CHECKING COOLANT LEVEL
Check the coolant levelin the reservoir when
the high voltage parts are cold. If the coolant
level is below the MIN level
*2, open the
reservoir cap and add coolant up to the MAX
level
*1. If the reservoir is empty, check the
coolant level in the coolant tank when the high
voltage parts are cold. If there is insufficient
coolant in the coolant tank, fill the coolant tank
with coolant up to the reservoir cap opening and
also add it to the reservoir up to the MAX level
*1.
Tighten the cap securely after adding coolant. If the cooling system frequently requires
coolant, have it checked by a NISSAN
certified LEAF dealer.
CHANGING COOLANT
Major cooling system repairs should be per-
formed by a NISSAN certified LEAF dealer. The
service procedures can be found in the appro-
priate NISSAN Service Manual.
Improper servicing can result in reduced
heater performance.

1. Remove the cell plugs*A.
2. Add distilled water up to the UPPER LEVEL
*1line.
If the side of the 12-volt battery is not clear,
check the distilled water level by looking
directly above the cell; the condition
*1indicates OK and the condition*2needs
more to be added.
3. Tighten cell plugs
*A.
Vehicles operated in high temperatures or under
severe conditions require frequent checks of the
12-volt battery fluid level.
JUMP STARTING
Jump starting provides power to the 12 volt
system to allow the electrical systems to
operate. The electrical systems must be operat-
ing to allow the Li-ion battery to be charged.
Jump starting does not charge the Li-ion battery.
The Li-ion battery must be charged before the
vehicle can be driven.
If jump starting is necessary, see “Jump starting”
in the “6. In case of emergency” section. If the
power switch does not switch to READY to drive
position by jump starting, the 12-volt battery
may have to be replaced. Contact a NISSAN
certified LEAF dealer.

7 Appearance and care
Cleaning exterior ...................................................................... 7-2Washing ................................................................................ 7-2
Waxing .................................................................................. 7-2
Removing spots .................................................................. 7-3Underbody ............................................................................ 7-3
Glass ..................................................................................... 7-3
Solar cell module (if so equipped) ................................ 7-3
Wheels .................................................................................. 7-3
Chrome parts ...................................................................... 7-4
Tire dressing ........................................................................ 7-4 Cleaning interior ...................................................................... 7-4
Air fresheners .................................................................... 7-5Floor mats .......................................................................... 7-5
Seat belts ........................................................................... 7-6
Electric Vehicle Supply Equipment (EVSE) .............. 7-6
Corrosion protection ............................................................... 7-7
Most common factors contributing to
vehicle corrosion .............................................................. 7-7
Environmental factors influence the rate
of corrosion ....................................................................... 7-7
To protect your vehicle from corrosion ...................... 7-7

Machine compound or aggressive polishing on a
base coat/clear coat paint finish may dull the
finish or leave swirl marks.
REMOVING SPOTS
Remove tar and oil spots, industrial dust,
insects, and tree sap as quickly as possible
from the paint surface to avoid lasting damage
or staining. Special cleaning products are
available at a NISSAN certified LEAF dealer or
any automotive accessory stores.
UNDERBODY
In areas where road salt is used in winter, the
underbody must be cleaned regularly. This will
prevent dirt and salt from building up and
causing the acceleration of corrosion on the
underbody and suspension. Before the winter
period and again in the spring, the underseal
must be checked and, if necessary, re-treated.
GLASS
Use glass cleaner to remove smoke and dust
film from the glass surfaces. It is normal for glass
to become coated with a film after the vehicle is
parked in the hot sun. Glass cleaner and a soft
cloth will easily remove this film.

wheel temperature should be the
same as ambient temperature.
. Rinse the wheel to completely re-
move the cleaner within 15 minutes
after the cleaner is applied.
CHROME PARTS
Clean chrome parts regularly with a non-
abrasive chrome polish to maintain the finish.
TIRE DRESSING
NISSAN does not recommend the use of tire
dressings. Tire manufacturers apply a coating to
the tires to help reduce discoloration of the
rubber. If a tire dressing is applied to the tires, it
may react with the coating and form a com-
pound. This compound may come off the tire
while driving and stain the vehicle paint.
If you choose to use a tire dressing, take the
following precautions:
. Use a water-based tire dressing. The coat-
ing on the tire dissolves more easily with an
oil-based tire dressing.
. Apply a light coat of tire dressing to help
prevent it from entering the tire tread/
grooves (where it would be difficult to
remove) . .
Wipe off excess tire dressing using a dry
towel. Make sure the tire dressing is
completely removed from the tire tread/
grooves.
. Allow the tire dressing to dry as recom-
mended by tire dressing manufacturer.
