NISSAN TEANA 2003 Service Manual

TROUBLE DIAGNOSIS
ATC-103
C
D
E
F
G
H
I
K
L
MA
B
AT C

2. CHECK CIRCUIT CONTINUITY BETWEEN SUNLOAD SENSOR AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector.
3. Check continuity between sunload sensor harness connector
M61 terminal 2 and unified meter and A/C amp. harness con-
nector M45 terminal 49.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3. CHECK SUNLOAD SENSOR
1. Reconnect sunload sensor connector and unified meter and A/C amp. connector.
2. Refer to ATC-104, "
Sunload Sensor" .
OK or NG
OK >> 1. Replace unified meter and A/C amp.
2. Go to self-diagnosis AT C - 4 7 , "
FUNCTION CONFIRMATION PROCEDURE" and perform self-
diagnosis STEP-2. Confirm that code No. 20 is displayed.
NG >> 1. Replace sunload sensor.
2. Go to self-diagnosis AT C - 4 7 , "
FUNCTION CONFIRMATION PROCEDURE" and perform self-
diagnosis STEP-2. Confirm that code No. 20 is displayed.
4. CHECK CIRCUIT CONTINUITY BETWEEN SUNLOAD SENSOR AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector.
3. Check continuity between sunload sensor harness connector
M61 terminal 1 and display and A/C auto amp. harness connec-
tor M45 terminal 50.
4. Check continuity between sunload sensor harness connector
M61 terminal 1 and ground.
OK or NG
OK >> 1. Replace unified meter and A/C amp.
2. Go to self-diagnosis AT C - 4 7 , "
FUNCTION CONFIRMATION PROCEDURE" and perform self-
diagnosis STEP-2. Confirm that code No. 20 is displayed.
NG >> Repair harness or connector.2 – 49 : Continuity should exist.
RJIA2028E
1 – 50 : Continuity should exist.
1 – Ground : Continuity should not exist.
RJIA2029E

ATC-104
TROUBLE DIAGNOSIS

COMPONENT INSPECTION
Sunload Sensor
Measure voltage between unified meter and A/C amp. harness con-
nector M45 terminal 50 and ground.

When checking sunload sensor, select a place where sun shines directly on it.
If NG, replace sunload sensor.
RJIA3280E
SHA930E

TROUBLE DIAGNOSIS
ATC-105
C
D
E
F
G
H
I
K
L
MA
B
AT C

Intake Sensor CircuitBJS000GF
COMPONENT DESCRIPTION
Intake Sensor
The intake sensor is located on the heater & cooling unit assembly. It
converts temperature of air after it passes through the evaporator
into a resistance value which is then input to the unified meter and A/
C amp.
DIAGNOSIS PROCEDURE FOR INTAKE SENSOR
SYMPTOM: Intake sensor circuit is open or shorted. (24 or −24 is
indicated on unified meter and A/C amp. as a result of performing
self-diagnosis STEP-2.)
1. CHECK VOLTAGE BETWEEN INTAKE SENSOR AND GROUND
1. Disconnect intake sensor connector.
2. Turn ignition switch ON.
3. Check voltage between intake sensor harness connector M256
terminal 1 and ground.
OK or NG
OK >> GO TO 2.
NG >> GO TO 4.
2. CHECK CIRCUIT CONTINUITY BETWEEN INTAKE SENSOR AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector.
3. Check continuity between intake sensor harness connector
M256 terminal 2 and unified meter and A/C amp. harness con-
nector M45 terminal 49.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
RJIA3281E
RJIA1458E
1 – Ground : Approx. 5 V
RJIA1809E
2 – 49 : Continuity should exist.
RJIA1810E

ATC-106
TROUBLE DIAGNOSIS

3. CHECK INTAKE SENSOR
Refer to ATC-106, "
Intake Sensor" .
OK or NG
OK >> 1. Replace unified meter and A/C amp.
2. Go to self-diagnosis AT C - 4 7 , "
FUNCTION CONFIRMATION PROCEDURE" and perform self-
diagnosis STEP-2. Confirm that code No. 20 is displayed.
NG >> 1. Replace intake sensor.
2. Go to self-diagnosis AT C - 4 7 , "
FUNCTION CONFIRMATION PROCEDURE" and perform self-
diagnosis STEP-2. Confirm that code No. 20 is displayed.
4. CHECK CIRCUIT CONTINUITY BETWEEN INTAKE SENSOR AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector.
3. Check continuity between intake sensor harness connector
M256 terminal 1 and unified meter and A/C amp. harness con-
nector M45 terminal 41.
4. Check continuity between intake sensor harness connector
M256 terminal 1 and ground.
OK or NG
OK >> 1. Replace unified meter and A/C amp.
2. Go to self-diagnosis AT C - 4 7 , "
FUNCTION CONFIRMATION PROCEDURE" and perform self-
diagnosis STEP-2. Confirm that code No. 20 is displayed.
NG >> Repair harness or connector.
COMPONENT INSPECTION
Intake Sensor
After disconnecting intake sensor connector M256, measure resis-
tance between terminals 1 and 2 at sensor side. Refer to the table
below.
If NG, replace intake sensor.1 – 41 : Continuity should exist.
1 – Ground : Continuity should not exist.
RJIA1811E
Temperature °C (°F) Resistance kΩ
−15 (5) 18.63
−10 (14) 14.14
−5 (23) 10.85
0 (32) 8.40
5 (41) 6.57
10 (50) 5.18
15 (59) 4.12
20 (68) 3.30
25 (77) 2.66
30 (86) 2.16
35 (95) 1.77
40 (104) 1.46
45 (113) 1.21
RJIA3282E

A/C CONTROLLER
ATC-107
C
D
E
F
G
H
I
K
L
MA
B
AT C

A/C CONTROLLERPFP:27500
Removal and Installation of A/C and AV SwitchBJS000H4
REMOVAL
Refer to AV- 1 5 , "Removal and Installation of Audio Unit" (Integrated display system) or AV- 3 4 , "Removal and
Installation of Audio Unit" (Integrated color display system).
INSTALLATION
Installation is basically the reverse order of removal.

ATC-108
AUTO AMP

AUTO AMPPFP:27760
Removal and Installation of Unified Meter and A/C Amp.BJS000H6
REMOVAL
Refer to AV- 1 5 , "Removal and Installation of Audio Unit" (Integrated display system) or AV- 3 4 , "Removal and
Installation of Audio Unit" (Integrated color display system).
INSTALLATION
Installation is basically the reverse order of removal.

AMBIENT SENSOR
ATC-109
C
D
E
F
G
H
I
K
L
MA
B
AT C

AMBIENT SENSORPFP:27722
Removal and InstallationBJS000H7
REMOVAL
1. Remove engine undercover.
2. Disconnect ambient sensor connector, and then remove ambi-
ent sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA2180E

ATC-110
IN-VEHICLE SENSOR

IN-VEHICLE SENSORPFP:27720
Removal and InstallationBJS000H8
REMOVAL
1. Remove instrument driver lower panel. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove mounting screw, and then remove in-vehicle sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA3291E

SUNLOAD SENSOR
ATC-111
C
D
E
F
G
H
I
K
L
MA
B
AT C

SUNLOAD SENSORPFP:27721
Removal and InstallationBJS000H9
REMOVAL
1. Remove sunload sensor garnish.
2. Disconnect sunload sensor connector, and then remove sunload
sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA3279E

ATC-112
INTAKE SENSOR

INTAKE SENSORPFP:27723
Removal and InstallationBJS000HA
REMOVAL
1. Remove low-pressure pipe 2 and high-pressure pipe 2. Refer to ATC-140, "Removal and Installation of
Low-pressure Pipe 2 and High-pressure Pipe 2" .
CAUTION:
Cap or wrap the joint of the pipe with suitable material such as vinyl tape to avoid the entry of air.
2. Slide evaporator to passenger side, and then remove intake
sensor.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:

Replace O-rings of A/C piping with new ones, and then apply compressor oil to it when installing
it.

Mark the mounting position of intake sensor bracket prior to removal so that the reinstalled sen-
sor can be located in the same position.

Female-side piping connection is thin and easy to deform. Slowly insert the male-side piping
straight in axial direction.

Insert piping securely until a click is heard.

After piping connection is completed, pull male-side piping by hand to make sure that connection
does not come loose.

When recharging refrigerant, check for leaks.
RJIA3281E
