After the child restraint is removed and the
seat belt is allowed to wind back into the
retractor, the automatic locking mode (child
restraint mode) is canceled; the seat belt may
be used as normal and will only lock during a
sudden stop or impact.
Top strap child restraint
If your child restraint has a top strap, install the
anchor bracket to the provided anchor point.
The top strap anchor bracket is available
through your NISSAN dealer.
Part No. 88894-89900
Secure the child restraint with the center lap
belt or the lap portion of an outboard 3-point
belt and latch the top strap hook onto the
appropriate anchor bracket. To install the an-
chor bracket, a metric bolt of the dimensions
listed below must be used.
Bolt diameter: 8.0 mmBolt length: more than 1.18 in (30 mm)
Thread pitch: 1.25 mm
The top strap should be secured to the attach-
ing bolt which provides the straightest installa-
tion of the top strap.
Child restraint anchor points are de-
signed to withstand only those loads
imposed by correctly fitted child re-
straints. Under no circumstances are
they to be used for adult seat belts or
harnesses.
APD0107
2-35
Z01.2.1/A32-DX

9 Technical and consumer information
Capacities and recommended
fuel/lubricants ............................................................ 9-2
Engine ....................................................................... 9-8
Wheels and tires ....................................................... 9-9
Dimensions and weights ........................................... 9-9
When traveling or registering your
vehicle in another country ....................................... 9-10
Vehicle identification ............................................... 9-10
Installing license plate ............................................. 9-12
Vehicle loading information ..................................... 9-13
Trailer towing ........................................................... 9-14
Uniform tire quality grading ..................................... 9-18
Emission control system warranty .......................... 9-19
Reporting safety defects (For U.S.A.) ..................... 9-19
Readiness for inspection/maintenance
(I/M) test (For U.S.A.) ............................................. 9-19
Z01.2.1/A32-DX

Road wheelSteel 15 x 6JJ
Offset in (mm) 1.57 (40)
Aluminum15 x 6.5JJ
16 x 6.5JJ
Offset in (mm) 1.77 (45)
Tire sizeConventionalP205/65R15 92S
P205/65R15 92H
P215/55R16 91H
SpareConventional*1
T125/70D16*2
T125/90D16*2, *3
*1: For CANADA
*2: For U.S.A.
*3: For models with Viscous LSD
Sedan
Overall length in (mm) 189.4 (4,810)
Overall width in (mm) 69.7 (1,770)
Overall height in (mm) 55.7 (1,415)
Front tread in (mm)60.2 (1,530)*1
59.8 (1,520)*2
Rear tread in (mm)59.4 (1,510)*1
59.1 (1,500)*2
Wheelbase in (mm) 106.3 (2,700)
Gross vehicle weight rating lb (kg)
See the ªF.M.V.S.S. certifica-
tion labelº on the driver's
side lock pillar. Gross axle weight rating
Front lb (kg)
Rear lb (kg)
*1: For models with steel wheels
*2: For models with aluminum wheels
WHEELS AND TIRES DIMENSIONS AND WEIGHTS
9-9
Z01.2.1/A32-DX

10 Index
A
Air bag system (See ªSupplemental restraint
systemº) .......................................................... 2-17
Air bag warning light (See ªSupplemental air bag
warning lightº) ................................................. 2-22
Air cleaner filter ............................................... 7-17
Air conditioner
Air conditioner operation ............................. 3-5
Air conditioner specification label.............. 9-12
Automatic air conditioner (If so equipped) .. 3-9
Air conditioning system refrigerant and lubricant
recommendations ............................................. 9-6
Air flow chart ..................................................... 3-6
Antenna........................................................... 3-28
Anti-lock brake system (ABS) (If so equipped) .. 4-
18
Audio main operation ...................................... 3-23
Automatic
Automatic air conditioner (If so equipped) .. 3-9
Automatic transmission fluid ..................... 7-10
Driving with automatic transmission............ 4-7
Avoiding collision and rollover .......................... 4-3
B
Battery............................................................. 7-13
Battery replacement.......................................... 2-7
Before starting the engine ................................ 4-6Brake
Anti-lock brake system (ABS) (If so
equipped)................................................... 4-18
Brake and clutch fluid................................ 7-12
Brake booster ............................................ 7-21
Brake pedal ............................................... 7-20
Brake system............................................. 4-17
Brake wear indicators ........................ 1-9, 7-20
Parking brake ................................... 4-12, 7-19
Break-in schedule ........................................... 4-15
C
Capacities and recommended fuel/lubricants... 9-2
Cargo (See ªVehicle loading
information) ..................................................... 9-13
Cassette tape player operation....................... 3-25
CB radio or car phone .................................... 3-29
Changing
Changing engine coolant ............................ 7-6
Changing engine oil .................................... 7-8
Changing oil filter ........................................ 7-9
Checking engine coolant level .......................... 7-5
Checking engine oil level .................................. 7-7
Child restraints for infants and small children .... 2-
31
Child safety rear door lock................................ 2-3
Cigarette lighter and ash trays ....................... 1-17
Cleaning exterior and interior ........................... 6-2
Clearing the programming information ........... 1-26Clock ............................................................... 1-22
Clutch pedal .................................................... 7-21
Cold weather driving ....................................... 4-19
Compact disc (CD) player operation .............. 3-26
Controls............................................................. 3-3
Coolant
Changing engine coolant ............................ 7-6
Checking engine coolant level .................... 7-5
Engine coolant temperature gauge ............. 1-4
Corrosion protection ......................................... 6-5
Cruise control.................................................. 4-13
Cup holder ...................................................... 1-19
D
Defogger switch
Rear window and outside mirror defogger
switch......................................................... 1-13
Dimensions and weights ................................... 9-9
Door lock operation .......................................... 2-6
Door locks ......................................................... 2-2
Door unlock operation ...................................... 2-6
Drinking alcohol/drugs and driving ................... 4-4
Drive belts ....................................................... 7-15
Driving
Cold weather driving ................................. 4-19
Drinking alcohol/drugs and driving .............. 4-4
Driving with automatic transmission............ 4-7
Driving with manual transmission ............. 4-10
