NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual https://www.carmanualsonline.info/img/5/221/w960_221-0.png NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual

Page 321 of 351

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual ENGINE SERIAL NUMBER
The number is stamped on the engine as shown.
F.M.V.S.S./C.M.V.S.S.
CERTIFICATION LABEL
The Federal/Canadian Motor Vehicle Safety
Standard (F.M.V.S.S./C.M.V.S.S.) certification la

Page 322 of 351

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual TIRE AND LOADING INFORMATION
LABEL
The cold tire pressure is shown on the Tire and
Loading Information label. The label is located as
shown.
AIR CONDITIONER SPECIFICATION
LABEL
The air conditioner spe

Page 323 of 351

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual Use the following steps to mount the front license
plate:
s1Make a shallow hole in each plastic finisher
at the location mark (small dimple) using a
0.31 in (8 mm) drill. To avoid damaging the
threads

Page 324 of 351

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual cGVW (Gross Vehicle Weight) - curb
weight plus the combined weight of
passengers and cargo.
cGVWR (Gross Vehicle Weight Rat-
ing) - maximum total combined
weight of the unloaded vehicle, pas-
sengers,

Page 325 of 351

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual Steps for determining correct load
limit
1. Locate the statement “The combined
weight of occupants and cargo
should never exceed XXX kg or XXX
lbs” on your vehicle’s placard.
2. Determine the co

Page 326 of 351

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual 5. Determine the combined weight of
luggage and cargo being loaded on
the vehicle. That weight may not
safely exceed the available cargo and
luggage load capacity calculated in
Step 4.
6. If your vehi

Page 327 of 351

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual WARNING
Overloading or improper loading of a
trailer and its cargo can adversely affect
vehicle handling, braking and perfor-
mance and may lead to accidents.
CAUTION
cDo not tow a trailer or haul a h

Page 328 of 351

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual Temperature conditions can also affect towing.
For example, towing a heavy trailer in high outside
temperatures on graded roads can affect engine
performance and cause overheating. The engine
protecti

Page 329 of 351

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual Towing capacities are calculated assuming a
base vehicle with driver and any options required
to achieve the rating. Additional passengers,
cargo and/or optional equipment, such as the
trailer hitch,

Page 330 of 351

NISSAN ALTIMA HYBRID 2008 L32A / 4.G Owners Manual TOWING LOAD/SPECIFICATION
TOWING LOAD / SPECIFICATION
UNIT: lb (kg)
MAXIMUM TOWING
LOAD1,000 (454)
MAXIMUM TONGUE
LOAD100 (45)
TOWING SAFETY
Trailer hitch
Choose a proper hitch for your vehicle and tr
