FUEL RECOMMENDATION:
NISSAN recommends the use of unleaded
premium gasoline with an octane rating of at
least 91 AKI (Anti-Knock Index) number (Re-
search octane number 96) .
If unleaded premium gasoline is not available,
you may use unleaded regular gasoline with an
octane rating of at least 87 AKI number
(Research octane number 91) , but you may
notice a decrease in performance.
CAUTION
.Using a fuel other than that speci-
fied could adversely affect the emis-
sion control systems, and may also
affect warranty coverage.
.Under no circumstances should a
leaded gasoline be used, since this
will damage the three way catalyst.
.Do not use E-85 fuel in your vehicle.
Your vehicle is not designed to run
on E-85 fuel. Using E-85 fuel can
damage the fuel system compo-
nents and is not covered by the
NISSAN new vehicle limited war-
ranty.
For additional information, see “CAPACITIESAND RECOMMENDED FUEL/LUBRICANTS”
in the “9. Technical and consumer information”
section.
ENGINE OIL RECOMMENDATION:
.Engine oil with API Certification Mark
.Viscosity SAE 5W-30
See “CAPACITIES AND RECOMMENDED
FUEL/LUBRICANTS” in the “9. Technical and
consumer information” section for engine oil and
oil filter recommendation.
COLD TIRE PRESSURES:
The label is typically located on the driver side
center pillar or on the driver’s door. For
additional information, see “WHEELS AND
TIRES” in the “8. Maintenance and do-it-
yourself” section.
NEW VEHICLE BREAK-IN PROCE-
DURES RECOMMENDATION:
During the first 1,200 miles (2,000 km) of
vehicle use, follow the recommendations out-
lined in the “BREAK-IN SCHEDULE” in the “5.
Starting and driving” section of this Owner’s
Manual. Follow these recommendations for the
future reliability and economy of your new
vehicle.
GAS STATION INFORMATION
Black plate (3,1)
Model "Z51-D" EDITED: 2007/ 10/ 2
STI0565
1. Battery (P.8-13)
2. Brake fluid (P.8-12)
3. Supplemental front-impact air bags (P.1-41)
4. Meters and gauges (P.2-4)
5. Hood release (P.3-18)
6. Seat (P.1-2)
7. Seat belt (P.1-10)
8. Door lock (P.3-4)
9. Fuel-filler door (P.3-23)
Fuel recommendation (P.9-3)
10. Engine oil (P.8-8)
11. Engine coolant (P.8-7)
12. Window washer fluid (P.8-12)
13. Air conditioner (P.4-26)
Audio system (P.4-31)
14. Spare tire (P.6-2)
QUICK REFERENCE
