NOTE:

If a key fob is lost, the ID code of the lost key fob must be erased to prevent unauthorized use. A specific
ID code can be erased with CONSULT-III. However, when the ID code of a lost key fob is not known, all
controller ID codes should be erased. After all ID codes are erased, the ID codes of all remaining and/or
new key fobs must be re-registered.
To erase all ID codes in memory, register one ID code (key fob) five times. After all ID codes are erased,
the ID codes of all remaining and/or new key fobs must be re-registered.

When registering an additional key fob, the existing ID codes in memory may or may not be erased. If five
ID codes are stored in memory, when an additional code is registered, only the oldest code is erased. If
less than five ID codes are stored in memory, when an additional ID code is registered, the new ID code is
added and no ID codes are erased.

If you need to activate more than two additional new key fobs, repeat the procedure “Additional ID code
entry” for each new key fob.

Entry of maximum five ID codes is allowed. When more than five ID codes are entered, the oldest ID code
will be erased.

Even if same ID code that is already in the memory is input, the same ID code can be entered. The code
is counted as an additional code.
Key Fob Battery ReplacementNIS0001V
SEL411Y

BL-92
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2006 November2007 350Z
Removal and Installation of Remote Keyless Entry ReceiverNIS0001W
REMOVAL
1. Remove the instrument passenger panel lower. Refer to IP-13, "(L) Instrument Passenger Panel Lower" .
2. Remove the screw and remote keyless entry receiver connector.
3. Remove the remote keyless entry receiver.
INSTALLATION
Install in the reverse order of removal.
PIIB3798E

DOOR
BL-93
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
DOORPFP:80100
Fitting AdjustmentNIS0001X
COUPE
DOOR
Longitudinal clearance and surface height adjustment at front end
1. Remove the fender protector. Refer to EI-21, "FENDER PROTECTOR" .
2. Loosen the hinge mounting bolts. Raise the door at rear end to adjust.
STRIKER ADJUSTMENT
Adjust the striker so that it becomes parallel with the lock insertion
direction.
PIIA2334E
PIIB1226E

BL-94
DOOR
Revision: 2006 November2007 350Z
ROADSTER
DOOR
Longitudinal clearance and surface height adjustment at front end
1. Remove the fender protector. Refer to EI-21, "FENDER PROTECTOR" .
2. Loosen the hinge mounting bolts. Raise the door at rear end to adjust.
STRIKER ADJUSTMENT
Adjust the striker so that it becomes parallel with the lock insertion
direction.
PIIA7605E
PIIB1226E

DOOR
BL-95
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
DOVE TAIL FEMALE ADJUSTMENT (ROADSTER)
Adjust the dove tail female so that it becomes parallel with the lock
insertion direction.
Removal and InstallationNIS0001Y
CAUTION:

When removing and installing the door assembly, support the door with a jack and cloth to protect
the door and body.

When removing and installing door assembly, be sure to perform the fitting adjustment Refer to
BL-93, "
Fitting Adjustment" .

Operate with two workers, because of its heavy weight.

Check the hinge rotating part for poor lubrication. If necessary, apply “body grease”.

After installing, check operation.

Apply sealant and coat with the same body color paint to door hinge installation part and mount-
ing nuts.
REMOVAL
1. Pull the lever and remove the door harness connector while
removing tabs of door harness connector.
2. Remove the mounting bolts of the check link on the vehicle.
PIIA7608E
PIIA2514E
PIIA2515E

BL-96
DOOR
Revision: 2006 November2007 350Z
3. Remove the door-side hinge mounting nuts, and remove the
door assembly.
INSTALLATION
Install in the reverse order of removal.
Removal and Installation of Dove Tail Male & Female (Roadster)NIS0001Z
REMOVAL
1. Remove the TORX bolts (T30) of dove tail male.
2. Soft top assembly locate like a figure.
3. Remove the body side welt. Refer to EI-37, "
Removal and Instal-
lation (for Roadster Models)" .
4. Remove the body side weatherstrip. Refer to EI-32, "
Removal
and Installation (for Roadster Models)" .
5. Remove the rear side finisher and kicking plate inner. Refer to
EI-37, "
Removal and Installation (for Roadster Models)" .
6. Remove the shoulder anchor. Refer to SB-6, "
Removal and
Installation of Seat Belt (Roadster)" .
7. Remove the rear side trim. Refer to EI-37, "
Removal and Instal-
lation (for Roadster Models)" .
8. Remove the dove tail female mounting nuts. Remove the dove
tail female.
INSTALLATION
Install in the reverse order of removal.
PIIA2516E
PIIA7607E
PIIA7606E
PIIA7608E

DOOR
BL-97
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
Door WeatherstripNIS00020
REMOVAL
Remove the weatherstrip clips and remove weatherstrip.
INSTALLATION
Install in the reverse order of removal.
PIIA2335E

BL-98
DOOR LOCK
Revision: 2006 November2007 350Z
DOOR LOCKPFP:80502
Component StructureNIS00021
Inspection and AdjustmentNIS00022
1. Remove the door finisher. Refer to EI-33, "Removal and Installation" .
2. Remove the door window and door module assembly. Refer to GW-51, "
Removal and Installation" .
EXTERIOR HANDLE ROD ADJUSTMENT
Rotate the bushing to adjust so that the clearance between the bush-
ing and rod becomes as shown in the figure.
CAUTION:
Be careful not to make the clearance 0 mm (0 in) or the rod will
be pressed continuously.
Removal and InstallationNIS00023
REMOVAL
1. Remove the door finisher. Refer to EI-33, "Removal and Installation" .
2. Remove the door window and door module assembly. Refer to GW-51, "
Removal and Installation" .
3. Disconnect the inside handle cable and locking knob cable from
the back side of the door finisher.
1. Outside handle 2. Key cylinder (driver side only) 3. Key lock rod (driver side only)
4. Door lock assembly 5. Outside handle rod 6. Door lock actuator
7. Lock knob cable 8. Inside handle cable 9. Inside handle
10. Lock knob
PIIA2402E
PIIA2336E
PIIA2337E

DOOR LOCK
BL-99
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
4. Reach to separate the key cylinder (driver side only) rod and outside handle rod connection (on the han-
dle).
5. Disconnect the door lock actuator connector.
6. Remove the mounting screws (TORX T30), remove the door
lock assembly.
7. Remove the outside handle mounting bolts, remove the outside
handle.
INSTALLATION
Install in the reverse order of removal.
CAUTION:

To install each rod, be sure to rotate the rod holder until a click is felt.

After installing, check operation.

After installing, perform fitting adjustment. Refer to BL-93, "Fitting Adjustment" .
Disassembly and AssemblyNIS00024
DISASSEMBLY
CAUTION:
Be sure to remove or install the actuator with the door lock assembly removed.
1. Remove the mounting screws, and remove the actuator from the
door lock assembly.
2. Pull the actuator straight downward to separate it from the door
lock assembly.
ASSEMBLY
1. Align the actuator pivot with the cutout on the knob lever of the door lock assembly, then assemble the
actuator.
2. Move the knob lever and the actuator pivot toward the lock-on direction, and check that it engages
securely.
PIIA1090E
PIIA2401E
PIIA2525E

BL-100
BACK DOOR
Revision: 2006 November2007 350Z
BACK DOORPFP:90100
Fitting AdjustmentNIS00025
VERTICAL/LATERAL CLEARANCE ADJUSTMENT
1. Remove back door weatherstrip. Refer to BL-103, "Removal and Installation of Back Door Weatherstrip" .
2. Remove the luggage finisher lower (center). Refer to EI-40, "
LUGGAGE FLOOR TRIM" .
3. Loosen the back door lock mounting bolts. Raise the back door lock to the top position, and temporarily
tighten the back door lock mounting bolt at the position.
4. Close the back door lightly and adjust the surface height, then open the back door to finally tighten the
back door lock mounting bolts to the specified torque.
Back Door AssemblyNIS00026
REMOVAL
1. Remove the headlining. Refer to EI-44, "Removal and Installation (for Coupe Models)" .
2. Disconnect each harness connector, which is out to body from back door.
3. Support the back door striker with a proper material to prevent it
from falling.
WARNING:
Body injury may occur if no supporting rod is holding the
back door open when removing the damper stay.
PIIA2403E
PIIA3078E
