WARNING
The temperature grade for this tire is
established for a tire that is properly
inflated and not overloaded. Excessive
speed, under-inflation, or excessive
loading, either separately or in combi-
nation, can cause heat build-up and
possible tire failure.Your NISSAN is covered by the following emis-
sion warranties.
For US:
Emission Defects Warranty
Emissions Performance Warranty
(See Warranty Information Booklet for de-
tails)
For Canada:
Emission Control System Warranty
Details of these warranties may be found with
other vehicle warranties in your Warranty Infor-
mation Booklet that comes with your NISSAN
vehicle. If you did not receive a Warranty Infor-
mation Booklet or it has become lost, you may
obtain a replacement by writing to:
Nissan North America, Inc.
Consumer Affairs Department
P.O. Box 685003
Franklin, TN 37068-5003
Nissan Canada Inc.
5290 Orbitor Drive
Mississauga, Ontario,
L4W 4Z5
If you believe that your vehicle has a
defect which could cause a crash or
could cause injury or death, you should
immediately inform the National High-
way Traffic Safety Administration(NHTSA)
in addition to notifying
NISSAN.
IfNHTSA
receives similar complaints,
it may open an investigation, and if it
finds that a safety defect exists in a
group of vehicles, it may order a recall
and remedy campaign. However,
NHTSA
cannot become involved in
individual problems between you, your
dealer, or NISSAN.
To contact
NHTSA
, you may call the
Vehicle Safety Hotline toll-free at
1-888-327-4236. (TTY: 1-800-424-
9153); go to http://www.safercar.gov;
or write to: Administrator,
NHTSA
, 400
Seventh Street, SW., Washington, DC
20590. You can also obtain other in-
formation about motor vehicle safety
from http://www.safercar.gov.
You may notify NISSAN by contacting
our Consumer Affairs Department, toll- EMISSIONCONTROL SYSTEM
WARRANTYREPORTING SAFETY DEFECTS
(US only)
9-24
Technical and consumer information
06.7.5/Z50-D/V5.0
Page 332 of 345
free, at 1-800-NISSAN-1 (1-800-647-
7261).
WARNING
A vehicle equipped with AWD (All-
Wheel Drive) should never be tested
using a two wheel dynamometer, similar
to the dynamometers used by some
states for emissions testing, or similar
equipment. Make sure you inform the
test facility personnel that your vehicle
is an AWD equipped vehicle before it is
placed on a dynamometer. Failure to do
so may result in transmission damage
or unexpected vehicle movement which
could result in serious vehicle damage
or personal injury.
Due to legal requirements in some states/
areas, your vehicle may be required to be in what
is called the “ready condition” for an
Inspection/Maintenance (I/M) test of the emis-
sion control system.
The vehicle is set to the “ready condition” when
it is driven through certain driving patterns.
Usually, the “ready condition” can be obtained
by ordinary usage of the vehicle.
If a powertrain system component is repaired orthe battery is disconnected, the vehicle may be
reset to a not “ready condition”. Before taking
the I/M test, check the vehicle’s inspection/
maintenance test readiness condition. Turn the
ignition switch ON without starting the engine. If
the Malfunction Indicator Light (MIL) comes on
steady for 20 seconds and then blinks for 10
seconds, the I/M test condition is “not ready”. If
the MIL does not blink after 20 seconds, the I/M
test condition is “ready”. If the MIL indicates the
vehicle is in a “not ready” condition, drive the
vehicle through the following pattern to set the
vehicle to the ready condition. If you cannot or
do not want to perform the driving pattern, a
NISSAN dealer can conduct it for you.
WARNING
Always drive the vehicle in a safe and
prudent manner according to traffic
conditions and obey all traffic laws.
1. Start the engine. Allow the engine to idle until
the engine coolant temperature gauge needle
points between the C and H (normal operat-
ing temperature).
2. Accelerate the vehicle to 55 MPH (88 km/h),
then quickly release the accelerator pedal
READINESS FOR INSPECTION/
MAINTENANCE (I/M) TEST (US
only)
Technical and consumer information
9-25
06.7.5/Z50-D/V5.0
Page 333 of 345
completely and keep it released for at least
10 seconds.
3. Quickly depress the accelerator pedal for a
moment, then drive the vehicle at a speed of
53 to 60 MPH (86 to 96 km/h) for at least 9
minutes.
4. Stop the vehicle. Leave the engine running.
5. Accelerate the vehicle to 35 MPH (55 km/h)
and maintain the speed for 20 seconds.
6. Repeat steps 4 and 5 at least 10 times.
7. Accelerate the vehicle to 55 MPH (88 km/h)
and maintain the speed for at least 3 minutes.
8. Stop the vehicle. Place the transmission se-
lector lever in the “P” or “N” position.
9. Turn the engine off.
10. Repeat steps 1 through 8 at least one more
time.
If step 1 through 7 is interrupted, repeat the
preceding step. Any safe driving mode is ac-
ceptable between steps. Do not stop the engine
until step 7 is completed.Your vehicle is equipped with a variety of
computers that monitor and control a num-
ber of systems to optimize performance
and help service technicians with diagno-
sis and repair. Some of the computers
monitor emission control systems, braking
systems, engine systems, transmission
systems, tire pressure systems and air bag
systems. Some data about vehicle opera-
tion may be stored in the computers for
use during servicing. Other data may be
stored if a crash event occurs. For example,
vehicle speed, brake application, steering
angle, air bag readiness, air bag perfor-
mance and seat belt use by the driver or
passenger may be recorded. These types of
systems are sometimes called Event Data
Recorders.
Special equipment can be used to access
the electronic data that may be stored in
the vehicle’s computers (sounds are not
recorded). NISSAN and NISSAN dealers
have equipment to access some of this
data; others may also have this equipment.
The data may be retrieved during routine
vehicle servicing or for special research. It
might also be accessed with the consent of
the vehicle owner or lessee, in response to
a request by law enforcement, or as other-
wise required or permitted by law.A genuine NISSAN Service Manual is the best
source of service and repair information for your
vehicle. Filled with wiring diagrams, illustrations
and step-by-step diagnostic and adjustment
procedures, this manual is the same one used by
the factory trained technicians working at autho-
rized NISSAN dealerships. Also available are
genuine NISSAN Owner’s Manuals, and genu-
ine NISSAN Service and Owner’s Manuals for
older NISSAN models.
In the USA:
For current pricing and availability of genuine
NISSAN Service Manualsfor the 2000 model
year and later, contact:
Tweddle Litho Company
1-800-450-9491
www.nissan-techinfo.com
For current pricing and availability of genuine
NISSAN Service Manualsfor the 1999 model
year and prior, see a NISSAN dealer, or contact:
Resolve Corporation
20770 Westwood Dr.
Strongsville OH 44136
1-800-247-5321
EVENT DATA RECORDERS
OWNER’S MANUAL/SERVICE
MANUAL ORDER INFORMATION
9-26
Technical and consumer information
06.7.5/Z50-D/V5.0
Page 334 of 345
For current pricing and availability of genuine
NISSAN Owner’s Manualsfor this model year
and prior, see a NISSAN dealer, or contact:
Resolve Corporation
20770 Westwood Dr.
Strongsville OH 44136
1-800-247-5321
In Canada:
To purchase a copy of a genuine NISSAN
Service Manual or Owner’s Manual please con-
tact your nearest NISSAN dealer. For the phone
number and location of a NISSAN Dealer in your
area call the NISSAN Satisfaction Center at
1-800-387-0122 and a bilingual NISSAN rep-
resentative will assist you.
Also available are Genuine NISSAN Service and
Owner’s Manuals for older NISSAN models.IN THE EVENT OF A COLLISIONUnfortunately, accidents do occur. In this unlikely
event, there is some important information you
should know. Many insurance companies rou-
tinely authorize the use of non-genuine collision
parts in order to cut costs, among other reasons.Insist on the use of Genuine NISSAN
Collision Parts!If you want your vehicle to be restored usingparts made to NISSAN’s original exacting speci-
fications — if you want to help it to last and hold
its resale value, the solution is simple.Tell your
insurance agent and your repair shop to
only use Genuine NISSAN Collision Parts.
NISSAN does not warrant non-NISSAN parts,
nor does NISSAN’s warranty apply to damage
caused by a non-genuine part.
Using Genuine NISSAN Parts can help protect
your personal safety, preserve your warranty
protection and maintain the resale value of your
vehicle. And if your vehicle was leased, using
Genuine NISSAN Parts may prevent or limit
unnecessary excess wear and tear expenses at
the end of your lease.
NISSAN designs its hoods with crumple zones
to minimize the risk that the hood will penetrate
the windshield of your vehicle in an accident.
Non-genuine (imitation) parts may not provide
such built in safeguards. Also, non-genuine
parts often show premature wear, rust and cor-
rosion.
Why should you take a chance?In over 40 states, the law says you must be
advised if non-genuine parts are used to repair
your vehicle. And some states have enacted
laws that restrict insurance companies from
authorizing the use of non-genuine collision
parts during the new vehicle warranty. Theselaws help protect you, so you can take action to
protect yourself.
It’s your right!If you should need further information visit us at:
www.nissanusa.com(for U.S. customers) or
www.nissan.ca(for Canadian customers).Technical and consumer information
9-27
06.7.5/Z50-D/V5.0
Page 335 of 345
MEMO9-28
Technical and consumer information
06.7.5/Z50-D/V5.0
Page 336 of 345
10 Index
A
Adjusting pedal position .......................................... 3-29
Aiming control, Headlights...................................... 2-25
Air bag system, Front passenger air bag and
status light................................................................... 1-49
Air bag warning labels ............................................. 1-55
Air bag warning light .................................... 1-56, 2-13
Air cleaner housing filter.......................................... 8-17
Air conditioner
Air conditioner operation .................................. 4-23
Air conditioner service ........................... 4-23, 4-26
Air conditioner specification label .................. 9-11
Air conditioning system refrigerant
and lubricant recommendations ............ 4-26, 9-6
Heater and air conditioner (automatic) ......... 4-23
In-cabin microfilter .............................................. 4-26
Alcohol, drugs and driving......................................... 5-6
All-wheel drive (AWD) ............................................. 5-25
All-wheel drive (AWD) warning light ...................... 2-9
All-wheel drive (AWD), AWD lock switch
operations.................................................................... 5-25
Antenna ........................................................................ 4-44
Anti-lock Braking System (ABS) ........................... 5-31
Anti-lock Braking System (ABS) warning
light ............................................................................... 2-10
Appearance care
Exterior appearance care .................................... 7-2
Interior appearance care ..................................... 7-4Armrest ........................................................................... 1-9
Audible reminders ..................................................... 2-16
Audio operation precautions .................................. 4-28
Audio system .............................................................. 4-27
FM-AM-SAT radio with casette player
and CD changer ................................................. 4-38
FM-AM-SAT radio with CD player................. 4-34
Steering switch for audio control ................... 4-43
Autochanger
Compact Disc (CD) ........................................... 4-42
Autolight system ........................................................ 2-23
Automatic
Anti-glare inside mirror ...................................... 3-31
Automatic sunroof .............................................. 2-40
Drive positioner ................................................... 3-33
Seat positioner .................................................... 3-33
Avoiding collision and rollover .................................. 5-5
B
Back door (See lift gate)......................................... 3-24
Battery .......................................................................... 8-14
Battery saver system ......................................... 2-25
Battery replacement
Intelligent Key system .......................................... 3-8
Remote keyless entry system............................. 3-8
Before starting the engine ...................................... 5-12
Belts (See drive belts) ............................................. 8-16
Booster seats ............................................................. 1-36Brake
Brake fluid............................................................. 8-13
Brake system ....................................................... 5-30
Parking brake operation .................................... 5-21
Warning light ....................................................... 2-10
Break-in schedule ..................................................... 5-24
Brightness control, Instrument panel ................... 2-26
Bulbcheck/instrument panel .................................... 2-9
Bulbreplacement ...................................................... 8-26
C
Cabin air filter ............................................................. 4-26
Capacities and recommended fuel/lubricants...... 9-2
Car phone or CB radio............................................ 4-45
Cargo (See vehicle loading information)............. 2-36
Cargo net .................................................................... 2-36
Cassette player (See audio system) .................... 4-41
Catalytic converter, Three way catalyst ................. 5-3
CD care and cleaning .............................................. 4-43
Ceiling light ................................................................. 2-42
Cellular phone holder ............................................... 2-31
Child restraints ........................................................... 1-21
Booster seats ...................................................... 1-36
Top tether strap .................................................. 1-25
Child safety ................................................................. 1-12
Child safety rear door lock ........................................ 3-5
06.7.5/Z50-D/V5.0
Page 337 of 345
Chimes
Audible reminders............................................... 2-16
Seat belt warning light and chime ................. 2-13
Circuit breaker, Fusible link .................................... 8-22
Cleaning exterior and interior .......................... 7-2, 7-4
Clock (models with navigation
system) .................................................................. 4-4, 4-9
Clock (models without navigation
system) ......................................................................... 4-18
Coin box ...................................................................... 2-31
Cold weather driving ................................................ 5-34
Compact Disc (CD) changer (See audio
system) ......................................................................... 4-42
Compact Disc (CD) player (See audio
system) ......................................................................... 4-36
Compass display ......................................................... 2-6
Console box................................................................ 2-34
Continuously variable transmission (CVT)
indicator light .............................................................. 2-14
Control panel buttons (models with navigation
system) ......................................................................... 4-11
Control panel buttons (models without
navigation system) ....................................................... 4-2
Controls
Control panel buttons (display with
navigation system) .............................................. 4-11
Control panel buttons (display without
navigation system) ................................................ 4-2
Heater and air conditioner controls
(automatic)............................................................ 4-23
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8Corrosion protection ................................................... 7-5
Cover, Tonneau cover .............................................. 2-37
Cruise control............................................................. 5-22
Cruise set indicator light ......................................... 2-14
Cup holders ................................................................ 2-32
CVT fluid...................................................................... 8-12
CVT, Driving with CVT (Continuously Variable
Transmission) ............................................................. 5-13
D
Daytime running light system ................................. 2-25
Defroster switch, Rear window and outside mirror
defroster switch ......................................................... 2-22
Dimensions and weights ............................................ 9-8
Display controls (See control panel buttons),
With navigation system............................................ 4-11
Display controls (See control panel buttons),
Without navigation system ........................................ 4-2
Door open warning light .......................................... 2-11
Door pockets .............................................................. 2-36
Drive belts ................................................................... 8-16
Drive positioner .......................................................... 3-33
Driving
All-wheel drive (AWD) ...................................... 5-25
Cold weather driving ......................................... 5-34
Driving with CVT (Continuously Variable
Transmission) ....................................................... 5-13
On-pavement and offroad driving ..................... 5-6
Precautions when starting and driving ............ 5-2
Safety precautions ................................................ 5-6E
Economy, Fuel............................................................ 5-24
Emergency unlock lever........................................... 3-25
Emission control information label ........................ 9-10
Emission control system warranty......................... 9-24
Engine
Before starting the engine................................ 5-12
Break-in schedule............................................... 5-24
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil ........................................... 8-10
Changing engine oil filter ................................. 8-11
Checking engine coolant level........................... 8-8
Checking engine oil level .................................... 8-9
Coolant temperature gauge ............................... 2-5
Engine block heater ........................................... 5-35
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil................................................................. 8-9
Engine oil and oil filter recommendation......... 9-5
Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-10
Engine specifications ........................................... 9-7
If your vehicle overheats ................................... 6-11
Starting the engine............................................. 5-13
Entry/exit function, Automatic drive
positioner ..................................................................... 3-33
Event data recorders ................................................ 9-26
Exhaust gas (Carbon monoxide).............................. 5-2
06.7.5/Z50-D/V5.0
10-2
Page 338 of 345
F
F.M.V.S.S./C.M.V.S.S. certification label ............. 9-10
Filter
Air cleaner housing filter ................................... 8-17
Changing engine oil filter ................................. 8-11
Flashers (See hazard warning flasher switch) ... 2-27
Flat tire............................................................................ 6-2
Flat towing .................................................................. 9-22
Floor mat cleaning ....................................................... 7-4
Fluid
Brake fluid............................................................. 8-13
Capacities and recommended fuel/
lubricants ................................................................. 9-2
CVT fluid ............................................................... 8-12
Engine coolant ....................................................... 8-8
Engine oil................................................................. 8-9
Power steering fluid ........................................... 8-12
Window washer fluid ......................................... 8-14
FM-AM-SAT radio with casette player
and CD changer ........................................................ 4-38
FM-AM-SAT radio with CD player ....................... 4-34
Fog light switch ......................................................... 2-27
Front manual seat adjustment .................................. 1-3
Front passenger air bag and status light ............ 1-49
Front power seat adjustment .................................... 1-3
Fuel
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Fuel economy ...................................................... 5-24
Fuel octane rating ................................................. 9-3
Fuel recommendation ........................................... 9-3
Fuel-filler cap ....................................................... 3-26
Fuel-filler door...................................................... 3-26Gauge ...................................................................... 2-5
Fuses ............................................................................ 8-21
Fusible links ................................................................ 8-22
G
Garage door opener, HomeLink
Universal
Transceiver .................................................................. 2-44
Gas cap ....................................................................... 3-26
Gauge ............................................................................. 2-3
Engine coolant temperature gauge .................. 2-5
Fuel gauge .............................................................. 2-5
Odometer ................................................................ 2-4
Speedometer .......................................................... 2-4
Tachometer ............................................................. 2-4
General maintenance .................................................. 8-2
Glove box .................................................................... 2-33
H
Hazard warning flasher switch............................... 2-27
Head restraints ............................................................. 1-7
Headlights
Aiming control ..................................................... 2-25
Bulbreplacement ............................................... 8-27
Headlight switch ................................................. 2-23
Xenon headlights ................................................ 2-22
Heated seats .............................................................. 2-28
Heater
Engine block heater ........................................... 5-35
Heater and air conditioner (automatic) ......... 4-23
HomeLink
Universal Transceiver ......................... 2-44
Hood release .............................................................. 3-24Horn .............................................................................. 2-28
I
Ignition knob(Intelligent Key system) .................. 3-13
Ignition switch
Key positions ....................................................... 5-10
Ignition switch (Except for Intelligent Key
equipped model) .......................................................... 5-9
Ignition switch (Intelligent Key System
equipped model) ....................................................... 5-10
Immobilizer system .................................................... 2-18
In-cabin microfilter .................................................... 4-26
Indicator lights............................................................ 2-14
Continuously variable transmission (CVT)
indicator light ....................................................... 2-14
Cruise set indicator light .................................. 2-14
Malfunction indicator light (MIL) .................... 2-14
Inside
Automatic anti-glare mirror............................... 3-31
Mirror...................................................................... 3-30
Inspection/maintenance (I/M) test ........................ 9-25
Instrument brightness control ................................ 2-26
Instrument panel........................................................... 2-2
Intelligent Key system ................................................. 3-9
Engine starting .................................................... 3-13
Key operating range........................................... 3-15
Key operation....................................................... 3-12
Mechanical key and valet key .......................... 3-23
Operating the engine......................................... 3-13
Remote keyless operation ................................ 3-20
Trouble-shooting guide ..................................... 3-19
Warning light ....................................................... 2-11
Warning signals .................................................. 3-17
06.7.5/Z50-D/V5.0
10-3
Page 339 of 345
Intelligent key warning light .................................... 2-11
Interior light replacement......................................... 8-28
Interior lights ............................................................... 2-42
J
Jump starting................................................................. 6-9
K
Keyless entry
With Intelligent Key system (See Intelligent
Key system) .......................................................... 3-20
Without Intelligent Key system (See remote
keyless entry system) ........................................... 3-5
Keys................................................................................. 3-2
Keys, For Intelligent Key system .............................. 3-9
L
Labels
Air bag warning labels ...................................... 1-55
Air conditioner specification label .................. 9-11
Emission control information label ................. 9-10
Engine serial number ......................................... 9-10
F.M.V.S.S./C.M.V.S.S. certification label ...... 9-10
Tire and Loading Information label ..... 8-31, 9-11
Vehicle identification number (VIN) .................. 9-9
License plate, Installing front license plate......... 9-12
Lift gate ........................................................................ 3-24
Light
Air bag warning light ......................................... 1-56
Bulbreplacement ............................................... 8-26Ceiling light .......................................................... 2-42
Fog light switch................................................... 2-27
Headlight switch ................................................. 2-23
Headlights bulb replacement........................... 8-27
Indicator lights ..................................................... 2-14
Interior lights ........................................................ 2-42
Luggage light ....................................................... 2-44
Map light ............................................................... 2-43
Rear personal light ............................................. 2-43
Replacement ........................................................ 8-26
Vanity mirror light ................................................ 2-44
Warning/indicator lights and audible
reminders................................................................. 2-9
Xenon headlights ................................................ 2-22
Lights, Exterior and interior light replacement ... 8-28
Loading information (See vehicle loading
information) ................................................................. 9-13
Lock
Door locks ............................................................... 3-3
Glove box lock..................................................... 2-33
Lift gate lock ........................................................ 3-24
Power door lock .................................................... 3-3
Low fuel warning light .............................................. 2-12
Low tire pressure warning light ............................. 2-12
Low tire pressure warning system (See tire
pressure monitoring system (TPMS)) ..................... 5-3
Luggage light ............................................................. 2-44
M
Maintenance
Battery ................................................................... 8-14
General maintenance ........................................... 8-2
Inside the vehicle................................................... 8-3Maintenance precautions .................................... 8-5
Maintenance requirements.................................. 8-2
Outside the vehicle............................................... 8-2
Seat belt maintenance ...................................... 1-20
Under the hood and vehicle ............................... 8-4
Malfunction indicator light (MIL) ............................ 2-14
Manual front seat adjustment ................................... 1-3
Map light...................................................................... 2-43
Mechanical key (for Intelligent Key system) ....... 3-23
Meters and gauges ..................................................... 2-3
Meters and gauges, Instrument brightness
control .......................................................................... 2-26
Mirror
Automatic anti-glare inside mirror .................. 3-31
Inside mirror ......................................................... 3-30
Outside mirrors ................................................... 3-32
Monitor, Rearview monitor ...................................... 4-19
N
Net, Cargo net ........................................................... 2-36
New vehicle break-in ................................................ 5-24
NISSAN Vehicle Immobilizer System ................... 2-18
Nissan Vehicle Immobilizer System
Engine start .............................................. 5-10, 5-12
O
Odometer ....................................................................... 2-4
Oil
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine oil ........................................... 8-10
06.7.5/Z50-D/V5.0
10-4
Page 340 of 345
Checking engine oil level .................................... 8-9
Engine oil................................................................. 8-9
Engine oil viscosity ............................................... 9-5
Operating the engine (Intelligent Key
system) ......................................................................... 3-13
Outside mirrors .......................................................... 3-32
Overheat, If your vehicle overheats ...................... 6-11
Owner’s Manual/Service Manual order
information................................................................... 9-26
P
Parking
Brake break-in ..................................................... 5-30
Parking brake operation .................................... 5-21
Parking on hills .................................................... 5-29
Pedal position adjustment....................................... 3-29
Phone, Car phone or CB radio ............................. 4-45
Power
Front seat adjustment .......................................... 1-3
Power door lock .................................................... 3-3
Power outlet ......................................................... 2-30
Power steering fluid ........................................... 8-12
Power steering system ...................................... 5-30
Power windows................................................... 2-38
P position selecting warning light ......................... 2-13
Pre-tensioner seat belt system .............................. 1-54
Precautions
Audio operation ................................................... 4-28
Braking precautions ........................................... 5-30
Child restraints .................................................... 1-21
Cruise control ...................................................... 5-22
Driving safety .......................................................... 5-6
Maintenance ........................................................... 8-5On-pavement and offroad driving ..................... 5-6
Seat belt usage ..................................................... 1-9
Supplemental restraint system ........................ 1-41
When starting and driving .................................. 5-2
Push starting .............................................................. 6-11
R
Radio, Car phone or CB radio .............................. 4-45
Readiness for inspection/maintenance (I/M)
test (US only) ............................................................. 9-25
Rear center seat belt................................................ 1-17
Rear door lock, Child safety rear door lock.......... 3-5
Rear personal light .................................................... 2-43
Rear power point....................................................... 2-30
Rear seat adjustment .................................................. 1-5
Rear window and outside mirror defroster
switch ........................................................................... 2-22
Rear window wiper and washer switch .............. 2-21
Rearview monitor ....................................................... 4-19
Recorders, Event data ............................................. 9-26
Registering your vehicle in another country.......... 9-9
Remote keyless entry
System, Except Intelligent Key system ............ 3-5
System, For Intelligent Key system ................ 3-20
Reporting safety defects (US only) ...................... 9-24
Rollover........................................................................... 5-5
S
Safety
Child seat belts ................................................... 1-12
Reporting safety defects (US only)................ 9-24Towing safety....................................................... 9-19
Seat adjustment
Front manual seat adjustment............................ 1-3
Front power seat adjustment ............................. 1-3
Rear seat adjustment ........................................... 1-5
Seat belt(s)
Child safety .......................................................... 1-12
Infants .................................................................... 1-12
Injured persons.................................................... 1-13
Larger children .................................................... 1-13
Pre-tensioner seat belt system ....................... 1-54
Precautions on seat belt usage......................... 1-9
Pregnant women ................................................. 1-13
Rear center seat belt ......................................... 1-17
Seat belt cleaning ................................................. 7-5
Seat belt extenders ............................................ 1-20
Seat belt hook ..................................................... 1-17
Seat belt maintenance ...................................... 1-20
Seat belt warning light and chime ................. 2-13
Seat belts ................................................................ 1-9
Shoulder belt height adjustment..................... 1-16
Small children ...................................................... 1-12
Three-point type with retractor ....................... 1-13
Seat(s)
Driver-side memory ............................................ 3-33
Heated seats........................................................ 2-28
Seats ........................................................................ 1-2
Security system (NISSAN Vehicle Immobilizer
System), Engine start ............................................... 2-18
Security system, Vehicle security system ........... 2-17
Selector lever, Shift lock release ............... 5-16, 5-20
Servicing air conditioner .............................. 4-23, 4-26
Shift lock release, Transmission ................ 5-16, 5-20
06.7.5/Z50-D/V5.0
10-5
