SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsNCS00012
Transmission modelFS6R31A
Number of speed6
Shift pattern
Synchromesh typeWarner
Gear ratio1st 3.794
2nd 2.324
3rd 1.624
4th 1.271
5th 1.000
6th 0.794
Reverse 3.446
Main gear
(Number of teeth)Drive 26
1st 37
2nd 34
3rd 33
4th 31
6th 31
Reverse 42
Counter gear
(Number of teeth)Drive 32
1st 12
2nd 18
3rd 25
4th 30
6th 48
Reverse 15
Reverse idler gear (Number of teeth)26
Oil capacity (Approx.)
(US pt, Imp pt)2.93 (6-1/4, 5-1/8)
RemarksReverse synchronizer Installed
Double cone synchronizer 4th
Triple cone synchronizer 1st, 2nd and 3rd
SCIA0955E

MT-62
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2006 November2007 350Z
End PlayNCS00013
Unit: mm (in)
Baulk Ring ClearanceNCS00016
Unit: mm (in) Item Standard value
Counter shaft0 - 0.10 (0 - 0.004)
Main drive gear0 - 0.10 (0 - 0.004)
Main shaft0 - 0.10 (0 - 0.004)
Measurement point Standard value Limit value
4th
(Double-cone synchronizer)Clearance between synchronizer cone
and inner baulk ring end face “A” 0.50 - 0.70 (0.020 - 0.028) 0.3 (0.012)
Clearance between outer baulk ring
pawl and synchronizer cone “B”0.85 - 1.35 (0.033 -0.053) 0.7 (0.028)
1st, 2nd and 3rd
(Triple-cone synchronizer)Clearance between synchronizer cone
and clutch gear end face “A”1st: 0.65 - 1.25 (0.026 - 0.049)
2nd: 0.60 - 1.30 (0.024 - 0.051)
3rd: 0.60 - 1.30 (0.024 - 0.051)0.3 (0.012)
0.3 (0.012)
0.3 (0.012)
Clearance between outer baulk ring
pawl and synchronizer cone “B”0.85 - 1.35 (0.033 - 0.053) 0.7 (0.028)
Clearance between inner baulk ring and
clutch gear end face “C”1st: 0.8 - 1.2 (0.031 - 0.047)
2nd: 0.75 - 1.25 (0.030 - 0.049)
3rd: 0.75 - 1.25 (0.030 - 0.049)0.3 (0.012)
0.3 (0.012)
0.3 (0.012)
5th and 6th0.70 - 1.35 (0.028 - 0.053) 0.5 (0.020)
Reverse0.75 - 1.20 (0.030 - 0.047) 0.5 (0.020)
PCIB0249E
