ABBREVIATIONS
GI-13
< HOW TO USE THIS MANUAL >
C
D
E
F
G
H
I
J
K
L
MB
GI
N
O
PABBREVIATIONS
Abbreviation ListINFOID:0000000003852769
The following ABBREVIATIONS are used:
ABBREVIATION DESCRIPTION
A/C Air Conditioner
A/T Automatic Transaxle/Transmission
ATF Automatic Transmission Fluid
D
1Drive range 1st gear
D
2Drive range 2nd gear
D
3Drive range 3rd gear
D
4Drive range 4th gear
FR, RR Front, Rear
LH, RH Left-Hand, Right-Hand
M/T Manual Transaxle/Transmission
OD Overdrive
P/S Power Steering
SAE Society of Automotive Engineers, Inc.
SDS Service Data and Specifications
SST Special Service Tools
2WD 2-Wheel Drive
2
22nd range 2nd gear
2
12nd range 1st gear
1
21st range 2nd gear
1
11st range 1st gear

GI-26
< PRECAUTION >
PRECAUTIONS
 Before starting repairs which do not require battery power:
Turn off ignition switch.
Disconnect the negative battery terminal.
 If the battery terminals are disconnected, recorded memory of
radio and each control unit is erased.
 To prevent serious burns:
Avoid contact with hot metal parts.
Do not remove the radiator cap when the engine is hot.
 Dispose of drained oil or the solvent used for cleaning parts in an
appropriate manner.
 Do not attempt to top off the fuel tank after the fuel pump nozzle
shuts off automatically.
Continued refueling may cause fuel overflow, resulting in fuel spray
and possibly a fire.
 Clean all disassembled parts in the designated liquid or solvent
prior to inspection or assembly.
 Replace oil seals, gaskets, packings, O-rings, locking washers,
cotter pins, self-locking nuts, etc. with new ones.
 Replace inner and outer races of tapered roller bearings and needle bearings as a set.
 Arrange the disassembled parts in accordance with their assembled locations and sequence.
 Do not touch the terminals of electrical components which use microcomputers (such as ECM).
Static electricity may damage internal electronic components.
 After disconnecting vacuum or air hoses, attach a tag to indicate the proper connection.
 Use only the fluids and lubricants specified in this manual.
 Use approved bonding agent, sealants or their equivalents when required.
 Use hand tools, power tools (disassembly only) and recommended
special tools where specified for safe and efficient service repairs.
 When repairing the fuel, oil, water, vacuum or exhaust systems,
check all affected lines for leaks.
 Before servicing the vehicle:
Protect fenders, upholstery and carpeting with appropriate covers.
Take caution that keys, buckles or buttons do not scratch paint.
WARNING:
To prevent ECM from storing the diagnostic trouble codes, do not carelessly disconnect the harness
connectors which are related to the engine control system and TCM (transmission control module)
SEF289H
SGI233
PBIC0190E
SGI234

TM-138
< PRECAUTION >[CVT: RE0F09B]
PRECAUTIONS
Precaution
INFOID:0000000003849071
Turn ignition switch OFF and disconnect negative battery
cable before connecting or disconnecting the TCM harness
connector. Because battery voltage is applied to TCM even if
ignition switch is turned OFF.
When connecting or disconnecting pin connectors into or
from TCM, do not damage pin terminals (bend or break).
Check that there are not any bends or breaks on TCM pin ter-
minal, when connecting pin connectors.
Perform TCM input/output signal inspection and check
whether TCM functions normally or not before replacing TCM.
TM-111, "
Reference Value".
Perform “DTC Confirmation Procedure” after performing each
TROUBLE DIAGNOSIS.
If the repair is completed the DTC should not be displayed in
the “DTC Confirmation Procedure”.
 Always use the specified brand of CVT fluid. Refer to MA-11, "
Flu-
ids and Lubricants".
 Use lint-free paper, not cloth rags, during work.
 Dispose of the waste oil using the methods prescribed by law, ordi-
nance, etc. after replacing the CVT fluid.
Service Notice or PrecautionINFOID:0000000003849072
OBD SELF-DIAGNOSIS
 CVT self-diagnosis is performed by the TCM in combination with the ECM. The results can be read through
the blinking pattern of the Malfunction Indicator (MI). Refer to the table on TM-37, "
CONSULT-III Function
(TRANSMISSION)" for the indicator used to display each self-diagnostic result.
 The self-diagnostic results indicated by the MI are automatically stored in both the ECM and TCM memories.
SEF289H
SEF291H
MEF040DA
SAT652J

TM-300
< PRECAUTION >[CVT: RE0F10A]
PRECAUTIONS
Turn ignition switch OFF and disconnect negative battery
cable before connecting or disconnecting the TCM harness
connector. Because battery voltage is applied to TCM even if
ignition switch is turned OFF.
When connecting or disconnecting pin connectors into or
from TCM, do not damage pin terminals (bend or break).
Check that there are not any bends or breaks on TCM pin ter-
minal, when connecting pin connectors.
Perform TCM input/output signal inspection and check
whether TCM functions normally or not before replacing TCM.
Refer to TM-275, "
Reference Value".
Perform “DTC Confirmation Procedure” after performing each
TROUBLE DIAGNOSIS.
If the repair is completed the DTC should not be displayed in
the “DTC Confirmation Procedure”.
 Always use the specified brand of CVT fluid. Refer to MA-11, "
Flu-
ids and Lubricants".
 Use lint-free paper, not cloth rags, during work.
 Dispose of the waste oil using the methods prescribed by law, ordi-
nance, etc. after replacing the CVT fluid.
Service Notice or PrecautionINFOID:0000000003806500
OBD SELF-DIAGNOSIS
 CVT self-diagnosis is performed by the TCM in combination with the ECM. The results can be read through
the blinking pattern of the Malfunction Indicator (MI). Refer to the table on TM-204, "
CONSULT-III Function
(TRANSMISSION)" for the indicator used to display each self-diagnostic result.
 The self-diagnostic results indicated by the MI are automatically stored in both the ECM and TCM memories.
Always perform the procedure on TM-202, "
Diagnosis Description" to complete the repair and avoid
unnecessary blinking of the MIL.
For details of OBD, refer to EC-102, "
Diagnosis Description".
SEF289H
SEF291H
MEF040DA
SAT652J
