NISSAN QUEST 2017 RE52 / 4.G Quick Reference Guide

9
POWER SLIDING DOOR RELEASE
(if so equipped)
Use one of the following methods to open the
power sliding doors:
Press the driver’s side 1 or the passenger’s
side
2 button on the Nissan Intelligent Key®
for approximately 1 second.
From the driver’s seat, push the driver’s side
3 or passenger’s side 4 sliding door
switch for about 0.5 seconds. The switches are
located on the driver’s side instrument panel.


Pull the sliding door handle (inside or outside) until you hear the chime.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Pre-driving checks and
adjustments (section 3)” of your Owner’s Manual.
43
1
2
2512696_17a_Quest_US_pQRG_092016.indd 99/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

10
FRONT POWER SEAT ADJUSTMENTS (if so equipped)
To slide the seat forward or backward, push the switch
1 forward or backward.
To adjust the angle of the seatback, push the switch
2 forward or backward.
POWER SEAT LIFTER (driver’s seat)
To raise or lower the height of the seat, push the switch 1 up or down.
To raise or lower the front portion of the seat, push the front or back end of the switch
1 up or down.
POWER LUMBAR SUPPORT (driver’s seat)
To adjust the seat lumbar area, push the front or back portion of the switch 3.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system
(section 1)” of your Owner’s Manual.
123
POWER LIFTGATE RELEASE (if so equipped)
Use one of the following methods to open
the lif tgate:

Press the button 1 on the Nissan
Intelligent Key® for more than 1 second.


Once unlocked, push the lif tgate opener switch
2 while carrying the
Intelligent Key with you (that
is, in your pocket or purse).


From inside the vehicle, push the power lif tgate switch
3 located on the instrument
panel to the lef t of the steering wheel.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Pre-driving checks and
adjustments (section 3)” of your Owner’s Manual.
1
3
2
FIRST DRIVE FEATURES
2512696_17a_Quest_US_pQRG_092016.indd 109/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

11
FOLDING THE 2ND ROW SEATS
Secure the seat belts on the seat belt hooks
1 on the side wall.
To fold down the seatbacks, pull the lever
2 on the 2nd row seat.
To return the seatbacks, lif t up each
seatback and push it to the upright position
until it is latched.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Safety — Seats, seat belts
and supplemental restraint system (section 1)” of your
Owner’s Manual.
1
2
2ND ROW SEAT ADJUSTMENTS
To slide the seat forward or backward, pull the lever
1 up and hold it while you
slide the seat forward or backward to the
desired position.
Release the lever 1 to lock the seat in position.
To adjust the angle of the seatback, pull the lever 2 up and lean back. To bring
the seatback forward, pull the lever up and lean your body forward.
Release the lever 2 to lock the seatback in position. Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system
(section 1)” of your Owner’s Manual.
ENTERING/EXITING THE 3RD ROW SEATS
The 2nd row seats can tilt and slide
forward for easy entry and exit to and from
the 3
rd row seats.
To enter or exit the 3rd row seat, pull the lever
1 or 2 up to tilt down the seatback and
slide the seat forward.
Return and lock the 2nd row seats by sliding
the seats to the rearmost position and tilting
up the seatback af ter use.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Safety — Seats, seat belts
and supplemental restraint system (section 1)” of your
Owner’s Manual.1
2
2
1
2512696_17a_Quest_US_pQRG_092016.indd 119/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

12
3RD ROW SEAT ADJUSTMENTS
To adjust the angle of the seatback, pull the strap
1 on the seatback and lean back.
Release the strap at the desired angle.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Safety — Seats, seat belts
and supplemental restraint system (section 1)” of your Owner’s Manual.1
AUTOMATIC DRIVE POSITIONER (if so equipped)
Two positions for the driver’s seat and outside mirrors can be stored in the
automatic drive positioner memory.
Follow this procedure to set the memory positions:



•

C
onfirm the shif t lever is in the P (PARK) position.



•

Plac
e the ignition switch in the ON position.



•

A
djust the driver’s seat and outside mirrors to the desired positions using the
adjusting switches for each feature.



•

Push the
SET switch, and within 5 seconds, push the memory switch (1 or 2) for
at least 1 second.



• The indic
ator light on the memory switch you select will illuminate for
approximately 5 seconds.



• The driv
er’s seat and outside mirror positions are now set to your preferences.
These memoriz ed positions can also be linked to your Nissan Intelligent Key®. To
link a memorized position to your Intelligent Key, press the unlock button on the
key fob af ter completing the previous step.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your
Owner’s Manual.
3RD ROW POWER FOLDING SEATS (if so equipped)
To fold the power 3rd row seats, push the front
side of the switch
1 located on the right
or lef t side of the cargo area. The
corresponding 3
rd row seatback will be folded
down automatically.
Push and hold the r ear side of the switch 2.
A beep will sound and the rear seatback will
rise up while you are holding the switch. A beep will sound when the seatback is
returned to its fully upright position.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system
(section 1)” of your Owner’s Manual.
12
FIRST DRIVE FEATURES
2512696_17a_Quest_US_pQRG_092016.indd 129/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

13
OUTSIDE MIRROR CONTROL SWITCH
To select the right or lef t side mirror, turn the control switch
1 right or lef t.
To adjust the mirror angle, move the control switch
1 up, down, right or lef t.
To prevent accidentally moving the mirror, turn and set the switch to the center
(neutral) position.
REVERSE TILT-DOWN FEATURE (if so equipped)
The reverse tilt-down feature will turn both of the outside mirror surfaces downward
to provide better rear visibility close to the vehicle.



1.
Place the ignition switch in the ON position.



2.

Choose either the right or lef
t outside mirror by operating the outside mirror
control switch
1.



3.

Move the shif t lever to the R (REVERSE) position.



4.

Both outside mirror surfaces will turn downward.
The outside mirror surfaces will return to their original positions when one of the
following conditions has occurred:



•

The shif t lever is moved to any position other than R (REVERSE).



•

The outside mirror control switch is set to the center (neutral) position.



•

The ignition switch is placed in the OFF position.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of
your Owner’s Manual.
1
STARTING/STOPPING THE ENGINE
It is impor tant to make sure the Nissan
Intelligent Key® is with you (that is, in your
pocket or purse).
Depress the brake pedal.



•

If the br
ake pedal is not depressed,
pushing the ignition switch once enters the
ACC mode.



•

If the ignition switch is pushed a sec
ond time, the vehicle will enter the ON mode.
Press the ignition switch START/STOP button to start the engine.
TURNING THE ENGINE OFF
Move the shif t lever to the P (PARK) position and apply the parking brake.
Press the ignition switch START/STOP button to turn the engine off.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
2512696_17a_Quest_US_pQRG_092016.indd 139/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

14
HEADLIGHT CONTROL SWITCH
HEADLIGHT CONTROL
Turn the headlight control switch to the
position 1 to turn on the front parking,
side marker, tail, license plate and instrument
panel lights. Turn the switch to the

position
2 to turn on the headlights.
AUTOLIGHT SYSTEM (if so equipped)
The autolight system wil l automatically turn the headlights on when it is dark
and off when it is light. The system will keep the headlights on for a period of
time af ter you turn the ignition off and all doors are closed.
To activate the autolight system, turn the headlight control switch to the AUTO
position
3 then place the ignition switch in the ON position. To deactivate the
autolight system, turn the headlight control switch to the OFF position,

position 1 or position 2.
HIGH BEAM SELECT
With the he adlights ON (either in the AUTO
or
position), push the headlight control
switch forward
4 to select the high beam
function. The blue indicator light will
illuminate in the instrument panel. Pull the
headlight switch back to the original position
to select the low beam
. The blue indicator
light will extinguish.
Pull and release the headlight control switch
5 to flash the headlight high beams
on and off.
FOG LIGHT SWITCH (if so equipped)
The headlights must be on and the low beams
selected for the fog lights to operate.
Turn the switch (inside collar) to the
position
6 to turn the fog lights on.
Turn the switch (inside collar) to the OFF position to turn the fog lights off.
LANE CHANGE SIGNAL
Move the lever up or down until the turn signal begins to flash but the lever does not latch to signal a lane change. Hold the lever until the lane change is
completed.
Move the lever up or down until the turn signal begins to flash but the lever does not latch and release the lever. The turn signal will automatically flash three times.
Choose the appr opriate method to signal a lane change based on the road and
traffic conditions.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
1
3
2
45
6
FIRST DRIVE FEATURES
2512696_17a_Quest_US_pQRG_092016.indd 149/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

15
WIPER AND WASHER SWITCH
Move the lever to one of the following positions to operate the front
windshield wipers:
1 Mist ( MIST) – One sweep operation of the
front wipers.
2 Intermittent (INT) – To operate intermittently, push the lever down. The
intermittent speed can be adjusted by
twisting the time control ring
3 to
increase or decrease wiper speed.
4 Low ( LO) – Front wipers operate at a
continuous low-speed.
5 High ( HI) – Front wipers operate at a
continuous high-speed.
6 Front washer – Pull the lever toward
you to activate the front washer. The
front wipers will operate several times.
REAR WIPER AND WASHER
7 Intermittent (INT) – Rear wiper operates intermittently.
8 Low ( ON) – Rear wiper operates at a
continuous low-speed.
9 Rear washer – Push the lever forward to activate the rear washer. The
rear wiper will operate several times.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
1
2
4
5
MIST
OFFINT
LO
HI
69
3
INT
ON7
8
2512696_17a_Quest_US_pQRG_092016.indd 159/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

16
HEATER AND AIR CONDITIONER (automatic) (if so equipped)
1 AUTO BUTTON
The automatic mode may be used year-round. Press the AUTO button to turn
the system on. The system will automatically control the inside temperature
(automatic cooling and/or dehumidified heating), air flow distribution
and fan speed.
2 FAN SPEED CONTROL BUTTON
Press the fan speed control button to manually adjust the fan speed
down – or up +.
3 DRIVER’S SIDE TEMPERATURE CONTROL BUTTONS
Press the driver’s side temperature control buttons up for warmer air or
down
for cooler air.
4 MODE BUT TON
Press the MODE button to cycle through the following air flow outlets:



Air flows from the center and side vents.



Air flo ws from the center, side and foot vents.



Air flo ws mainly from the foot vents.



Air flo ws from the front defroster and foot vents.
5 PASSENGER’S SIDE TEMPERATURE CONTROL BUTTONS
Press the passenger’s side temperature control buttons up for warmer air
or down
for cooler air.
6 DUAL BUTTON
Press the DU AL button to turn the passenger’s side temperature controls
on or off. This will allow the passenger’s side temperature to be adjusted
independently from the driver’s side by pressing the passenger’s side
temperature control buttons.
97810
3
4
5
6
11311122
FIRST DRIVE FEATURES
2512696_17a_Quest_US_pQRG_092016.indd 169/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

17
7 AIR RECIRCULATION BUTTON
Press the air recirculation button to recirculate interior air inside the
vehicle. The indicator light on the button will illuminate. This system is used to
avoid certain outside odors and to help adjust the inside vehicle temperature
more effectively.
The air recirculation mode cannot be activated when the climate control system is in the front defroster mode
FRONT or in the front defroster and
foot vent mode
.8 AUTO-RECIRCULATION BUTTON
Press the auto-recirculation button AUTO to switch to the automatic air
intake control mode. The indicator light on the button will illuminate.
In this mode, the sensor detects certain odors and gases to
automatically switch between the air recirculation mode and the outside air
circulation mode.
The auto-r ecirculation mode cannot be activated when the air flow control
is in the front defroster mode
FRONT or in the front defroster and foot
outlet mode
.9 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Press the front defroster button FRONT to turn the system on.
The A/C automatically turns on when the front defroster mode is selected.
This feature removes humidity from the air.
Press the temperature control buttons or to set the desired temperature.
To defrost the front and side windows quickly, set the temperature controls
and fan speed controls to their maximum settings.
10 DEFROSTING REAR WINDOW AND OUTSIDE MIRRORS (if so equipped)
Push the r ear window defroster switch REAR to turn the system on or off.
This function automatically turns off af ter approximately 15 minutes.
11 A/C BUTTON
Press the A/C button to turn the air conditioner system on or off. This system
helps cool and dehumidify the air inside the cabin and defog the windows.
12 REAR BUT TON
To control the rear automatic air conditioning system with the front air
conditioner control panel, press the REAR button.
When the r ear automatic air conditioning
system is on, the indicator light on the REAR
button will illuminate and the front display
will switch to the rear air conditioner screen.
To adjust the front air conditioning system, press the REAR button again or wait 10 seconds.
The rear passenger controls are unavailable when REAR is shown on
the front display.
13 ON•OFF BUT TON
Press the ON•OFF button to turn the climate control system on or off.Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” and the“Monitor, heater, air
conditioner, audio, phone and voice recognition systems (section 4)” of your Owner’s Manual.
2512696_17a_Quest_US_pQRG_092016.indd 179/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

18
65
3
12
FM/AM/SiriusXM® SATELLITE RADIO WITH CD/DVD PLAYER
(if so equipped)
1 ON•OFF BUTTON/VOL (volume) CONTROL KNOB
Press the ON•OFF button to turn the system on or off.
Turn the VO L (volume) control knob right or lef t to increase or decrease
the volume.
2 AUDIO BUTTON/TUNE/FOLDER KNOB
Press the AUDIO button to go to the audio settings screen.
To manually tune the radio, turn the TUNE/FOLDER knob lef t or right.
3 SEEK/CAT AND TRACK BUTTONS
To scan quickly and stop at the previous or next broadcast station, press the
SEEK/CAT button or the TRACK button.
For satellite radio, press the SEEK/CAT button or the TRACK button to
switch to the first channel of the previous or next category.
To change tracks on a CD, press the SEEK/CAT button or the
TRACK
button.
To rewind or fast forward a track on a CD, press and hold the SEEK/CAT
button or the TRACK
button.
4 STATION SELECT BUTTONS
Twelve stations can be set for the FM band, six for the AM band and 18 for satellite radio.
To store a station in a preset, you must first select a radio band by pressing the FM•AM button
5 or XM button 6 then tune to the desired FM, AM or
satellite radio station.
Next press and hold the desired station select button (1-6) until the sound is briefly muted. The channel indicator will then display, and the sound will
resume. Programing is now complete.
To retrieve a previously set station, select the radio band where the preset was stored then press the corresponding station select button (1-6).
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Monitor, heater, air conditioner, audio, phone and voice recognition
systems (section 4)” of your Owner’s Manual.
4
FIRST DRIVE FEATURES
2512696_17a_Quest_US_pQRG_092016.indd 189/20/16 4:47 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
