engine MITSUBISHI OUTLANDER 2020 (in English) Owner's Guide

Free-hand Advanced Securi
ty Transmitter (F.A.S.T.-key) (if so equipped)
Features and controls 5-25
5
N00514301107
After pressing the engine switch and opera- tion mode in OFF, when driver’s door isopened, the steering wheel is locked.
The following methods can be used to unlock the steering wheel.  Put the operation mode in ACC.  Start the engine.
Steering wheel lock
(if so equipped)
To l o c k

NOTE
When the following operation is performed with the operation mode in OFF and theselector lever is in
the “P” (PARK) position,
the steering wheel is locked. • Open or close one of the doors. (except the liftgate) • Lock all the doors and the liftgate by using the F.A.S.T.-key operation or the remote control transmitter of the F.A.S.T.-key.
 When the driver’s door is opened while the steering wheel does not lock, warning dis-play will appear a
nd the buzzer sounds to
alert the steering
wheel is unlocked.
To unlock

WA R N I N GIf the engine is stopped while driving, do not open a door or
press the LOCK switch
on the remote control switch until the vehicle stops in a safe
place. This could
cause the steering wheel to lock, making it impossible to operate the vehicle.CAUTION Carry the F.A.S.T.-key with you when leav- ing the vehicle.If your vehicle needs to be towed, put the operation mode in ACC to unlock the steer- ing wheel.
NOTE
 When the steering wheel does not unlock, the warning display wi
ll appear. Press the
engine switch again
while moving the steer-
ing wheel slightly
right and left.
 When the steering wheel lock is abnormal, the warning display will
appear and the inner
buzzer will sound. Put
the operation mode in
OFF and then press the lock switch of the F.A.S.T.-key. If the warning will appear again, contact an authorized MitsubishiMotors dealer.  If there is a fault in the steering wheel lock, the warning display will
appear. Immediately
stop the vehicle in a sa
fe place and contact
an authorized Mitsubishi Motors dealer.
BK0278200US.book 25 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced
Security Transmitter (F.A.S
.T.-key) (if so equipped)
5-26 Features and controls
5
N00514601432
 The operation mode ca
n be in any mode
to start the engine.  The starter motor will be turning for up to approximately 15 seconds if the engine switch is released at once. Pressing the engine switch again while the starter motor is still turning will stop the starter motor.The starter motor will be turning for up to approximately 30 se
conds while the
engine switch is pressed.If the engine does not start, wait for a while and then attempt to start the engine again. Trying repeatedly with the engineor starter motor still turning will damage the starter mechanism.  If the engine will not start because the bat- tery is weak or discharged, refer to “Jump-starting the engine” on page 8-2 for instructions. A longer warm up period will only con- sume extra fuel.
The engine is warmed up enough for driv- ing when the bar graph of engine coolanttemperature display star
ts to move or the
low coolant temperature indicator goes out. Refer to “Engine coolant temperaturedisplay” on page 5-163.
Your vehicle is equipped with an electroni- cally controlled fuel injection system. This system automatically controls fuel injection. There is usually no need to depress the accel-erator pedal when starting the engine. To prevent battery drai
n, wait a few seconds
between attempts to restart the engine.
1. Make sure all occupants are properly seated with seat belts fastened.2. Make sure the parking brake is applied. 3. Press and hold the brake pedal down firmly with your right foot. 4. Make sure the selector
lever is in the “P”
(PARK) position. 5. Press the engine switch. 6. Confirm that all warning lights and warn- ing displays are functioning properly.
Starting and stopping the engine

Tips for starting

WA R N I N G Never run the engine in
a closed or poorly
ventilated area any longer than is neededto move your vehicle out of the area. Car- bon monoxide gas, which is odorless and extremely poisonous, could build up andcause serious injury or death.CAUTION Do not push-start the vehicle.Do not run the engine at high rpms or drive at high speeds until the engine has had a chance to warm up.
Starting the engine

NOTE
 After the engine has not
started for a while,
the brake pedal effort needed to start the engine may become grea
ter. If this occurs,
depress the brake pedal more firmly than usual.NOTE
 The engine can only be started when the selector lever is in the “P” (PARK) or “N” (NEUTRAL) position. For safety reasons,
the engine should be
started when the selector lever is in the “P” (PARK) position in which the driving wheels lock.
BK0278200US.book 26 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced Securi
ty Transmitter (F.A.S.T.-key) (if so equipped)
Features and controls 5-27
5
After several attempts, you may experience that the engine still does not start. 1. Make sure that all electric devices, such as lights, air conditio
ning blower and rear
window defogger, are turned off.2. While depressing the brake pedal, press the accelerator peda
l halfway and hold it
there, then crank th
e engine. Release the
accelerator pedal, immediately after the engine starts.
3. If the engine still will not start, the engine could be flooded with too much gasoline.While depressing the brake pedal, push the accelerator pedal all the way down and hold it there, then press the engineswitch to crank the engine. If the engine does not start after 5 to 6 seconds, push the engine switch
to stop cranking the
engine, and release th
e accelerator pedal.
Put the operation mode in OFF. Wait a few seconds, and then press the engine switch to crank the engine again while depressing the brake pedal, but do notpush the accelerator
pedal. If the engine
fails to start, repeat
these procedures. If
the engine still will
not start, contact your
local Mitsubishi Motors dealer or a repair facility of your choi
ce for assistance.
Startability of the engine with an ambient temperature of -22 °F (-30 °C) or lowerWhen the ambient temperature is -22 °F (-30 °C) or lower, it may not be possible to start from a standstill even with the selector leverin the “D” (DRIVE) or “R” (REVERSE) position. This phenomenon occurs because the trans-axle has not warmed up sufficiently; it does not indicate a problem.
If this occurs, place
the selector lever in the “P” (PARK) positionand let the engine idle for at least 10 minutes.
The transaxle will wa
rm up, and you will be
able to start normally.Do not leave the vehicle during warm-up operation. The MIVEC engine automatically switches its intake-valve control between a low-speed mode and a high-speed mode in accordance with driving conditions for maximum engine performance.
N00568201024
NOTE
 Minor noises may be heard on engine start- up. These will disappear as the engine warmsup.
When the engine is hard to start
Using the MIVEC engine
NOTE
 To protect the engine
, the high-speed mode
may not be selected wh
ile the engine coolant
temperature is low. In such a case, the engine revolutions do not rise to over 5,000 rpm even if the accelerato
r pedal is depressed.
Stopping the engine

WA R N I N GDo not operate the en
gine switch while
driving except in an emergency. If theengine is stopped while driving, the brake servomechanism will ce
ase to function and
braking efficiency will deteriorate. Also,the power steering system will not func- tion and it will require greater manual effort to operate the steering. This couldresult in a serious accident.
BK0278200US.book 27 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced
Security Transmitter (F.A.S
.T.-key) (if so equipped)
5-28 Features and controls
5
1. Stop the vehicle. 2. Fully engage the parking brake while depressing the brake pedal. 3. Move the selector
lever to the “P”
(PARK) position, and then press the engine switch to stop the engine.
N00568301142
Insert the F.A.S.T.-key into the key slot in the instrument panel. St
arting the engine and
changing the operation mode should be now possible. Remove the F.A.S.T.-key from the key slotafter starting the engine
or changing the oper-
ation mode.
If the operation mode is in OFF and the driver’s door is opened with the F.A.S.T.-key in the key slot, a warni
ng is issued with the
warning display and
the buzzer buzzing for
approximately 3 seconds to remind you to remove the key.
NOTE
 If you have to bring the engine to an emer- gency stop while driving, press and hold theengine switch for 3 seconds or more, or pressit quickly 3 times or
more. The engine will
stop and the operation m
ode will go to ACC.
 Do not stop the engine wi
th the selector lever
in any position other than the “P” (PARK) position. If the engine is stopped with theselector lever in any
position other than the
“P” (PARK) position, the operation mode will go to ACC rather than OFF.Put the operation mode
in OFF after placing
the selector lever in the “P” (PARK) posi- tion.
If the F.A.S.T.-key is not operat- ing properly

NOTE
 Do not insert into the
key slot anything other
than the F.A.S.T.-key. This could cause dam-age or a malfunction.
 Remove the object or
additional key from the
F.A.S.T.-key before inserting the key into thekey slot. The vehicle may not be able toreceive the registered ID code from the regis- tered key. Therefore, th
e engine may not start
and the operation mode
may not change.
 The F.A.S.T.-key is fixed in the key slot when inserted in the illustrated direction.Simply pull out the key to
remove it from the
key slot.
F.A.S.T.-key reminder

NOTE
BK0278200US.book 28 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Power door locks 5-38 Features and controls
5
2. Be sure the keys are not inside the vehi- cle. Close the door.
N00549601292
If the ignition switch is turned off and thedriver’s door is opened with the key in theignition switch, the ke
y reminder buzzer will
sound intermittently to remind you to remove the key.
The warning display will be displayed on the information screen in the multi-informationdisplay.
N00517301052
If the key is in the ignition switch or the oper-ation mode is in any
mode other than OFF,
when you push the lock knob forward with the driver’s door or passenger’s door open, the lock knob will automatically return to the unlocked position.
N00503801186
If the driver’s door is opened while the engineis stopped and the operation mode is in anymode other than OFF, the operation mode ON buzzer will sound intermittently to remind you put the operation mode in OFF.The warning display will be displayed on the information screen in the multi-information display.
N00509301662
Key reminder system (except for vehicles equipped with the F.A.S.T.-key)
Lock out protection Operation mode ON reminder system (vehicles equipped with F. A . S . T. - k e y )
Power door locks
NOTE
 When locking or unlocking with the key on the driver’s door, only the driver’s door willlock or unlock.  Repeated continuous
operation between lock
and unlock could acti
vate the power door
locking system’s built-in
protection circuit,
and prevent the system from operating. Ifthis occurs, wait about
1 minute before oper-
ating the power door lock switch.
BK0278200US.book 38 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Power door locks
Features and controls 5-39
5
All of the doors and the
liftgate can be locked
or unlocked by pressing the power door lockswitch on the driver’s or the front passenger door.
N00563401265
All doors and the liftgate will unlock when the ignition switch is turned to the “OFF” or“LOCK” position or the operation mode is put in OFF.
All doors and the liftg
ate will unlock when
the selector lever is moved to the “P” (PARK) position with the ignition switch or the opera- tion mode in ON.
To lock and unlock the doors and liftgate Using the power door lock switch 1- Lock 2- Unlock
To unlock the doors and liftgate You can select the functions to unlock thedoors and liftgate either using the ignitionswitch position or the engine switch, or using the selector lever position. These functions are not
activated when the
vehicle is shipped from the factory. To acti- vate or deactivate
these functions, please
contact your authorized Mitsubishi Motorsdealer.Using the ignition switch or the engine switch
Using the selector lever position
NOTE
 On a vehicle equipped
with the Smartphone-
link Display Audio (SDA
), the functions can
be adjusted on the screen. For details, referto a separate owner’s manual.
BK0278200US.book 39 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Child safety locks for rear door 5-40 Features and controls
5
N00509401298
Child safety locks help prevent rear passen- gers, especially children, from opening therear door using the inside door handle. A lock lever for the child safety lock is pro- vided on each rear door.When the lever is in the lock position (1), the rear door cannot be opened using the inside door handle.To open the rear door when the child safety lock lever is in the lock position, pull the out- side door handle.When the lever is in the release position (2), the child safety lock is released and the rear
door can be opened using the inside door han- dle.
N00510101367
Child safety locks for rear door 1- To lock 2- To release
WA R N I N G Always keep the door
s tightly closed and
locked when driving. An unlocked door may be accidentally
opened by a passen-
ger, especially by
a child who could fall
out. Also, if the doors are not locked, there is a greater risk of
someone being thrown
from the vehicle in an accident.
Liftgate (except for vehicles equipped with the power liftgate)
WA R N I N G It is dangerous to drive with the liftgate open since carbon mo
noxide (CO) gas con-
tained in engine exhaust gases can enter the passenger compartment.CO is an invisible,
odorless gas that can
cause unconsciousness and even death. When opening and closing the liftgate, make sure that there are no people nearby and be careful not to hit your head or pinch your hands, neck, etc.
 If snow or ice has ac
cumulated on the lift-
gate, remove it before
opening the liftgate.
Otherwise the liftgate may abruptly closedue to the weight of the snow or ice. When opening the lift
gate, always fully
open it. A partially opened liftgate can unexpectedly close due to its own weight. When the vehicle is parked on a slope, the effort required to open or close the liftgate may be greater or less than expected.The liftgate may also open or close more quickly.CAUTION Do not stand behind the exhaust pipe when loading and unloading
luggage. Heat from
the exhaust could lead to burns. To avoid damage to th
e liftgate, make sure
that area above and
behind the liftgate is
clear before opening it.NOTE
 Locking and unlocking the doors by using power door locks (driver and front passenger side), keyless entry system, or F.A.S.T.-key operation (vehicles equipped with theF.A.S.T.-key) also locks and unlocks the lift- gate.WA R N I N G
BK0278200US.book 40 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Power liftgate (if so equipped) Features and controls 5-43
5
N00576500045
When the power liftgate main switch (A) is on, the power liftgate
can be operated using
either the power liftgate switch on theF.A.S.T.-key, the driver’s side power liftgate switch or the open/close switches on the power liftgate.Refer to “Operating conditions” on page 5-43.
N00576100038
The power liftgate can be opened automati-cally when all of the following conditions are met.  The operation mode is in OFF.  The power liftgate is completely closed.  The power liftgate is unlocked.
 The operation mode is in ON with the selector lever in the “P” (PARK) position.
Automatic operation

WA R N I N G To avoid accidental or
unintended opera-
tion of the power liftgate, turn off thepower liftgate main switch when not oper- ating the power liftgate. Do not turn off the power liftgate main switch while the power liftgate is opening or closing.
CAUTION Do not apply excessive force to the power liftgate when opening
or closing it. Doing so
could damage to th
e power liftgate.
NOTE
Do not start the engine while the power lift- gate is operating. Th
e sudden operation pre-
vention mechanism c
ould operate, making
the power liftgate stop
intermittently while it
moves.  The power liftgate
cannot be opened when
the battery is discharged or disconnected. The liftgate must be then opened using the inside liftgate release.Refer to “Inside lift
gate release” on page
5-48.  If the keyless entry syst
em or close switch is
operated when the power liftgate main switch is off, the warning buzzer sounds 4times to notify the driver that the power lift- gate cannot be operated.  The power liftgate does
not operate normally
under the following conditions: • When parked on an incline • In strong winds • When the power liftg
ate is covered with
snow
 Repeated continuous opening and closing operation of the power li
ftgate will activate a
built-in protec
tion circuit and switch the
power liftgate to manual operation.
 If one of the power liftgate switches is oper- ated while the power lift
gate is operating, the
power liftgate will reverse and return to thefull open or close position.  If the selector lever is moved from “P” (PARK) position to a
nother position while
the power liftgate is
operating or completely
open, a warning buzzer will sound forapproximately 10 sec
onds to notify the
driver that the power liftgate is open.  If the battery or fuse is replaced while the power liftgate is open,
it cannot be closed
automatically.In this case close th
e power liftgate manu-
ally.
Operating conditions

NOTE
BK0278200US.book 43 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Power liftgate (if so equipped) Features and controls 5-47
5
If the engine is started while the power lift- gate is operating, the power liftgate may intermittently move or stop moving to pre- vent the power liftgate from moving abruptly.Approximately 10 seconds after the power liftgate has fully closed or opened, power lift- gate operation will again resume.
N00576300030
When the power liftgate main switch is off,the power liftgate can be manually openedand closed. After unlocking the power liftgate, push the power liftgate open switch (A) and pull up the power liftgate.
To close the power liftgate, pull the power liftgate grip (B) do
wnward and release it
before the power liftgate is completely closed, and then gently close the power lift- gate from the outside.
Sudden operation prevention mechanism

CAUTION The auto reverse will not operate while the sudden operation prev
ention mechanism is
activated.
Manual operation

WA R N I N G When the power liftgate is closed manu- ally, the auto reverse mechanism will notoperate even if something is trapped under the liftgate.CAUTION Make sure there is no one around the power liftgate when
opening it.
NOTE
The liftgate cannot be
opened if it is not
raised immediately after pressing the powerliftgate open switch. If this happens, raise th
e liftgate again after
pressing the liftgate open switch.
 When the battery is discharged or discon- nected, the power lift
gate cannot be opened
even manually. At that time, the liftgate canbe opened only by using
the inside liftgate
release. Refer to “Inside liftgate release” on page 5-48.CAUTION The auto reverse mechanism will not operate when the power liftgate
is closed manually.
Therefore be especially
careful not to trap a
hand or finger.NOTE
BK0278200US.book 47 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Theft-alarm system
Features and controls 5-49
5
3. Push out on the liftgate to open it.
N00510201267
The theft-alarm system is designed to provide protection from unauthorized entry into the vehicle. This system
is operated in three
stages: the first is the “armed” stage, the sec-ond is the “alarm” stage, and third is the “dis- armed” stage. If triggered, the system provides both audible a
nd visual alarm sig-
nals.
N00510301242
Park the vehicle and st
op the engine. Arm the
system as described below. 1. Except for vehicles
equipped with the
F.A.S.T.-key, remove the key from theignition switch. For vehicles equipped with the F.A.S.T.- key, put the operation mode in OFF.2. Make sure that the engine hood is closed. 3. Lock all doors and the liftgate by using the keyless entry system or the F.A.S.T.-key operation.
At this time, the theft-alarm indicator (A) in the instrument cl
uster flashes for con-
firmation. 4. The system has entered the armed stage after about 20 seconds, when the theft- alarm indicator (A) flashing becomesslower. The theft-alarm indicator (A) continues to flash while the system is in the armedstage.
CAUTION Always keep the releas
e lever lid on the lift-
gate closed when driving so that your lug-gage cannot accidentally
bump the lever and
open the liftgate.
Theft-alarm system Liftgate Power liftgate
CAUTION Do not modify or add parts to the theft-alarm system. Doing so could cause the theft-alarmto malfunction.
Armed stage Arm the system and leave
NOTE
 If the engine hood is open, the theft-alarm indicator (A) illuminate
s and the system can-
not enter the armed stage.The system enters the armed stage about 20 seconds after the engine hood is closed.  The system will be disarmed if, while the theft-alarm indicator (A) is illuminated, all doors and the liftgate are unlocked by usingthe keyless entry system or the F.A.S.T.-key operation.
BK0278200US.book 49 ページ ２０１９年４月１０日　水曜日　午前１０時５９分
