NISSAN ALTIMA HYBRID 2008 L32A / 4.G Dismantling Guide

11. Remove the outlet duct bolts (1), then remove the outlet
duct (2) from the HV battery (3).










12. Disconnect the HV battery blower motor connector (1)
from the HV battery blower (2).
13. Remove the HV battery blower motor harness clips and
HV battery blower motor harness from the HV battery.








14. Remove the lock (1) from the RH cover (6) on the HV
battery (7) using the service plug grip (2).
15. Remove the nuts (3), bolts (4) and ground wires (5) from
the RH cover (6).
16. Remove the RH cover (6) from the HV battery (7).







17. Remove the terminal cover and 12 volt terminal nut (1),
then remove the terminal cable (2) and 12 volt harness
from the HV battery.
18. Remove the battery shield contact (4), HV wire nuts (6)
and HV wires (5) from the HV battery.
- 21 -
rom
19. Disconnect the body harness connector (3) from the HV
battery.
20. Disconnect the EPS DC/DC converter connector (7) f
the HV battery.
21. Remove the harnesses from the HV battery.

22. Disconnect the electrical connectors (1) from the EPS
DC/DC converter (2).
23. Remove the harness clips and harness from the HV
battery.








24. Disconnect the vent hose (3) from the vehicle.
25. Remove the HV battery bolts (1) from the HV battery (2).
26. Remove the HV battery from the vehicle.










27. Remove the HV battery blower motor bolts (1) and duct
clips (2), then remove the HV battery blower motor (3)
and ducts (4) from the HV battery.









28. Remove the EPS DC/DC converter nuts (1), then
remove the EPS DC/DC converter (2) from the HV
battery (3).










Removal of HV Components

Dismantling the remainder of the Nissan Altima Hybrid may be performed like conventional Nissan vehicles
once the HV system is disabled.
