UNIFIED METER AND A/C AMP
DI-27
C
D
E
F
G
H
I
J
L
MA
B
DI
UNIFIED METER AND A/C AMPPFP:27760
System DescriptionBKS001SK
For the unified meter and A/C amp., the signal required for con-
trolling the combination meter are integrated in the A/C auto
amp.
Unified meter and A/C amp. controls each operation for A/C
auto amp. For information regarding A/C control, refer to AT C -
24, "AIR CONDITIONER CONTROL" .
Unified meter and A/C amp. inputs necessary information for
combination meter from each unit by CAN communication and
so on.
And unified meter and A/C amp. outputs these signals using
communication line (TX, RX) between unified meter and A/C
amp. and combination meter.
The signals required for the distance to empty (DTE) display are centralized in the unified meter and A/C
amp., converted into data, and sent to the display unit (with display unit) using CAN communication.
Other input signals are also sent to the ECM, TCM, BCM and display unit (with display unit) using CAN
communication.
The unified meter and A/C amp. correspond a CONSULT-II function (self-diagnostic results, CAN diag-
nostic support monitor and data monitor).
INPUT/OUTPUT SIGNALS
Between Unified Meter and A/C amp. and Combination Meter
SKIB0778E
Unit Input Output
Unified meter and A/C amp.
Seat belt buckle switch signal (Driver's side)
Parking brake signal
Illumination control nighttime required signal
Refuel status signal
Low-fuel warning lamp condition signal
Combination meter receive error signal
Delivery destination data signal
Combination meter specifications signal
Vehicle speed signal (8-pulse)
Engine speed signal
Engine coolant temperature signal
Fuel level sensor signal (resistance value)
Malfunction indicator lamp signal
ABS warning lamp signal
Brake warning lamp signal
KEY warning lamp signal (With Intelligent Key)
LOCK warning lamp signal (With Intelligent Key)
High-beam request signal
Turn indicator signal
VDC OFF indicator lamp signal (With VDC)
SLIP indicator lamp signal (With VDC)
ASCD CRUISE indicator lamp signal
ASCD SET indicator lamp signal
A/T position indicator signal
A/T CHECK warning lamp signal
CVT indicator lamp signal
CVT position indicator signal
Door switch signal
Oil pressure switch signal
Position lights request signal
Front fog light request signal
Rear fog light request signal
Buzzer output signal
