body.
The seat belts should be correctly worn
and the driver and passenger seated
upright as far as practical away from the
side air bags. The side air bags and
curtain air bags inflate quickly in order
to help protect occupants. Because of
this, the force of the side air bags and
curtain air bags inflating can increase the
risk of injury if the occupant is too close
to, or is against, these air bag modules
during inflation. In a rollover, the curtain
air bags on both sides are designed to
inflate. Under both side-impact situations,
the curtain air bags will remain inflated
for a short period of time.
The side air bags and curtain air bags
operate only when the ignition switch is
in the ON position.
After placing the ignition switch in the
ON position, the supplemental air bag
warning light illuminates. The air bag
warning light will turn off after about 7
seconds if the systems are operational.
WARNING
SEAT BELTS WITH PRETEN-
SIONERS (front seats)
WARNING
.The pretensioners cannot be re-
used after activation. They must
be replaced together with the
retractor and buckle as a unit.

.If the vehicle becomes involved in
a collision but the pretensioner is
not activated, it is recommended
to have the pretensioner system
checked and, if necessary, re-
placed by a GT-R certified NISSAN
dealer.
. No unauthorized changes should
be made to any components or
wiring of the pretensioners. This
is to prevent damage to or acci-
dental activation of the preten-
sioners. Tampering with the
pretensioner system may result
in serious personal injury.
. Work around and on the preten-
sioners should be done by a GT-R
certified NISSAN dealer. Installa-
tion of electrical equipment
should also be done by a GT-R
certified NISSAN dealer. Un-
authorized electrical test equip-
ment and probing devices should
not be used on the pretensioners.
. If you need to dispose of a pre-
tensioner or scrap the vehicle, it is
recommended you contact a
GT-R certified NISSAN dealer. In-
correct disposal procedures
could cause personal injury. The pretensioner system may activate
with the supplemental air bag system in
certain types of collisions. Working with
the seat belt retractor, it helps tighten the
seat belt when the vehicle becomes
involved in certain types of collisions,
helping to restrain front seat occupants.
The pretensioner is encased with the seat
belt retractor. These seat belts are used
the same way as conventional seat belts.
When a pretensioner activates, smoke is
released and a loud noise may be heard.
The smoke is not harmful, and it does not
indicate a fire. Care should be taken not
to inhale it as it may cause irritation and
choking. Those with a history of a breath-
ing condition should get fresh air
promptly.
After pretensioner activation, load limiters
allow the seat belt to release webbing (if
necessary) to reduce forces against the
chest.
The supplemental air bag warning light
“Supplemental air bag warning light”
page 1-48 for more details.) If the opera-
tion of the supplemental air bag warning
light indicates there is a malfunction, it is
recommended you have the system
checked by a GT-R certified NISSAN deal-
er. When selling your vehicle, we request that
you inform the buyer about the preten-
sioner system and guide the buyer to the
appropriate sections in this Owner’s Man-
ual.
Safety — Seats, seat belts and supplemental restraint system
1-47

SUPPLEMENTAL AIR BAG WARNING
LIGHTThe supplemental air bag warning light,
displaying
in the meter, monitors the
circuits for the air bag systems, preten-
sioners and all related wirings.
When the ignition switch is in the ON
position, the supplemental air bag warn-
ing light illuminates for about 7 seconds
and then turns off. This means the SRS air
bag systems are operational.
If any of the following conditions occur,
the air bag and/or pretensioner systems
need servicing:

.The supplemental air bag warning
light remains on after approximately
7 seconds.
. The supplemental air bag warning
light flashes intermittently.
. The supplemental air bag warning
light does not come on at all.
Under these conditions, the air bag and/
or pretensioner systems may not operate
properly. They must be checked and
repaired. It is recommended you take
your vehicle to the nearest GT-R certified
NISSAN dealer.
Safety — Seats, seat belts and supplemental restraint system
1-49

NOTICE
If the gauge indicates engine coolant
temperature near the hot (H) end of
the normal range, reduce vehicle
speed to decrease temperature. If
gauge is over the normal range, stop
the vehicle as soon as safely possi-
ble. If the engine is overheated,
continued operation of the vehicle
may seriously damage the engine.
(
“If your vehicle overheats” page
6-8)
FUEL GAUGEThe gauge indicates the approximate
fuel level in the tank.
The gauge may move slightly during
braking, turning, acceleration, or going
up or down hills.
The gauge needle returns to E (Empty)
after the ignition switch is pushed to the
LOCK position.
Refill the fuel tank before the gauge
registers “E” (Empty).
The low fuel warning will be indicated on
the vehicle information display when the
fuel tank is getting low. Refuel as soon as
it is convenient, preferably before the gauge reaches “E”. There will be a small
reserve of fuel in the tank when the fuel
gauge needle reaches “E”. (
“Low fuel
warning” page 2-43)
The
indicates that the fuel-filler door
is located on the passenger’s side of the
vehicle. (
“Fuel-filler door” page 3-24)
NOTE:
If the vehicle runs out of fuel, the
Malfunction Indicator Light (MIL) may
come on. Refuel as soon as possible.
After a few driving trips, the
light
should turn off. If the light remains on
after a few driving trips, it is recom-
mended you have the vehicle inspected
by a GT-R certified NISSAN dealer.
(
“Malfunction Indicator Light (MIL)”
page 2-32)
Instruments and controls
2-9

2. NEXT switch3. Vehicle information displayThe drive computer displays the following
information:
.Current fuel consumption
. Vehicle speed
. Cruise control
. Average fuel consumption and speed
. Elapsed time and trip computer
. Distance to empty
. Outside air temperature
. Setting .
Warning
The vehicle information display
can be
changed when the ignition switch is in
the ON position. Push the ENTER switch
to change the display.
NOTE:
. The cruise control display is shown if
cruise control is set. (
“Cruise
control” page 5-35)
. The warning display is not shown if
there are no conditions to warn the
driver.
. Depending on the driving conditions
and other factors, the displayed
values may differ from the actual
values.
. The position of the speedometer
needle and the speed shown in the
vehicle information display may
slightly differ.
CURRENT FUEL CONSUMPTIONThe current fuel economy is displayed
when driving.
DRIVE COMPUTER

All-Wheel Drive (AWD) warning light
Cruise main switch indicator light
Anti-lock Braking System (ABS) warn-
ing light
Cruise set switch indicator light
Charge warning light
Exterior light indicator
Engine oil pressure warning light
Intelligent Key warning light
Front passenger air bag status light
Seat belt warning light
Low tire pressure warning light
High beam indicator light
Supplemental air bag warning light
Malfunction Indicator Light (MIL)
Turn signal/hazard indicator lights
Master warning lightTransmission warning lightVehicle Dynamic Control (VDC) off
indicator lightVehicle Dynamic Control (VDC) warn-
ing light
CHECKING LIGHTSWith all doors closed, apply the parking
brake, fasten the seat belts and place the
ignition switch in the ON position without
starting the engine. The following lights (if
so equipped) will come on:
,
or
,
,
,
The following lights (if so equipped) willcome on briefly and then go off:
,
or
,
,
,
,
,
If any light does not come on or operates
in a way other than described, it may
indicate a burned-out bulb and/or a
system malfunction. It is recommended
you have the system checked by a GT-R
certified NISSAN dealer.
WARNING/INDICATOR LIGHTS (red)See
“Warning display” page 2-36 and
“Vehicle information display” page 2-
13.
Brake warning light
This light functions for both the parking
brake and the foot brake systems.
WARNING LIGHTS, INDICATOR
LIGHTS AND AUDIBLE REMINDERS

Parking brake indicator:
When the ignition switch is in the ON
position, the light comes on when the
parking brake is applied.
Low brake fluid warning light:
When the ignition switch is in the ON
position, the light warns of a low brake
fluid level. If the light comes on while the
engine is running with the parking brake
not applied, stop the vehicle and perform
the following:
1. Check the brake fluid level. Add brakefluid as necessary. (
“Brake fluid”
page 8-11)
2. If the brake fluid level is correct, it is recommended you have the warning
system checked by a GT-R certified
NISSAN dealer.
Anti-lock Braking System (ABS) warning
indicator:
When the parking brake is released and
the brake fluid level is sufficient, if both
the brake warning light and the Anti-lock
Braking System (ABS) warning light illu-
minate, it may indicate the ABS is not
functioning properly. It is recommended
you have the brake system checked, and
if necessary repaired, by a GT-R certified
NISSAN dealer promptly. (
“Anti-lock
Braking System (ABS) warning light” page 2-29)
Brake pad wear warning indicator
(models with NCCB (NISSAN Carbon
Ceramic Brake) package):
When the brake warning light illuminates,
it may indicate that there is brake pad
wear. Have the brake system checked
and brake pads replaced as soon as
possible. It is recommended you contact
a GT-R certified NISSAN dealer for this
service.
WARNING
.
Your brake system may not be
working properly if the warning
light is on. Driving could be dan-
gerous. If you judge it to be safe,
drive carefully to the nearest
service station for repairs. Other-
wise, have your vehicle towed because driving it could be dan-
gerous.
. Pressing the brake pedal with the
engine stopped and/or low brake
fluid level may increase your
stopping distance and braking
will require greater pedal effort
as well as pedal travel.
. If the brake fluid level is below the
minimum or MIN mark on the
brake fluid reservoir, do not drive
until the brake system has been
checked. It is recommended you
contact a GT-R certified NISSAN
dealer.
Charge warning light
If the light comes on while the engine is
running, it may indicate the charging
system is not functioning properly. Turn
the engine off and check the alternator
belt. If the belt is loose, broken, missing or
if the light remains on, it is recommended
you see a GT-R certified NISSAN dealer
immediately.
Instruments and controls
2-27

NOTICE
Do not continue driving if the alter-
nator belt is loose, broken or miss-
ing.
Engine oil pressure warning
light
This light warns of low engine oil pres-
sure. If the light flickers or comes on
during normal driving, pull off the road in
a safe area and stop the engine immedi-
ately. It is recommended you call a GT-R
certified NISSAN dealer.
The engine oil pressure warning light is
not designed to indicate a low oil level.
Check the vehicle information display or
use the dipstick to check the oil level.
(
“Engine oil level display” page 2-13)
(“Checking engine oil level” page 8-9)
NOTICE
Running the engine with the engine
oil pressure warning light on could
cause serious damage to the engine
almost immediately. Turn off the
engine as soon as it is safe to do so.
Seat belt warning light and
chime
The light and chime remind you to fasten
seat belts. The light illuminates whenever
the ignition switch is placed in the ON
position, and will remain illuminated until
the driver’s seat belt is fastened. At the
same time, the chime will sound for about
6 seconds unless the driver’s seat belt is
securely fastened.
The seat belt warning light for the front
passenger will illuminate if the seat belt is
not fastened when the front passenger’s
seat is occupied. For approximately 5
seconds after the ignition switch is placed
in the ON position, the system does not
activate the warning light for the front
passenger. (
“Seat belts” page 1-6)
“Supplemental re-
straint system” page 1-34)

WARNING/INDICATOR LIGHTS (yel-
low)See
“Warning display” page 2-36 and
“Vehicle information display” page 2-
13.
warning light comes on when the
ignition switch is pushed to ON. It turns
off soon after the engine is started.
If the AWD system malfunctions, the
warning light will either remain illumi-
nated or blink. (
“All-Wheel Drive
(AWD)” page 5-42)
“Tire and loading infor-
mation label” page 10-14)
If the tire pressure is insuffi-
cient, fill with nitrogen gas. It
is recommended you contact
a GT-R certified NISSAN dealer
about filling with nitrogen
gas. If nitrogen gas is not
available, compressed air
may be safely used under
normal driving conditions. However, NISSAN recom-
mends refilling with nitrogen
gas for maximum tire perfor-
mance.
. If the warning light is still on after
the above operations, have your
vehicle checked as soon as pos-
sible. It is recommended you have
the vehicle checked by a GT-R
certified NISSAN dealer.
or
Anti-lock Braking
System (ABS) warning light
When the ignition switch is in the ON
position, the Anti-lock Braking System
(ABS) warning light illuminates and then
turns off. This indicates the ABS is opera-
tional.
If the ABS warning light illuminates while
the engine is running, or while driving, it
may indicate the ABS is not functioning
properly. It is recommended you have the
system checked by a GT-R certified
NISSAN dealer.
If an ABS malfunction occurs, the anti-
lock function is turned off. The brake
system then operates normally, but with-
out anti-lock assistance. (
“Brake sys-
tem” page 5-52)
Instruments and controls
2-29
