MITSUBISHI OUTLANDER 2020 (in English) Owners Manual

Keyless entry system (if so equipped) 5-10 Features and controls
5
2. Using a valid (already registered) remote control transmitter, ac
tivate the registra-
tion mode according to the following steps. Steps ii to iv should be completed within 8 seconds.
3. Within 60 seconds after step 2, complete the following ID code
registration opera-
tion using the next remote control trans- mitter you wish to register within 4 seconds. 4. To register the ID
codes of additional
remote control transmitters, repeat step 3 within 60 seconds after step 3.5. If no ID code of a remote control trans- mitter is registered within 60 seconds after step 3, the regi
stration mode is can-
celed and the normal mode returns.
i) Press and hold the
UNLOCK button (2) for 4 to 8 seconds.
ii) While holding the
UNLOCK button (2), press the LOCK but-ton (1).
iii) While holding the
UNLOCK button (2), release the LOCK but- ton (1).
iv)
Release the UNLOCK button (2).NOTE
 ID codes for all remote control transmitters except for the transmitter used in steps 2 are erased and the answerback function (door is locked and unlocked) informs you that theregistration mode ha
s been activated.
i) Press both the LOCK
and UNLOCK but- tons for 2 seconds.
ii) Release both the
LOCK and UNLOCK buttons for 1 second.
iii)
Press the UNLOCK button.NOTE
 Be sure to press the buttons correctly when performing the procedures. If you perform the procedures incorrectly, the registered ID code information could
be deleted or the set-
tings could be changed
unintentionally. If the
registered ID code in
formation is deleted,
register the remote control transmittersagain.
 For verification purposes, try to lock and unlock the doors after the registration iscompleted.  The indicator light (4) comes on each time a button is pressed.  The keyless entry system does not work if the key is in the ignition switch.  The remote control transmitter can be used from approximately 40
feet (12 m) away.
However, this distance
may change if your
vehicle is near a TV
transmitting tower, a
power station, or
a radio station.
 If the following conditi
ons are observed after
pressing the LOCK (1) or UNLOCK (2) but-ton on the remote control transmitter, the battery in the remote control transmitter may need to be replaced. • The doors and the lift
gate cannot be locked
or unlocked. • The panic alarm
cannot be operated.
• The indicator light
(4) is dim or does not
come on.
 If you lose your remote control transmitter, please contact an au
thorized Mitsubishi
Motors dealer for a replacement.  If you wish to obtain
an additional remote
control transmitter, please contact an autho-rized Mitsubishi Moto
rs dealer. A maximum
of 8 remote control tr
ansmitters can be pro-
grammed for your vehicle.NOTE
BK0278200US.book 10 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Keyless entry system (if so equipped)
Features and controls 5-11
5
 To use the new remote control transmitters, it is necessary to register the key with both theelectronic immobilizer
and keyless entry sys-
tem. Also refer to “Electr
onic immobilizer (Anti-
theft starting system): Customer key pro-gramming” on page 5-6.NOTE
BK0278200US.book 11 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Keyless entry system (if so equipped) 5-12 Features and controls
5
N00596500041
You can change the settings for the follow
ing functions according to your preferences.
When changing a setting, perform the fol
lowing steps.
1. Remove the key from
the ignition switch.
2. Open the driver’s door and turn the combination
headlights and dimmer switc
h to the “OFF” position.
3. Complete steps i to iv of the procedure. Step
s ii to iv should be completed within 8 seconds.
Customizing the keyless entry system

Item
Ste p i
Ste p i i
Step iii
Ste p i v
Notification
Horn deactiva- tion/reactivation
Press and hold the LOCK button (1) for 4 to 8 seconds.
While holding the LOCK button (1), press the UNLOCK button (2).
While holding the LOCK button (1), release the UNLOCK button (2).
Release the LOCK but- ton (1).
Chimes  Page 5-8
Turn signal lights deactivation/reac- tivation
Press and hold the UNLOCK button (2) for 4 to 8 seconds.
While holding the UNLOCK button (2), press the LOCK button (1).
While holding the LOCK button (1), release the UNLOCK button (2).
Release the LOCK but- ton (1).
Chimes  Page 5-8
Setting the door and liftgate unlock function
Press and hold the LOCK button (1) for 4 to 8 seconds.
While holding the LOCK button (1), press the UNLOCK button (2).
While holding the UNLOCK button (2), release the LOCK button (1).
Release the UNLOCK button (2).
Chimes  Page 5-8
BK0278200US.book 12 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Keyless entry system (if so equipped)
Features and controls 5-13
5
N00546101124
Your keyless entry system operates on a radio frequency subject to
Federal Communica-
tions Commission (FCC)
Rules (For vehicles
sold in U.S.A.) and Industry Canada Rules (For vehicles sold in Canada). This device complies with Part 15 of FCC Rules andIndustry Canada licenc
e-exempt RSS stan-
dard(s). Operation is subject to the following two con-ditions.  This device may not
cause harmful inter-
ference.  This device must ac
cept any interference
received, including interference that may cause undesired operation.
N00544101247
1. Before replacing the battery, remove staticelectricity from your body by touching a metal grounded object.
NOTE
 Be sure to press the buttons correctly wh
en performing the procedures. If you perform
the procedures incorrectly, the registere
d ID code information could
be deleted or the settings
could be changed uninten
tionally. If the registered ID code info
rmation is deleted, register the rem
ote control transmitters again.
Refer to “Customer remote control tr
ansmitter programming (Except for vehicl
es sold in Canada)” on page 5-9.
General information

CAUTIONChanges or modifica
tions not expressly
approved by the manufacturer for compli- ance could void the user’s authority to oper-ate the equipment.
Procedure for replacing the remote control transmitter bat-tery
WA R N I N G Do not swallow a coin type battery.• This product contains coin type battery. If a coin type battery is swallowed, it can cause severe internal burns and can lead to death.There have been case
s where a swallowed
battery has caused severe internal burns in just 2 hours.• Keep new and used batteries away fromchildren.• If the remote control transmitter casedoes not close securely, stop using theproduct and keep it away from children.• If you think batter
ies might have been
swallowed or placed in
side any part of a
person’s body, seek immediate medical attention.
 To prevent that can result in an explosion or the leakage of fl
ammable liquid or gas.
• Do not replace an
incorrectly battery.
Replace only with th
e same or equivalent
type.• Do not dispose of a battery into fire orincinerator, or mech
anically crushing or
cutting of a battery.• Do not use, store in or bring into a bat-tery where it may be exposed to extremely high temperature or extremelylow air pressure.CAUTION When the remote control transmitter case is opened, be careful to keep water, dust, etc.out. Also, do not touch the internal compo- nents. Dispose of used battery according to regula- tions for the disposal of battery.WA R N I N G
BK0278200US.book 13 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Keyless entry system (if so equipped) 5-14 Features and controls
5
2. Remove the screw (A) from the remote control transmitter. 3. With the Mitsubishi mark facing you, insert the cloth-cov-ered tip of a flat blade screwdriver into the notch in the remote control transmitter case and use it to openthe case.
4. Remove the used battery.
5. Install a new battery with the +side (B) up. 6. Close the remote control transmitter case firmly. 7. Attach the screw (A) removed in step 2. 8. Check the keyless entry system to see thatit works.
NOTE
 Be sure to perform the procedure with the Mitsubishi mark facing you. If the Mitsubi-shi mark is not facing you when you open theremote control transmitter case, the buttons may come out.  The Federal Communications Commission (FCC) ID number, the Industry Canada (IC) number and the model
number (radio certifi-
cation) are indicated in
the illustrated posi-
tion.
NOTE
 You may purchase a replacement battery at an electric appliance store.  An authorized Mitsubishi Motors dealer can replace the battery for you if you prefer.
+ side - side Coin type bat- tery CR1620
BK0278200US.book 14 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced Securi
ty Transmitter (F.A.S.T.-key) (if so equipped)
Features and controls 5-15
5
N00503101222
The Free-hand Advanced Security Transmit- ter (F.A.S.T.-key) enables the doors and theliftgate to be locked
and unlocked, the engine
to be started and the operation mode to be changed simply by carrying it. The F.A.S.T.-key can also be used as the remote control transmitter of the keylessentry system. Refer to “Free-hand
Advanced Security
Transmitter (F.A.S.T.-key): Keyless entrysystem” on page 5-31.
The operations possible with the F.A.S.T.- key can be modified as stated below. (Keyless entry operations are possible.) For details, contact an
authorized Mitsubi-
shi Motors dealer. • Enabling only the locking and unlocking of the doors and the liftgate• Enabling only the starting of the engine • Deactivating the F.A.S.T.-key
Free-hand Advanced Secu- rity Transmitter (F.A.S.T.-key)
(if so equipped)
The F.A.S.T.-key must be carried by the driver. The F.A.S.T.-key is required for vehicle operations su
ch as locking and
unlocking the doors and the liftgate, starting the engine
and changing the
operation mode. When
leaving the vehi-
cle, make sure you are carrying the F.A.S.T.-key and then lock the vehicle.
WA R N I N G Individuals who use
implantable pace-
makers or implanta
ble cardiovascular-
defibrillators should keep away from theexternal and internal
transmitters. The
electromagnetic w
aves used in the
F.A.S.T.-key may affe
ct the operation of
implantable pacemakers and implantable cardiovascular-defibrillators.A- External transmitter B- Internal transmitter
WA R N I N G Individuals using ot
her electro-medical
apparatus besides implantable pacemak-ers and implantable
cardiovascular-defi-
brillators should
check with the
manufacturer of the apparatus to confirm the effect of the el
ectromagnetic waves
used by the F.A.S.T.-key. The electromag- netic waves may affect
the operations of
the electro-medical apparatus.NOTE
 The F.A.S.T.-key uses weak electromagnetic waves.In cases such as the following, operationmay be imprope
r or unstable.
• The vehicle is near a facility that emits strong electroma
gnetic waves, such as a TV
transmitting tower, a po
wer station, a radio
station or an airport
BK0278200US.book 15 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced
Security Transmitter (F.A.S
.T.-key) (if so equipped)
5-16 Features and controls
5
N00503201249
When a person enters the operating range of the F.A.S.T.-key while carrying the F.A.S.T.-key and presses the driver’s or front passen- ger’s door lock/unlock switch, the liftgate LOCK switch or the liftgate OPEN switch,verification of the ID
code is performed.
The doors and the liftgate can be locked and unlocked and the engine
can be started only
when the ID codes of the vehicle and F.A.S.T.-key match.
The operating range is
within about 2.3 feet
(70 cm) of the handles of the driver’s door,front passenger door and liftgate.
• The key is carried together with other com- munication devices such
as cellular phones
or radios, or electrical appliances such ascomputers • The F.A.S.T.-key touches or is covered by a metal object • A keyless entry system is being used nearby • The battery of the F.A.S.T.-key is run down• The vehicle is in
a location with strong
electromagnetic
waves or noise
Use the emergency key to lock and unlock the driver’s door in such circumstances.Refer to “To operate
without using the
F.A.S.T.-key” on page 5-29.  The F.A.S.T.-key is constantly performing reception opera
tions in its communication
with the vehicle. This means that the batteryis always running down, regardless of how often the F.A.S.T.-key is used. The battery life is approximately
1 to 3 years, depending
on the usage conditions.  Since the F.A.S.T.-key is constantly perform- ing reception operati
ons, the reception of
strong electrom
agnetic waves
can accelerate
the running down of the ba
ttery. Do not place
near to electrical appliances such as televi- sions or computers.NOTE
Operating range of the F. A . S . T. - k e y

NOTE
 When the battery of the F.A.S.T.-key has run down or there are st
rong electromagnetic
waves or noise in the area, the operating range could decrease
or operations could
become unstable.
Operating range for locking and unlocking the doors and the lift-gate
* : Front of the vehicle : Operating range
NOTE
 The door or liftgate switch can only be used for locking or unlocking when a matching F.A.S.T.-key is detected.  The system may not operate if the F.A.S.T.- key is too close to the windshield, door win-dows or liftgate.
BK0278200US.book 16 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced Securi
ty Transmitter (F.A.S.T.-key) (if so equipped)
Features and controls 5-17
5
N00503301077
The operating range is the interior of the vehicle.
N00503401472
While carrying the F.A.S.T.-key, press thedriver’s or front passenger’s door lock/unlockswitch (A), or the liftgate LOCK switch (B) within the operating range to lock all the doors and the liftgate. The turn signal lights will blink once and the buzzer will sound once. Also refer to “Doors locks”, “Power door locks”, “Liftgate” and “Power liftgate” on pages 5-36, 5-38, 5-40 and 5-42 respectively.
 Even if the F.A.S.T.-key is within about 2.3 feet (70 cm) of the handle of the driver’sdoor, front passenger’s door or liftgate, thesystem may not operate if the key is close to the ground or in a high position.  If the F.A.S.T.-key is within the operating range, even a person not carrying the F.A.S.T.-key can lock and unlock the doorsor the liftgate by pressing the driver’s or front passenger’s door lock/unlock switch, the liftgate LOCK switch or the liftgateOPEN switch.
Operating range for starting the engine and changing the opera- tion mode

NOTE
* : Front of the vehicle : Operating range
NOTE
 Even if the F.A.S.T.-key is within the operat- ing range, it may not be possible to start the engine and change the
operation mode if the
key is in a storage space such as the glovecompartment, on top of the instrument panel, or in the door pocket or luggage compart- ment.  Even if the F.A.S.T.-key is inside the vehicle, it may not be possible to
start the engine and
change the operation mode if the key is too close to a door or door window.
To operate using the F.A.S.T.- key

To l o c k

Driver’s and front passenger’s door lock/unlock switches
BK0278200US.book 17 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced
Security Transmitter (F.A.S
.T.-key) (if so equipped)
5-18 Features and controls
5
While carrying the F.A.S.T.-key within the operating range, you can unlock the doorsand the liftgate by using the F.A.S.T.-key operation. The dome light will turn on for 30 seconds.The turn signal lights will blink twice and the buzzer will
sound twice.
Also refer to “Door locks”, “Power door locks”, “Liftgate” and “Power liftgate” onpages 5-36, 5-38, 5-40 and 5-42 respectively. Press the driver’s door lock/unlock switch (A) to unlock only the driver’s door. Within approximately 2 seconds, press thedriver’s door lock/unlock switch one more time to unlock all the
doors and the liftgate.
Press the front passenger’s door lock/unlock switch (B) or the liftgate OPEN switch (C) to unlock all the doors and the liftgate.
NOTE
 On the vehicles equipped with the mirror retractor switch, the out
side rearview mirrors
automatically retract when all doors and lift- gate are locked using the driver’s or front passenger’s door lock/unlock switch (A) orthe liftgate LOCK switch (B).  In cases such as the following, the F.A.S.T.- key does not operate. • There is a F.A.S.T.-key in the passenger compartment • A door or the liftgate is open or ajar• The operation mode
is not in OFF.
 The liftgate OPEN switch (C) can be used to confirm that the vehicl
e is locked properly.
Press the liftgate OPEN switch withinapproximately 3 seconds of locking.  If the liftgate OPEN switch is pressed 3 sec- onds or more after the
vehicle is locked, the
doors and the liftga
te are unlocked.
Liftgate switches
The time within which locking confirmation is possible can be adjusted. See an autho-rized Mitsubishi Motors
dealer for details.
On a vehicle equipped
with the Smartphone-
link Display Audio (SDA
), the function can
be adjusted on the screen. For details, referto the separate owner’s manual.
To u n l o c k

NOTE
NOTE
 On the vehicles equipped with the mirror retractor switch, the out
side rearview mirrors
automatically extend when the driver’s door is unlocked using the
driver’s lock/unlock
switch (A), front passenger’s doorlock/unlock switch (B)
or the liftgate open
switch (C).  Settings can be change
d so that all doors and
the liftgate are unloc
ked automatically by
pressing the driver’s door lock/unlock switchonce. Refer to “Setting of door
and liftgate unlock
function” on page 5-33.Driver’s door lock/unlock switch
BK0278200US.book 18 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced Securi
ty Transmitter (F.A.S.T.-key) (if so equipped)
Features and controls 5-19
5
N00513501216
To prevent vehicle theft, no F.A.S.T.-keys other than those regist
ered in advance can be
used to start the engi
ne. (Electronic immobi-
lizer function)While carrying the F.A.S.T.-key, the engine switch can be used
to start the engine.
NOTE
If the doors and the liftgate are unlocked using the driver’s or front passenger’s doorlock/unlock switch when all doors and the liftgate are locked and no doors or the lift- gate are opened with
in approximately 30
seconds, the doors and th
e liftgate will auto-
matically re-lock.Front passenger’s door lock/unlock switchLiftgate OPEN switch
 The amount of time af
ter unlocking until the
vehicle re-locks au
tomatically can be
adjusted. See an authorized MitsubishiMotors dealer for details. On a vehicle equipped
with the Smartphone-
link Display Audio (SDA), the functions canbe adjusted on the scre
en. For details, refer
to the separate owner’s manual.  The F.A.S.T.-key does not operate when the operation mode is not in OFF.  The doors and the liftgate cannot be unlocked by using the li
ftgate OPEN switch
for approximately 3 seconds after locking.  The time within which locking confirmation is possible can be adjusted. See an autho-rized Mitsubishi Motors
dealer for details.
On a vehicle equipped
with the Smartphone-
link Display Audio (SDA
), the function can
be adjusted on the scre
en. For details, refer
to the separate owner’s manual.  Functions settings can
be modified as stated
below. See an authorized Mitsubishi Motors dealerfor details. On a vehicle equipped
with the Smartphone-
link Display Audio (SDA), the functions canbe modified on the scre
en. For details, refer
to the separate owner’s manual. • Activating the operati
on confirmation func-
tion (blinking of the turn signal lights) only during locking, or only during unlocking.NOTE
• Deactivating the operation confirmationfunction (blinking of th
e turn signal lights)
and buzzer. • Modifying the number of blinks in the operation confirmati
on function (blinking
of the turn signal lights). • Making the buzzer sound when the F.A.S.T.-key is removed from the passenger compartment when all the doors and the liftgate are closed.
Engine switch

NOTE
BK0278200US.book 19 ページ ２０１９年４月１０日　水曜日　午前１０時５９分
