Page 13 of 1501
![MITSUBISHI MONTERO 1998 Service Manual Fig. 16: Connecting Rod Identification Location (Montero)
Courtesy of Mitsubishi Motor Sales of America.
ENGINE OILING
OIL PUMP SPECIFICATIONS\
\](/img/19/57333/w960_57333-12.png "MITSUBISHI MONTERO 1998 Service Manual Fig. 16: Connecting Rod Identification Location (Montero)
Courtesy of Mitsubishi Motor Sales of America.
ENGINE OILING
OIL PUMP SPECIFICATIONS\
\")
Fig. 16: Connecting Rod Identification Location (Montero)
Courtesy of Mitsubishi Motor Sales of America.
ENGINE OILING
OIL PUMP SPECIFICATIONS\
\
\
\
\
\
\
Application Specification
Gear Side Clearance ..................... .0016-.0039" (.040-.10 mm)\
Gear-To-Front Cover Clearance
Standard .............................. .0039-.0071" (.10-.180 mm)\
Limit ........................................... .0138" (.350 mm)\
Tip to Tip Clearance ................... .0024-.0071" (.060-.180 mm)\
Minimum Warm Oil Pressure at Idle ............. 11.4 psi (.8 kg/cm
)\
\
\
\
\
\
\
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS\
\
\
\
\
\
\
Application Ft. Lbs. (N.m)\
Crankshaft Drive Plate ..................................... 55 (74)\
Crankshaft Main Bearing Cap Bolt
Diamante ................................................. 69 (93)\
Montero .................................................. 55 (74)\
Crankshaft Pulley Bolt ................................... 134 (182)\
Cylinder Head Bolt ( 1) .................................... 80 (108)
Distributor Lock Nut (Diamante) ............................ 17 (23\
)
Exhaust Manifold Nut ....................................... 21 (29)\
Generator & Drive Belt
Accessory Mount Bolt (Montero) ........................... 32 (44\
)
Page 16 of 1501
![MITSUBISHI MONTERO 1998 Service Manual Stroke ........................................... 3.3779" (85.8 mm)\
Compression Ratio ............................................ 9.0:1
Fuel System ...........................................](/img/19/57333/w960_57333-15.png "MITSUBISHI MONTERO 1998 Service Manual Stroke ........................................... 3.3779\" (85.8 mm)\
Compression Ratio ............................................ 9.0:1
Fuel System ...........................................")
Stroke ........................................... 3.3779" (85.8 mm)\
Compression Ratio ............................................ 9.0:1
Fuel System .................................................... MFI
Horsepower @ RPM ........................................ 200 @ 5000
Torque Ft. Lbs. @ RPM ................................... 228 @ 3500
\
\
\
\
\
\
\
ROCKER ARMS & CAMSHAFT
ROCKER ARMS & CAMSHAFT\
\
\
\
\
\
\
Application In. (mm)\
Camshaft Lobe Height
Montero
Intake
Standard ..................................... 1.4846 (37.710)\
Limit ........................................ 1.4650 (37.210)\
Exhaust
Standard ..................................... 1.4622 (37.140)\
Limit ........................................ 1.4425 (36.640)\
Diamante
Intake
Standard ..................................... 1.4795 (37.580)\
Limit ........................................ 1.4598 (37.080)\
Exhaust
Standard ..................................... 1.4547 (36.950)\
Limit ........................................ 1.4350 (36.450)\
Camshaft Journal Diameter .......................... 1.7689 (44.930)\
\
\
\
\
\
\
\
CYLINDER HEAD & VALVES
CYLINDER HEAD & VALVES\
\
\
\
\
\
\
Application Specification
Head Warpage
Standard ........................................ .0012" (.030 mm)\
Limit ........................................... .0079" (.200 mm)\
Maximum Resurface ................................. .0079" (.200 mm)\
Overall Height ................................ 4.7244" (120.000 mm)\
Valve Margin
Intake
Standard ..................................... .0394" (1.000 mm)\
Limit ......................................... .0197" (.500 mm)\
Exhaust
Standard ..................................... .0472" (1.200 mm)\
Limit ......................................... .0276" (.700 mm)\
Valve Height (Montero)
Intake
Standard .................................. 4.4213" (112.300 mm)\
Limit ..................................... 4.4016" (111.800 mm)\
Exhaust
Standard .................................. 4.4924" (114.110 mm)\
Limit ..................................... 4.4728" (113.610 mm)\
Stem Diameter
Intake ......................................... .2362" (6.000 mm)\
Exhaust ........................................ .2362" (6.000 mm)\
Stem to Guide Clearance
Intake
Standard ........................... .0008-.0020" (.020-.050 mm)\
Limit ......................................... .0039" (.100 mm)\
Page 34 of 1501
TCC Torque Converter Clutch
TCCS Toyota Computer Control System
TDC Top Dead Center
TDCL Total Diagnostic Communication Link
TFI Thick Film Ignition system
TGS Top Gear Switch (cancels SIL in top gear)
THERMAC Thermostatic Air Cleaner
THS Transmission Hydraulic Switch
TP/TPS Throttle Position Sensor
TPI Tuned Port Injection
TPS Throttle Position Sensor/Switch
TS Temperature Sensor
TSB Technical Service Bulletin
TTS Transmission Temperature Switch
TV Thermovalve
TWC Three-Way Catalyst
Temp. Temperature
Trans. Transaxle/Transmission
\
\
\
\
\
\
\
\f
"V" ABBREVIATION TABLE
"V" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
V Valve
VAF Vane Air Flow sensor or circuit
VAPS Variable Assist Power Steering
VAT Vane Air Temperature
VATS Vehicle Anti-Theft System
VBATT Vehicle Battery Voltage
VCC Viscous Converter Clutch
VIN Vehicle Identification Number
VIO Violet
VLR Volt Loop Reserve
VM Vacuum Modulator
VM Vane Meter
VOM Volt-Ohmmeter (Analog)
VPWR Vehicle Power supply voltage (10-14 volts)
VREF Voltage Reference (ECA supplied reference voltage
VRV Vacuum Regulator Valve
VSC Vehicle Speed Control sensor or signal
VSS Vehicle Speed Sensor or signal
VSV Vacuum Switching Valve
Vac. Vacuum
Volt. Voltage
\
\
\
\
\
\
\
\f
"W" ABBREVIATION TABLE
"W" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
W/ With
W/O Without
WAC WOT A/C Cut-off switch or circuit
WAC Wide Open Throttle A/C Switch
WHT White
WOT Wide Open Throttle
YEL Yellow
Page 40 of 1501
SHAFT SEAL
CAUTION: Secure rear housing to compressor body using a vise before
removing front housing through-bolts. Compressor rear housing
may separate from compressor body, spilling refrigerant oil.
Removal
1) Remove clutch coil. See CLUTCH COIL. See Fig. 1 or 2.
Position compressor in a vise so compressor rear housing is secured to
compressor body. Remove front housing through-bolts and front housing.
2) Using a flat-blade screwdriver, remove felt retainer and
felt from front housing. Remove shaft seal snap ring. Using a flat-
blade screwdriver, remove shaft seal and "O" ring. See Fig. 1 or 2.
Installation
1) Inspect compressor shaft and front housing bore for damage
and/or excessive wear. Ensure "O" ring and shaft seal seat are clean.
Apply NEW refrigerant oil to compressor side of front housing bore.
Lubricate "O" ring and shaft seal with NEW refrigerant oil. Using a
21-mm socket, install shaft seal with "O" ring side facing away from
compressor. Install shaft seal snap ring. See Fig. 1 or 2.
2) Install felt into felt retainer. Using a 14-mm deep
socket, install felt and felt retainer. Lubricate compressor shaft.
Install front housing using care not damage shaft seal lip. See Fig. 1
or 2.
3) Alternately tighten front housing through-bolts to 19 ft.
lbs. (26 N.m). Install clutch plate center bolt. Using an INCH-lb.
torque wrench, ensure compressor breakaway torque is 43 INCH lbs. (4.9
N.m) or less. To complete installation, reverse removal procedures.
Ensure air gap between clutch plate and pulley is correct. See
CLUTCH COIL .
Fig. 1: Exploded View Of Compressor (Nippondenso 10PA17C 10-Cyl.)
Courtesy of Toyota Motor Sales, U.S.A., Inc.
Page 93 of 1501
A/C SWITCH
Removal & Installation
Lower glove box. Remove instrument cover. Remove lap cooler
and foot shower ducts. Remove center panel and A/C-heater control
panel. Remove bezel and knob. Disconnect A/C switch connector, and
remove A/C switch. To install, reverse removal procedure.
A/C ENGINE COOLANT TEMPERATURE SWITCH
Removal & Installation
Drain coolant below level of thermostat housing. See Fig. 8.
Remove A/C engine coolant temperature switch wiring harness connector,
and unscrew A/C engine coolant temperature switch from thermostat
housing. To install, reverse removal procedure. Tighten A/C engine
coolant temperature switch to specification. See TORQUE SPECIFICATIONS
. Add coolant and check for leaks.
Fig. 8: Locating A/C Engine Coolant Temperature Switch
Courtesy of Mitsubishi Motor Sales of America.
BLOWER MOTOR & RESISTOR
Removal & Installation
Remove right side foot shower duct. Disconnect blower and/or
resistor. Remove blower motor and/or resistor. See Fig. 9. To install,
reverse removal procedure.
Page 99 of 1501
Removal & Installation
Discharge A/C system, using approved refrigerant
recovery/recycling equipment. Disconnect refrigerant temperature
sensor wiring connector. Remove temperature sensor from compressor. To
install, reverse removal procedure. Use new "O" ring on temperature
sensor.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS TABLE \
\
\
\
\
\
Application Ft. Lbs. (N.m)
A/C Compressor Bolt/Nut .................... 17-20 (23-27)
A/C Compressor Bracket Bolt/Nut .................. 37 (50)
A/C Compressor Clutch Coil Nut ................... 12 (16)
A/C Engine Coolant Temperature Switch ............ 26 (35)
INCH Lbs. (N.m)
Blower Motor Bolts/Nuts ........................... 44 (5)
Condenser Bolts/Nuts ............................ 106 (12)
Dual-Pressure Switch ............................. 89 (10)
Evaporator Assembly Bolts/Nuts .................... 44 (5)
Heater Assembly Bolts/Nuts ........................ 44 (5)
\
\
\
\
\
\
WIRING DIAGRAMS
Page 114 of 1501
clockspring, the steering wheel may not turn completely, or
flat cable inside clockspring may be severed, disabling SRS
system and possibly causing serious injury to driver.
Installation
1) Ensure front wheels are in straight-ahead position. Align
mating marks on clockspring. See CLOCKSPRING CENTERING under
ADJUSTMENTS. Install clockspring. To install remaining components,
reverse removal procedure. Before installing air bag module, ensure
horn switch wiring is positioned so that it will not be pinched.
2) Tighten fasteners to spec. See TORQUE SPECIFICATIONS.
Activate SRS. See DISABLING & ACTIVATING AIR BAG SYSTEM . Check AIR BAG
warning light for proper system function. SYSTEM OPERATION CHECK.
PASSENGER-SIDE AIR BAG MODULE
Removal & Installation
1) Before proceeding, see SERVICE PRECAUTIONS. Deactivate
SRS. See DISABLING & ACTIVATING AIR BAG SYSTEM .
2) Remove right-side foot shower duct and two stoppers on
either side. Remove and lower glove box. Disconnect air bag module
connector. Remove retaining bolts and passenger-side air bag module.
See Fig. 5 .
3) To install, reverse removal procedure. Tighten bolts to
specification. See TORQUE SPECIFICATIONS . Activate SRS. See procedures
under DISABLING & ACTIVATING AIR BAG SYSTEM . Check AIR BAG warning
light for proper system function. SYSTEM OPERATION CHECK.
Fig. 5: Removing Passenger-Side Air Bag Module
Courtesy of Mitsubishi Motor Sales of America.
SRS AIR BAG CONTROL UNIT (ECU)
Page 115 of 1501
CAUTION: SRS-ECU connector is a double-locking mechanism. DO NOT use
excessive force when disconnecting connector.
Removal & Installation
1) Before proceeding, see SERVICE PRECAUTIONS. Deactivate
SRS. See DISABLING & ACTIVATING AIR BAG SYSTEM .
2) Remove rear and front floor console assembly. Remove
switch panel and suspension control switch. Disconnect rear console
harness connector. Remove side panel A and rear console assembly.
3) Remove shift lever. Disconnect front console harness
connector and remove front console assembly. Disconnect SRS-ECU
connector. Remove mounting bolts, bracket and SRS-ECU. See Fig. 6.
4) To install, reverse removal procedure. Tighten bolts to
specification. See TORQUE SPECIFICATIONS . Activate SRS. See procedures
under DISABLING & ACTIVATING AIR BAG SYSTEM . Check AIR BAG warning
light for proper system function. SYSTEM OPERATION CHECK.
Fig. 6: Removing SRS Air Bag Control Unit (ECU)
Courtesy of Mitsubishi Motor Sales of America.
FRONT IMPACT SENSORS
Removal & Installation
Page 116 of 1501
1) Before proceeding, see SERVICE PRECAUTIONS. Deactivate
SRS. See DISABLING & ACTIVATING AIR BAG SYSTEM .
2) Remove components for access to front impact sensors as
necessary. See Fig. 7. Remove front impact sensor mounting bolts.
Slide Green section of connector to release lock. Push down on pawl.
Disconnect electrical connector. Remove front impact sensor.
3) To install, reverse removal procedure. Position sensor
with arrow facing toward front of vehicle. Tighten bolts to
specification. See TORQUE SPECIFICATIONS . Activate SRS. See procedures
under DISABLING & ACTIVATING AIR BAG SYSTEM . Check AIR BAG warning
light for proper system function. SYSTEM OPERATION CHECK.
Fig. 7: Locating Front Impact Sensors
Courtesy of Mitsubishi Motor Sales of America.
ADJUSTMENTS
Page 117 of 1501
CLOCKSPRING CENTERING
WARNING: If front wheels are not in straight-ahead position or
clockspring mating marks are not aligned before installing
clockspring, the steering wheel may not turn completely, or
flat cable inside clockspring may be severed, disabling SRS
system and possibly causing serious injury to driver.
With clockspring removed, ensure front wheels are in
straight-ahead position. Turn clockspring fully clockwise, and then
turn it back approximately 3.3 turns counterclockwise to align mating
marks. See Fig. 8.
Fig. 8: Aligning Clockspring Mating Marks
Courtesy of Mitsubishi Motor Sales of America.
WIRE REPAIR
DO NOT repair SRS wiring or harness connectors. If SRS wiring
or harness connectors are faulty, replace faulty wiring harness.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS\
\
\
\
\
\
Application Ft. Lbs. (N.m)
Steering Wheel Nut ............................... 29 (39)
