.While the battery is being charged, the
Climate Ctrl. Timer cannot be operated until
the Li-ion battery available charge gauge
reached the full mark. When the battery is
not being charged, the Climate Ctrl. Timer
can be operated, even if the Li-ion battery
available charge gauge has not reached the
full mark.
. When the climate control is set on first
priority, the Climate Ctrl. Timer works
regardless of the remaining battery energy.
. If the Climate Ctrl. Timer starts its operation
while the vehicle is being charged, the
charging time will be prolonged.
. Operating the Climate Ctrl. Timer or remote
climate control in an environment with low
temperature may decrease the rate of
battery charge.
. The Climate Ctrl. Timer settings cannot be
modified while it is operating. If timer
settings are modified while the Climate Ctrl.
Timer is operating, these changes will be
reflected the next time the Climate Ctrl.
Timer operates.
. When charging is set as the first priority, the
Climate Ctrl. Timer does not start until 10
segments of the LI-ION BATTERY AVAIL-
ABLE CHARGE GAUGE are illuminated. .
When the climate control is set as the first
priority, the climate control system will be
turned on as scheduled by the Climate Ctrl.
Timer regardless of the remaining battery
energy.
. Even when the climate control is set as the
first priority, the climate control system will
be turned off when the climate control
spends more electric than the charging Li-
ion battery.
. The Li-ion battery may not charge or may
even become discharged if the Climate Ctrl.
Timer or remote climate control is used in
low ambient temperatures.
REMOTE CLIMATE CONTROL
This vehicle incorporates a communication
device that is called a TCU (Telematics Com-
munication Unit). The communication connec-
tion between this unit and NISSAN CARWINGS
Data Center allows for various remote function
services.
Even when away from the vehicle, climate
control can be started by accessing the
NISSAN CARWINGS Data Center website
using a cellular phone or a personal computer.
When operation is started, or at the set start
time, the NISSAN CARWINGS Data Center accesses the vehicle. When the vehicle receives
a command for remote operation, the climate
control immediately turns ON and operates for
the specified period of time. Confirmation of the
ON/OFF of the climate control operation can be
checked by accessing the website or by e-mail.
Establishing the CARWINGS
TMservice is ne-
cessary before using the service. See LEAF
Navigation System Owner’s Manual.

high enough to cause severe or
possibly fatal injuries to people or
animals.
NOTE:
. To check the Li-ion battery charging
status using an internet enabled smart
phone or personal computer.
—The vehicle must be located in a
cellular phone coverage area.
— The cellular phone must be located
in an area with cellular phone
coverage.
— The computer must be connected to
the internet.
. Some cellular phones are not compa-
tible with this system and cannot be
used to check the Li-ion battery char-
ging status. Confirm this beforehand.
Operating tips
.When the charge connector is connected,
the climate control operates using electric
power. When the charge connector is
disconnected from the vehicle, the climate
control operates using vehicle battery elec-
tric power. .
The climate control can be operated for a
maximum of 2 hours when the charge
connector is connected to the vehicle, or a
maximum of 15 minutes when the charge
connector is disconnected.
. The remote climate control will only start to
operate when the power switch is in the
OFF position. Be sure to check that the
power switch is in the OFF position.
. Remote climate control operation is not
available when the vehicle is in an area of
cellular communication range.
. Communication becomes unavailable when
the vehicle is not used for two weeks or
more. When the power switch is placed in
the ON position, communication with the
NISSAN CARWINGS Data Center can be
restored.
. Air conditioning is limited to the capacity of
the electric power when the charge con-
nector is connected to the vehicle. There-
fore, the temperature may not reach a
comfortable level due to performance of
the air conditioning being limited, if the
outside temperature is excessively high or
low, or if the charge connector is connected
to a 120V outlet. .
If the power switch is in the ON position or
the charge connector is disconnected, while
the remote climate control is being oper-
ated, remote climate control operation is
automatically stopped and an e-mail is sent.
. If remote climate control operation is started
while the vehicle is in normal charge mode,
the climate control operates in climate
control priority mode and charging is con-
tinued.
. If remote climate control operation is started
and charging is stopped while the vehicle is
in quick charge mode, climate control
operation is also stopped.
. If the quick charge connector is connected
and charging is not performed, remote
climate control operation starts using the
battery electric power of the vehicle.

10 Index
A
ABS (Anti-lock Braking System) ............................ 5-23
Advanced air bag system ......................................... 1-42
Air bag systemAdvanced air bag system .................................. 1-42
Front passenger air bag and status light....... 1-44
Front-seat mounted side-impact supplemental
air bag system....................................................... 1-47
Roof-mounted curtain side-impact
supplemental air bag system ............................ 1-47
Air bag warning labels............................................... 1-50
Air bag warning light...................................... 1-50, 2-18
Air conditioner Air conditioner specification label....................... 9-8
Air conditioning system refrigerant and
lubricant recommendations................................... 9-3
Alarm, How to stop alarm (see vehicle
security system)........................................................... 2-36
Alcohol, drugs and driving.......................................... 5-6
Anti-lock Braking System (ABS) ............................ 5-23
Anti-lock braking system (ABS) warning light..... 2-14
Appearance care Exterior appearance care ...................................... 7-2
Interior appearance care ....................................... 7-4
Audible reminders....................................................... 2-21
Autolight system.......................................................... 2-42
Automatic Door locks................................................................. 3-5
Automatic climate control ........................................... 4-6
Avoiding collision and rollover ................................... 5-5
B
Battery 12-volt battery....................................................... 8-11
Battery saver system........................................... 2-43
Intelligent Key battery.......................................... 8-18
Li-ion battery.......................................................... EV-2
Li-ion battery temperature gauge........................ 2-7
Before starting system............................................... 5-10
Booster seats............................................................... 1-33
Brake Anti-lock Braking System (ABS) ..................... 5-23
Brake fluid................................................................. 8-9
Brake system......................................................... 5-21
BRAKE system warning light (yellow) ............ 2-14
BRAKE warning light (red) ................................ 2-15
Brakes..................................................................... 8-15
Electric parking brake operation ...................... 5-15
BRAKE system warning light (yellow) ................... 2-14
BRAKE warning light (red) ....................................... 2-15
Bulb replacement........................................................ 8-20
C
Cabin air filter............................................................... 4-13
Capacities and recommended lubricants ............... 9-2
Cargo cover.................................................................. 2-51
Ceiling light................................................................... 2-57
Charging Charge port lid...................................................... 3-17
Charging related indicator light.................... CH-26
Charging timer .................................................. CH-19
Cleaning .................................................................... 7-6
Normal charge ..................................................... CH-9
Precautions on charging ................................... CH-2 Quick charge..................................................... CH-16
Specifications........................................................... 9-4
Tricklle charge................................................... CH-11
Charging methods .................................................. CH-19
Charging related indicator light........................... CH-26
Charging related remote function....................... CH-25
Charging status indicator light ............................ CH-26
Charging timer ......................................................... CH-19
Charging troubleshooting guide.......................... CH-30
Checking Checking bulbs..................................................... 2-13
Checking coolant level .......................................... 8-8
Child restraints............................................................. 1-19 Booster seats........................................................ 1-33
Precautions on child restraints......................... 1-19
Top tether strap.................................................... 1-22
Child safety................................................................... 1-17
Child safety rear door lock ......................................... 3-6
Circuit breaker, Fusible link...................................... 8-17
Cleaning exterior and interior............................ 7-2, 7-4
Climate control Climate control service....................................... 4-14
Climate control system refrigerant and
lubricant recommendations................................ 4-14
In-cabin microfilter ............................................... 4-13
Climate control system Climate control operation...................................... 4-3
Climate Ctrl. Timer........................................................ 4-7
Clock.............................................................................. 2-11
Cockpit ............................................................................ 2-3
Cold weather driving.................................................. 5-26
Console box ................................................................. 2-51
Coolant Capacities and recommended lubricants ......... 9-2
Changing coolant.................................................... 8-8

Checking coolant level .......................................... 8-8
Cooling system.............................................................. 8-7
Corrosion protection .................................................... 7-7
Cruise control............................................................... 5-17
Cup holders.................................................................. 2-49
D
Defroster switch, Rear window and outside mirror
defroster switch........................................................... 2-40
Dimensions and weights............................................. 9-5
Dot matrix liquid crystal display............................... 2-22
Driving Cold weather driving........................................... 5-26
Driving vehicle....................................................... 5-11
Precautions when starting and driving .............. 5-2
Driving range.................................................................. 2-8
Driving vehicle.............................................................. 5-11
E
ECO indicator.............................................................. 2-10
Efficient use of your vehicle ................................. EV-22
Electric parking brake break-in................................ 5-23
Electric parking brake indicator light...................... 2-19
Electric power steering system ............................... 5-21
Emergency charge.................................................. CH-11
Emergency EV (Electric Vehicle) shut off...... 5-9, 6-2
Emergency shutoff system........................................ EV-9
Emission control information label............................ 9-7
EV Characteristics ..................................................... EV-9
EV system ..................................................................... EV-2
EV unique information............................................. EV-24
Event Data Recorder (EDR)..................................... 9-18
EVSE (Electric Vehicle Supply Equipment) ..... CH-11
EVSE (Electric Vehicle Supply
Equipment) cleaning..................................................... 7-6
F
F.M.V.S.S./C.M.V.S.S. certification label ................. 9-7
Flashers (See hazard warning flasher switch)..... 2-45
Flat tire............................................................................. 6-2
Flat towing .................................................................... 9-14
Floor mat cleaning ........................................................ 7-5
Fluid Brake fluid................................................................. 8-9
Capacities and recommended lubricants ......... 9-2
coolant ....................................................................... 8-7
Reduction gear fluid............................................... 8-9
Window washer fluid .......................................... 8-10
Fog light switch........................................................... 2-44
Front manual seat adjustment.................................... 1-3
Front passenger air bag and status light.............. 1-44
Front seat, Front seat adjustment............................. 1-3
Fuses.............................................................................. 8-16
Fusible links.................................................................. 8-17
G
Garage door open, HomeLink®Universal
Transceiver............................................................. 2-58
Gauge .............................................................................. 2-5 Driving range............................................................ 2-8
ECO indicator....................................................... 2-10
Li-ion battery available charge gauge................ 2-9
Li-ion battery capacity level gauge.................. 2-10
Li-ion battery temperature gauge........................ 2-7
Odometer.................................................................. 2-6
Power meter ............................................................. 2-7
Speedometer............................................................ 2-6
General maintenance ................................................... 8-2
Glove box...................................................................... 2-51
H
Hazard warning flasher switch................................. 2-45
Head restraints .............................................................. 1-4
Headlights Bulb replacement................................................. 8-21
Headlight Aiming Control ................................. 2-44
Headlight switch................................................... 2-41
Heated seats................................................................ 2-46
Heated steering wheel............................................... 2-45
High voltage precautions .......................................... EV-7
HomeLink
®universal transceiver............................. 2-58
Hood release................................................................ 3-16
Horn................................................................................ 2-46
How to normal charge.............................................. CH-9
How to quick charge.............................................. CH-16
How to trickle charge ............................................ CH-11
I
If the Li-ion battery becomes
completely discharged............................................... 6-12
Immediate charge.................................................... CH-24
Immobilizer system...................................................... 2-36
In-cabin microfilter ...................................................... 4-13
indicator Electric parking brake indicator light............... 2-19
Indicator lights.............................................................. 2-19
Indicators for operation.............................................. 2-23
Inside rearview mirror................................................. 3-20
Instrument brightness control .................................. 2-41
Instrument panel............................................................ 2-4
Intelligent Key system ......................................... 3-6, 5-7 Key operating range ............................................... 3-8
Key operation ........................................................ 3-10
Remote keyless operation.................................. 3-13

Parking brake mechanically release ....................... 6-16
PowerElectric power steering system ........................ 5-21
Power door lock...................................................... 3-4
Power windows .................................................... 2-53
Power economy........................................................... 5-19
Power meter ................................................................... 2-7
Power outlet ................................................................. 2-48
Power switch......................................................... 5-7, 5-8
Precautions Braking precautions............................................. 5-21
Charging................................................................ CH-2
Child restraints...................................................... 1-19
Cruise control........................................................ 5-17
High voltage precautions ................................... EV-7
Maintenance ............................................................. 8-4
Road accident precautions................................ EV-8
Seat belt usage .................................................... 1-10
Supplemental restraint system.......................... 1-36
When starting and driving .................................... 5-2
Push starting ................................................................ 6-12
Q
Quick charge............................................................ CH-16
R
Rapid air pressure loss................................................ 5-5
Rear center seat belt ................................................. 1-16
Rear door lock, Child safety rear door lock........... 3-6
Rear hatch..................................................................... 3-17
Rear seats....................................................................... 1-4
Rear window and outside mirror
defroster switch........................................................... 2-40
Rear window wiper and washer switch ............... 2-39
Reduction gear fluid..................................................... 8-9 Remote charge ........................................................ CH-25
Remote climate control.............................................. 4-11
Remote keyless entry function, For Intelligent
Key system.................................................................... 3-13
Repairing flat tire........................................................... 6-3
Repairing tire.................................................................. 6-5
Reporting safety defects........................................... 9-15
Road accident precautions....................................... EV-8
Roadside assistance program ................................... 6-2
Rollover............................................................................ 5-5
S
Safety Child seat belts .................................................... 1-17
Reporting safety defects.................................... 9-15
Scene guide At home after driving......................................... EV-21
Before driving your vehicle .............................. EV-13
Charging the Li-ion battery.............................. EV-10
Driving the vehicle.............................................. EV-17
Parking the vehicle............................................. EV-20
Starting your vehicle.......................................... EV-16
Seat adjustment Front manual seat adjustment.............................. 1-3
Front seats................................................................ 1-3
Seat belt(s) Child safety............................................................ 1-17
Infants...................................................................... 1-17
Injured persons..................................................... 1-12
Larger children...................................................... 1-18
Precautions on seat belt usage........................ 1-10
Pregnant women .................................................. 1-12
Rear center seat belt .......................................... 1-16
Seat belt cleaning................................................... 7-6
Seat belt extenders.............................................. 1-16
Seat belt hooks .................................................... 1-15 Seat belt maintenance........................................ 1-16
Seat belt warning light........................................ 2-18
Seat belts............................................................... 1-10
Seat belts with pretensioners........................... 1-49
Shoulder belt height adjustment...................... 1-15
Small children........................................................ 1-18
Three-point type................................................... 1-12
Seat(s) , Seats................................................................ 1-2 Heated seats......................................................... 2-46
Security system (NISSAN Vehicle Immobilizer
System) , EV system start.......................................... 2-36
Servicing climate control........................................... 4-14
Shifting Electric shift control system .............................. 5-11
Shoulder belt height adjustment, For
front seats..................................................................... 1-15
Soft bottle holders...................................................... 2-50
Solar cell module .......................................................... 7-3
Speedometer.................................................................. 2-6
Starting .......................................................................... 5-11 Before starting system........................................ 5-10
Jump starting............................................................ 6-9
Precautions when starting and driving .............. 5-2
Push starting ......................................................... 6-12
Status light, Front passenger air bag .................... 1-44
Steering Electric power steering system ........................ 5-21
Heated steering wheel........................................ 2-45
Tilting steering column........................................ 3-19
Stopping the vehicle .................................................... 6-4
Storage .......................................................................... 2-49
Stowing golf bags....................................................... 2-53
Sun visors ..................................................................... 3-20
Supplemental air bag warning labels..................... 1-50
Supplemental air bag warning light............ 1-50, 2-18
Supplemental restraint system................................. 1-36

10 Index
A
ABS (Anti-lock Braking System) ............................ 5-23
Advanced air bag system ......................................... 1-42
Air bag systemAdvanced air bag system .................................. 1-42
Front passenger air bag and status light....... 1-44
Front-seat mounted side-impact supplemental
air bag system....................................................... 1-47
Roof-mounted curtain side-impact
supplemental air bag system ............................ 1-47
Air bag warning labels............................................... 1-50
Air bag warning light...................................... 1-50, 2-18
Air conditioner Air conditioner specification label....................... 9-8
Air conditioning system refrigerant and
lubricant recommendations................................... 9-3
Alarm, How to stop alarm (see vehicle
security system)........................................................... 2-36
Alcohol, drugs and driving.......................................... 5-6
Anti-lock Braking System (ABS) ............................ 5-23
Anti-lock braking system (ABS) warning light..... 2-14
Appearance care Exterior appearance care ...................................... 7-2
Interior appearance care ....................................... 7-4
Audible reminders....................................................... 2-21
Autolight system.......................................................... 2-42
Automatic Door locks................................................................. 3-5
Automatic climate control ........................................... 4-6
Avoiding collision and rollover ................................... 5-5
B
Battery 12-volt battery....................................................... 8-11
Battery saver system........................................... 2-43
Intelligent Key battery.......................................... 8-18
Li-ion battery.......................................................... EV-2
Li-ion battery temperature gauge........................ 2-7
Before starting system............................................... 5-10
Booster seats............................................................... 1-33
Brake Anti-lock Braking System (ABS) ..................... 5-23
Brake fluid................................................................. 8-9
Brake system......................................................... 5-21
BRAKE system warning light (yellow) ............ 2-14
BRAKE warning light (red) ................................ 2-15
Brakes..................................................................... 8-15
Electric parking brake operation ...................... 5-15
BRAKE system warning light (yellow) ................... 2-14
BRAKE warning light (red) ....................................... 2-15
Bulb replacement........................................................ 8-20
C
Cabin air filter............................................................... 4-13
Capacities and recommended lubricants ............... 9-2
Cargo cover.................................................................. 2-51
Ceiling light................................................................... 2-57
Charging Charge port lid...................................................... 3-17
Charging related indicator light.................... CH-26
Charging timer .................................................. CH-19
Cleaning .................................................................... 7-6
Normal charge ..................................................... CH-9
Precautions on charging ................................... CH-2 Quick charge..................................................... CH-16
Specifications........................................................... 9-4
Tricklle charge................................................... CH-11
Charging methods .................................................. CH-19
Charging related indicator light........................... CH-26
Charging related remote function....................... CH-25
Charging status indicator light ............................ CH-26
Charging timer ......................................................... CH-19
Charging troubleshooting guide.......................... CH-30
Checking Checking bulbs..................................................... 2-13
Checking coolant level .......................................... 8-8
Child restraints............................................................. 1-19 Booster seats........................................................ 1-33
Precautions on child restraints......................... 1-19
Top tether strap.................................................... 1-22
Child safety................................................................... 1-17
Child safety rear door lock ......................................... 3-6
Circuit breaker, Fusible link...................................... 8-17
Cleaning exterior and interior............................ 7-2, 7-4
Climate control Climate control service....................................... 4-14
Climate control system refrigerant and
lubricant recommendations................................ 4-14
In-cabin microfilter ............................................... 4-13
Climate control system Climate control operation...................................... 4-3
Climate Ctrl. Timer........................................................ 4-7
Clock.............................................................................. 2-11
Cockpit ............................................................................ 2-3
Cold weather driving.................................................. 5-26
Console box ................................................................. 2-51
Coolant Capacities and recommended lubricants ......... 9-2
Changing coolant.................................................... 8-8

Checking coolant level .......................................... 8-8
Cooling system.............................................................. 8-7
Corrosion protection .................................................... 7-7
Cruise control............................................................... 5-17
Cup holders.................................................................. 2-49
D
Defroster switch, Rear window and outside mirror
defroster switch........................................................... 2-40
Dimensions and weights............................................. 9-5
Dot matrix liquid crystal display............................... 2-22
Driving Cold weather driving........................................... 5-26
Driving vehicle....................................................... 5-11
Precautions when starting and driving .............. 5-2
Driving range.................................................................. 2-8
Driving vehicle.............................................................. 5-11
E
ECO indicator.............................................................. 2-10
Efficient use of your vehicle ................................. EV-22
Electric parking brake break-in................................ 5-23
Electric parking brake indicator light...................... 2-19
Electric power steering system ............................... 5-21
Emergency charge.................................................. CH-11
Emergency EV (Electric Vehicle) shut off...... 5-9, 6-2
Emergency shutoff system........................................ EV-9
Emission control information label............................ 9-7
EV Characteristics ..................................................... EV-9
EV system ..................................................................... EV-2
EV unique information............................................. EV-24
Event Data Recorder (EDR)..................................... 9-18
EVSE (Electric Vehicle Supply Equipment) ..... CH-11
EVSE (Electric Vehicle Supply
Equipment) cleaning..................................................... 7-6
F
F.M.V.S.S./C.M.V.S.S. certification label ................. 9-7
Flashers (See hazard warning flasher switch)..... 2-45
Flat tire............................................................................. 6-2
Flat towing .................................................................... 9-14
Floor mat cleaning ........................................................ 7-5
Fluid Brake fluid................................................................. 8-9
Capacities and recommended lubricants ......... 9-2
coolant ....................................................................... 8-7
Reduction gear fluid............................................... 8-9
Window washer fluid .......................................... 8-10
Fog light switch........................................................... 2-44
Front manual seat adjustment.................................... 1-3
Front passenger air bag and status light.............. 1-44
Front seat, Front seat adjustment............................. 1-3
Fuses.............................................................................. 8-16
Fusible links.................................................................. 8-17
G
Garage door open, HomeLink®Universal
Transceiver............................................................. 2-58
Gauge .............................................................................. 2-5 Driving range............................................................ 2-8
ECO indicator....................................................... 2-10
Li-ion battery available charge gauge................ 2-9
Li-ion battery capacity level gauge.................. 2-10
Li-ion battery temperature gauge........................ 2-7
Odometer.................................................................. 2-6
Power meter ............................................................. 2-7
Speedometer............................................................ 2-6
General maintenance ................................................... 8-2
Glove box...................................................................... 2-51
H
Hazard warning flasher switch................................. 2-45
Head restraints .............................................................. 1-4
Headlights Bulb replacement................................................. 8-21
Headlight Aiming Control ................................. 2-44
Headlight switch................................................... 2-41
Heated seats................................................................ 2-46
Heated steering wheel............................................... 2-45
High voltage precautions .......................................... EV-7
HomeLink
®universal transceiver............................. 2-58
Hood release................................................................ 3-16
Horn................................................................................ 2-46
How to normal charge.............................................. CH-9
How to quick charge.............................................. CH-16
How to trickle charge ............................................ CH-11
I
If the Li-ion battery becomes
completely discharged............................................... 6-12
Immediate charge.................................................... CH-24
Immobilizer system...................................................... 2-36
In-cabin microfilter ...................................................... 4-13
indicator Electric parking brake indicator light............... 2-19
Indicator lights.............................................................. 2-19
Indicators for operation.............................................. 2-23
Inside rearview mirror................................................. 3-20
Instrument brightness control .................................. 2-41
Instrument panel............................................................ 2-4
Intelligent Key system ......................................... 3-6, 5-7 Key operating range ............................................... 3-8
Key operation ........................................................ 3-10
Remote keyless operation.................................. 3-13

Parking brake mechanically release ....................... 6-16
PowerElectric power steering system ........................ 5-21
Power door lock...................................................... 3-4
Power windows .................................................... 2-53
Power economy........................................................... 5-19
Power meter ................................................................... 2-7
Power outlet ................................................................. 2-48
Power switch......................................................... 5-7, 5-8
Precautions Braking precautions............................................. 5-21
Charging................................................................ CH-2
Child restraints...................................................... 1-19
Cruise control........................................................ 5-17
High voltage precautions ................................... EV-7
Maintenance ............................................................. 8-4
Road accident precautions................................ EV-8
Seat belt usage .................................................... 1-10
Supplemental restraint system.......................... 1-36
When starting and driving .................................... 5-2
Push starting ................................................................ 6-12
Q
Quick charge............................................................ CH-16
R
Rapid air pressure loss................................................ 5-5
Rear center seat belt ................................................. 1-16
Rear door lock, Child safety rear door lock........... 3-6
Rear hatch..................................................................... 3-17
Rear seats....................................................................... 1-4
Rear window and outside mirror
defroster switch........................................................... 2-40
Rear window wiper and washer switch ............... 2-39
Reduction gear fluid..................................................... 8-9 Remote charge ........................................................ CH-25
Remote climate control.............................................. 4-11
Remote keyless entry function, For Intelligent
Key system.................................................................... 3-13
Repairing flat tire........................................................... 6-3
Repairing tire.................................................................. 6-5
Reporting safety defects........................................... 9-15
Road accident precautions....................................... EV-8
Roadside assistance program ................................... 6-2
Rollover............................................................................ 5-5
S
Safety Child seat belts .................................................... 1-17
Reporting safety defects.................................... 9-15
Scene guide At home after driving......................................... EV-21
Before driving your vehicle .............................. EV-13
Charging the Li-ion battery.............................. EV-10
Driving the vehicle.............................................. EV-17
Parking the vehicle............................................. EV-20
Starting your vehicle.......................................... EV-16
Seat adjustment Front manual seat adjustment.............................. 1-3
Front seats................................................................ 1-3
Seat belt(s) Child safety............................................................ 1-17
Infants...................................................................... 1-17
Injured persons..................................................... 1-12
Larger children...................................................... 1-18
Precautions on seat belt usage........................ 1-10
Pregnant women .................................................. 1-12
Rear center seat belt .......................................... 1-16
Seat belt cleaning................................................... 7-6
Seat belt extenders.............................................. 1-16
Seat belt hooks .................................................... 1-15 Seat belt maintenance........................................ 1-16
Seat belt warning light........................................ 2-18
Seat belts............................................................... 1-10
Seat belts with pretensioners........................... 1-49
Shoulder belt height adjustment...................... 1-15
Small children........................................................ 1-18
Three-point type................................................... 1-12
Seat(s) , Seats................................................................ 1-2 Heated seats......................................................... 2-46
Security system (NISSAN Vehicle Immobilizer
System) , EV system start.......................................... 2-36
Servicing climate control........................................... 4-14
Shifting Electric shift control system .............................. 5-11
Shoulder belt height adjustment, For
front seats..................................................................... 1-15
Soft bottle holders...................................................... 2-50
Solar cell module .......................................................... 7-3
Speedometer.................................................................. 2-6
Starting .......................................................................... 5-11 Before starting system........................................ 5-10
Jump starting............................................................ 6-9
Precautions when starting and driving .............. 5-2
Push starting ......................................................... 6-12
Status light, Front passenger air bag .................... 1-44
Steering Electric power steering system ........................ 5-21
Heated steering wheel........................................ 2-45
Tilting steering column........................................ 3-19
Stopping the vehicle .................................................... 6-4
Storage .......................................................................... 2-49
Stowing golf bags....................................................... 2-53
Sun visors ..................................................................... 3-20
Supplemental air bag warning labels..................... 1-50
Supplemental air bag warning light............ 1-50, 2-18
Supplemental restraint system................................. 1-36

CAUTION
.Be sure to carry the Intelligent Key
with you when operating the vehi-
cle.
. Never leave the Intelligent Key in
the vehicle when you leave the
vehicle.
The Intelligent Key is always communicating with
the vehicle because it receives radio waves. The
Intelligent Key system transmits weak radio
waves. Environmental conditions may interfere
with the operation of the Intelligent Key system
under the following operating conditions.
. When operating near a location where
strong radio waves are transmitted, such
as a TV tower, power station or broad-
casting station.
. When in possession of wireless equipment,
such as a cellular phone, transceiver or CB
radio.
. When the Intelligent Key is in contact with or
covered by metallic materials.
. When any type of radio wave remote control
is used nearby. .
When the Intelligent Key is placed near an
electric appliance such as a personal
computer.
. When the vehicle is parked near a parking
meter.
In such cases, correct the operating conditions
before using the Intelligent Key function or use
the mechanical key.
Although the life of the battery varies depending
on the operating conditions, the battery’s life is
approximately 2 years. If the battery is dis-
charged, replace it with a new one.
When the Intelligent Key battery is almost
discharged, firmly apply the foot brake and
touch the power switch with the Intelligent Key.
Then push the power switch while depressing
the brake pedal within 10 seconds after the
chime sound.
Since the Intelligent Key is continuously receiv-
ing radio waves, if the key is left near equipment
that transmits strong radio waves, such as
signals from a TV or personal computer, the
battery life may become shorter.
For information regarding replacement of a
battery, see “Intelligent Key battery replacement”
in the “8. Maintenance and do-it-yourself”
section. Pay special attention that the vehicle battery is
not completely discharged.
As many as 4 Intelligent Keys can be registered
and used with one vehicle. For information about
the purchase and use of additional Intelligent
Keys, contact a NISSAN certified LEAF dealer.

CHARGING THE 12-VOLT BATTERY
The 12-volt battery is charged automatically
using electricity stored in the Li-ion battery.
When the 12-volt battery is being charged, the
charge status indicator light on the instrument
panel flashes. (except when charging the Li-ion
battery or the power switch is in the READY to
drive position.) See “Charging status indicator
lights” in the “CH. Charging” section.
While vehicle is in use
The Li-ion battery charges the 12-volt battery as
necessary when the power switch is in the
READY to drive position or ON position.
The 12-volt battery is not charged in the
following conditions.
.When the power switch is in ACC position.
. When the power switch is in ON position
and shift position is in the N (Neutal)
position.
While the vehicle is not in use
When the EV (Electric Vehicle) system is off for
an extended time, the 12-volt battery may be
automatically charged for a short period of time
on a regular basis.
LI-ION BATTERY HEATER
CAUTION
The Li-ion battery heater does not
operate if the available Li-ion battery
charge is less than approximately 30%
and the charger is not connected to the
vehicle. To help prevent the Li-ion
battery from freezing, do not leave the
vehicle in an environment if tempera-
tures may go below -48F (-208C) unless
the vehicle is connected to a charger.
The Li-ion battery heater helps to prevent the Li-
ion battery from freezing and helps to prevent
significant reductions in the Li-ion battery output
when the temperature is cold. The Li-ion battery
heater automatically turns on when the Li-ion
battery temperature is approximately -48 F
(-208C) or colder. The Li-ion battery heater
automatically turns off when the Li-ion battery
temperture is approximately 148F (-108C) or
higher.
The Li-ion battery heater uses electrical power
from an external source when a charger is
connected to the vehicle. The Li-ion battery
heater uses electrical power from the Li-ion
battery when the charger is not connected to the vehicle.
NOTE:
.
Connect the charger to the vehicle and
place the power switch in the OFF
position when parking the vehicle if
temperatures may go below -48 F
(-208C) . This provides external power
to the Li-ion battery heater when it
operates and does not discharge the
Li-ion battery.
. The charging status indicator lights
illuminate in a specific pattern when
the Li-ion battery heater operates. The
charging status indicator lights use the
same pattern to indicate 12-volt battery
charging, Climate Ctrl. Timer operation
or Remote Climate Control operation.
The charging status indicator lights do
not change if the Li-ion battery heater
operates at the same time as the above
features. See “Charging status indica-
tor lights” in the “CH. Charging” sec-
tion.
. The Li-ion battery heater uses Li-ion
battery power to operate, even if the
vehicle is connected to a charger when:
EV OverviewEV-5
