Foreword
Welcome to the growing family of new NISSAN owners. This vehicle has been delivered to you with confidence. Your vehicle has been produced
using the latest techniques and strict quality control.
This manual has been prepared to help you understand the operation and maintenance of your vehicle so that you may enjoy many miles of driving
pleasure. Please read through this manual before operating your vehicle.
A separate Warranty Information and Maintenance Log Booklet explains details about the warranties covering your vehicle and vehicle maintenance
schedules.
Your NISSAN dealer knows your vehicle best. When you require any service or have any questions, he will be glad to assist you with the extensive
resources available to him.
IMPORTANT SAFETY INFORMATION
REMINDERS FOR SAFETY!
Follow these five important driving rules to help ensure a safe
and complete trip for you and your passengers!
INEVER drive under the influence of alcohol or drugs.
IALWAYS observe posted speed limits and never drive too
fast for conditions.
IALWAYS use your seat belts and appropriate child re-
straint systems.
IALWAYS provide information about the proper use of
vehicle safety features to all occupants of the vehicle.
IALWAYS review this Owner's Manual for important safety
information.
NOTES ON THE INFORMATION CONTAINED IN THIS
OWNER'S MANUAL
This owner's manual contains descriptions and operating instruc-
tions for all systems, features and optional equipment that might
appear in any model of this vehicle built for any destination in
North America, including the continental United States, Canada
and Hawaii. Therefore, you may very well find information in this
manual that does not apply to your vehicle.
For descriptions specified for 4-wheel drive models, a
mark is
placed at the beginning of the applicable sections/items.
ON-PAVEMENT AND OFF-ROAD DRIVING
This vehicle will handle and maneuver differently from an
ordinary passenger car, because it has a higher center of
gravity for off-road use. As with other vehicles with features of
this type, failure to operate this vehicle correctly may result in
loss of control or an accident.
Be sure to read ªOn-Pavement and Off-Road driving precau-
tionsº and ªAvoiding collision and rolloverº in the ªStarting and
drivingº section of this manual.
Z01.2.1/R50-DX
Page 2 of 233
MODIFICATION OF YOUR VEHICLE
This vehicle should not be modified. Modification could affect
its performance, safety or durability, and may even violate
governmental regulations. In addition, damage or performance
problems resulting from modification may not be covered under
NISSAN warranties.
All information, specifications and illustrations in this manual are those
in effect at the time of printing. NISSAN reserves the right to change
specifications or design without notice and without obligation.
IMPORTANT INFORMATION ABOUT THIS MANUAL
You will see various symbols in this manual. They are used in the
following ways:
This is used to indicate the presence of a hazard that could
cause death or serious personal injury. To avoid or reduce
the risk, the procedures must be followed precisely.
This is used to indicate the presence of a hazard that could
cause minor or moderate personal injury or damage to
your vehicle. To avoid or reduce the risk, the procedures
must be followed carefully.
If you see this symbol, it means ªDo not do thisº or ªDo not let this
happenº.
1996 NISSAN MOTOR CO., LTD.
TOKYO, JAPAN
All rights reserved. No part of this Owner's Manual may be reproduced or stored in a
retrieval system, or transmitted in any form, or by any means, electronic, mechanical,
photocopying, recording or otherwise, without the prior written permission of Nissan
Motor Co., Ltd.
SIC0697
Z01.2.1/R50-DX
Page 3 of 233
Welcome To The World Of NISSAN
Your new Nissan is the result of our dedication to
produce the finest in safe, reliable and economi-
cal transportation. Your vehicle is the product of
a successful worldwide company that manufac-
tures cars and trucks in over 17 countries and
distributes them in 170 nations.
Nissan vehicles are designed and manufactured
by Nissan Motor Co., Ltd. which was founded in
Tokyo, Japan in 1933, and Nissan affiliates world
wide, collectively growing to become the fifth
largest automaker in the world. In addition to cars
and trucks, Nissan also makes textile machinery,
fork-lift trucks, marine engines, boats and other
products.
Nissan has made a substantial and growing
investment in North America, starting with the
opening of Nissan Motor Corporation U.S.A. in
1960 and continuing with the production of some
cars and trucks at one of the world's mostmodern manufacturing facilities, Nissan Motor
Manufacturing Corporation U.S.A. in Smyrna,
Tennessee, vehicle styling at Nissan Design
International in San Diego, California, and engi-
neering at Nissan Research and Development in
Farmington Hills, Michigan.
Nissan Motor Corporation U.S.A. and its dealers
indirectly employ about 60,000 Americans.
Nissan is also a substantial contributor to the
Canadian economy. Nissan Canada Inc., its sup-
pliers and over 170 dealers employ approxi-
mately 4,500 people. These include company
employees and the staffs of Nissan dealers all
across Canada. In addition, many Canadians
work for companies that supply Nissan and
Nissan dealers with materials and services rang-
ing from operation of port facilities and transpor-
tation services, to the supply of lubricants, parts
and accessories.Nissan pioneered the use of electronics and
computers in automobiles, and has led the indus-
try in improving both performance and fuel effi-
ciency through new engine designs and the use
of synthetic materials to reduce vehicle weight.
The company has also developed ways to build
quality into its vehicles at each stage of the
production process, both through extensive use
of automation and Ð most importantly Ð
through an awareness thatpeopleare the cen-
tral element in quality control.
From the time the parts arrived from our suppli-
ers until you took delivery of your new Nissan,
dozens of checks were made to ensure that only
the best job was being done in producing and
delivering your vehicle. Nissan also takes great
care to ensure that when you take your Nissan to
your dealer for maintenance, the service techni-
cian will perform his work according to the quality
standards that have been established by the
factory.
Safety has also been built into your Nissan. As
you know, seat belts are an integral part of the
safety systems that will help protect you and your
passengers in the event of a sudden stop or an
accident. We urge you to use the belts every time
you drive the vehicle.
The Nissan story of growth and achievement
reflects our major goal: to provide you, our
customer, with a vehicle that is built with quality
and craftsmanship Ð a product that we can be
proud to build and you can be proud to own.
AFW0001
Z01.2.1/R50-DX
Page 4 of 233
NISSAN CUSTOMER CARE PROGRAM
NISSAN CARES ...
Both NISSAN and your NISSAN dealer are dedicated to serving all your automotive needs. Your satisfaction with your
vehicle and your NISSAN dealer are our primary concerns. Your NISSAN dealer is always available to assist you with all
your automobile sales and service needs.
However, if there is something that your NISSAN dealer
can not assist you with or you would like to provide
NISSAN directly with comments or questions, please
contact our (NISSAN's) Consumer Affairs Department
using our toll-free number:
For U.S. mainland customers
1-800-NISSAN-1 (1-800-647-7261)
For Hawaii customers
(808) 836-0888 (Oahu Number)
For Canada customers
1-800-387-0122
The Consumer Affairs Department will ask for the following information:
Ð Your name, address, and telephone number
Ð Vehicle identification number (on dashboard)
Ð Date of purchase
Ð Current odometer reading
Ð Your NISSAN dealer's name
Ð Your comments or questions
ORYou can write to NISSAN with the information on the left
at:
For U.S. mainland and Alaska customers
Nissan Motor Corporation U.S.A.
Consumer Affairs Department
P.O. Box 191
Gardena, California 90248-0191
For Hawaii customers
Nissan Motor Corporation in Hawaii
2880 Kilihau St.
Honolulu, Hawaii 96819
For Canada customers
Nissan Canada Inc.
P.O. Box 1709, Station ªBº
Mississauga, Ontario L4Y 4H6
We appreciate your interest in NISSAN and thank you for buying a quality NISSAN vehicle.
Z01.2.1/R50-DX
Page 5 of 233
ContentsInstruments and controls
Pre-driving checks and adjustments
Heater, air conditioner and audio system
Starting and driving
In case of emergency
Appearance and interior care
Do-it-yourself operations
Maintenance schedule
Technical and consumer information
Index
Z01.2.1/R50-DX
Page 6 of 233
1 Instruments and controls
Meters and gauges ................................................. 1-3
Speedometer and odometer .................................. 1-3
Tachometer ............................................................ 1-4
Engine coolant temperature gauge ........................ 1-4
Fuel gauge ............................................................. 1-5
Compass and outside temperature display
(If so equipped) ....................................................... 1-5
Clock ....................................................................... 1-8
Warning/indicator light and buzzer .......................... 1-9
Theft warning (If so equipped) .............................. 1-13
Headlight and turn signal switch .......................... 1-15
Windshield wiper and washer switch .................... 1-16
Rear window wiper and washer switch ............... 1-17
Rear window defroster switch .............................. 1-18
Instrument brightness control ............................... 1-18
Front fog light switch ............................................. 1-19
Hazard warning flasher switch ............................. 1-19Heated seats (If so equipped) ............................... 1-20
Cigarette lighter and ash trays ............................. 1-21
Power socket ......................................................... 1-22
Coin tray ................................................................ 1-22
Cup holder ............................................................. 1-23
Glasses case ......................................................... 1-24
Console box .......................................................... 1-24
Luggage board and box ........................................ 1-26
Tonneau cover ...................................................... 1-26
Power window ....................................................... 1-27
Sunroof (if so equipped) ....................................... 1-29
Interior light ........................................................... 1-30
Spot light ............................................................... 1-31
Vanity mirror light ................................................. 1-31
Integrated HomeLink
transmitter
(If so equipped) ....................................................... 1-31
Z01.2.1/R50-DX
Page 7 of 233
Driver's supplemental air bag (P.2-23)
Cruise control
set switch
(P.4-14)
Outside mirror remote control
(P.2-42) Headlight/dimmer/turn signal switch (P.1-15)
Front fog light switch (P.1-19)Meter/gauge (P.1-3)
Windshield wiper/washer switch (P.1-16)
Hazard warning flasher switch (P.1-19)
Center ventilator (P.3-2)
Heater/air conditioner control (P.3-3)Compass/outside air temperature display (P.1-5)
Passenger supplemental air bag (P.2-23)
Side ventilator (P.3-2)
Glove box (P.2-10)
Cigarette lighter (P.1-21)
Radio/CD player (P.3-15)/clock (P.1-8)
Rear window wiper/washer switch (P.1-17)
Rear window/outside mirror defroster switch (P.1-18)Ignition switch/steering lock (P.4-5)Heated seat switch (P.1-20)
Tilting steering wheel adjust lever (P.2-41)Hood release handle (P.2-9) Fuse box cover (P.7-21)
Coin tray (P.1-22) Theft warning light (P.1-13) Cruise control main switch (P.4-14)
Instrument brightness control
(P.1-18)
SIC0682
See the page indicated in parentheses for operating details.
1-2
Z01.2.1/R50-DX
Page 8 of 233
Speedometer
The speedometer indicates vehicle speed.
Odometer
The odometer records the total distance the
vehicle has been driven.
Trip odometer
The trip odometer records the distance of
individual trips. Before each trip, set the trip
odometer to zero by pushing the RESET knob.
SIC0586
SIC0587
METERS AND GAUGES SPEEDOMETER AND ODOMETER
1-3
Z01.2.1/R50-DX
Page 9 of 233
The tachometer indicates engine speed in
revolutions per minute (r/min).
When engine speed approaches the red
zone, shift to a higher gear. Operating
the engine in the red zone may cause
serious engine damage.
The gauge indicates the engine coolant tem-
perature.
The engine coolant temperature will vary with
the outside air temperature and driving condi-
tions.
If the gauge indicates over the normal
range, stop the vehicle as soon as safely
possible. If the engine is overheated,
continued operation of the vehicle may
seriously damage the engine. See ªIn
case of emergencyº section for immedi-ate action required.
SIC0588SIC0545
TACHOMETER
ENGINE COOLANT
TEMPERATURE GAUGE
1-4
Z01.2.1/R50-DX
Page 10 of 233
The gauge indicates the APPROXIMATE fuel
level in the tank.
The gauge may move slightly during braking,
turning, acceleration, or going up or down hill.
The gauge needle is designed to remain in
approximately the same position, even when
the ignition key is turned ªOFFº.
Refill the fuel tank before the gauge regis-
ters Empty.This unit is a display unit which possesses the
following functions:
IFunction to measure terrestrial magnetism
and indicate heading direction of vehicle
IFunction to indicate outside air temperature
IFunction to indicate caution for frozen road
surfacesOutside temperature display
Push the switch when the ignition key is in the
ªACCº or ªONº position. The outside tempera-
ture will be displayed in ªÉFº.
ISelecting the indication range
Push the switch to change from ªÉFº to ªÉCº.
IIf the outside temperature drops below the
freezing point, the display indicates
ICE .
SIC0546SIC0590SIC0610
FUEL GAUGECOMPASS AND OUTSIDE
TEMPERATURE DISPLAY
(If so equipped)
1-5
Z01.2.1/R50-DX
