NISSAN 350Z 2005 Z33 Navigation Manual

Symptom Possible cause Remedy
The location of vehicle icon does not match the actual
position.Driving on slippery road surface If the position marker does not move to the correct
position even after the vehicle has been driven ap-
proximately 6 miles (10km), adjust the current loca-
tion. If necessary, adjust the moving speed of the ve-
hicle. Driving on slanted area
Rough or violent driving If the position marker does not move to the correct
position even after the vehicle has been driven ap-
proximately 6 miles (10km), adjust the current loca-
tion.
GPS indicator remains gray. Please check the GPS indicator on the screen to see
if it remains gray. If it remains gray, drive the vehicle
to a place where the GPS can be received.
Because the vehicle has tire chains on, or the system
was transferred to a different vehicle, errors (gain or
loss) result in calculating the speed from the speed
pulse.The location of the vehicle icon will move by driving
the vehicle for 30minutes (in case it is running at 18-
3/4 miles/hour (30km/h)). If you still notice errors,
adjust moving speed.
The map data has an error or is incomplete (if the
location error always happens in the same area).Please wait for the update of the Map DVD-ROM.
VEHICLE ICON
Troubleshooting guide
14-5


04.7.6/Z33-N


Symptom Possible cause Remedy
The message “Error” appears after operation. Map DVD-ROM is soiled or partially damaged. Check the DVD-ROM and wipe it clean with a soft
cloth, following cautions and instructions on page
13-2.
If you see any damage, replace the DVD-ROM.
MAP DVD-ROM14-6
Troubleshooting guide


04.7.6/Z33-N


Symptom Possible cause Remedy
Turn list is not displayed. Route search does not occur. Set designation areas and perform route search.
Car marker does not appear on recommended route. Drive on the recommended route.
Route guide is OFF. Turn the route guide ON.
In rerouting, the waypoints are not included in the cal-
culation.The system has judged that the vehicle has already
passed the point being chosen or set.If you want to go to that point again, edit the route
again.
DESTINATION, WAYPOINTS OR
MENU CONTENTS CANNOT BE
CHOSEN OR SET
Troubleshooting guide
14-7


04.7.6/Z33-N


Symptom Possible cause Remedy
Route information is not displayed. Route calculation has not yet been requested. Set the destination and request route calculation.
The vehicle icon is not on the suggested route. Please drive the vehicle along the suggested route.
Route guidance is off. Turn the route guidance on.
Route is not calculated automatically. The vehicle is not running on a route from which cal-
culation can occur.Enter a route from which calculation can occur. Alter-
natively, you can calculate the route manually. In this
case, the entire route will be calculated again.
It is impossible to request a detour. Your vehicle is not running on the suggested route. Restart route calculation or enter the suggested route.
The detour found is the same as the previous sugges-
tion.The system took many conditions into consideration,
but the same result was obtained.This condition is not abnormal.
It is impossible to set the waypoints. The number of waypoints exceeds 5. It is impossible to set more than 5 waypoints. Please
decrease the number of the waypoints.
Some items in the menu cannot be selected. The vehicle is moving. Park the vehicle in a safe place and select the desired
items for the suggested route.
DESTINATION, WAYPOINTS OR
MENU CONTENTS CANNOT BE
CHOSEN OR SET14-8
Troubleshooting guide


04.7.6/Z33-N


Symptom Possible cause Remedy
The voice guidance is not available. Voice guidance is only available at certain intersec-
tions marked with
. In some cases, the guidance is
not available even when the vehicle should make a
turn.This condition is not abnormal.
The vehicle is off the suggested route. Go back to the suggested route or request route cal-
culation again.
Voice guidance is set OFF. Turn the voice guidance ON.
Route guidance is set OFF. Turn the route guidance ON.
The guidance content does not correspond to the
actual condition.The content of the voice guidance may vary, depend-
ing on the types of junctions at which turns are made.Follow the actual rules and regulations of the roads
upon which you are driving.
VOICE GUIDANCE
Troubleshooting guide
14-9


04.7.6/Z33-N


Symptom Possible cause Remedy
Although the system is set with the moving direction
as the preference, it does not find the route by
matching the preference.There is no route found in that direction. This condition is not abnormal.
Route is not indicated. There is no road that can be found by this system
close to the destination.Reset the destination closer to the road displayed in
orange. Especially with roads which have separate
lanes for opposite directions, be careful in setting the
destination or waypoints on it, because results may
differ depending on the lane you choose.
The starting point to the destination is too close. Set more distant destinations.
The system may not calculate a route if the current
vehicle location is too far away from the destination.Divide your trip by selecting one or two intermediate
destinations.
The route is not displayed continuously at waypoints,
for example, that are not calculated route from the
vehicle’s current position.Suggested routes may be displayed discontinuously
near waypoints as route calculation is done at each
waypoint.This condition is not abnormal.
The suggested route the vehicle has traveled is
erased.Suggested routes are stored in memory by the
blocks; if the vehicle travels past waypoint block 1,
the previous data will be erased.This condition is not abnormal.
ROUTE CALCULATION14-10
Troubleshooting guide


04.7.6/Z33-N


Symptom Possible cause Remedy
A route with many detours is suggested. If there are restrictions (such as one-way traffic) on
roads close to the starting point or destination, the
system may suggest a detoured route.Try slightly moving the starting point or destination.
The landmark description does not correspond to the
actual one.This may be caused by insufficient or incorrect data
on the DVD-ROM.Exchange the Map DVD-ROM. The new DVD-ROM
will be updated.
The suggested route does not exactly connect to the
starting point, waypoints, or destination.There is no data for route calculation closer to these
points.Set these points on the main road displayed in thick
orange. Please note that in some cases even main
roads lack the data for route calculation.
ROUTE CALCULATION
Troubleshooting guide
14-11


04.7.6/Z33-N


MEMO14-12
Troubleshooting guide


04.7.6/Z33-N


15 Index
A
Address book (Editing) .............................................. 7-8
Address book (Setting) .............................................. 7-2
Automatic rerouting ..................................................... 9-2
Avoid areas (Editing)................................................... 8-5
Avoid areas (Setting) .................................................. 8-2
B
Birdview
TMdisplay .................................................... 11-2
C
Clear memory ............................................................. 4-21
Complete route ....................................................... 11-10
D
Destination (Adjusting)............................................. 5-39
Destination (Deleting)............................................... 5-39
Destination (Setting) ................................................... 5-2
Detour ............................................................................. 9-3
Display (Direction)..................................................... 11-7
Display (Error) ............................................................ 4-25
Display (Maintenance) ........................................... 11-28
Display (Setting) ..................................................... 11-21E
Enlarged intersection display ................................. 5-37
G
GPS (Global Positioning System)........................... 2-2
GPS information ..................................................... 11-17
H
Heading ....................................................................... 11-7
I
Icon (Changing) ......................................................... 7-10
Icon (Legend)...................................... 7-13, 13-4, 13-5
Information on screen (Planview/Birdview
TM) .... 11-2
Intersection ................................................................. 5-14
J
Joystick ........................................................................... 4-6
L
Liquid crystal display (LCD)................................. 11-28M
Map DVD-ROM ............................................. 13-2, 14-6
Map coverage areas ................................................... 2-4
N
Nearby display icons ................................................ 6-15
P
Point of Interest (POI) ................................................ 6-2
Preferences for route calculation .......................... 5-36
Previous Dest. ............................................................ 5-5
Q
Quick stop .................................................................. 5-43
Quick stop customer settings................................ 5-44
R
Reference symbols ...................................................... 1-2
Route calculation and guidance ............................ 5-36
Route guidance ......................................................... 4-24


04.7.6/Z33-N


S
Safe operation .............................................................. 1-2
Safety note .................................................................... 1-2
Scrolling the map ...................................................... 11-9
Simulation drive ....................................................... 11-13
Start-up screen .......................................................... 4-17
Storing current vehicle position ............................... 7-4
Street Address ............................................................. 5-7
T
Tracking ..................................................................... 11-15
Troubleshooting ......................................................... 14-1
Turn list...................................................................... 11-11
U
Updating the current vehicle location and the
direction .................................................................... 11-18
V
Voice guidance .......................................................... 10-2
Voice guidance (Notes) ........................................... 10-4
W
Waypoint (Adjusting)................................................ 5-39
Waypoint (Deleting).................................................. 5-39
Waypoint (Setting).................................................... 5-33Where am I ? ............................................................. 5-46
Z
Zoom in (IN) ............................................................... 11-6
Zoom out (OUT) ........................................................ 11-6


04.7.6/Z33-N

15-2
