NISSAN 350Z 2007 Z33 Power Supply, Ground And Circuit Service Manual HARNESS
PG-41
C
D
E
F
G
H
I
J
L
MA
B
PG
Revision: 2006 November2007 350Z
HARNESS PFP:00011
Harness Layout NKS000EG
HOW TO READ HARNESS LAYOUT
The following Harness Layouts use a map style grid to help

HARNESS
PG-41
C
D
E
F
G
H
I
J
L
MA
B
PG
Revision: 2006 November2007 350Z
HARNESS PFP:00011
Harness Layout NKS000EG
HOW TO READ HARNESS LAYOUT
The following Harness Layouts use a map style grid to help locate
connectors on the figures:
Main Harness
Engine Room Harness (Engine Compartment)
Engine Control Harness (Engine Compartment)
Body Harness
To Use the Grid Reference
1. Find the desired connector number on the connector list.
2. Find the grid reference.
3. On the figure, find the crossing of the grid reference letter column and number row.
4. Find the connector number in the crossing zone.
5. Follow the line (if used) to the connector.
CONNECTOR SYMBOL
Main symbols of connector (in Harness Layout) are indicated in the below.
SEL252V
CKIT0108E

Page 42 of 86

NISSAN 350Z 2007 Z33 Power Supply, Ground And Circuit Service Manual PG-42
HARNESS
Revision: 2006 November2007 350Z
OUTLINE
Coupe Models
Roadster Models
TKIT0885E
TKIT0886E

PG-42
HARNESS
Revision: 2006 November2007 350Z
OUTLINE
Coupe Models
Roadster Models
TKIT0885E
TKIT0886E

Page 43 of 86

NISSAN 350Z 2007 Z33 Power Supply, Ground And Circuit Service Manual HARNESS
PG-43
C
D
E
F
G
H
I
J
L
MA
B
PG
Revision: 2006 November2007 350Z
MAIN HARNESS
TKIT0887E

HARNESS
PG-43
C
D
E
F
G
H
I
J
L
MA
B
PG
Revision: 2006 November2007 350Z
MAIN HARNESS
TKIT0887E

Page 44 of 86

PG-44
HARNESS
Revision: 2006 November2007 350Z
TKIT0888E

Page 45 of 86

HARNESS
PG-45
C
D
E
F
G
H
I
J
L
MA
B
PG
Revision: 2006 November2007 350Z
TKIT0889E

Page 46 of 86

NISSAN 350Z 2007 Z33 Power Supply, Ground And Circuit Service Manual PG-46
HARNESS
Revision: 2006 November2007 350Z
ENGINE ROOM HARNESS
Engine Compartment
TKIT0890E

PG-46
HARNESS
Revision: 2006 November2007 350Z
ENGINE ROOM HARNESS
Engine Compartment
TKIT0890E

Page 47 of 86

HARNESS
PG-47
C
D
E
F
G
H
I
J
L
MA
B
PG
Revision: 2006 November2007 350Z
TKIT0891E

Page 48 of 86

NISSAN 350Z 2007 Z33 Power Supply, Ground And Circuit Service Manual PG-48
HARNESS
Revision: 2006 November2007 350Z
Passenger Compartment
TKIT0899E

PG-48
HARNESS
Revision: 2006 November2007 350Z
Passenger Compartment
TKIT0899E

Page 49 of 86

NISSAN 350Z 2007 Z33 Power Supply, Ground And Circuit Service Manual HARNESS
PG-49
C
D
E
F
G
H
I
J
L
MA
B
PG
Revision: 2006 November2007 350Z
Battery Cable
TKIT0892E

HARNESS
PG-49
C
D
E
F
G
H
I
J
L
MA
B
PG
Revision: 2006 November2007 350Z
Battery Cable
TKIT0892E

Page 50 of 86

NISSAN 350Z 2007 Z33 Power Supply, Ground And Circuit Service Manual PG-50
HARNESS
Revision: 2006 November2007 350Z
ENGINE CONTROL HARNESS
Engine Compartment
TKIT0893E

PG-50
HARNESS
Revision: 2006 November2007 350Z
ENGINE CONTROL HARNESS
Engine Compartment
TKIT0893E
