MITSUBISHI OUTLANDER 2020 Owner's Manual (in English)

Free-hand Advanced
Security Transmitter (F.A.S
.T.-key) (if so equipped)
5-30 Features and controls
5
N00561100014
To add a F.A.S.T.-key, you must already have 2 registered F.A.S.T.-keys. You need to regis- ter the ID code to the vehicle.Registering the ID code can be done by your authorized Mitsubishi Motors dealer. Or it can be done by yourself (except for vehiclessold in Canada). For you to register the ID code yourself, fol- low the “Customer F.A.S.T.-key program- ming” procedure below. If you choose to have your authorizedMitsubishi Motors dealer register the ID code, take your vehicle and all remaining F.A.S.T.-keys to your authorized MitsubishiMotors dealer.
N00561201302
You can program new F.A.S.T.-keys to thesystem if you have tw
o valid (already regis-
tered) F.A.S.T.-keys and a blank (not regis- tered) F.A.S.T.-key. For F.A.S.T.-key programming, follow the procedures below. 1. Open the driver’s door. 2. While carrying the fi
rst valid F.A.S.T.-
key, put the operation mode in ON. (Per- form the following procedure within 30 seconds.)
3. Insert the new F.A.S.T.-key into the key slot in the illustrated direction. 4. With the first valid F.A.S.T.-key, press the UNLOCK button for 4 to 8 seconds and press the LOCK button during this time. 5. Release in sequence the LOCK andUNLOCK buttons within 8 seconds of pressing the LOCK button in step 4. (Per- form the following procedure within 30seconds.) 6. With the second valid F.A.S.T.-key, press the UNLOCK button for 4 to 8 secondsand press the LOCK button during this time.
Additional F.A.S.T.-keys

NOTE
 You are provided with 2 F.A.S.T.-keys, but you may register up to 4 F.A.S.T.-keys. You can obtain blank F.
A.S.T.-keys specially
cut for your vehicle from your MitsubishiMotors dealer.
Customer F.A.S.T.-key program- ming (Except for vehicles sold in Canada)

NOTE
 Keep the driver’s door open until F.A.S.T.- key programming is finished. Do not open or close other doors.
BK0278200US.book 30 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced Securi
ty Transmitter (F.A.S.T.-key) (if so equipped)
Features and controls 5-31
5
7. Release in sequence the LOCK and UNLOCK buttons within 8 seconds ofpressing the LOCK button in step 6. The immobilizer display on the information screen in the multi-information displaywill blink. (Perform
the following step
within 20 seconds.) When registration of ID code is complete, the buzzer will s
ound 3 times and the
immobilizer display will come on for 30 seconds. If an error occurs, F.A.S.T.-key program-ming will be terminated and the buzzer will sound for 3 seconds. 8. If you wish to register another F.A.S.T.- key, repeat the proc
ess from step 1 after
the operation mode is put in OFF. 9. When all F.A.S.T.-keys are registered, remove the F.A.S.T.-key from the keyslot.
N00515501412
Press the remote control transmitter buttonsto lock or unlock the doors and the liftgate.It can also help you signal for attention by setting off the panic alarm.
Press the LOCK button (1) to lock all the doors and the liftgate. The turn signal lights
will also blink once.
Press the UNLOCK button (2) to unlock the driver’s door only.
NOTE
 F.A.S.T.-key programming will be termi- nated if the operation mode is put in OFF before the immobilizer
display starts blink-
ing.
NOTE
 The immobilizer displa
y will go off immedi-
ately if the operation
mode is put in OFF.
 Perform the operation when the interrupt dis- play screen is not show
ing. The interrupt dis-
play screen may prevent you from seeing theimmobilizer display.  It is not possible to register a F.A.S.T.-key if the immobilizer displa
y goes off during the
procedure.
Keyless entry system

1-
LOCK ( ) button
2-
UNLOCK ( ) button
3- Power liftgate button (if so equipped) 4- PANIC button 5- Operation indicator light
NOTE
 On vehicles equipped wi
th the mirror retrac-
tor switch, the outside rearview mirrors auto- matically retract or extend when the doors and the liftgate are locked or unlocked usingthe remote control transmitter buttons. Refer to “Features and controls: Outside rearview mirrors” on page 5-63.
To l o c k

NOTE
 If you press the LOCK button (1) twice, the horn will sound once.
To u n l o c k

BK0278200US.book 31 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced
Security Transmitter (F.A.S
.T.-key) (if so equipped)
5-32 Features and controls
5
Within approximately 2 seconds, press the UNLOCK button one more time to unlock allthe doors and liftgate. The dome light will turn on for 30 seconds. The turn signal lights will also blink twice.The front side-marker and parking lights will also turn on for approximately 30 seconds. Refer to “Welcome light” on page 5-207.
N00544501140
The horn and turn signal lights of the keylessentry system answerback function can be changed as required. This is done with the operation mode in OFF.
N00597200058
The answerback function can be set in thefollowing three ways.Each time the answerback function is set, a chime will sound to tell you the condition of the answerback function. To change the settings, refer to “Customizing the Free-hand Advanced Security Transmitter(F.A.S.T.-key)” on page 5-34.
N00597300059
The answerback function from the turn signallights can be turned ON or OFF separately. Each time the answerback function is set, a chime will sound to
tell you the condition of
the answerback function. To change the settings, refer to “Customizing the Free-hand Advanced Security Transmitter (F.A.S.T.-key)” on page 5-34.
N00597400050
The buzzer answerback function can beturned ON or OFF as required.
NOTE
 If the UNLOCK button (2) is pressed and no doors or the liftgate are opened within approximately 30 seconds, the doors and the liftgate will automatically re-lock.On a vehicle equipped
with the Smartphone-
link Display Audio (SDA), the functions can be adjusted on the scre
en. For details, refer
to the separate owner’s manual.  The door and liftgate
unlock function can be
set so that all doors a
nd liftgate unlock when
the UNLOCK button (2) is pressed once. Refer to “Setting of door
and liftgate unlock
function” on page 5-33.
Answerback function

NOTE
 On a vehicle equipped
with the Smartphone-
link Display Audio (SDA
), the functions can
be adjusted on the screen. For details, referto the separate owner’s manual.

Horn deactivation/reactivation Number of chimes
Condition
One chime The horn will not sound. Two chimes The horn will sound. Four chimes
The horn will sound if the- LOCK button (1) is pressed twice within 1 second.

Turn signal lights deactivation/reac- tivation Number of chimes
To l o c k
To unlock
One chime One flash Two flashes Two chimes One flash No flash Three chimes No flash Two flashes Four chimes Two flashes One flash Five chimes No
flash One flash
Six chimes Two flashes No flash Seven chimes No flash No flash
Buzzer deactivation/reactivation
BK0278200US.book 32 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced Securi
ty Transmitter (F.A.S.T.-key) (if so equipped)
Features and controls 5-33
5
N00544601271
The door and liftgate unlock function can be set to the following two conditions. Each time the door and
liftgate unlock func-
tion is set, a chime will
sound to tell you the
condition of the door and liftgate unlock function. To change the settings, refer to “Customizing the Free-hand Advanced Security Transmitter(F.A.S.T.-key)” on page 5-34.
N00579500020
After unlocking the doors and the liftgate, the power liftgate can be operated by pressing the power liftgate button (3).Refer to “Power lift
gate” on page 5-42.
N00544701142
If you are near your vehicle and feel threat- ened, you can activate the alarm to call atten- tion as follows: 1. Press the PANIC button (4) for more than 1 second. 2. The headlights will blink on and off and the horn will sound intermittently forapproximately 3 minutes. 3. To turn off the alarm, press any button on the remote control transmitter.
Setting the door and liftgate unlock function

Number of chimes
Condition
One chime [Factory setting]
When the UNLOCK button, driver’s or front passenger’s door lock/unlock switch, or liftgate OPEN switch is pressed one time, all doors and the liftgate unlock.
Tw o chimes
When the UNLOCK button or the driver’s door lock/unlock switch is pressed one time, only the driver's door unlocks.When the UNLOCK button or the driver’s door lock/unlock switch is pressed two times in succession, all doors and the liftgate unlock.
Operating the power liftgate

Using the panic alarm

NOTE
 The indicator light (5) comes on each time a button is pressed.  The F.A.S.T.-key can be used from approxi- mately 40 feet (12 m) away. However, this distance may change if
your vehicle is near a
TV transmitting tower, a power station, or a radio station.
 If the following conditions are observed after pressing the LOCK (1) or UNLOCK (2) but-ton on the remote control transmitter, thebattery in the F.A.S.T.-key may need to be replaced. • The doors and the liftgate cannot be locked or unlocked. • The panic alarm
cannot be operated.
• The indicator light
(5) is dim or does not
come on.
 If you lose your F.A.S.T.-key, please contact an authorized Mitsubishi Motors dealer for a replacement.  If you wish to obtain an additional F.A.S.T.- key, please contact an
authorized Mitsubishi
Motors dealer. A maximum of four F.A.S.T.-key can be programme
d for your vehicle.
 To use the new remote control transmitters, it is necessary to register
the key with both the
electronic immobilizer
and keyless entry sys-
tem.Also refer to “Electronic immobilizer (Anti- theft starting system): Customer F.A.S.T.- key programming” on page 5-30.NOTE
BK0278200US.book 33 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced
Security Transmitter (F.A.S
.T.-key) (if so equipped)
5-34 Features and controls
5
N00596600055
You can change the settings for the follow
ing functions according to your preferences.
When changing a setting, perform the fol
lowing steps.
1. Put the operation mode in OFF. 2. Open the driver’s door and turn the combination
headlights and dimmer switc
h to the “OFF” position.
3. Complete steps i to iv of the procedure. Step
s ii to iv should be completed within 8 seconds.
Customizing the Free-hand Advanced
Security Transmitter (F.A.S.T.-key)

Item
Ste p i
Ste p i i
Step iii
Ste p i v
Notification
Horn deactiva- tion/reactivation
Press and hold the LOCK button (1) for 4 to 8 seconds.
While holding the LOCK button (1), press the UNLOCK button (2).
While holding the LOCK button (1), release the UNLOCK button (2).
Release the LOCK but- ton (1).
Chimes  Page 5-32
Turn signal lights deactivation/reac- tivation
Press and hold the UNLOCK button (2) for 4 to 8 seconds.
While holding the UNLOCK button (2), press the LOCK button (1).
While holding the LOCK button (1), release the UNLOCK button (2).
Release the LOCK but- ton (1).
Chimes  Page 5-32
Setting the door and liftgate unlock function
Press and hold the LOCK button (1) for 4 to 8 seconds.
While holding the LOCK button (1), press the UNLOCK button (2).
While holding the UNLOCK button (2), release the LOCK button (1).
Release the UNLOCK button (2).
Chimes  Page 5-33
BK0278200US.book 34 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced Securi
ty Transmitter (F.A.S.T.-key) (if so equipped)
Features and controls 5-35
5
N00562001062
N00562101164
1. Before replacing the battery, remove static electricity from your body by touching a metal grounded object. 2. Remove the emergency key from the key.Refer to “Emergency key” on page 5-29.
NOTE
 Be sure to press the buttons correctly wh
en performing the procedures. If you perform
the procedures incorrectly, the settings
could be changed uninten-
tionally.
General information

Your F.A.S.T.-key operates on a radio fre- quency subject to
Federal Communications
Commission (FCC) Rules
(For vehicles sold
in U.S.A.) and Industry Canada Rules (For vehicles sold in Cana
da). This device com-
plies with Part 15 of
FCC Rules and Industry
Canada licence-exemp
t RSS standard(s).
Operation is subject to the following two con- ditions.
•This device may
not cause harmful
interference. •This device must ac
cept any interference
received, including interference that may cause undesired operation.CAUTION Changes or modifica
tions not expressly
approved by the manufacturer for compli-ance could void the user’s authority to oper- ate the equipment.
Procedure for replacing the remote control transmitter bat- tery
WA R N I N G Do not swallow a coin type battery.• This product contains coin type battery. If a coin type battery is swallowed, it cancause severe internal burns and can lead to death. There have been case
s where a swallowed
battery has caused severe internal burns in just 2 hours.• Keep new and used batteries away fromchildren.• If the remote control transmitter casedoes not close securely, stop using the product and keep it away from children.• If you think batter
ies might have been
swallowed or placed in
side any part of a
person’s body, seek immediate medicalattention.
 To prevent that can result in an explosion or the leakage of fl
ammable liquid or gas.
• Do not replace an incorrectly battery. Replace only with th
e same or equivalent
type.
• Do not dispose of a battery into fire orincinerator, or mech
anically crushing or
cutting of a battery.• Do not use, store in or bring into a bat-tery where it may be exposed toextremely high temperature or extremely low air pressure.CAUTION When the remote control transmitter case is opened, be careful to keep water, dust, etc. out. Also, do not touch the internal compo- nents. Dispose of used battery according to regula- tions for the disposal of battery.WA R N I N G
BK0278200US.book 35 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Door locks 5-36 Features and controls
5
3. With the Mitsubishi mark facing you, insert the cloth-covered tip of a flat bladescrewdriver into the notch in the case and use it to open the case. 4. Remove the used battery.
5. Install a new battery with the +side (A) up. 6. Close the case firmly. 7. Install the emergency key removed in step2. 8. Check the keyless entry system to see that it works.
N00509201544
NOTE
 Be sure to perform the procedure with the Mitsubishi mark faci
ng you. If the Mitsubi-
shi mark is not facing you when you open thecase, the transmitter may come out.
NOTE
 You may purchase a re
placement battery at
an electric appliance store.  An authorized Mitsubish
i Motors dealer can
replace the battery for you if you prefer.
Door locks
WA R N I N G Make sure all doors are tightly closed and locked while driving.
+ side - side
Coin type bat- tery CR2032
• Locked doors, in co
mbination with the
use of seat belts, can help reduce the riskof ejection in an accident.• Locked doors can help keep passengers,especially small child
ren, from opening
doors and falling out
of moving vehicles.
• Locked doors can help prevent outsiders from gaining access
to your vehicle when
you slow or come to a stop.
 Lock your vehicle whenever you leave it. Children who get into unlocked vehicles may not be able to get out. Childrentrapped inside vehicles can quickly be overcome by heat and suffer serious injury or death due to heat stroke. Never leave a child alon
e in the vehicle. In
addition to the risk
of heat stroke, chil-
dren can activate switches and controls, resulting in an injury
or fatal accident.
When closing a door,
make sure that the
door is fully closed and the door-ajar warning display goes out on the informa-tion screen on the multi-information dis- play. If the door is aj
ar it could open while
driving and caus
e an accident.
WA R N I N G
BK0278200US.book 36 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Door locks
Features and controls 5-37
5
Turn the key toward the front of the vehicle to lock the door. After checking that the door is locked, turn the key back to the center andremove it.
Move the lock knob to the lock position to lock the door. All doors should be kept locked while driv-ing. The driver’s door can be unlocked without using the lock knob by pulling on the insidedoor handle. 1. Move the inside lock knob to the locked position.
To lock and unlock with the key (driver’s door) 1- Insert or remove the key 2- Lock3- Unlock
NOTE
 When locking or unlocking with the key, only the driver’s door will be locked orunlocked.To lock or unlock all doors and liftgate, use the power door lock switch, the keyless entry system or the F.A.S.T.-key operation.Refer to “Power door locks” on page 5-38, “Keyless entry system” on pages 5-7 and 5-31, and “To operate using the F.A.S.T.-key” on page 5-17.  In vehicles equipped wi
th the F.A.S.T.-key,
the driver’s door can be locked and unlocked using the emergency key. Refer to “Emergency key” on page 5-29.
To lock or unlock the door from the inside 1- Lock 2- UnlockTo lock the door without using the key
BK0278200US.book 37 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Power door locks 5-38 Features and controls
5
2. Be sure the keys are not inside the vehi- cle. Close the door.
N00549601292
If the ignition switch is turned off and thedriver’s door is opened with the key in theignition switch, the ke
y reminder buzzer will
sound intermittently to remind you to remove the key.
The warning display will be displayed on the information screen in the multi-informationdisplay.
N00517301052
If the key is in the ignition switch or the oper-ation mode is in any
mode other than OFF,
when you push the lock knob forward with the driver’s door or passenger’s door open, the lock knob will automatically return to the unlocked position.
N00503801186
If the driver’s door is opened while the engineis stopped and the operation mode is in anymode other than OFF, the operation mode ON buzzer will sound intermittently to remind you put the operation mode in OFF.The warning display will be displayed on the information screen in the multi-information display.
N00509301662
Key reminder system (except for vehicles equipped with the F.A.S.T.-key)
Lock out protection Operation mode ON reminder system (vehicles equipped with F. A . S . T. - k e y )
Power door locks
NOTE
 When locking or unlocking with the key on the driver’s door, only the driver’s door willlock or unlock.  Repeated continuous
operation between lock
and unlock could acti
vate the power door
locking system’s built-in
protection circuit,
and prevent the system from operating. Ifthis occurs, wait about
1 minute before oper-
ating the power door lock switch.
BK0278200US.book 38 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Power door locks
Features and controls 5-39
5
All of the doors and the
liftgate can be locked
or unlocked by pressing the power door lockswitch on the driver’s or the front passenger door.
N00563401265
All doors and the liftgate will unlock when the ignition switch is turned to the “OFF” or“LOCK” position or the operation mode is put in OFF.
All doors and the liftg
ate will unlock when
the selector lever is moved to the “P” (PARK) position with the ignition switch or the opera- tion mode in ON.
To lock and unlock the doors and liftgate Using the power door lock switch 1- Lock 2- Unlock
To unlock the doors and liftgate You can select the functions to unlock thedoors and liftgate either using the ignitionswitch position or the engine switch, or using the selector lever position. These functions are not
activated when the
vehicle is shipped from the factory. To acti- vate or deactivate
these functions, please
contact your authorized Mitsubishi Motorsdealer.Using the ignition switch or the engine switch
Using the selector lever position
NOTE
 On a vehicle equipped
with the Smartphone-
link Display Audio (SDA
), the functions can
be adjusted on the screen. For details, referto a separate owner’s manual.
BK0278200US.book 39 ページ ２０１９年４月１０日　水曜日　午前１０時５９分
