Page 32 of 1501
![MITSUBISHI MONTERO 1998 Service Manual "P" ABBREVIATION TABLE
"P" ABBREVIATION TABLE \
\
\
\
\
\
\](/img/19/57333/w960_57333-31.png "MITSUBISHI MONTERO 1998 Service Manual \"P\" ABBREVIATION TABLE
\"P\" ABBREVIATION TABLE \
\
\
\
\
\
\")
"P" ABBREVIATION TABLE
"P" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
"P" Park
P/C Printed Circuit
P/N Park/Neutral
P/S Power Steering
PAV Pulse Air Valve
PC-SOL Purge Control Solenoid
PCM Powertrain Control Module
PCS Purge Control Solenoid
PCSDM Passenger Compartment Sensor/Diagnostic Module
PCV Positive Crankcase Ventilation
PFE Pressure Feedback EGR sensor or circuit
PFI Port Fuel Injection (see MA SEFI)
PGM-CARB Programmed Carburetor
PGM-FI Programmed Fuel Injection
PIP Profile Ignition Pickup
PNK Pink
PPL Purple
PRNDL Park Reverse Neutral Drive Low
PROM Programmable Read-Only Memory
psi Pounds Per Square Inch
PSPS Power Steering Pressure Switch
PTC Positive Temperature Coefficient
PTO Power Take-Off
PWR GND Power Ground circuit
Pkg. Package
Press. Pressure
Prog. Programmed or Programmable
Pts. Pints
Pwr. Power
\
\
\
\
\
\
\
\f
"Q" ABBREVIATION TABLE
"Q" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
Qts. Quarts
\
\
\
\
\
\
\
\f
"R" ABBREVIATION TABLE
"R" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
RABS Rear Anti-Lock Brake System
RAC Remote Accessory Control
RAM Random Access Memory
RAP Retained Accessory Power
RECIRC Recirculation
RED Red
RH Right Hand
ROM Read Only Memory
RPM Revolutions Per Minute
Page 323 of 1501
Main Switch
1) In each switch position, continuity should be present
between terminals No. 2 and 7 for switch illumination. See Fig. 8.
When switch is moved to Neutral position, continuity should be present
between terminals No. 1 and 4.
2) When switch is moved to ON position, continuity should be
present between terminals No. 4 and 5. Connect battery voltage to
terminal No. 5 and ground terminal No. 4.
3) Battery voltage should be present on terminal No. 1 when
main switch is moved to ON position. Replace main switch if it does
not test as specified.
PARK/NEUTRAL SWITCH TEST
Disconnect switch connector. Shift transmission into Neutral
position. Continuity should be present between terminals No. 5
(Black/Blue wire) and No. 6 (Blue/Black wire). See Fig. 7. If
continuity is not present, adjust park/neutral switch. If switch is
adjusted properly, replace switch.
VACUUM PUMP TEST
1) Disconnect vacuum pump connector A-105. Resistance should
be 50-60 ohms between terminals No. 1 and 2 and terminals No. 1 and 3.
See Fig. 6 . Ensure solenoid valve makes operating noise when battery
voltage is applied between terminals No. 1 and 2 and terminals No. 1
and 3.
2) If solenoid valve does not operate, replace vacuum pump
assembly. Apply battery voltage and ground between terminals No. 1 and
4. Motor should operate. Replace vacuum pump if motor does not
operate.
VEHICLE SPEED SENSOR TEST
Remove speed sensor from transmission. Connect speed sensor,
resistor (3000-10,000 ohms) and battery. See Fig. 34. Using a
voltmeter, ensure voltage pulses on and off 4 times per revolution of
speedometer shaft. Replace sensor if voltage is not as specified.
Fig. 34: Testing Vehicle Speed Sensor
Courtesy of Mitsubishi Motor Sales of America
SELF-DIAGNOSTIC SYSTEM
Page 376 of 1501
![MITSUBISHI MONTERO 1998 Service Manual .060 (1.52) .................................................... Red\
.067 (1.70) ................................................. Purple\
.073 (1.85) .........................................](/img/19/57333/w960_57333-375.png "MITSUBISHI MONTERO 1998 Service Manual .060 (1.52) .................................................... Red\
.067 (1.70) ................................................. Purple\
.073 (1.85) .........................................")
.060 (1.52) .................................................... Red\
.067 (1.70) ................................................. Purple\
.073 (1.85) ................................................... Blue\
.079 (2.01) ................................................. Yellow\
.085 (2.16) ................................................ Neutral\
\
\
\
\
\
\
\
DIFFERENTIAL ASSEMBLY (CONVENTIONAL)
Pre-Disassembly Inspection
1) Secure differential assembly in appropriate holder. Secure
drive pinion from turning. Mount dial indicator on case and check ring
gear backlash at 4 positions. See Fig. 6. Backlash should be .005-.
007" (.13-.18 mm).
2) Remount dial indicator and measure ring gear runout. See
Fig. 7 . On all models, runout should not exceed .002" (.05 mm).
Remount dial indicator and measure pinion gear backlash on models
without limited slip differential. See Fig. 8. Secure side gear from
turning with wedge. Backlash should be 0-.003" (0-.08 mm). Pinion gear\
backlash service limit is .008" (.20 mm).
3) Check gear tooth contact pattern between ring gear and
drive pinion gear. Apply Prussian Blue to both surfaces of ring gear
teeth. Insert brass rod between differential housing and carrier
assembly to provide resistance while turning drive pinion.
4) Turning resistance of drive pinion should be 28-33 INCH
lbs. (2.5-3.0 N.m). Rotate drive pinion until ring gear completes one
revolution. Reverse direction of rotation and return to original
starting point. Check wear pattern. See GEAR TOOTH CONTACT PATTERNS
article in GENERAL INFORMATION.
5) On Montero models with differential lock, connect air
supply hose with pressure gauge and regulator to actuator air pipe.
Apply 4 psi (.28 kg/cm
) of pressure. Using Adapter Shaft (MB990992),
turn side gear on one side of carrier assembly only. Locking mechanism
should engage. To disengage, release air pressure and turn side gear
1/4-1/2 turn.
6) With lock mechanism engaged, measure turning torque of
drive pinion. Turning torque should not be less than 36 ft. lbs. (50
N.m). With lock mechanism disengaged, turning torque should not be
more than 36 ft. lbs. (50 N.m).
Fig. 6: Measuring Ring Gear Backlash
Courtesy of Mitsubishi Motor Sales of America.
Page 766 of 1501
VACUUM DIAGRAMS article. Install hoses as necessary and go to step
20). If hoses are okay, go to next step.
14) Disconnect OFLV-to-EVAP canister hose at OFLV and EVAP
canister. Plug hose at OFLV end. Connect hand-held pressure/vacuum
pump to hose at EVAP canister end. Apply 0.9 psi. If pressure is not
maintained, replace hose. Go to step 20). If pressure is maintained,
go to next step.
15) Using scan tool, read Fuel Tank Differential Pressure
(FTDP) sensor (item 73). Connect hand-held pressure/vacuum pump to
OFLV. While monitoring scan tool, apply 0.42 psi. If scan tool reading
reaches 0.42 psi, go to next step. If reading does not reach 0.42 psi,
go to step 19).
16) Disconnect OFLV-to-EVAP canister hose at EVAP canister.
Connect hand-held pressure/vacuum pump to hose and apply 0.9 psi. If
pressure is not maintained, go to next step. If pressure is
maintained, go to step 18).
17) Disconnect EVAP purge solenoid-to-EVAP canister hose at
EVAP canister. Connect hand-held pressure/vacuum pump to hose.
Disconnect intake manifold plenum-to-EVAP purge solenoid at intake
manifold plenum. Operate vacuum pump several times to apply vacuum. If
vacuum leaks, replace EVAP canister. Go to step 20). If vacuum does
not leak, repair clog in hose between EVAP canister and EVAP Purge
solenoid. Go to step 20).
18) Disconnect EVAP canister-to-OFLV hose at OFLV. If vacuum
does not leak, repair clog in hose between EVAP canister and OFLV. Go
to step 20). If vacuum leaks, check fuel tank filler tube assembly. If
fuel tank filler tube assembly is okay, repair clog in hose between
OFLV and fuel cut-off valve. Go to step 20).
19) Replace fuel tank filler tube and OFLV-to-fuel cut-off
valve hose. While monitoring scan tool, apply 0.42 psi with hand-held
pressure/vacuum pump. If scan tool reading does not reach 0.42 psi,
replace fuel tank. Go to next step.
20) Road test vehicle and attempt to duplicate conditions
that caused original complaint. Recheck for DTCs. If no DTCs are
displayed, test is complete.
DTC P0500: VEHICLE SPEED SENSOR (VSS) CIRCUIT FAILURE
NOTE: Speedometer testing procedures for 3000GT are not available
from manufacturer at time of publication. For terminal
identification, see TERMINAL IDENTIFICATION.
For circuit and wire color identification, see
L - WIRING DIAGRAMS article.
1) If using scan tool, go to step 4). On 3000GT, go to step
3). On Montero, speedometer testing procedures using DVOM require
removal of instrument panel. Removal and installation of instrument
panel is basically an unbolt and bolt-on procedure.
2) DO NOT disconnect connectors. Using DVOM, check continuity
between indicated speedometer terminals. See Fig. 40. Ensure
continuity pulses on and off with speedometer shaft revolution. If
continuity is not as specified, replace speedometer. If continuity is
as specified, go to next step.
Page 767 of 1501
Fig. 40: Identifying VSS Test Terminals (Montero)
Courtesy of Mitsubishi Motor Sales of America
3) VSS is located at end of speedometer cable at
transmission. Connect battery, resistor (3-10 ohms) and voltmeter to
indicated terminals. See Fig. 41. Ensure voltage pulses 4 times per
speedometer shaft revolution. If voltage is not as specified, replace
VSS. If voltage is as specified, go to step 5).
Fig. 41: Testing VSS
Courtesy of Mitsubishi Motor Sales of America
4) With an assistant, road test vehicle. Drive vehicle at 25
Page 768 of 1501
MPH. Using scan tool, read vehicle speed (item 24). If scan tool does
not read 25 MPH, replace VSS. If scan tool reads 25 MPH, go to next
step.
5) Turn ignition switch to OFF position. Disconnect PCM
connector. Using DVOM, check continuity between chassis ground and PCM
connector terminal No. 80. Move vehicle. Ensure continuity pulses on
and off with tire revolution. If continuity is not as specified on
3000GT, go to step 7). On Montero, go to next step. If continuity is
as specified, go to step 9).
6) With PCM connector disconnected, disconnect VSS connector.
Ground PCM connector terminal No. 80. Using DVOM, check for continuity
between chassis ground and VSS connector terminal No. 1. See Fig. 42.
If continuity does not exist, repair wiring harness as necessary. If
continuity exists, go to next step.
Fig. 42: Identifying VSS Connector Terminals (Montero)
Courtesy of Mitsubishi Motor Sales of America
7) With VSS connector disconnected, check for continuity
between chassis ground and specified VSS connector terminal. See
Fig. 42 or 43. See VSS GROUND CIRCUIT IDENTIFICATION table. If
continuity does not exist, repair wiring harness as necessary. If
continuity exists, go to next step.
VSS GROUND CIRCUIT IDENTIFICATION TABLE
\
\
\
\
\
\
Application Terminal No.
Montero ............................................... 43
3000GT ................................................. 2
\
\
\
\
\
\
Fig. 43: Identifying VSS Connector Terminals (3000GT)
Courtesy of Mitsubishi Motor Sales of America
8) With VSS connector disconnected, turn ignition switch to
ON position. Using DVOM, check for voltage between chassis ground and
Page 836 of 1501
unit. Turn ignition on. Check voltage between ground and sending unit
harness-side connector. If battery voltage is present, problem is
intermittent. If battery voltage is not present, go to next step.
2) Check sending unit harness connector. Repair as necessary.
If connector is okay, check circuit (Yellow wire) between oil pressure\
gauge and oil pressure sending unit. See WIRING DIAGRAMS. Repair as
necessary. If circuit is okay, go to next step.
3) Remove multi-meter assembly. Check voltage between ground
and harness-side connector terminal No. 10 (Red/Black wire). See
WIRING DIAGRAMS . If battery voltage is present, problem is
intermittent. If battery voltage is not present, go to next step.
4) Check harness connector to multi-meter assembly. Repair as
necessary. If connector is okay, check circuit between multi-meter
harness connector and fusible link No. 6. See WIRING DIAGRAMS. Repair
as necessary. If circuit is okay, go to next step.
5) Turn ignition on. Check voltage between ground and multi-
meter harness-side connector terminal No. 11 (Black/White wire). See
WIRING DIAGRAMS . If battery voltage is present, problem is
intermittent. If battery voltage is not present, go to next step.
6) Check harness connector to multi-meter assembly. Repair as
necessary. If connector is okay, check circuit between multi-meter
assembly harness connector and ignition switch. See WIRING DIAGRAMS.
Repair as necessary. If circuit is okay, go to next step.
7) Turn ignition off. Check continuity between ground and
multi-meter assembly harness-side connector terminal No. 3 (Black
wire). If continuity is present, problem is intermittent. If
continuity is not present, go to next step.
8) Check harness connector to multi-meter assembly. Repair as
necessary. If connector is okay, check circuit (Black wire) between
multi-meter assembly harness connector and ground. See WIRING DIAGRAMS
. Repair as necessary. If circuit is okay, problem is intermittent.
Gauge Sending Unit Resistance Test (Montero Sport)
Disconnect harness connector to oil pressure sending unit.
Start and idle engine. Check resistance between oil pressure gauge
sending unit terminal and engine block. Resistance should be about 2
ohms. Replace sending unit if resistance is not as specified.
REED SWITCH
Continuity Check (Montero)
1) Remove instrument cluster. See INSTRUMENT CLUSTER under
REMOVAL & INSTALLATION. Check continuity between reed switch terminals
No. 1 and 2. See Fig. 20.
2) Ensure continuity pulses on and off 4 times per revolution
of speedometer shaft connection. If continuity is not as specified,
replace reed switch.
Fig. 20: Identifying Reed Switch Test Terminals (Montero)
Courtesy of Mitsubishi Motor Sales of America
SPEEDOMETER TEST
Page 846 of 1501
NOTE: Vehicle speed sensor circuit test for Montero and 3000GT is
not available from manufacturer at time of publication.
Circuit Test (Eclipse, Galant & Mirage)
1) Disconnect vehicle speed sensor harness connector. Turn
ignition on. Check voltage between ground and vehicle speed sensor
harness-side connector terminal No. 3 (Yellow/White wire on Eclipse 2.
0L Non-Turbo models and Galant, or Yellow wire on Eclipse 2.0L Turbo
and 2.4L models and Mirage). Voltmeter should read 4.5 volts or
greater. If voltage is as specified, go to step 4). If voltage is not
as specified, go to step 5).
2) Check voltage between ground and vehicle speed sensor
harness-side connector terminal No. 1 (Yellow wire on Eclipse 2.0L
Non-Turbo models, Black/White wire on Eclipse 2.0L Turbo and 2.4L
models and Mirage, or Yellow/White wire on Galant). Voltmeter should
read battery voltage. If voltage is as specified, go to step 4). If
voltage is not as specified, go to step 5).
3) Check continuity between ground and vehicle speed sensor
harness-side connector terminal No. 2 (Black/Green wire on Eclipse 2.
0L Non-Turbo models, or Black wire on Eclipse 2.0L Turbo and 2.4L
models, Galant and Mirage). If continuity is present, go to next step.
If continuity is not present, go to step 5).
4) Check harness connector to instrument cluster. Repair as
necessary. If connector is okay, check circuit between vehicle speed
sensor and power supply. See WIRING DIAGRAMS. Repair as necessary.
5) Check harness connectors to instrument cluster and vehicle
speed sensor. Repair as necessary. If connectors are okay, check
circuit between vehicle speed sensor and instrument cluster. See
WIRING DIAGRAMS . Repair as necessary.
Circuit Test (Montero Sport)
1) Disconnect vehicle speed sensor harness connector. Check
circuit between instrument cluster harness connector and ignition
switch. See WIRING DIAGRAMS . Repair as necessary. If circuit is okay,
go to next step.
2) Remove instrument cluster. See INSTRUMENT CLUSTER under
REMOVAL & INSTALLATION. Check continuity between ground and instrument
cluster harness-side connector terminal No. 31 (Black wire). See
WIRING DIAGRAMS . If continuity is present, problem is intermittent. If
continuity is not present, go to next step.
3) Check circuit between instrument cluster and ignition
switch. See WIRING DIAGRAMS . Repair as necessary. If circuit is okay,
replace speedometer assembly.
Sensor Test (All Models)
1) Remove vehicle speed sensor from transaxle. Jumper a 3000-
10,000 ohm resistor between sensor terminals No. 1 and 3. Connect
battery positive to sensor terminal No. 1 and battery negative to
sensor terminal No. 2. See Fig. 29.
2) Connect a voltmeter between sensor terminals No. 2 and 3.
Manually turn speed sensor shaft. Voltage should pulse 4 times each
revolution. Replace vehicle speed sensor if operation is not correct.
Page 1434 of 1501
severe weakness that we will look at later). If an injector has a
fault where it occasionally skips a pulse, the meter registers it and
the reading changes accordingly.
Let's go back to figuring out dwell/duty readings by using
injector on-time specification. This is not generally practical, but
we will cover it for completeness. You NEED to know three things:
* Injector mS on-time specification.
* Engine RPM when specification is valid.
* How many times the injectors fire per crankshaft revolution.
The first two are self-explanatory. The last one may require
some research into whether it is a bank-fire type that injects every
360
of crankshaft rotation, a bank-fire that injects every 720 , or
an SFI that injects every 720 . Many manufacturers do not release this
data so you may have to figure it out yourself with a frequency meter.
Here are the four complete steps to convert millisecond on-
time:
1) Determine the injector pulse width and RPM it was obtained
at. Let's say the specification is for one millisecond of on-time at a
hot idle of 600 RPM.
2) Determine injector firing method for the complete 4 stroke
cycle. Let's say this is a 360
bank-fired, meaning an injector fires
each and every crankshaft revolution.
3) Determine how many times the injector will fire at the
specified engine speed (600 RPM) in a fixed time period. We will use
100 milliseconds because it is easy to use.
Six hundred crankshaft Revolutions Per Minute (RPM) divided
by 60 seconds equals 10 revolutions per second.
Multiplying 10 times .100 yields one; the crankshaft turns
one time in 100 milliseconds. With exactly one crankshaft rotation in
100 milliseconds, we know that the injector fires exactly one time.
4) Determine the ratio of injector on-time vs. off-time in
the fixed time period, then figure duty cycle and/or dwell. The
injector fires one time for a total of one millisecond in any given
100 millisecond period.
One hundred minus one equals 99. We have a 99% duty cycle. If
we wanted to know the dwell (on 6 cylinder scale), multiple 99% times
.6; this equals 59.4
dwell.
Weaknesses of Dwell/Duty Meter
The weaknesses are significant. First, there is no one-to-one
correspondence to actual mS on-time. No manufacturer releases
dwell/duty data, and it is time-consuming to convert the mS on-time
readings. Besides, there can be a large degree of error because the
conversion forces you to assume that the injector(s) are always firing\
at the same rate for the same period of time. This can be a dangerous
assumption.
Second, all level of detail is lost in the averaging process.
This is the primary weakness. You cannot see the details you need to
make a confident diagnosis.
Here is one example. Imagine a vehicle that has a faulty
injector driver that occasionally skips an injector pulse. Every
skipped pulse means that that cylinder does not fire, thus unburned O2
gets pushed into the exhaust and passes the O2 sensor. The O2 sensor
indicates lean, so the computer fattens up the mixture to compensate
for the supposed "lean" condition.
A connected dwell/duty meter would see the fattened pulse
width but would also see the skipped pulses. It would tally both and
likely come back with a reading that indicated the "pulse width" was
within specification because the rich mixture and missing pulses
offset each other.
This situation is not a far-fetched scenario. Some early GM
