Page 1 of 312
AT-1
AUTOMATIC TRANSMISSION
C TRANSMISSION/TRANSAXLE
CONTENTS
D
E
F
G
H
I
J
K
L
M
SECTION AT
A
B
AT
Revision: 2006 November2007 350Z
AUTOMATIC TRANSMISSION
INDEX FOR DTC ........................................................ 5
Alphabetical Index .................................................... 5
DTC No. Index ......................................................... 6
PRECAUTIONS .......................................................... 7
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 7
Precautions for Battery Service ................................ 7
Precautions for On Board Diagnostic (OBD) System
of A/T and Engine .................................................... 7
Precautions .............................................................. 8
Service Notice or Precautions .................................. 9
PREPARATION ......................................................... 10
Special Service Tools ............................................. 10
Commercial Service Tools ....................................... 11
A/T FLUID ................................................................. 12
Changing A/T Fluid ................................................ 12
Checking A/T Fluid ................................................. 12
A/T Fluid Cooler Cleaning ...................................... 14
A/T CONTROL SYSTEM .......................................... 17
Cross-sectional View .............................................. 17
Shift Mechanism ..................................................... 18
TCM Function ......................................................... 29
CAN Communication .............................................. 30
Input/Output Signal of TCM .................................... 30
Line Pressure Control ............................................ 31
Shift Control ........................................................... 32
Lock-up Control ...................................................... 34
Engine Brake Control ............................................. 35
Control Valve .......................................................... 35
ON BOARD DIAGNOSTIC (OBD) SYSTEM ............ 37
Introduction ............................................................ 37
OBD-II Function for A/T System ............................. 37
One or Two Trip Detection Logic of OBD-II ............ 37
OBD-II Diagnostic Trouble Code (DTC) ................. 37
Malfunction Indicator Lamp (MIL) ........................... 39
TROUBLE DIAGNOSIS ............................................ 40
DTC Inspection Priority Chart ................................ 40
Fail-safe ................................................................. 40
How to Perform Trouble Diagnosis for Quick and Accurate Repair ...................................................... 42
A/T Electrical Parts Location .................................. 47
Circuit Diagram ....................................................... 48
Inspections Before Trouble Diagnosis .................... 49
Check Before Engine is Started .............................. 53
Check at Idle ........................................................... 53
Cruise Test — Part 1 .............................................. 55
Cruise Test — Part 2 .............................................. 57
Cruise Test — Part 3 .............................................. 58
Vehicle Speed at When Gears Shifting Occurs ...... 58
Vehicle Speed at Which Lock-up Occurs/Releases ... 58
Symptom Chart ....................................................... 59
TCM Input/Output Signal Reference Values ........... 83
CONSULT-III Function (TRANSMISSION) ............. 84
Diagnostic Procedure Without CONSULT-III .......... 92
DTC U1000 CAN COMMUNICATION LINE .............. 94
Description .............................................................. 94
On Board Diagnosis Logic ...................................... 94
Possible Cause ....................................................... 94
DTC Confirmation Procedure ................................. 94
Wiring Diagram — AT — CAN ................................ 95
Diagnostic Procedure ............................................. 96
DTC P0615 START SIGNAL CIRCUIT ..................... 97
Description .............................................................. 97
CONSULT-III Reference Value ............................... 97
On Board Diagnosis Logic ...................................... 97
Possible Cause ....................................................... 97
DTC Confirmation Procedure ................................. 97
Wiring Diagram — AT — STSIG ............................ 98
Diagnostic Procedure ............................................. 99
DTC P0700 TCM .....................................................101
Description ............................................................101
On Board Diagnosis Logic ....................................101
Possible Cause .....................................................101
DTC Confirmation Procedure ...............................101
Diagnostic Procedure ...........................................101
DTC P0705 PARK/NEUTRAL POSITION SWITCH .102
Description ............................................................102
CONSULT-III Reference Value .............................102
On Board Diagnosis Logic ....................................102
Page 3 of 312
AT-3
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z Description ........................................................... 145
CONSULT-III Reference Value ............................. 145
On Board Diagnosis Logic ................................... 145
Possible Cause .................................................... 145
DTC Confirmation Procedure ............................... 145
Diagnostic Procedure ........................................... 146
DTC P1757 FRONT BRAKE SOLENOID VALVE .. 147
Description ........................................................... 147
CONSULT-III Reference Value ............................. 147
On Board Diagnosis Logic ................................... 147
Possible Cause .................................................... 147
DTC Confirmation Procedure ............................... 147
Diagnostic Procedure ........................................... 148
DTC P1762 DIRECT CLUTCH SOLENOID VALVE . 149
Description ........................................................... 149
CONSULT-III Reference Value ............................. 149
On Board Diagnosis Logic ................................... 149
Possible Cause .................................................... 149
DTC Confirmation Procedure ............................... 149
Diagnostic Procedure ........................................... 150
DTC P1767 HIGH AND LOW REVERSE CLUTCH
SOLENOID VALVE ................................................. 151
Description ........................................................... 151
CONSULT-III Reference Value ............................. 151
On Board Diagnosis Logic ................................... 151
Possible Cause .................................................... 151
DTC Confirmation Procedure ............................... 151
Diagnostic Procedure ........................................... 152
DTC P1772 LOW COAST BRAKE SOLENOID
VALVE ..................................................................... 153
Description ........................................................... 153
CONSULT-III Reference Value ............................. 153
On Board Diagnosis Logic ................................... 153
Possible Cause .................................................... 153
DTC Confirmation Procedure ............................... 153
Diagnostic Procedure ........................................... 154
DTC P1774 LOW COAST BRAKE SOLENOID
VALVE FUNCTION ................................................. 155
Description ........................................................... 155
CONSULT-III Reference Value ............................. 155
On Board Diagnosis Logic ................................... 155
Possible Cause .................................................... 155
DTC Confirmation Procedure ............................... 155
Diagnostic Procedure ........................................... 156
DTC P1815 MANUAL MODE SWITCH .................. 157
Description ........................................................... 157
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... 157
On Board Diagnosis Logic ................................... 157
Possible Cause .................................................... 157
DTC Confirmation Procedure ............................... 157
Wiring Diagram — AT — MMSW ......................... 158
Diagnostic Procedure ........................................... 160
Component Inspection ......................................... 161
MAIN POWER SUPPLY AND GROUND CIRCUIT . 162
Wiring Diagram — AT — MAIN ............................ 162
Diagnostic Procedure ........................................... 163
CLOSED THROTTLE POSITION AND WIDE OPEN
THROTTLE POSITION CIRCUIT ........................... 166CONSULT-III Reference Value .............................166
Diagnostic Procedure ...........................................166
BRAKE SIGNAL CIRCUIT ......................................167
CONSULT-III Reference Value .............................167
Diagnostic Procedure ...........................................167
A/T INDICATOR CIRCUIT .......................................168
Description ............................................................168
CONSULT-III Reference Value .............................168
Diagnostic Procedure ...........................................168
TROUBLE DIAGNOSIS FOR SYMPTOMS ............169
Wiring Diagram — AT — NONDTC ......................169
A/T Check Indicator Lamp Does Not Come On ....172
Engine Cannot Be Started in “P” or “N” Position ..173
In “P” Position, Vehicle Moves When Pushed ......173
In “N” Position, Vehicle Moves ..............................174
Large Shock (“N” to “D” Position) .........................175
Vehicle Does Not Creep Backward in “R” Position .177
Vehicle Does Not Creep Forward in “D” Position . 179
Vehicle Cannot Be Started from D
1 ......................181
A/T Does Not Shift: D
1 → D2 ................................183
A/T Does Not Shift: D
2 → D3 ................................185
A/T Does Not Shift: D
3 → D4 ................................187
A/T Does Not Shift: D
4 → D5 ................................189
A/T Does Not Lock-up ..........................................191
A/T Does Not Hold Lock-up Condition ..................193
Lock-up Is Not Released ......................................194
Engine Speed Does Not Return to Idle ................195
Cannot Be Changed to Manual Mode ..................196
A/T Does Not Shift: 5th Gear → 4th Gear ............196
A/T Does Not Shift: 4th Gear → 3rd Gear ............198
A/T Does Not Shift: 3rd Gear → 2nd Gear ...........199
A/T Does Not Shift: 2nd Gear → 1st Gear ...........201
Vehicle Does Not Decelerate by Engine Brake ....202
SHIFT CONTROL SYSTEM ....................................204
Control Device Removal and Installation ..............204
Control Rod Removal and Installation ..................205
Adjustment of A/T Position ...................................206
Checking of A/T Position ......................................206
A/T SHIFT LOCK SYSTEM ....................................207
Description ............................................................207
Shift Lock System Electrical Parts Location .........207
Wiring Diagram — AT — SHIFT ...........................208
Diagnostic Procedure ...........................................209
KEY INTERLOCK CABLE ......................................212
Components .........................................................212
Removal and Installation ......................................213
ON-VEHICLE SERVICE ..........................................215
Control Valve with TCM and A/T Fluid Temperature
Sensor 2 ...............................................................215
Parking Components ............................................227
Rear Oil Seal ........................................................234
Revolution Sensor ................................................235
AIR BREATHER HOSE ..........................................241
Removal and Installation ......................................241
TRANSMISSION ASSEMBLY ................................242
Removal and Installation ......................................242
OVERHAUL ............................................................246
Components .........................................................246
Page 12 of 312
AT-12
A/T FLUID
Revision: 2006 November2007 350Z
A/T FLUIDPFP:KLE40
Changing A/T FluidNCS0001H
1. Warm up ATF.
2. Stop engine.
3. Loosen the level gauge bolt.
4. Drain ATF from drain plug and refill with new ATF. Always refill
same volume with drained ATF.
To replace the ATF, pour in new ATF at the A/T fluid charging
pipe with the engine idling and at the same time drain the old
ATF from the radiator cooler hose return side.
When the color of the ATF coming out is about the same as
the color of the new ATF, the replacement is complete. The
amount of new ATF to use should be 30 to 50% increase of
the stipulated amount.
CAUTION:
Use only Genuine NISSAN Matic J ATF. Do not mix with other ATF.
Using ATF other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and A/
T durability, and may damage the A/T, which is not covered by the NISSAN new vehicle limited
warranty.
When filling ATF, take care not to splash heat generating parts such as exhaust with ATF.
Do not reuse drain plug gasket.
5. Run engine at idle speed for 5 minutes.
6. Check A/T fluid level and condition. Refer to AT- 1 2 , "
Checking A/T Fluid" . If ATF is still dirty, repeat step 2.
through 5.
7. Install the removed A/T fluid level gauge in the A/T fluid charging pipe.
8. Tighten the level gauge bolt.
Checking A/T FluidNCS0001I
1. Warm up engine.
2. Check for A/T fluid leakage.
3. Loosen the level gauge bolt.
4. Before driving, A/T fluid level can be checked at A/T fluid tem-
peratures of 30 to 50°C (86 to 122°F) using “COLD” range on A/
T fluid level gauge as follows.
a. Park vehicle on level surface and set parking brake.
b. Start engine and move selector lever through each gear posi-
tion. Leave selector lever in “P” position.
c. Check A/T fluid level with engine idling.
d. Remove A/T fluid level gauge and wipe clean with lint-free
paper.
CAUTION:
When wiping away the A/T fluid level gauge, always use
lint-free paper, not a cloth one.ATF: Genuine NISSAN Matic J ATF
Fluid capacity:
10.3 (10-7/8 US qt, 9-1/8 lmp qt)
Drain plug:
: 34 N·m (3.5 kg-m, 25 ft-lb)
Level gauge bolt:
: 5.1 N·m (0.52 kg-m, 45 in-lb)
SCIA4896E
SCIA7120E
Page 29 of 312
A/T CONTROL SYSTEM
AT-29
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
TCM FunctionNCS0001M
The function of the TCM is to:
Receive input signals sent from various switches and sensors.
Determine required line pressure, shifting point, lock-up operation, and engine brake operation.
Send required output signals to the respective solenoids.
CONTROL SYSTEM OUTLINE
The A/T senses vehicle operating conditions through various sensors or signals. It always controls the opti-
mum shift position and reduces shifting and lock-up shocks.
CONTROL SYSTEM DIAGRAM
SENSORS (or SIGNALS)
TCM
ACTUATORS
PNP switch
Accelerator pedal position signal
Closed throttle position signal
Wide open throttle position signal
Engine speed signal
A/T fluid temperature sensor
Revolution sensor
Vehicle speed signal
Manual mode switch signal
Stop lamp switch signal
Turbine revolution sensor
ATF pressure switchShift control
Line pressure control
Lock-up control
Engine brake control
Timing control
Fail-safe control
Self-diagnosis
CONSULT-III communication line
Duet-EA control
CAN systemInput clutch solenoid valve
Direct clutch solenoid valve
Front brake solenoid valve
High and low reverse clutch
solenoid valve
Low coast brake solenoid valve
Torque converter clutch sole-
noid valve
Line pressure solenoid valve
A/T CHECK indicator lamp
Starter relay
Back-up lamp relay
SCIA8327E
Page 37 of 312
ON BOARD DIAGNOSTIC (OBD) SYSTEM
AT-37
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
ON BOARD DIAGNOSTIC (OBD) SYSTEMPFP:00028
IntroductionNCS0001U
The A/T system has two self-diagnostic systems.
The first is the emission-related on board diagnostic system (OBD-II) performed by the TCM in combination
with the ECM. The malfunction is indicated by the MIL (malfunction indicator lamp) and is stored as a DTC in
the ECM memory but not the TCM memory.
The second is the TCM original self-diagnosis indicated by the A/T CHECK indicator lamp. The malfunction is
stored in the TCM memory. The detected items are overlapped with OBD-II self-diagnostic items. For detail,
refer to AT- 8 6 , "
SELF-DIAGNOSTIC RESULT MODE" .
OBD-II Function for A/T SystemNCS0001V
The ECM provides emission-related on board diagnostic (OBD-II) functions for the A/T system. One function
is to receive a signal from the TCM used with OBD-related parts of the A/T system. The signal is sent to the
ECM when a malfunction occurs in the corresponding OBD-related part. The other function is to indicate a
diagnostic result by means of the MIL (malfunction indicator lamp) on the instrument panel. Sensors, switches
and solenoid valves are used as sensing elements.
The MIL automatically illuminates in “One or Two Trip Detection Logic” when a malfunction is sensed in rela-
tion to A/T system parts.
One or Two Trip Detection Logic of OBD-IINCS0001W
ONE TRIP DETECTION LOGIC
If a malfunction is sensed during the first test drive, the MIL will illuminate and the malfunction will be stored in
the ECM memory as a DTC. The TCM is not provided with such a memory function.
TWO TRIP DETECTION LOGIC
When a malfunction is sensed during the first test drive, it is stored in the ECM memory as a 1st trip DTC
(diagnostic trouble code) or 1st trip freeze frame data. At this point, the MIL will not illuminate. — 1st trip
If the same malfunction as that experienced during the first test drive is sensed during the second test drive,
the MIL will illuminate. — 2nd trip
The “Trip” in the “One or Two Trip Detection Logic” means a driving mode in which self-diagnosis is performed
during vehicle operation.
OBD-II Diagnostic Trouble Code (DTC)NCS0001X
HOW TO READ DTC AND 1ST TRIP DTC
DTC and 1st trip DTC can be read by the following methods.
( with CONSULT-III or GST) CONSULT-III or GST (Generic Scan Tool) Examples: P0705, P0720 etc.
These DTC are prescribed by SAE J2012.
(CONSULT-III also displays the malfunctioning component or system.)
1st trip DTC No. is the same as DTC No.
Output of the diagnostic trouble code indicates that the indicated circuit has a malfunction. How-
ever, in case of the Mode II and GST, they do not indicate whether the malfunction is still occurring
or occurred in the past and returned to normal.
CONSULT-III can identify them as shown below, therefore, CONSULT-III (if available) is recom-
mended.
Freeze Frame Data and 1st Trip Freeze Frame Data
The ECM has a memory function, which stores the driving condition such as fuel system status, calculated
load value, engine coolant temperature, short term fuel trim, long term fuel trim, engine speed and vehicle
speed at the moment the ECM detects a malfunction.
Data which are stored in the ECM memory, along with the 1st trip DTC, are called 1st trip freeze frame data,
and the data, stored together with the DTC data, are called freeze frame data and displayed on CONSULT-III
or GST. The 1st trip freeze frame data can only be displayed on the CONSULT-III screen, not on the GST. For
detail, refer to EC-116, "
CONSULT-III Function (ENGINE)" .
Only one set of freeze frame data (either 1st trip freeze frame data of freeze frame data) can be stored in the
ECM. 1st trip freeze frame data is stored in the ECM memory along with the 1st trip DTC. There is no priority
for 1st trip freeze frame data and it is updated each time a different 1st trip DTC is detected. However, once
freeze frame data (2nd trip detection/MIL on) is stored in the ECM memory, 1st trip freeze frame data is no
longer stored. Remember, only one set of freeze frame data can be stored in the ECM. The ECM has the fol-
lowing priorities to update the data.
Page 38 of 312
AT-38
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 November2007 350Z
Both 1st trip freeze frame data and freeze frame data (along with the DTC) are cleared when the ECM mem-
ory is erased.
HOW TO ERASE DTC
The diagnostic trouble code can be erased by CONSULT-III, GST or ECM DIAGNOSTIC TEST MODE as
described following.
If the battery cable is disconnected, the diagnostic trouble code will be lost within 24 hours.
When you erase the DTC, using CONSULT-III or GST is easier and quicker than switching the
mode selector on the ECM.
The following emission-related diagnostic information is cleared from the ECM memory when erasing DTC
related to OBD-II. For details, refer to EC-48, "
Emission-related Diagnostic Information" .
Diagnostic trouble codes (DTC)
1st trip diagnostic trouble codes (1st trip DTC)
Freeze frame data
1st trip freeze frame data
System readiness test (SRT) codes
Test values
HOW TO ERASE DTC (WITH CONSULT-III)
1. The emission related diagnostic information in the TCM and ECM can be erased by selecting “ALL Erase”
in the “Description” of “FINAL CHECK” mode with CONSULT-III.
HOW TO ERASE DTC (WITH GST)
1. If the ignition switch stays ON after repair work, be sure to turn ignition switch OFF once. Wait at least 10
seconds and then turn it ON (engine stopped) again.
2. Perform AT- 9 2 , "
OBD-II SELF-DIAGNOSTIC PROCEDURE (WITH GST)" . (The engine warm-up step
can be skipped when performing the diagnosis only to erase the DTC.)
3. Select Mode 4 with GST (Generic Scan Tool). For details, refer to EC-125, "
Generic Scan Tool (GST)
Function" .
HOW TO ERASE DTC (NO TOOLS)
The A/T CHECK indicator lamp is located on the instrument panel.
1. If the ignition switch stays ON after repair work, be sure to turn ignition switch OFF once. Wait at least 10
seconds and then turn it ON (engine stopped) again.
2. Perform AT- 9 2 , "
TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)" . (The engine warm-up step can
be skipped when performing the diagnosis only to erase the DTC.)
3. Perform “OBD-II SELF-DIAGNOSTIC PROCEDURE (No tools)”. Refer to EC-61, "
How to Erase DTC" .
Priority Items
1
Freeze frame dataMisfire — DTC: P0300 - P0306
Fuel Injection System Function — DTC: P0171, P0172, P0174, P0175
2 Except the above items (Includes A/T related items)
3 1st trip freeze frame data
Page 39 of 312
ON BOARD DIAGNOSTIC (OBD) SYSTEM
AT-39
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
Malfunction Indicator Lamp (MIL)NCS0001Y
DESCRIPTION
The MIL is located on the instrument panel.
1. The MIL will light up when the ignition switch is turned ON with-
out the engine running. This is a bulb check.
If the MIL does not light up, refer to DI-56, "WARNING LAMPS" ,
or see EC-716, "
MIL AND DATA LINK CONNECTOR" .
2. When the engine is started, the MIL should go off.
If the MIL remains on, the on board diagnostic system has
detected an engine system malfunction.
SEF217U
Page 42 of 312
AT-42
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
How to Perform Trouble Diagnosis for Quick and Accurate RepairNCS00021
INTRODUCTION
The TCM receives a signal from the vehicle speed sensor, accelera-
tor pedal position sensor (throttle position sensor) or PNP switch and
provides shift control or lock-up control via A/T solenoid valves.
The TCM also communicates with the ECM by means of a signal
sent from sensing elements used with the OBD-related parts of the
A/T system for malfunction-diagnostic purposes. The TCM is capa-
ble of diagnosing malfunctioning parts while the ECM can store mal-
functions in its memory.
Input and output signals must always be correct and stable in the
operation of the A/T system. The A/T system must be in good oper-
ating condition and be free of valve seizure, solenoid valve malfunc-
tion, etc.
It is much more difficult to diagnose a error that occurs intermittently
rather than continuously. Most intermittent errors are caused by poor
electric connections or improper wiring. In this case, careful check-
ing of suspected circuits may help prevent the replacement of good
parts.
A visual check only may not find the cause of the errors. A road test
with CONSULT-III (or GST) or a circuit tester connected should be
performed. Follow the AT- 4 3 , "
WORK FLOW" .
Before undertaking actual checks, take a few minutes to talk with a
customer who approaches with a driveability complaint. The cus-
tomer can supply good information about such errors, especially
intermittent ones. Find out what symptoms are present and under
what conditions they occur. A “DIAGNOSTIC WORKSHEET” as
shown on the example (Refer to AT- 4 4
) should be used.
Start your diagnosis by looking for “conventional” errors first. This will
help troubleshoot driveability errors on an electronically controlled
engine vehicle.
Also check related Service bulletins.
SAT631IB
SAT632I
SEF234G
Page 44 of 312
AT-44
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
DIAGNOSTIC WORKSHEET
Information from Customer
KEY POINTS
WHAT..... Vehicle & A/T model
WHEN..... Date, Frequencies
WHERE..... Road conditions
HOW..... Operating conditions, Symptoms
Diagnostic Worksheet Chart
Customer name MR/MS Model & Year VIN
Trans. Model Engine Mileage
Incident Date Manuf. Date In Service Date
Frequency❏ Continuous❏ Intermittent ( times a day)
Symptoms❏ Vehicle does not move. (❏ Any position❏ Particular position)
❏ No up-shift (❏ 1st → 2nd❏ 2nd → 3rd❏ 3rd → 4th ❏ 4th → 5th)
❏ No down-shift (❏ 5th → 4th ❏ 4th → 3rd❏ 3rd → 2nd❏ 2nd → 1st)
❏ Lock-up malfunction
❏ Shift point too high or too low.
❏ Shift shock or slip (❏ N → D❏ Lock-up❏ Any drive position)
❏ Noise or vibration
❏ No kick down
❏ No pattern select
❏ Others
()
A/T CHECK indicator lamp❏ Continuously lit❏ Not lit
Malfunction indicator lamp (MIL)❏ Continuously lit❏ Not lit
1❏ Read the item on cautions concerning fail-safe and understand the customer's complaint.AT- 4 0
2❏ A/T fluid inspectionAT- 4 9❏ Leak (Repair leak location.)
❏ State
❏ Amount
3❏ Stall test and line pressure testAT- 4 9
,
AT- 5 0
❏ Stall test
❏ Torque converter one-way clutch
❏ Front brake
❏ High and low reverse clutch
❏ Low coast brake
❏ Forward brake
❏ Reverse brake
❏ Forward one-way clutch❏ 1st one-way clutch
❏ 3rd one-way clutch
❏ Engine
❏ Line pressure low
❏ Except for input clutch and direct
clutch, clutches and brakes OK
❏ Line pressure inspection - Suspected part:
Page 45 of 312
TROUBLE DIAGNOSIS
AT-45
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
4❏ Perform all road tests and enter checks in required inspection items.AT- 5 2
4-1.Check before engine is started AT- 5 3
❏ AT- 1 7 2 , "A/T Check Indicator Lamp Does Not Come On"
❏ Perform self-diagnostics. Enter checks for detected items. AT- 8 6 , AT- 9 2
❏ AT-94, "DTC U1000 CAN COMMUNICATION LINE"
❏ AT-97, "DTC P0615 START SIGNAL CIRCUIT"
❏ AT-101, "DTC P0700 TCM"
❏ AT-102, "DTC P0705 PARK/NEUTRAL POSITION SWITCH"
❏ AT-106, "DTC P0717 TURBINE REVOLUTION SENSOR"
❏ AT-108, "DTC P0720 VEHICLE SPEED SENSOR A/T (REVOLUTION SENSOR)"
❏ AT-113, "DTC P0725 ENGINE SPEED SIGNAL"
❏ AT-115, "DTC P0731 A/T 1ST GEAR FUNCTION"
❏ AT-117, "DTC P0732 A/T 2ND GEAR FUNCTION"
❏ AT-119, "DTC P0733 A/T 3RD GEAR FUNCTION"
❏ AT-121, "DTC P0734 A/T 4TH GEAR FUNCTION"
❏ AT-123, "DTC P0735 A/T 5TH GEAR FUNCTION"
❏ AT-125, "DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE"
❏ AT-127, "DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)"
❏ AT-129, "DTC P0745 LINE PRESSURE SOLENOID VALVE"
❏ AT-131, "DTC P1705 THROTTLE POSITION SENSOR"
❏ AT-134, "DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT"
❏ AT-139, "DTC P1721 VEHICLE SPEED SENSOR MTR"
❏ AT-141, "DTC P1730 A/T INTERLOCK"
❏ AT-143, "DTC P1731 A/T 1ST ENGINE BRAKING"
❏ AT-145, "DTC P1752 INPUT CLUTCH SOLENOID VALVE"
❏ AT-147, "DTC P1757 FRONT BRAKE SOLENOID VALVE"
❏ AT-149, "DTC P1762 DIRECT CLUTCH SOLENOID VALVE"
❏ AT-151, "DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE"
❏ AT-153, "DTC P1772 LOW COAST BRAKE SOLENOID VALVE"
❏ AT-155, "DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTION"
❏ AT-157, "DTC P1815 MANUAL MODE SWITCH"
4-2.Check at IdleAT- 5 3
❏ AT- 1 7 3 , "Engine Cannot Be Started in “P” or “N” Position"
❏ AT- 1 7 3 , "In “P” Position, Vehicle Moves When Pushed"
❏ AT- 1 7 4 , "In “N” Position, Vehicle Moves"
❏ AT- 1 7 5 , "Large Shock (“N” to “D” Position)"
❏ AT- 1 7 7 , "Vehicle Does Not Creep Backward in “R” Position"
❏ AT- 1 7 9 , "Vehicle Does Not Creep Forward in “D” Position"
4-3.Cruise testAT- 5 5
Part 1
❏ AT- 1 8 1 , "
Vehicle Cannot Be Started from D1"
❏ AT- 1 8 3 , "A/T Does Not Shift: D1 → D2"
❏ AT- 1 8 5 , "A/T Does Not Shift: D2 → D3"
❏ AT- 1 8 7 , "A/T Does Not Shift: D3 → D4"
❏ AT- 1 8 9 , "A/T Does Not Shift: D4 → D5"
❏ AT- 1 9 1 , "A/T Does Not Lock-up"
❏ AT- 1 9 3 , "A/T Does Not Hold Lock-up Condition"
❏ AT- 1 9 4 , "Lock-up Is Not Released"
❏ AT- 1 9 5 , "Engine Speed Does Not Return to Idle"
