VACUUM HOSES, TUBES AND CONNECTIONS (NON-METALLIC)
VACUUM REGULATOR SOLENOIDS
VACUUM TUBES
VEHICLE SPEED SENSORS
VOLUME AIR FLOW SENSORS
WASTE GATE CONTROL SOLENOIDS
WASTE GATES AND BOOST CONTROL MECHANISMS
WATER PUMPS (ELECTRIC)
WATER PUMPS (NON-ELECTRIC)
WIRING HARNESSES AND CONNECTORS
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
The Motorist Assurance Program is the consumer outreach
effort of the Automotive Maintenance and Repair Association, Inc.
(AMRA). Participation in the Motorist Assurance Program is drawn from
retailers, suppliers, independent repair facilities, vehicle
manufacturers and industry associations.
Our organization's mission is to strengthen the relationship
between the consumer and the auto repair industry. We produce
materials that give motorists the information and encouragement to
take greater responsibility for their vehicles-through proper,
manufacturer-recommended, maintenance. We encourage participating
service and repair shops (including franchisees and dealers) to adopt
(1) a Pledge of Assurance to their Customers and (2) the Motorist
Assurance Program Standards of Service. All participating service
providers have agreed to subscribe to this Pledge and to adhere to the
promulgated Standards of Service demonstrating to their customers that
they are serious about customer satisfaction.
These Standards of Service require that an inspection of the
vehicle's (problem) system be made and the results communicated to the\
customer according to industry standards. Given that the industry did
not have such standards, the Motorist Assurance Program successfully
promulgated industry inspection communication standards in 1994-95 for
the following systems: Exhaust, Brakes, ABS, Steering and Suspension,
Engine Maintenance and Performance, HVAC, and Electrical Systems.
Further, revisions to all of these inspection communication standards
are continually re-published. In addition to these, standards for
Drive Train and Transmissions have recently been promulgated.
Participating shops utilize these Uniform Inspection & Communication
Page 683 of 1501
service intervals.
Missing ................. C ........ (3) Require replacement.
Noisy ................... 2 .......... ( 4) Further inspection
required.
See note below.
Plies separated ......... A ............ Require replacement.
Tension out of
specification .......... B ........... Require adjustment or
replacement.
Teeth missing ........... A ............ Require replacement.
( 1) - Inspect belt tensioners, pulleys, and cover.
( 2) - Determine cause of incorrect alignment and require repair.
( 3) - CAUTION: Internal engine damage may result from timing
belt damage/failure.
( 4) - Determine cause of noise and suggest repair.
\
\
\
\
\
\
\
TORQUE STRUTS
TORQUE STRUT INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Binding ................. A ............ Require replacement.
Body dented ............. A .......... ( 1) Further inspection
required.
Body punctured .......... A ............ Require replacement.
Bushing deteriorated,
affecting performance .. A ............ Require replacement.
Bushing deteriorated, not
affecting performance .. .. ........ No service suggested or
required.
Bushings missing ........ C ............ Require replacement.
Bushings separated from
mounting eye ........... 1 ............ Suggest replacement.
Damping (none) .......... A ............ Require replacement.
Leaking oil, enough for
fluid to be running down
the body ............... A ............ Require replacement.
Missing ................. C ............ Require replacement.
Noisy ................... 2 .......... ( 2) Further inspection
required.
Piston rod bent ......... A ............ Require replacement.
Piston rod broken ....... A ............ Require replacement.
Seized .................. A ............ Require replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
( 1) - Require replacement of units where dents restrict strut
piston rod movement. If dents don't restrict movement, no
service is suggested or required.
( 2) - If noise is isolated to shock or strut, suggest replacement.
Page 723 of 1501
purge control valve, or vacuum hose routing.
DTC P0443
Evaporative (EVAP) purge control valve circuit failure.
Possible causes are: connector or harness, or faulty EVAP solenoid.
DTC P0446
Evaporative (EVAP) emission control system vent control
failure. Possible causes are: connector or harness, faulty EVAP vent
solenoid.
DTC P0450
Evaporative (EVAP) emission control system pressure sensor
failure. Possible causes are: connector or harness, or faulty fuel
tank differential pressure sensor.
DTC P0455
Evaporative (EVAP) emission control system large leak
detected. Possible causes are: connector or harness, faulty EVAP purge
solenoid, purge control valve, or vacuum hose routing.
DTC P0500
Vehicle Speed Sensor (VSS) failure. Possible causes are:
connector or harness, or faulty VSS.
DTC P0505
Idle Air Control (IAC) system failure. Possible causes are:
connector or harness, or faulty IAC motor.
DTC P0510
Closed Throttle Position (TP) switch failure. Possible causes\
are: connector or harness, or faulty closed TP switch.
DTC P0551
Power Steering Pressure (PSP) sensor failure. Possible causes\
are: connector or harness, or faulty PSP sensor.
DTC P0705
Automatic transaxle/transmission range sensor circuit
failure. Possible causes are: connector or harness, or faulty PNP
switch.
DTC P0710
Automatic transaxle/transmission fluid sensor failure.
Possible causes are: connector or harness, or faulty
transaxle/transmission sensor.
DTC P0715
Automatic transaxle input/turbine speed sensor circuit
failure. Possible causes are: connector or harness, or pulse
generator.
DTC P0720
Automatic transaxle input/turbine speed sensor circuit
failure. Possible causes are: connector or harness, or pulse
generator.
DTC P0725
Engine speed input circuit failure. Possible causes are:
connector or harness.
DTC P0740
Torque converter clutch system failure. Possible causes are:
Page 724 of 1501
connector or harness, or torque converter clutch solenoid.
DTC P0750
Shift solenoid "A" failure. Possible causes are: connector or
harness, or low-reverse solenoid.
DTC P0755
Shift solenoid "B" failure. Possible causes are: connector or
harness, or underdrive solenoid.
DTC P0760
Shift solenoid "C" failure. Possible causes are: connector or
harness, or second solenoid.
DTC P0765
Shift solenoid "D" failure. Possible causes are: connector or
harness, or overdrive solenoid.
DTC P1103
Turbocharger wastegate actuator failure. Possible causes are:
connector or harness, faulty wastegate solenoid or actuator, or vacuum
hose routing.
DTC P1104
Turbocharger wastegate solenoid failure. Possible causes are:
connector or harness, or faulty wastegate solenoid.
DTC P1105
Fuel pressure solenoid failure. Possible causes are:
connector or harness, or faulty fuel pressure solenoid.
DTC P1400
Manifold Differential Pressure (MDP) sensor circuit failure.
Possible causes are: connector or harness, or faulty MDP sensor.
DTC P1500
Generator FR terminal circuit failure. Possible causes are:
connector or harness.
DTC P1600
Serial communication link failure. Possible causes are:
connector or harness.
DTC P1715
Pulse Generator (PG) failure. Possible causes are: connector
or harness, or faulty PG.
DTC P1750
Solenoid failure. Possible causes are: connector or harness,
faulty converter clutch solenoid, shift control solenoid, or pressure
control solenoid.
DTC P0751
Automatic transaxle control relay failure. Possible causes
are: connector or harness, or automatic transaxle relay.
DTC P1791
Engine coolant temperature level input circuit (to TCM)
failure. Possible causes are: connector or harness.
DTC P1795
Throttle position input circuit failure. Possible causes are:
connector or harness.
Page 785 of 1501
1) Check continuity across rotor slip rings. Resistance
should be 3-5 ohms. Replace rotor if continuity is not present or
resistance is not within specification.
2) Check continuity between individual slip rings and rotor
shaft. If continuity is present, rotor coil or slip ring is grounded.
Replace rotor.
STATOR
Ensure continuity is not present between stator coil leads
and stator core. Check continuity between leads of stator coil. If
continuity is not present between coil leads, replace stator.
OVERHAUL
Replace brushes if worn to limit line. Limit line is line
closest to rotor contact end of brush. Brushes can be retained in
brush holder while installing rotor by inserting wire into back of
rear housing. See Fig. 3.
Fig. 3: Exploded View Of Mitsubishi Generator (Typical)
Courtesy of Mitsubishi Motor Sales of America
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS TABLE \
\
\
\
\
\
\
Application Ft. Lbs. (N.m)\
Page 816 of 1501
Torque Converter Clutch Solenoid/Switch ......... Engine Performance
Traction Control Switch ........................... Anti-Lock Brakes
Trailer Tow Connector .............................. Exterior Lights
Trailer Tow Relay .................................. Exterior Lights
Transmission/Transaxle .......................... Engine Performance
Transmission Control Module (TCM) ............... Engine Performance\
Starters
Transmission Range Sensor ................................. Starters
Back-Up Lights
Engine Performance
Transmission Range Switch ........................... Back-Up Lights
Engine Performance
Anti-Theft System
Turn Signal Flasher ................................ Exterior Lights
Turn Signal Lights ................................. Exterior Lights
Twilight Sentinel Switch ......................... Headlight Systems
Daytime Running Lights
Vapor Canister Leak Detection Pump .............. Engine Performance
Vehicle Control Module (VCM) .................... Engine Performance\
Vehicle Dynamic Module ....................... Electronic Suspension
Vehicle Speed Control Servo ................. Cruise Control Systems
Vehicle Speed Sensor .......................... Data Link Connectors
Analog Instrument Panels
Cruise Control Systems
Electronic Suspension
Voltage Regulator .......................... Generators & Regulators
Water-In-Fuel Sensor ............................ Engine Performance
Analog Instrument Panels
Wheel Speed Sensors ............................... Anti-Lock Brakes
Window Timer Module .......................... Power Convertible Top
Windshield Intermittent Wiper Relay ........... Wiper/Washer Systems
Windshield Washer Motor ....................... Wiper/Washer Systems
Wiper Motor ................................... Wiper/Washer Systems
\
\
\
\
\
\
\
