POWER STEERING FLUIDPFP:KLF20
Checking Fluid LevelBGS0003P

Check fluid level with the engine stopped.

Make sure that fluid level is between MIN and MAX.

Fluid levels at HOT and COLD are different. Do not confuse
them.
CAUTION:

The fluid level should not exceed the MAX line. Excessive
fluid will cause fluid leakage from the cap.

Do not reuse drained power steering fluid.
Checking Fluid LeakageBGS0003Q
Check hydraulic connections for fluid leakage, cracks, damage,
looseness, or wear.
1. Run engine until the fluid temperature reaches 50 to 80°C
(122 to 176°F) in reservoir tank, and keep engine speed idle.
2. Turn steering wheel several times from full left stop to full right
stop.
3. Hold steering wheel at each lock position for five seconds and
carefully, check for fluid leakage.
CAUTION:
Do not hold the steering wheel in a locked position for more
than 10 seconds. (There is the possibility that oil pump may
be damaged.)
4. If fluid leakage at connections is noticed, then loosen flare nut and then retighten. Do not overtighten con-
nector as this can damage O-ring, washer and connector.
5. If fluid leakage from oil pump is noticed, check oil pump. Refer to PS-29, "
POWER STEERING OIL
PUMP" .
6. Check steering gear boots for accumulation of fluid, indicating from steering gear.
Air Bleeding Hydraulic SystemBGS0003R
If air bleeding is not complete, the following symptoms can be observed.

Bubbles are created in reservoir tank.

Clicking noise can be heard from oil pump.

Excessive buzzing in oil pump.
NOTE:
Fluid noise may occur in the steering gear or oil pump. This does not affect performance or durability of
the system.
1. Turn steering wheel several times from full left stop to full right stop with engine off.
CAUTION:
Filling reservoir tank with fluid so as not to lower fluid level below the MIN line while steering
wheel turning.
2. Start engine and hold steering wheel at each lock position for 3 seconds at idle to check for fluid leakage.
3. Repeat step 2 above several times at approximately 3 second intervals.
CAUTION:
Do not hold the steering wheel in a locked position for more than 10 seconds. (There is the possi-
bility that oil pump may be damaged.)
4. Check fluid for bubbles and white contamination.
5. Stop engine if bubbles and white contamination do not drain out. Perform steps 2 to 3 above after waiting
until bubbles and white contamination drain out.HOT : Fluid temperature 50 – 80°C (122 – 176°F)
COLD : Fluid temperature 0 – 30°C (32 – 86°F)
SGIA0232J
SGIA0506E

PS-8
POWER STEERING FLUID

6. Stop the engine, and then check fluid level.

STEERING WHEEL
PS-9
C
D
E
F
H
I
J
K
L
MA
B
PS

STEERING WHEELPFP:48430
On-Vehicle Inspection and ServiceBGS0003S
CHECKING CONDITION OF INSTALLATION

Check installation conditions of steering gear assembly, front suspension assembly, axle and steering col-
umn assembly.

Check if movement exists when steering wheel is moved up and down, to the left and right and to the axial
direction.

Check steering gear assembly mounting nut and bolts for looseness. Refer to PS-17, "COMPONENTS" .
CHECKING STEERING WHEEL PLAY

Turn steering wheel so that front wheels come to the straight-ahead position. Start engine and lightly turn
steering wheel to the left and right until front wheels start to move. Measure steering wheel movement on
the outer circumference.

When the measurement value is outside the standard value, check backlash for each joint of steering col-
umn assembly and installation condition of power steering gear assembly.
CHECKING NEUTRAL POSITION STEERING WHEEL

Make sure that steering gear assembly, steering column and steering wheel are installed in the correct
position.

Perform neutral position inspection after wheel alignment. Refer to FSU-5, "Wheel Alignment Inspection" .

Set vehicle to the straight-ahead position and confirm steering wheel is in the neutral position.

Loosen outer socket lock nut and turn inner socket to left and right equally to make fine adjustments if
steering wheel is not in the neutral position.
CHECKING STEERING WHEEL TURNING FORCE
1. Park vehicle on a level and dry surface, set parking brake.
2. Start engine.
3. Bring power steering fluid up to adequate operating temperature. [Make sure temperature of fluid is
approximately 50 to 80°C (122 to 176°F).]
NOTE:
Tires need to be inflated normal pressure.
4. Check steering wheel turning force when steering wheel has
been turned 360° from neutral position.
NOTE:
Multiply the distance L from the hook of spring balance to the
center of steering wheel by the measurement value with a spring
balance.
5. If steering wheel turning force is out of the specification, check
rack sliding force and relief hydraulic pressure of oil pump.
Regarding relief hydraulic pressure of oil pump, refer to PS-29,
"CHECKING RELIEF OIL PRESSURE" .
a. Disconnect lower shaft and steering knuckle from steering gear assembly. Refer to FAX-5, "
COMPO-
NENT" , PS-12, "COMPONENTS" .
b. Start and run engine at idle to make sure steering fluid has reached normal operating temperature.Steering wheel axial end play : 0 mm (0 in)
Steering wheel play : 0 – 35 mm (0 – 1.38 in)
Steering wheel turning force
: Less than 45 N (4.6 kg, 10 lb)
SGIA1615E

PS-10
STEERING WHEEL

c. While pulling outer socket slowly in ±11.5 mm (±0.453 in) range
from neutral position, make sure rack sliding force is within
specification.
d. If rack sliding force is not within specification, overhaul steering
gear assembly.
CHECKING FRONT WHEEL TURNING ANGLE

Check front wheel turning angle after toe-in inspection. Place
front wheels on turning radius gauges and rear wheels on
stands. Check the maximum inner and outer wheel turning
angles for LH and RH road wheels.

With the engine at idle, turn steering wheel from full left stop to
full right stop and measure the turning angles.

Measure rack stroke if angles are outside the specified value.

Disassemble steering gear assembly to check the cause that
rack stroke is outside of the standard.

Steering angles are not adjustable. Check steering gear assem-
bly, steering column assembly and front suspension compo-
nents for wear or damage if any of the turning angles are
different from the specified value. Replace any of them, if any
non-standard condition exists.Rack sliding force
: 210.6 – 269.4 N (21.5 – 27.5 kg, 47 – 61 lb)
SST090B
FAA0016D
Tire size 205/65R16 215/55R17
Inner wheel (Angle: A)Minimum 37°00′ (37.0°)33°00′ (33.0°)
Nominal 41°00′ (41.0°)37°00′ (37.0°)
Maximum 42°00′ (42.0°)38°00′ (38.0°)
Outer wheel (Angle: B) 33°00′ (33.0°)31°00′ (31.0°)
SGIA0055E
Tire size 205/65R16 215/55R17
Rack stroke L 73.5 mm (2.894 in) 68.5 mm (2.697 in)
SGIA0629J

STEERING WHEEL
PS-11
C
D
E
F
H
I
J
K
L
MA
B
PS

Removal and InstallationBGS0003T
REMOVAL
NOTE:
When reconnecting spiral cable, fix cable with a tape so that fixing case and rotating part keep aligned. This
will omit neutral position alignment procedure during spiral cable installation.
1. Set vehicle to the straight-ahead direction.
2. Remove driver air bag module. Refer to SRS-35, "
DRIVER AIR BAG MODULE" .
3. Remove steering wheel lock nut after steering is locked.
4. Remove steering wheel with the steering wheel puller [SST].
INSTALLATION
Installation is the reverse order of removal. For tightening torque, refer to PS-12, "COMPONENTS" .
NOTE:
Check the spiral cable neutral position after replacing or rotating spiral cable. Refer to SRS-38, "
INSTALLA-
TION" .
CAUTION:
Do not twist spiral cable freely on excessively after it becomes tight (doing so may cause the cable to
be turn off).
SGIA0080E

PS-12
STEERING COLUMN

STEERING COLUMNPFP:48810
Removal and InstallationBGS0003U
COMPONENTS
CAUTION:

Do not give axial impact to steering column assembly during removal and installation.

Do not move steering gear assembly when removing steering column assembly.
REMOVAL
1. Set vehicle to the straight-ahead position.
2. Remove driver air bag module. Refer to SRS-35, "
Removal and Installation" .
3. Remove steering wheel. Refer to PS-11, "
Removal and Installation" .
4. Remove steering column cover (upper and lower), steering lock escutcheon and instrument driver lower
cover. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
5. Remove combination switch & spiral cable. Refer to SRS-37, "
Removal and Installation" .
6. Disconnect each switch connectors installed to steering column assembly, and then disconnect harness
from steering column assembly.
7. Remove the clip, then remove lower cover.
1. Steering wheel 2. Combination switch & spiral cable 3. Steering column assembly
4. Hole cover seal 5. Clamp 6. Hole cover
7. Lower shaft 8. Lower cover
SGIA0952E

STEERING COLUMN
PS-13
C
D
E
F
H
I
J
K
L
MA
B
PS

8. Remove fixing nut and bolt, then separate lower shaft from
steering column assembly (joint part).
9. Remove steering column assembly mounting nuts, then remove
steering column assembly from vehicle.
10. Loosen clamp, and then remove hole cover seal from hole
cover.
11. Remove mounting nuts of hole cover, and then remove clamp
and hole cover from dash panel.
12. Raise vehicle.
13. Remove fixing bolt of lower shaft, and then remove lower shaft
from vehicle.
INSPECTION AFTER REMOVAL

Check component parts for damage or other malfunctions. Replace if there are.

Measure the length L as shown in the figure if vehicle has been
involved in a minor collision. Replace steering column assembly
if outside the standard.

Measure steering column assembly rotating torque using pre-
load gauge [SST: ST3127S000]. Replace steering column
assembly if outside the standard.
SGIA0993E
SGIA0953E
Steering column length L : 510.5 mm (20.10 in)
Rotating torque : 0 – 0.27 N·m (0 – 0.02 kg-m)
SGIA0986E

PS-14
STEERING COLUMN

INSTALLATION

Installation is the reverse order of removal. For tightening torque, refer to PS-12, "COMPONENTS" .

Install steering column assembly with tilt neutral condition to steering column assembly. Start installation
from vehicle front at this time.

When installing lower shaft to steering gear assembly, follow the procedure listed below.
–Set rack of steering gear in the neutral position.
NOTE:
To get the neutral position of rack, turn pinion assembly and measure the distance of inner socket, and
then measure the intermediate position of the distance.
–Align rear cover cap projection (A) with the marking position (B)
of gear housing assembly.
–Install slit part of lower shaft (C) aligning with the projection (A)
of rear cover cap (1). Make sure that the slit part of lower shaft
(C) is aligned with both the projection (A) of rear cover cap (1)
and the marking position (B) of gear housing assembly.
INSPECTION AFTER INSTALLATION
Make sure that steering wheel operates smoothly by turning several times from full left stop to full right stop.
SGIA1140E

STEERING COLUMN
PS-15
C
D
E
F
H
I
J
K
L
MA
B
PS

Disassembly and AssemblyBGS0003V
COMPONENTS
DISASSEMBLY
1. Remove spring from jacket tube assembly and column mounting bracket.
2. Remove the TORX bolt (securing tilt lever), then remove tilt lever and adjusting nut from jacket tube
assembly.
3. Remove column mounting bracket from jacket tube assembly.
INSPECTION AFTER DISASSEMBLY

Check jacket tube assembly for deformation or damage. Replace if there are.

Check tilt mechanism components for malfunction. Replace if there are.
ASSEMBLY

Assembly is the reverse order of the disassembly. For tightening torque, refer to PS-15, "COMPONENTS"
.

Tighten TORX nut (for securing tilt lever) to the specified torque
so that tilt lever locks when tilt lever turns from unlock to lock.
Refer to PS-15, "
COMPONENTS" .
1. Jacket tube assembly 2. Column mounting bracket 3. Spring
4. Adjusting nut 5. Tilt lever
SGIA0994E
SGIA0992E

PS-16
STEERING COLUMN

INSPECTION AFTER ASSEMBLY
Check tilt mechanism operating range.
Operating range L : 31.5 mm (1.240 in)
SGIA1616E
