NISSAN 350Z 2007 Z33 Owners Manual
Manufacturer: NISSAN, Model Year: 2007, Model line: 350Z, Model: NISSAN 350Z 2007 Z33Pages: 311, PDF Size: 3.43 MB
Page 251 of 311
Check the fluid level in each cell. It should be
between the UPPER LEVEL
1
and LOWER
LEVEL
2lines.
If it is necessary to add fluid, add only distilled
water to bring the level to the indicator in each
filler opening.Do not overfill.
Vehicles operated in high temperatures or under
severe conditions require frequent checks of the
battery fluid level.
1. Remove the cell plugs
A.
2. Add distilled water up to the UPPER LEVEL
line
1.
3. Tighten cell plugs.
JUMP STARTINGIf jump starting is necessary, see “Jump starting”
in the “6. In case of emergency” section. If the
engine does not start by jump starting, the
battery may have to be replaced. Contact a
NISSAN dealer.1. Power steering fluid pump
2. Alternator
3. Crankshaft pulley
4. Air conditioner compressor
5. Drive belt auto-tensioner
WARNING
Be sure the ignition key is in the OFF or
LOCK position before servicing drive
belts. The engine could rotate
DI0137MA
SDI1480
SDI2061
DRIVE BELTS
8-16
Maintenance and do-it-yourself
06.10.24/Z33-D/V5.0
Page 252 of 311
unexpectedly.
1. Visually inspect each belt for signs of unusual
wear, cuts, fraying, oil adhesion or looseness.
If the belt is in poor condition or loose, have
it replaced or adjusted by a NISSAN dealer.
2. Have the belts checked regularly for condi-
tion.
REPLACING SPARK PLUGSIf replacement is required, see a NISSAN dealer
for servicing.
WARNING
Be sure the engine and ignition switch
are off and that the parking brake is
engaged securely.
CAUTION
Be sure to use the correct socket to
remove the spark plugs. An incorrect
socket can damage the spark plugs.
Iridium-tipped spark plugsIt is not necessary to replace the iridium-tipped
spark plugs as frequently as the conventional
type spark plugs since they will last much longer.
Follow the maintenance log shown in the
“NISSAN Service and Maintenance Guide”, but
do not service iridium-tipped spark plugs by
cleaning or regapping.
Always replace spark plugs with recom-
mended or equivalent ones.
SDI2020
SPARK PLUGS
Maintenance and do-it-yourself
8-17
06.10.24/Z33-D/V5.0
Page 253 of 311
To remove the filter from the air cleaner, pull off
the retainers
1
and pull the unit upward
2.
The filter element should not be cleaned and
reused. Replace it according to the maintenance
log shown in the “NISSAN Service and Mainte-
nance Guide”. When replacing the filter, wipethe inside of the air cleaner housing and the
cover with a damp cloth.
WARNING
Operating the engine with the air
cleaner removed can cause you or
others to be burned. The air cleaner
not only cleans the air, it stops the
flame if the engine backfires. If it is
not there, and the engine backfires,
you could be burned. Do not drive
with the air cleaner removed, and be
careful when working on the engine
with the air cleaner removed.
Never pour fuel into the throttle body
or attempt to start the engine with
the air cleaner removed. Doing so
could result in serious injury.
CAUTION
After wiper blade replacement, return
the wiper arm to its original position.
Otherwise it may be damaged when
the engine hood is opened.
Make sure the wiper blades contact
the glass; otherwise the arms may be
damaged from wind pressure.
Worn windshield wiper blades can
damage the windshield and impair
driver vision.CLEANINGIf your windshield is not clear after using the
windshield washer or if a wiper blade chatters
when running, wax or other material may be on
the blade or windshield.
Clean the outside of the windshield with a
washer solution or a mild detergent. Your wind-
shield is clean if beads do not form when rinsing
with clear water.
Clean the blade by wiping it with a cloth soaked
in a washer solution or a mild detergent. Then
SDI2054
AIR CLEANERS WINDSHIELD WIPER BLADES8-18
Maintenance and do-it-yourself
06.10.24/Z33-D/V5.0
Page 254 of 311
rinse the blade with clear water. If your wind-
shield is still not clear after cleaning the blades
and using the wiper, replace the blades.
REPLACINGReplace the wiper blades if they are worn.
1. Pull the wiper arm.
2. Push the release tab
A, then move the wiper
blade down the wiper arm to remove
1.
3. Insert the new wiper blade onto the wiper arm
until a click sounds.
SDI1649
Maintenance and do-it-yourself
8-19
06.10.24/Z33-D/V5.0
Page 255 of 311
If necessary, clean the windshield washer
nozzle
A
with a needle or small pin
B.
*1: Only for passenger’s side wiper arm
*2: Adjustable washer nozzlesIf the brakes do not operate properly, have the
brakes checked by a NISSAN dealer.
SELF-ADJUSTING BRAKESYour vehicle is equipped with self-adjusting
brakes.
The disc-type brakes self-adjust every time the
brake pedal is applied.
WARNING
See a NISSAN dealer for a brake system
check if the brake pedal height does not
return to normal.BRAKE PAD WEAR INDICATORSThe disc brake pads on your vehicle have au-
dible wear indicators. When a brake pad re-
quires replacement, it will make a high pitched
scraping or screeching sound when the vehicle
is in motion whether or not the brake pedal is
depressed. Have the brakes checked as soon as
possible if the wear indicator sound is heard.
Under some driving or climate conditions, occa-
sional brake squeak, squeal or other noise may
be heard. Occasional brake noise during light to
moderate stops is normal and does not affectthe function or performance of the brake system.
Proper brake inspection intervals should
be followed.For additional information, see the
appropriate maintenance log shown in the
NISSAN Service and Maintenance Guide.
SDI1730A
BRAKES
8-20
Maintenance and do-it-yourself
06.10.24/Z33-D/V5.0
Page 256 of 311
Some vehicles are equipped with engine com-
partment and passenger compartment fuse
boxes that use only type
A
fuses. Other ve-
hicles are equipped with typeA
fuses in the
engine compartment fuse box and type
Bfuses
in the passenger compartment fuse box.
Type
Afuses are provided as spare fuses. They
are stored in the passenger compartment fuse
box.
Type
A
fuses can be installed in the engine
compartment and passenger compartment fuse
boxes.If a type
A
fuse is used to replace a type
B
fuse, the type
A
fuse will not be level with the
fuse pocket as shown in the illustration. This will
not affect the performance of the fuse. Make
sure the fuse is installed in the fuse box securely.
Type
B
fuses cannot be installed in the under-
hood fuse boxes. Only use type
A
fuses in the
underhood fuse boxes.
ENGINE COMPARTMENT
CAUTION
Never use a fuse of a higher or lower
amperage rating than that specified on
the fuse box cover. This could damage
the electrical system or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition switch and headlight
switch are OFF.
SDI1751
SDI1752
SDI1479B
FUSES
Maintenance and do-it-yourself
8-21
06.10.24/Z33-D/V5.0
Page 257 of 311
2. Open the engine hood and remove the cover
on the battery and the fuse/fusible link holder.
3. Remove the fuse/fusible link holder cover by
pushing the tabs
1
and lifting the cover
2.
4. Remove the fuse with the fuse puller. The
fuse puller is located in the passenger com-
partment fuse box.
5. If the fuse is open
A, replace it with a new
fuse
B. Spare fuses are stored in the pas-
senger compartment fuse box.
6. If a new fuse also opens, have the electrical
system checked and repaired by a NISSAN
dealer.
Fusible linksIf any electrical equipment does not operate and
fuses are in good condition, check the fusible
links. If any of these fusible links are melted,
replace only with genuine NISSAN parts.
SDI1753
8-22
Maintenance and do-it-yourself
06.10.24/Z33-D/V5.0
Page 258 of 311
PASSENGER COMPARTMENT
CAUTION
Never use a fuse of a higher or lower
amperage rating than that specified on
the fuse box cover. This could damage
the electrical system or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition switch and the headlight
switch are OFF.2. Open the fuse box lid
1.
3. Pinch the fuse perpendicularly with the fuse
puller
2
and pull it out.4. If the fuse is open
A, replace it with a new
fuse
B. Spare fuses
3
are stored in the
fuse box.
5. If a new fuse also opens, have the electrical
system checked and repaired by a NISSAN
dealer.
SDI1962
SDI1754
Maintenance and do-it-yourself
8-23
06.10.24/Z33-D/V5.0
Page 259 of 311
Replace the battery as follows:
1. Open the lid using a suitable tool.
2. Replace the battery with a new one.
Recommended battery: CR2025 or equiva-
lentMake sure that the⊕side faces the
bottom case.
3. Close the lid securely.
4. Push the keyfobbutton two or three times to
check its operation.
See a NISSAN dealer if you need any assistance
for replacement.
If the battery is removed for any reason
other than replacement, perform step 4
above.
Be careful not to touch the circuit board
and the battery terminal.
An improperly disposed battery can
harm the environment. Always confirm
local regulations for battery disposal.
The keyfob is water-resistant; however,
if it gets wet, immediately wipe it com-
pletely dry.
When changing batteries, do not let
dust or oil get on the keyfob.
FCC Notice:
Changes or modifications not expressly
approved by the party responsible for com-
pliance could void the user’s authority to
operate the equipment.This device complies with Part 15 of the
FCC Rules and RSS-210 of Industry
Canada.
Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device
must accept any interference received, in-
cluding interference that may cause undes-
ired operation of the device.
SDI1608
KEYFOB BATTERY
REPLACEMENT8-24
Maintenance and do-it-yourself
06.10.24/Z33-D/V5.0
Page 260 of 311
1
Front view
1. Headlight (low-beam, high-beam)
2. Spot light
3. Front park light
4. Front turn signal light
5. Front side marker light2
Rear view (Coupe),
3
Rear view (Roadster)
6. Luggage compartment light (Coupe) or Trunk
light (Roadster)
7. High-mounted stop light
8. Rear combination light
(Side marker, Stop/Tail)
9. License plate lights
10. Rear combination light
(Back-up, Turn signal)
SDI2058
LIGHTS
Maintenance and do-it-yourself
8-25
06.10.24/Z33-D/V5.0
