NISSAN ALTIMA HYBRID 2008 L32A / 4.G Dismantling Guide

Page 2 of 22

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Dismantling Guide
     - 2 -

Foreword........................................................................\
............................................................................. - 3 -
About the Nissan A

Page 3 of 22

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Dismantling Guide
Foreword

Nissan released the Altima Hybrid in North America in August of 2007. The Altima Hybrid runs on conventional
gasoline and a traction motor. The basic vehicle systems and features of the

Page 4 of 22

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Dismantling Guide
     - 4 -
About the Nissan Altima Hybrid

There are two power sources stored on board that are used to drive the vehicle:
•  Gasoline is stored in a fuel tank and is used to supply the gasolin

Page 5 of 22

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Dismantling Guide

Altima Hybrid Identification

In appearance, the Nissan Altima Hybrid is nearly identical to the conventional Nissan Altima.

VIN Location

The VIN can be located on either the front windshi

Page 6 of 22

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Dismantling Guide
Engine Compartment

The engine compartment of the Altima Hybrid houses an aluminum alloy 2.5 liter gasoline engine, the high
voltage harnesses, fuse/fusible link box, fuse block, inverter unit, tr

Page 7 of 22

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Dismantling Guide
Exterior

• A Hybrid logo is located on the right side of the trunk.












• A Hybrid logo is located on each front door above the
body side molding.










In

Page 8 of 22

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Dismantling Guide
Hybrid System

Component Location and Description
Component Location Description
1. Electric Air
Conditioning
Compressor
Engine compartment, front
passenger side
Motor driven electric air co

Page 9 of 22

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Dismantling Guide
Battery Information

The Altima Hybrid utilizes two batteries in order to supply both low and high voltage.

Low Voltage Battery

The Altima Hybrid contains a lead-acid 12 volt DC low voltage

Page 10 of 22

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Dismantling Guide
     - 10 -
Recovery/Recycling of the Ni-MH High Voltage Battery
The high voltage battery is recyclable. For information regarding recycling of the high voltage battery, contact
the nearest Nissan
