NISSAN PATHFINDER 1998 R50 / 2.G Owners Manual

troller and vehicle is more than approx.
49 ft (15 m).
IWhen one of the doors is ajar, only the
unlock function can be operated.
BATTERY REPLACEMENTReplace the battery as follows:
1. Open the lid using a coin.
2. Replace the battery with a new one. Insertthe battery as illustrated above.
Recommended battery: Sanyo CR2025
or equivalent.
3. Close the lid securely.
SPA0650
3-6
Pre-driving checks and adjustments
Z
01.1.31/R50-D
X

4. Press the
button, then the
button two or three times to check the
multi-remote controller operation.
If the battery is removed for any reason
other than replacement, perform step 4
above.
IAn improperly disposed battery can hurt
the environment. Always confirm local
regulations for battery disposal.
IThe multi-remote controller is water-
resistant; however, if it does get wet,
immediately wipe completely dry.
IWhen changing battery, do not let dust
or oil get on the controller.
FCC Notice:
Changes or modifications not expressly
approved by the manufacturer compliance
could void the user's authority to operate
the equipment.
This device complies with Part 15 of the
FCC Rules and RSS-210 of Industry
Canada. Operation is subject to the follow-
ing two conditions: (1) This device may not
cause harmful interference and (2) this de-
vice must accept any interference received,
including interference that may cause un-
desired operation of the device.
Pre-driving checks and adjustments
3-7
Z
01.1.31/R50-D
X

1. Pull the hood lock release handle located
below the instrument panel; the hood will
then spring up slightly.
2. Raise the lever at the front of the hood with
your fingertips and raise the hood.3. Insert the assist bar into the slot in the front
edge of the hood.
4. When closing the hood, reset the assist bar
to its original position, then slowly close the
hood and make sure it locks into place.
IMake sure the hood is completely
closed and latched before driving.
Failure to do so could cause the hood
to fly open and result in an accident.
IIf you see steam or smoke comingfrom the engine compartment, to
avoid injury do not open the hood.
SPA0387
HOOD3-8
Pre-driving checks and adjustments
Z
01.1.31/R50-D
X

KEY OPERATION1. Turn the key counterclockwise to unlock the
back door.
2. Pull the opener handle to open the back
door.
3. To lock the back door, push it down firmly
and turn the key clockwise.IAlways check the back door has been
closed securely to prevent it from
opening while driving.IDo not drive with the back door open.
This could allow dangerous exhaust
gases to be drawn into the vehicle.
See ªPrecautions when starting and
drivingº in the ª5. Starting and driv-
ingº section for exhaust gas.
When opening the back door, first open the
spare tire carrier in the sequence shown in the
illustration above. Then insert the stopper into
the hole to secure the carrier in the open
position.IBe certain that there is adequate area
to allow the carrier to open fully.
IOpen and close the spare tire carrier
slowly.
SPA0462
SPA0385
BACK DOOR SPARE TIRE CARRIER
Pre-driving checks and adjustments
3-9
Z
01.1.31/R50-D
X

IBefore driving, be certain that the
spare tire carrier is firmly closed and
latched.
IFailure to do so may injure pedestri-
ans or damage the vehicle.To open the rear window, turn the key fully
clockwise and pull the opener handle. To
close, lower and push the rear window down
securely.
Do not drive with the rear window open.
This could allow dangerous exhaust
gases to be drawn into the vehicle. See
ªPrecautions when starting and drivingº
in the ª5. Starting and drivingº section
for exhaust gas.
Do not open the rear window unless the
wiper is in the stowed position.
SPA0386
SPA0338
REAR WINDOW
3-10
Pre-driving checks and adjustments
Z
01.1.31/R50-D
X

OPENER OPERATION
Opener leverTo open the fuel filler lid, push the opener lever
down. To lock, close the fuel filler lid securely.
FUEL FILLER CAPThe fuel filler cap is a screw-on ratcheting
type. Tighten the cap clockwise until ratcheting
clicks are heard.IGasoline is extremely flammable and
highly explosive under certain condi-
tions. You could be burned or seri-
ously injured if it is misused or mis-
handled. Always stop the engine and
do not smoke or allow open flames orsparks near the vehicle when refuel-
ing.
IFuel may be under pressure. Turn the
cap one-half turn, and wait for any
hissing sound to stop to prevent fuel
from spraying out and possible per-
sonal injury. Then remove the cap.
IDo not attempt to top off the fuel tank
after the fuel pump nozzle shuts off
automatically. Continued refueling
may cause fuel over-flow, resulting in
fuel spray and possibly a fire.
IUse only a genuine NISSAN fuel filler
cap as a replacement. It has a built-in
safety valve needed for proper opera-
tion of the fuel system and emission
control system. An incorrect cap can
result in a serious malfunction and
possible injury.
INever pour fuel into the throttle body
to attempt to start your vehicle.
SPA0389
SPA0341
FUEL FILLER LID
Pre-driving checks and adjustments
3-11
Z
01.1.31/R50-D
X

IIf fuel is spilled on the vehicle body,
flush it away with water to avoid paint
damage.
ITighten until cap clicks, failure to
tighten fuel cap properly may cause
the
malfunction indicator light
(MIL) to illuminate. If this occurs, it
will be necessary to take your vehicle
in for service by an authorized
NISSAN dealer.
Put the fuel filler cap on the cap holder while
refueling.
SPA0342
3-12
Pre-driving checks and adjustments
Z
01.1.31/R50-D
X

TILT OPERATIONWhile pushing down on the lock lever, adjust
the steering wheel up or down to the desired
position. Push the lock lever up securely to
lock the steering wheel in place.Do not adjust the steering wheel while
driving. You could lose control of your
vehicle and cause an accident.
USING THE SUN VISORS1. To block out glare from the front, swing
down the main sun visor.
2. To block glare from the side, remove the
main sun visor from the center mount and
swing it to the side.
3. Then, to block glare from the front too,
swing down the sub-sun visor.
4. To adjust the glare block position, slide the
sub-sun visor to the left.IDo not store the main sun visor be-
fore storing the sub-sun visor.
IDo not pull the sub-sun visor forcedly
downwards.
SPA0394
SPA0395
STEERING WHEEL SUN VISORS
Pre-driving checks and adjustments
3-13
Z
01.1.31/R50-D
X

INSIDE MIRRORThe night position will reduce glare from the
headlights of vehicles behind you at night.Use the night position only when neces-
sary, because it reduces rear view
clarity.
OUTSIDE MIRRORSPush the right or left end of the switch to adjust
the right or left side mirror, then control the
lever.
Objects viewed in the outside mirror on
the passenger side are closer than they
appear. Be careful when moving to the
right. Using only this mirror could cause
an accident. Use inside mirror or glance
over your shoulder to properly judge
distances to other objects.
PD1006M
SPA0112A
PD1183MB
MIRRORS3-14
Pre-driving checks and adjustments
Z
01.1.31/R50-D
X

The outside mirror can be moved in any direc-
tion for a better rear view.
FOLDING OUTSIDE MIRRORPush the mirror backward to fold it.
M008
Pre-driving checks and adjustments
3-15
Z
01.1.31/R50-D
X
