< COMPONENT DIAGNOSIS >
BCM (BODY CONTROL MODULE)
REQ SW -RRNOTE:
The item is indicated, but not monitored. Off
REQ SW -BD/TRTrunk lid opener request switch is not pressed Off
Trunk lid opener request switch is pressed On
PUSH SWPush-button ignition switch (push switch) is not pressed Off
Push-button ignition switch (push switch) is pressed On
IGN RLY2 -F/BIgnition switch in OFF or ACC position Off
Ignition switch in ON position On
CLUCH SWNOTE:
The item is indicated, but not monitored. Off
BRAKE SW 1The brake pedal is not depressed On
The brake pedal is depressed Off
DETE/CANCL SWSelector lever in P position Off
Selector lever in any position other than P On
SFT PN/N SWSelector lever in any position other than P and N Off
Selector lever in P or N position On
S/L -LOCKSteering is locked Off
Steering is unlocked On
S/L -UNLOCKSteering is unlocked Off
Steering is locked On
S/L RELAY-F/BIgnition switch in OFF or ACC position Off
Ignition switch in ON position On
UNLK SEN -DRDriver door is unlocked Off
Driver door is locked On
PUSH SW -IPDMPush-button ignition switch (push-switch) is not pressed Off
Push-button ignition switch (push-switch) is pressed On
IGN RLY1 -F/BIgnition switch in OFF or ACC position Off
Ignition switch in ON position On
DETE SW -IPDMSelector lever in P position Off
Selector lever in any position other than P On
SFT PN -IPDMSelector lever in any position other than P and N Off
Selector lever in P or N position On
SFT P -METSelector lever in any position other than P Off
Selector lever in P position On
SFT N -METSelector lever in any position other than N Off
Selector lever in N position On
ENGINE STATEEngine stopped Stop
While the engine stalls Stall
At engine cranking Crank
Engine running Run
S/L LOCK-IPDMSteering is locked Off
Steering is unlocked On
S/L UNLK-IPDMSteering is unlocked Off
Steering is locked On Monitor Item Condition Value/Status

BCM (BODY CONTROL MODULE)
ADP-97
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
K
L
MA
B
ADP
N
O
P
111
(L/Y)GroundSteering lock unit
communicationInput/
OutputSteering lockLOCK status Battery voltage
LOCK or UNLOCK
For 15 seconds after UN-
LOCKBattery voltage
15 seconds or later after
UNLOCK0 V
11 3
(P/B)Ground Optical sensor InputIgnition switch
ONWhen bright outside of
the vehicleClose to 5 V
When dark outside of the
vehicleClose to 0 V
11 5
(L)Ground Shock sensor Input Ignition switchOFF 0 V
ACC 5.0 V
ON
2.5 V
11 6
(R/W)GroundFuse check (Stop
lamp switch)Input — Battery voltage
11 8
(O/L)Ground Stop lamp switch Input Stop lamp switchOFF (Brake pedal is not
depressed)0 V
ON (Brake pedal is de-
pressed)Battery voltage
11 9
(G/W)GroundFront door lock as-
sembly driver side
(unlock sensor)Input Driver doorLOCK status (unlock sen-
sor switch OFF)
1.1 V
UNLOCK status (unlock
sensor switch ON)0 V
121
(Y)Ground Key slot switch InputWhen the key is inserted into key slot Battery voltage
When the key is not inserted into key slot 0 V
122
(V/R)Ground ACC feedback Input Ignition switchOFF 0 V
ACC or ON Battery voltage
123
(G/W)Ground IGN feedback Input Ignition switchOFF or ACC 0 V
ON Battery voltage Te r m i n a l N o .
(Wire color)Description
ConditionVa l u e
(Approx.)
Signal nameInput/
Output +–
JMKIA0066GB
JPMIA1034GB
JPMIA0012GB

AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-61
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
NOTE:
*:On-board self-diagnosis is not supported. Only CONSULT-III is supported.
STARTING PROCEDURE
1. Start the engine.
2. Turn the audio system OFF.
3. While pressing the “SETTING” button, turn the volume control
dial clockwise or counterclockwise for 40 clicks or more. (When
the self-diagnosis mode is started, a short beep will be heard.)
 Shifting from current screen to previous screen is performed
by pressing “BACK” button.
4. The trouble diagnosis initial screen is displayed, and then the
items of “Self Diagnosis” and “Confirmation/Adjustment” can be
selected.
SELF-DIAGNOSIS MODE
1. Start the self-diagnosis function and select “Self Diagnosis”.
- Self-diagnosis subdivision screen is displayed, and the self-diagnosis mode starts.
- The bar graph visible on the center of the self-diagnosis subdivision screen indicates progress of the trou-
ble diagnosis.
Confirmation/
AdjustmentDisplay DiagnosisThe following check functions are available: color tone check by color
bar display, light and shade check by grey scale display and touch panel
calibration response check.
Vehicle SignalsDiagnosis of signals can be performed for vehicle speed, parking brake,
lights, ignition switch, and reverse.
Speaker Test The connection of a speaker can be confirmed by test tone.
Climate Control
*Not used.
Error HistoryThe system malfunction and the frequency when occurred in the past are
displayed. When the malfunctioning item is selected, the time and place
that the selected malfunction last occurred are displayed.
Camera Cont.It can perform the confirmation of a signal connection to the camera con-
trol unit, the calibration of each camera, Correct Draw Line of Camera
Image, and Fine Tuning of Birds-Eye View.
Refer to AV- 6 0 , "
Diagnosis Description".
Vehicle CAN Diagnosis The transmitting/receiving of CAN communication can be monitored.
AV COMM DiagnosisThe communication condition of each unit of Multi AV system can be
monitored.
Delete Unit Connection Log Erase the connection history of unit and error history.
Initialize Settings Initializes the AV control unit memory.Mode Description
JSNIA1285GB
JSNIA0138GB

AV-64
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
The tint of the color bar indication is as per the following list if RGB signal error is detected.
Vehicle Signals
A comparison check can be made of each actual vehicle signal and
the signals recognized by the system.
Speaker Test
Select “SPEAKER DIAGNOSIS” to display the Speaker Diagnosis
screen. Press “START and NEXT” to generate a test tone in a
speaker. Press “Start” to generate a test tone in the next speaker.
Press “End” to stop the test tones.
NOTE:
The frequency of test tone emitted from each speaker is as follows.
Climate Control
On-board self-diagnosis is not supported. Only CONSULT-III is supported.
Refer to HAC-156, "
WITHOUT INTELLIGENT AIR CONDITIONER SYSTEM : CONSULT-III Function"for
details.
Camera Cont.
Refer to AV-56, "System Description".
Error History
R (red) signal error : Light blue (Cyan) tint
G (green) signal error : Purple (Magenta) tint
B (blue) signal error : Yellow tint
JSNIA0149GB
Diagnosis item Display Vehicle status Remarks
Vehicle speedON Vehicle speed > 0 km/h (0 MPH)
Changes in indication may be delayed by approximately
1.5 seconds. This is normal. OFF Vehicle speed = 0 km/h (0 MPH)
Parking brakeON Parking brake is applied.
OFF Parking brake is released.
LightsON Light switch ON
Block the light beam from the auto light optical sensor.
OFF Light switch OFF
IgnitionON Ignition switch ON
—
OFF Ignition switch in ACC position
ReverseONShift the selector lever to “R” posi-
tion
Changes in indication may be delayed by approximately
1.5 seconds. This is normal.
OFFShift the selector lever other than
“R” position
Squawker : 3 kHz
Front speaker : 300 Hz
Rear speaker : 1 kHz
JSNIA0150GB

AV-70
< FUNCTION DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DATA MONITOR
ALL SIGNALS
 Displays the status of the following vehicle signals inputted to the AV control unit.
 For each signal, actual signal can be compared with the condition recognized on the system.
SELECTION FROM MENU
 AV COMM CIRCUIT [U1300]
 REAR-CAMERA LAN CONN [U1252]With rear control switch
When either one of the following items is
detected:
 camera control unit power supply and
ground circuits are malfunctioning.
 AV communication signal between AV
control unit and Camera control unit is
malfunctioning.
 AV communication circuits between mul-
tifunction switch and rear control switch
are malfunctioning.
 AV communication circuits between rear
control switch and camera control unit
are malfunctioning. Camera control unit power supply and
ground circuits
Refer to AV- 8 4 , "
CAMERA CONTROL
UNIT : Diagnosis Procedure".
 AV communication circuits between mul-
tifunction switch and rear control switch
 AV communication circuits between rear
control switch and camera control unit
Without rear control switch
When either one of the following items is
detected:
 camera control unit power supply and
ground circuits are malfunctioning.
 AV communication circuits between AV
control unit and camera control unit is
malfunctioning.
 AV communication signal between AV
control unit and camera control unit is
malfunctioning.  Camera control unit power supply and
ground circuits
Refer to AV- 8 4 , "
CAMERA CONTROL
UNIT : Diagnosis Procedure".
 AV communication circuits between mul-
tifunction switch and camera control unit
 AV COMM CIRCUIT [U1300]
 SWITCH CONN [U1240]
 REAR-CAMERA LAN CONN [U1252]When either one of the following items is
detected:
 AV communication circuits between AV
control unit and multifunction switch are
malfunctioning.
 AV communication signal between AV
control unit and multifunction switch is
malfunctioning.AV communication circuits between AV
control unit and multifunction switch Error item Detection logic Possible malfunction factor/Action to take
Display Item Display Vehicle status Remarks
VHCL SPD SIGOn Vehicle speed >0 km/h (0 MPH)
Changes in indication may be delayed. This is
normal. Off Vehicle speed =0 km/h (0 MPH)
PKB SIGOn Parking brake is applied.
Off Parking brake is released.
ILLUM SIGOnBlock the light beam from the auto
light optical sensor when the light
switch is ON .
—
OffExpose the auto light optical sensor
to light when the light switch is OFF
or ON.
IGN SIGOn Ignition switch ON
Off Ignition switch in ACC position
REV SIGOn Selector lever in R position
Changes in indication may be delayed. This is
normal.
OffSelector lever in any position other
than R

AV-106
< ECU DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
AV CONTROL UNIT
ECU DIAGNOSIS
AV CONTROL UNIT
Reference ValueINFOID:0000000003897072
VALUES ON THE DIAGNOSIS TOOL
CONSULT-III data monitor item
TERMINAL LAYOUT
PHYSICAL VALUES
Display ItemDis-
playVehicle status Remarks
VHCL SPD SIGOn Vehicle speed >0 km/h (0 MPH)
Changes in indication may be delayed. This is nor-
mal.
Off Vehicle speed =0 km/h (0 MPH)
PKB SIGOn Parking brake is applied.
Changes in indication may be delayed. This is nor-
mal.
Off Parking brake is released.
ILLUM SIGOn Light switch ON.
—
Off Light switch OFF.
IGN SIGOn Ignition switch ON.
—
Off Ignition switch in ACC position.
REV SIGOn Selector lever in R position.
Changes in indication may be delayed. This is nor-
mal.
OffSelector lever in any position other
than R.
JSNIA1440ZZ

AV
AV CONTROL UNIT
AV-111
< ECU DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
*:Stereo sounds are input only when the 2 channel stereo sound is played.96
(B)97
(R)AUX sound signal LH InputIgnition
switch
ONAUX sound input.
101
(BR)Ground Switch ground —Ignition
switch
ON—0 V
103
(SB)Ground Disk eject signal InputIgnition
switch
ONPressing the eject switch. 0 V
Except for above. 3.3 V
104
(O)Ground Ignition signal InputIgnition
switch
ON— Battery voltage
105
(P/B)Ground Reverse signal InputIgnition
switch
ONSelector lever in R position. 12.0 V
Other than selector lever in
R position.0 V
106
(G/R)Ground Parking brake signal InputIgnition
switch
ONParking brake ON. 0 V
Parking brake OFF.
107
(V/W)GroundVehicle speed signal
(8-pulse)InputIgnition
switch
ONWhen vehicle speed is ap-
prox. 40 km/h (25MPH).NOTE:
The maximum voltage varies de-
pending on the specification
(destination unit).
111 — S h i e l d — — — —Te r m i n a l
(Wire color)Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
SKIB3609E
JSNIA0007GB
JSNIA0012GB

AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-201
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
NOTE:
*:On-board self-diagnosis is not supported. Only CONSULT-III is supported.
STARTING PROCEDURE
1. Start the engine.
2. Turn the audio system OFF.
3. While pressing the “SETTING” button, turn the volume control
dial clockwise or counterclockwise for 40 clicks or more. (When
the self-diagnosis mode is started, a short beep will be heard.)
 Shifting from current screen to previous screen is performed
by pressing “BACK” button.
4. The trouble diagnosis initial screen is displayed, and then the
items of “Self Diagnosis” and “Confirmation/Adjustment” can be
selected.
SELF-DIAGNOSIS MODE
1. Start the self-diagnosis function and select “Self Diagnosis”.
- Self-diagnosis subdivision screen is displayed, and the self-diagnosis mode starts.
- The bar graph visible on the center of the self-diagnosis subdivision screen indicates progress of the trou-
ble diagnosis.
Confirmation/
AdjustmentDisplay DiagnosisThe following check functions are available: color tone check by color
bar display, light and shade check by grey scale display and touch panel
calibration response check.
Vehicle SignalsDiagnosis of signals can be performed for vehicle speed, parking brake,
lights, ignition switch, and reverse.
Speaker Test The connection of a speaker can be confirmed by test tone.
Climate Control
*Not used.
Error HistoryThe system malfunction and the frequency when occurred in the past are
displayed. When the malfunctioning item is selected, the time and place
that the selected malfunction last occurred are displayed.
Camera Cont.It can perform the confirmation of a signal connection to the camera con-
trol unit, the calibration of each camera, Correct Draw Line of Camera
Image, and Fine Tuning of Birds-Eye View.
Refer to AV- 2 0 0 , "
Diagnosis Description".
Vehicle CAN Diagnosis The transmitting/receiving of CAN communication can be monitored.
AV COMM DiagnosisThe communication condition of each unit of Multi AV system can be
monitored.
Delete Unit Connection Log Erase the connection history of unit and error history.
Initialize Settings Initializes the AV control unit memory.Mode Description
JSNIA1285GB
JSNIA0138GB

AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-205
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P Display Diagnosis
The tint of the color bar indication is as per the following list if RGB signal error is detected.
Vehicle Signals
A comparison check can be made of each actual vehicle signal and
the signals recognized by the system.
Sp ea ke r Tes t
JSNIA0688GB
R (red) signal error : Light blue (Cyan) tint
G (green) signal error : Purple (Magenta) tint
B (blue) signal error : Yellow tint
JSNIA0149GB
Diagnosis item Display Vehicle status Remarks
Vehicle speedON Vehicle speed > 0 km/h (0 MPH)
Changes in indication may be delayed by approximately
1.5 seconds. This is normal. OFF Vehicle speed = 0 km/h (0 MPH)
Parking brakeON Parking brake is applied.
OFF Parking brake is released.
LightsON Light switch ON
Block the light beam from the auto light optical sensor.
OFF Light switch OFF
IgnitionON Ignition switch ON
—
OFF Ignition switch in ACC position
ReverseONShift the selector lever to “R” posi-
tion
Changes in indication may be delayed by approximately
1.5 seconds. This is normal.
OFFShift the selector lever other than
“R” position
