NISSAN MAXIMA 1996 A32 / 4.G Owners Manual
Manufacturer: NISSAN, Model Year: 1996, Model line: MAXIMA, Model: NISSAN MAXIMA 1996 A32 / 4.GPages: 197, PDF Size: 1.53 MB
Page 111 of 197

If you have a flat tire, follow the instructions
below.
Stopping the vehicle
1. Safely move the vehicle off the road away
from traffic.
2. Turn on the hazard warning flashers.
3. Park on a level surface and apply the
parking brake. Shift the manual transmis-
sion into reverse (automatic transmission in
ªPº).
4. Turn off the engine.
IMake sure that the parking brake is
securely applied and the manual
transmission is shifted into reverse
(automatic transmission in ªPº).
INever change tires when the vehicle
is on a slope, ice or slippery areas.
This is dangerous.
INever change tires if oncoming traffic
is close to your vehicle. Wait for pro-
fessional road assistance.
IRaise the hood to warn other traffic,and to signal professional road assis-
tance personnel that you need assis-
tance.
IHave all passengers get out of the
vehicle and stand in a safe place,
away from traffic and clear of the
vehicle.
Getting the spare tire and tools
Remove jacking tools and spare tire from the
storage area located inside the trunk as illus-
trated.
SCE0036
FLAT TIRE
5-2
Z01.2.1/A32-DX
Page 112 of 197

Blocking wheels
Place suitable blocks at both the front and
back of the wheel diagonally opposite the flat
tire to prevent the vehicle from rolling when it is
jacked up.
Be sure to block the wheel as the vehicle
may move and could cause personal
injury.
Removing wheel caps
Do not use your hands to pry off wheel
caps. Doing so could result in personal
injury.
SCE0037
MCE0001SCE0053
5-3
Z01.2.1/A32-DX
Page 113 of 197

Jacking up and removing tire
To help avoid personal injury, carefully
read the caution label attached to the jack
body and the following instructions.
1. Place the jack directly under the jack-up
point as illustrated above so that top of the
jack contacts the vehicle at the jack up
point. Align the jack head between the two
notches in the front or the rear as shown.
Also fit the groove of the jack head between
the notches as shown.The jack should be used on level firm
ground.
2. Loosen each wheel nut one or two turns by
turning counterclockwise with the wheel nut
wrench.Do not remove the wheel nuts
until the tire is off the ground.
3. Carefully raise the vehicle until the tire
clears the ground. Remove the wheel nuts,
and then remove the tire.INever get under the vehicle while it is
supported only by the jack.
IUse only the jack provided with your
vehicle. Do not use the jack provided
with your vehicle on other vehicles.
The jack is designed only for lifting
your vehicle during a tire change.
ITo lift the vehicle, securely hold the
jack lever and rod with both hands as
shown above.
CE1089CE1092
5-4
Z01.2.1/A32-DX
Page 114 of 197

IUse the correct jack up points; never
use any other part of the vehicle for
jack support.
INever jack up the vehicle more than
necessary.
INever use blocks on or under the
jack.
IDo not start or run engine while ve-
hicle is on the jack.
IDo not allow passengers to stay in
the vehicle while it is on the jack.
IDo not raise the vehicle using a
bumper jack.
Installing wheel
The T-type spare tire is designed for emer-
gency use. See specific instructions under
the heading ªWheel and tireº in the ªDo-it-
yourself operationsº section.
1. Clean any mud or dirt from the surface
between the wheel and hub.
2. Carefully put the wheel on and tighten the
wheel nuts finger tight.
3. With the wheel nut wrench, tighten wheel
nuts alternately and evenly until they are
tight.4. Lower the vehicle slowly until the tire
touches the ground. Then, with the wheel
nut wrench, tighten the wheel nuts securely
in the sequence as illustrated.
IAs soon as possible tighten the wheel nuts
to the specified torque with a torque
wrench.
Wheel nut tightening torque:
72 to 87 ft-lb
(98 to 118 )
IAdjust tire pressure to the COLD pres-
sure.
COLD pressure:
After vehicle has been parked for three
hours or more or driven less than 1 mile
(1.6 km).
COLD tire pressures are shown on the tire
placard affixed to the center console lid.
IRetighten the wheel nuts when the ve-
hicle has been run for 600 miles (1,000
km) after installing the aluminum wheel.
SCE0039
5-5
Z01.2.1/A32-DX
Page 115 of 197

5. Securely store the spare tire and jacking
equipment in the vehicle.
IAlways make sure that the spare tire and
jacking equipment are properly secured
after use. Such items can become dan-
gerous projectiles in an accident or sud-
den stop.
IThe T-type spare tire and small size
spare tire are designed for emergency
use. See specific instructions under the
heading ªWheel and tireº in the ªDo-it-
yourself operationsº section.To start your engine with a booster battery, the
instructions and precautions below must be
followed.
IIf done incorrectly, jump starting can
be hazardous.
IExplosive hydrogen gas is always
present in the vicinity of the battery.
Keep all sparks and flames away from
the battery.
IDo not allow battery fluid to come
into contact with eyes, skin, cloth or
painted surfaces. Battery fluid is a
corrosive sulphuric acid solution
which can cause severe burns. If the
fluid should come into contact with
anything, immediately flush the con-
tacted area with water.
IA battery rated at above 12 volts
should not be used for a booster.
IWhenever working on or near a bat-
tery, always wear suitable eye protec-
tors (e.g., goggles or industrial safety
spectacles) and remove rings, metal
bands, or any other metal jewelry.IKeep battery out of the reach of
children.
SCE0040
JUMP STARTING
5-6
Z01.2.1/A32-DX
Page 116 of 197

Always follow the instructions below. Fail-
ure to do so could result in damage to the
charging system and cause personal in-
jury.
1. If the booster battery is in another vehicle,
position the two vehicles to bring their bat-
teries into close proximity to each other.
Do not allow the two vehicles to touch.
2. Apply parking brake. Move the shift lever to
ªNeutralº (On automatic transmission mod-
els, move the lever to ªPº). Switch off all
unnecessary electrical systems (light,
heater, air conditioner, etc.).3. Remove vent caps on the battery (if so
equipped). Cover the battery with an old
cloth to reduce explosion hazard.
4. Connect jumper cables in the sequence as
illustrated.
IAlways connect positive (+) to posi-
tive (+) and negative (þ) to body
ground (e.g., strut mounting bolt, etc.
Ð not to the battery).
IMake sure that cables do not touch
moving parts in the engine compart-
ment and that clamps do not contact
any other metal.
5. Start the engine of the other vehicle and let
it run for a few minutes.
6. Keep the engine speed of the other vehicle
at about 2,000 rpm, and start your engine in
the normal manner.
Do not keep starter motor engaged for
more than 10 seconds. If the enginedoes not start right away, turn the key
off and wait 3 to 4 seconds before trying
again.
7. After starting your engine, carefully discon-
nect the negative cable and then the posi-
tive cable.
8. Replace the vent caps (if so equipped). Be
sure to dispose of the cloth used to cover
the vent holes as it may be contaminated
with corrosive acid.
CE1005-A
5-7
Z01.2.1/A32-DX
Page 117 of 197

IAutomatic transmission models can-
not be push started. This may cause
transmission damage.
IThree-way catalyst equipped models
should not be started by pushing
since the three-way catalyst may be
damaged.
INever try to start the vehicle by tow-
ing it; when the engine starts, the
forward surge could cause the ve-
hicle to collide with the tow vehicle.
If your vehicle is overheating (indicated by an
extremely high temperature gauge reading), or
if you feel a lack of engine power, detect
abnormal noise, etc., take the following steps:
To avoid the danger of being scalded,
never remove the radiator cap while the
engine is still hot. When the radiator cap
is removed, pressurized hot water will
spurt out, possibly causing serious
injury.
1. Move the vehicle safely off the road, apply
the parking brake and move the gearshift
lever to neutral (automatic transmission to
ªPº).
Do not stop the engine.
2. Turn off the air conditioner switch. Open all
the windows, move the heater or air condi-
tioner temperature control to ªmaximum
hotº and fan control to ªhigh speedº.
3. Get out of the vehicle. Look and listen for
steam or coolant escaping from the radiator
before opening the hood. Wait until no
steam or coolant can be seen before pro-
ceeding.4. Open the engine hood.
If steam or water is coming from the
engine, stand clear to prevent getting
burned.
5. If engine overheating is caused by climbing
a long hill on a hot day, run the engine at a
fast idle (approximately 1,500 rpm) until the
temperature gauge indication returns to
normal.
6. Visually check drive belts for damage or
looseness. Also check if the cooling fan is
running. The radiator hoses and radiator
should not leak water.
Be careful not to allow your hands, hair
or clothing to come into contact with, or
to get caught in, the running fan, belts,
or motor fan.
The fan motor can start at any time when
the coolant temperature is high.
If coolant is leaking, the cooling fan belt
PUSH STARTING IF YOUR VEHICLE OVERHEATS
5-8
Z01.2.1/A32-DX
Page 118 of 197

is missing or loose, or the cooling fan
does not run, stop the engine.
7. After the engine cools down, check the
coolant level in the reservoir tank with the
engine running. Add coolant to the reservoir
tank if necessary. Have your vehicle re-
paired at the nearest NISSAN dealer.When towing your vehicle, all State (Provincial
in Canada) and local regulations for towing
must be followed. Incorrect towing equipment
could damage your vehicle. Towing instruc-
tions are available from your NISSAN dealer.
Local service operators will generally be famil-
iar with the applicable laws and procedures for
towing. To assure proper towing and to pre-
vent accidental damage to your vehicle, NIS-
SAN recommends that you have a service
operator tow your vehicle. It is advisable to
have the service operator carefully read the
following precautions.
IWhen towing, make sure that the
transmission, axles, steering system
and power train are in working condi-
tion. If any unit is damaged, a dolly
must be used.
IWhen towing with the front wheels on
the ground:
Turn the ignition key to the ªOFFº
position and secure the steering
wheel in a straight-ahead position
with a rope or similar device. Never
place the ignition key in the ªLOCKºposition. This will result in damage to
the steering lock mechanism.
Move the gearshift lever to the neutral
(ªNº position).
On automatic transmission models,
to move the shift lever to the Neutral
position, turn the ignition key to the
ªOFFº or ªACCº position. After mov-
ing the shift lever to the Neutral posi-
tion, be sure to turn the ignition key
to the ªOFFº position.
IWhen towing with the rear wheels on
the ground, release the parking
brake.
On automatic transmission models,
to move the shift lever to the Neutral
(ªNº position), turn the ignition key to
the ªOFFº or ªACCº position. After
moving the shift lever to the Neutral
position, be sure to turn the ignition
key to the ªOFFº position.
IAttach safety chains for all towing.
TOW TRUCK TOWING
5-9
Z01.2.1/A32-DX
Page 119 of 197

NISSAN recommends that your vehicle be
towed with the driving (front) wheels off the
ground as illustrated.
ISpeed: Below 70MPH (115 km/h)
IDistance: Less than 500 miles (800 km)Towing an automatic transmission
model with rear wheels raised (with
front wheels on the ground)
Never tow an automatic transmission
model with the rear wheels raised (with
the front wheels on the ground)as this
may cause serious and expensive damage
to the transmission. If it is necessary to tow
the vehicle with the rear wheels raised,
always use a towing dolly under the frontwheels.
If you have to tow an automatic
transmission model with four wheels
on ground
Observe the following restricted towing speeds
and distances.
ISpeed: Below 30 MPH (50 km/h)
IDistance: Less than 40 miles (65 km)
Never tow an automatic transmission
model from the rear (i.e., backward) with
four wheels on the ground as this may
cause serious and expensive damage to
the transmission.
VEHICLE RECOVERY (Freeing a
stuck vehicle)
ITow chains or cables must be attached only
to the main structural members of the ve-
hicle.
IPulling devices should be routed so they do
not touch any part of the suspension, steer-
CE1051CE1052
5-10
Z01.2.1/A32-DX
Page 120 of 197

ing, brake or cooling systems.
IAlways pull the cable straight out from the
front or rear of the vehicle. Never pull on the
vehicle at a sideways angle.
IPulling devices such as ropes or canvas
straps are not recommended for use in
vehicle towing or recovery.
5-11
Z01.2.1/A32-DX
