BL-1
BODY, LOCK & SECURITY SYSTEM
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION BL
A
B
BL
Revision: June 20062007 Versa PRECAUTIONS .......................................................... 5
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 5
Precautions Necessary for Steering Wheel Rotation
After Battery Disconnect .......................................... 5
OPERATION PROCEDURE ................................. 5
Precautions for Procedures without Cowl Top Cover ..... 6
Precautions for Work ................................................ 6
PREPARATION ........................................................... 7
Special service tool .................................................. 7
Commercial Service Tools ........................................ 7
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 8
Work Flow ................................................................ 8
CUSTOMER INTERVIEW ..................................... 8
DUPLICATE THE NOISE AND TEST DRIVE ....... 9
CHECK RELATED SERVICE BULLETINS ........... 9
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 9
REPAIR THE CAUSE ........................................... 9
CONFIRM THE REPAIR ..................................... 10
Generic Squeak and Rattle Troubleshooting ......... 10
INSTRUMENT PANEL ........................................ 10
CENTER CONSOLE ........................................... 10
DOORS ............................................................... 10
TRUNK .................................................................11
SUNROOF/HEADLINING ....................................11
OVERHEAD CONSOLE (FRONT AND REAR) ....11
SEATS ..................................................................11
UNDERHOOD ......................................................11
Diagnostic Worksheet ............................................ 12
HOOD ....................................................................... 14
Fitting Adjustment .................................................. 14
FRONT END HEIGHT ADJUSTMENT AND LAT-
ERAL/LONGITUDINAL CLEARANCE ADJUST-
MENT .................................................................. 14
SURFACE MISMATCH ADJUSTMENT .............. 14
Removal and Installation ........................................ 15
HOOD ASSEMBLY ............................................. 15
HOOD HINGE ..................................................... 16Removal and Installation of Hood Lock Control ..... 17
REMOVAL ........................................................... 17
INSTALLATION ................................................... 18
Hood Lock Control Inspection ................................ 19
RADIATOR CORE SUPPORT .................................. 20
Removal and Installation ........................................ 20
REMOVAL ........................................................... 20
INSTALLATION ................................................... 21
FRONT FENDER ...................................................... 22
Removal and Installation ........................................ 22
REMOVAL ........................................................... 22
INSTALLATION ................................................... 22
POWER DOOR LOCK SYSTEM .............................. 23
Component Parts and Harness Connector Location ... 23
System Description ................................................. 24
LOCK OPERATION ............................................. 24
UNLOCK OPERATION ........................................ 24
OUTLINE ............................................................. 25
CAN Communication System Description .............. 25
Schematic ............................................................... 26
WITHOUT INTELLIGENT KEY SYSTEM ............ 26
Wiring Diagram — D/LOCK — ............................... 27
WITHOUT INTELLIGENT KEY SYSTEM ............ 27
Schematic ............................................................... 31
WITH INTELLIGENT KEY SYSTEM ................... 31
Wiring Diagram — D/LOCK — ............................... 32
WITH INTELLIGENT KEY SYSTEM ................... 32
Terminals and Reference Value for BCM ............... 37
Work Flow ............................................................... 37
CONSULT–II Function (BCM) ................................ 37
CONSULT–II START PROCEDURE ................... 37
WORK SUPPORT ............................................... 37
DATA MONITOR ................................................. 37
ACTIVE TEST ..................................................... 38
Trouble Diagnoses Symptom Chart ....................... 39
BCM Power Supply and Ground Circuit ................. 40
Door Switch Check ................................................. 40
Key Switch (Insert) Check ...................................... 43
Door Lock and Unlock Switch Check ..................... 45
Front Door Lock Assembly LH (Actuator) Check .... 48

SQUEAK AND RATTLE TROUBLE DIAGNOSES
BL-11
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa
TRUNK
Trunk noises are often caused by a loose jack or loose items put into the trunk by the owner.
In addition look for:
1. Trunk lid bumpers out of adjustment
2. Trunk lid striker out of adjustment
3. The trunk lid torsion bars knocking together
4. A loose license plate or bracket
Most of these incidents can be repaired by adjusting, securing or insulating the item(s) or component(s) caus-
ing the noise.
SUNROOF/HEADLINING
Noises in the sunroof/headlining area can often be traced to one of the following:
1. Sunroof lid, rail, linkage or seals making a rattle or light knocking noise
2. Sun visor shaft shaking in the holder
3. Front or rear windshield touching headliner and squeaking
Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these
incidents. Repairs usually consist of insulating with felt cloth tape.
OVERHEAD CONSOLE (FRONT AND REAR)
Overhead console noises are often caused by the console panel clips not being engaged correctly. Most of
these incidents are repaired by pushing up on the console at the clip locations until the clips engage.
In addition look for:
1. Loose harness or harness connectors.
2. Front console map/reading lamp lense loose.
3. Loose screws at console attachment points.
SEATS
When isolating seat noise it's important to note the position the seat is in and the load placed on the seat when
the noise is present. These conditions should be duplicated when verifying and isolating the cause of the
noise.
Cause of seat noise include:
1. Headrest rods and holder
2. A squeak between the seat pad cushion and frame
3. The rear seatback lock and bracket
These noises can be isolated by moving or pressing on the suspected components while duplicating the con-
ditions under which the noise occurs. Most of these incidents can be repaired by repositioning the component
or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then
transmitted into the passenger compartment.
Causes of transmitted underhood noise include:
1. Any component mounted to the engine wall
2. Components that pass through the engine wall
3. Engine wall mounts and connectors
4. Loose radiator mounting pins
5. Hood bumpers out of adjustment
6. Hood striker out of adjustment
These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best
method is to secure, move or insulate one component at a time and test drive the vehicle. Also, engine RPM
or load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or
insulating the component causing the noise.

BL-236
BODY REPAIR
Revision: June 20062007 Versa
1. Roof panel assembly
2. Rear roof rail assembly
3. 4th roof rail assembly
4. 3rd roof rail assembly
5. 2nd roof rail assembly
6. 1st roof rail assembly
7. Front roof rail assembly
8. Sun roof assembly
9. Front roof rail assembly (if equipped with sunroof)
10. Roof side rail reinforcement (RH & LH)
11. Inner center pillar (RH & LH)
12. Hood assembly
13. Center pillar reinforcement (RH & LH)
14. Front pillar inner (RH & LH)
15. Front pillar upper reinforcement (RH & LH)
16. Front pillar lower reinforcement (RH & LH)
17. Fender (RH & LH)
18. Side body (RH & LH)
19. Side body assembly (RH & LH)
20. Outer sill (RH & LH)
21. Outer sill reinforcement (RH & LH)
22. Front door assembly (RH & LH)
23. Outer front door panel (RH & LH)
24. Outer rear door panel (RH & LH)
25. Rear door assembly (RH & LH)
26. Rear fender (RH & LH)
27. Rear fender assembly (RH & LH)
28. Rear fender corner (RH & LH)
29. Rear fender extension (RH & LH)
30. Rear combination lamp base (RH & LH)
31. Rear pillar inner reinforcement (RH & LH)
32. Rear wheel housing outer (RH & LH)
33. Rear wheel housing inner (RH & LH)
34. Rear spring base assembly (RH & LH)
35. Rear seatback hinge bracket (RH & LH)
36. Rear seatback catch bracket (RH & LH)
37. Rear pillar inner (RH & LH)
38. Rear roof rail reinforcement (RH & LH)
39. Rear roof rail brace (RH & LH)
40. Rear panel inner reinforcement (RH & LH)
41. Rear panel support bracket
42. Rear panel
43. Rear bumper fascia lower bracket
44. Rear bumper fascia upper bracket
45. Rear bumper fascia center bracket
46. Rear end crossmember
47. Rear panel assembly

EI-1
EXTERIOR & INTERIOR
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION EI
A
B
EI
Revision: June 20062007 Versa PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions .............................................................. 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 4
SQUEAK AND RATTLE TROUBLE DIAGNOSIS ...... 5
Work Flow ................................................................ 5
CUSTOMER INTERVIEW ..................................... 5
DUPLICATE THE NOISE AND TEST DRIVE ....... 6
CHECK RELATED SERVICE BULLETINS ........... 6
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 6
REPAIR THE CAUSE ........................................... 6
CONFIRM THE REPAIR ....................................... 7
Generic Squeak and Rattle Troubleshooting ........... 7
INSTRUMENT PANEL .......................................... 7
CENTER CONSOLE ............................................. 7
DOORS ................................................................. 7
TRUNK .................................................................. 8
SUNROOF/HEADLINING ..................................... 8
OVERHEAD CONSOLE (FRONT AND REAR) ..... 8
SEATS ................................................................... 8
UNDERHOOD ....................................................... 8
Diagnostic Worksheet .............................................. 9
CLIP AND FASTENER ..............................................11
Description ..............................................................11
FRONT BUMPER ..................................................... 14
Removal and Installation ........................................ 14
REMOVAL ........................................................... 15
INSTALLATION ................................................... 16
REAR BUMPER ....................................................... 17
Removal and Installation ........................................ 17
REMOVAL ........................................................... 18
INSTALLATION ................................................... 18FRONT GRILLE ........................................................ 19
Removal and Installation ........................................ 19
REMOVAL ........................................................... 19
INSTALLATION ................................................... 19
COWL TOP ............................................................... 20
Removal and Installation ........................................ 20
REMOVAL ........................................................... 20
INSTALLATION ................................................... 21
FENDER PROTECTOR ............................................ 22
Components ........................................................... 22
Removal and Installation ........................................ 22
FRONT FENDER PROTECTOR ......................... 22
REAR FENDER PROTECTOR ........................... 22
ROOF SIDE MOLDING ............................................. 23
Removal and Installation ........................................ 23
REMOVAL ........................................................... 23
INSTALLATION ................................................... 23
DOOR OUTSIDE MOLDING ..................................... 24
Components ........................................................... 24
Removal and Installation ........................................ 24
FRONT DOOR OUTSIDE MOLDING .................. 24
REAR DOOR OUTSIDE MOLDING .................... 25
REAR DOOR CORNER COVER ........................ 25
CENTER MUD GUARD ............................................ 26
Removal and Installation ........................................ 26
REMOVAL ........................................................... 26
INSTALLATION ................................................... 26
DOOR FINISHER ...................................................... 27
Removal and Installation ........................................ 27
FRONT DOOR .................................................... 27
REAR DOOR ....................................................... 29
BACK DOOR TRIM ................................................... 31
Removal and Installation ........................................ 31
REMOVAL ........................................................... 31
INSTALLATION ................................................... 31

EI-8
SQUEAK AND RATTLE TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
Tapping or moving the components or pressing on them while driving to duplicate the conditions can isolate
many of these incidents. You can usually insulate the areas with felt cloth tape or insulator foam blocks from
the NISSAN Squeak and Rattle Kit (J-43980) to repair the noise.
TRUNK
Trunk noises are often caused by a loose jack or loose items put into the trunk by the owner.
In addition look for:
1. Trunk lid bumpers out of adjustment
2. Trunk lid striker out of adjustment
3. The trunk lid torsion bars knocking together
4. A loose license plate or bracket
Most of these incidents can be repaired by adjusting, securing or insulating the item(s) or component(s) caus-
ing the noise.
SUNROOF/HEADLINING
Noises in the sunroof/headlining area can often be traced to one of the following:
1. Sunroof lid, rail, linkage or seals making a rattle or light knocking noise
2. Sun visor shaft shaking in the holder
3. Front or rear windshield touching headliner and squeaking
Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these
incidents. Repairs usually consist of insulating with felt cloth tape.
OVERHEAD CONSOLE (FRONT AND REAR)
Overhead console noises are often caused by the console panel clips not being engaged correctly. Most of
these incidents are repaired by pushing up on the console at the clip locations until the clips engage.
In addition look for:
1. Loose harness or harness connectors.
2. Front console map/reading lamp lens loose.
3. Loose screws at console attachment points.
SEATS
When isolating seat noise it's important to note the position the seat is in and the load placed on the seat when
the noise is present. These conditions should be duplicated when verifying and isolating the cause of the
noise.
Cause of seat noise include:
1. Headrest rods and holder
2. A squeak between the seat pad cushion and frame
3. The rear seatback lock and bracket
These noises can be isolated by moving or pressing on the suspected components while duplicating the con-
ditions under which the noise occurs. Most of these incidents can be repaired by repositioning the component
or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then
transmitted into the passenger compartment.
Causes of transmitted underhood noise include:
1. Any component installed on the engine wall
2. Components that pass through the engine wall
3. Engine wall mounts and connectors
4. Loose radiator pins
5. Hood bumpers out of adjustment
6. Hood striker out of adjustment
These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best
method is to secure, move or insulate one component at a time and test drive the vehicle. Also, engine RPM
or load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or
insulating the component causing the noise.

EI-40
HEADLINING
Revision: June 20062007 Versa
REMOVAL
1. Remove the negative and positive battery cables.
2. Remove front seat assembly RH/LH. Refer to SE-12, "
Removal and Installation" .
3. Remove rear seat cushion and rear seatback. Refer to SE-15, "
Removal and Installation" .
4. Remove front seat belt shoulder anchor RH/LH. Refer to SB-3, "
Removal and Installation of Front Seat
Belt" .
5. Remove center console body assembly. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
6. Remove front pillar garnish RH/LH. Refer to EI-33, "
FRONT PILLAR GARNISH" .
7. Remove antenna feeder cable clip, then disconnect antenna
feeder cable connector.
8. Remove front and rear kicking plate inner RH/LH, center pillar lower garnish, center pillar upper garnish,
front and rear body side welt RH/LH. Refer to EI-32, "
Removal and Installation" .
WAR NIN G:
Do not reuse center pillar upper garnish if removed.
9. Remove back door weatherstrip. Refer to EI-31, "
BACK DOOR TRIM" .
10. Release the clips using a suitable tool, then remove the front
and rear assist grips.
11. Remove the sunvisor caps and screws, then remove sunvisor RH/LH.
12. Remove sunvisor holders RH/LH by rotating 45 degrees, then
pulling outward.
1. Headlining 2. Assist grip 3. Sunvisor
4. Cap 5. Sunvisor holder 6. Roof console retainer
7. Roof console/map lamp assembly 8. Antenna feeder cable 9. Room lamp
10. Dual lock fastener 11. Room lamp harness 12. Insulator
13. Finisher A. With sunroof B. Without sunroof
Metal clip Clip C103⇐Vehicle front
PIIB2583J
PIIB2584J
PIIB3982J

GW-1
GLASSES, WINDOW SYSTEM & MIRRORS
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION GW
A
B
GW
Revision: June 20062007 Versa PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions for Procedures without Cowl Top Cover ..... 3
Handling for Adhesive and Primer ........................... 3
PREPARATION ........................................................... 4
Commercial Service Tools ........................................ 4
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 5
Work Flow ................................................................ 5
CUSTOMER INTERVIEW ..................................... 5
DUPLICATE THE NOISE AND TEST DRIVE ....... 6
CHECK RELATED SERVICE BULLETINS ........... 6
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 6
REPAIR THE CAUSE ........................................... 6
CONFIRM THE REPAIR ....................................... 7
Generic Squeak and Rattle Troubleshooting ........... 7
INSTRUMENT PANEL .......................................... 7
CENTER CONSOLE ............................................. 7
DOORS ................................................................. 7
TRUNK .................................................................. 8
SUNROOF/HEADLINING ..................................... 8
OVERHEAD CONSOLE (FRONT AND REAR) ..... 8
SEATS ................................................................... 8
UNDERHOOD ....................................................... 8
Diagnostic Worksheet .............................................. 9
WINDSHIELD GLASS ...............................................11
Removal and Installation .........................................11
REMOVAL ............................................................11
INSTALLATION ................................................... 12
OPERA WINDOW GLASS ....................................... 13
Removal and Installation ........................................ 13
REMOVAL ........................................................... 13
INSTALLATION ................................................... 13
REAR WINDOW GLASS AND MOLDING ............... 15
Removal and Installation ........................................ 15
REMOVAL ........................................................... 15
INSTALLATION ................................................... 16
POWER WINDOW SYSTEM .................................... 17Component Parts and Harness Connector Location ... 17
System Description ................................................. 17
MANUAL OPERATION ........................................ 18
AUTO OPERATION ............................................. 20
POWER WINDOW LOCK ................................... 21
RETAINED POWER OPERATION ...................... 21
CAN Communication System Description .............. 21
Schematic ............................................................... 22
Wiring Diagram — WINDOW — ............................. 23
Main Power Window and Door Lock/Unlock Switch
Harness Connector Terminal Layout ...................... 27
Terminal and Reference Value for Main Power Win-
dow and Door Lock/Unlock Switch ......................... 27
Terminal and Reference Value for BCM ................. 28
Work Flow ............................................................... 28
CONSULT-II Function (BCM) ................................. 28
CONSULT-II START PROCEDURE .................... 28
ACTIVE TEST ..................................................... 29
WORK SUPPORT ............................................... 29
DATA MONITOR ................................................. 29
Trouble Diagnoses Symptom Chart ....................... 29
BCM Power Supply and Ground Circuit Check ...... 30
Main Power Window and Door Lock/Unlock Switch
Power Supply and Ground Circuit Check ............... 30
Front Power Window Motor LH Circuit Check ........ 32
Front Power Window RH Circuit Check (Power Win-
dow and Door Lock/Unlock Switch RH Operation) ... 33
Front Power Window Motor RH Circuit Check ....... 33
Encoder Circuit Check ............................................ 34
Door Switch Check ................................................. 37
Rear Power Window LH Circuit Check (Rear Power
Window Switch LH Operation) ................................ 38
Rear Power Window RH Circuit Check (Rear Power
Window Switch RH Operation) ............................... 39
Rear Power Window Motor LH Circuit Check ......... 39
Rear Power Window Motor RH Circuit Check ........ 41
FRONT DOOR GLASS AND REGULATOR ............. 43
Removal and Installation ........................................ 43
DOOR GLASS ..................................................... 43
REGULATOR ASSEMBLY .................................. 44

GW-8
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: June 20062007 Versa
TRUNK
Trunk noises are often caused by a loose jack or loose items put into the trunk by the owner.
In addition look for:
1. Trunk lid bumpers out of adjustment
2. Trunk lid striker out of adjustment
3. The trunk lid torsion bars knocking together
4. A loose license plate or bracket
Most of these incidents can be repaired by adjusting, securing or insulating the item(s) or component(s) caus-
ing the noise.
SUNROOF/HEADLINING
Noises in the sunroof/headlining area can often be traced to one of the following:
1. Sunroof lid, rail, linkage or seals making a rattle or light knocking noise
2. Sun visor shaft shaking in the holder
3. Front or rear windshield touching headliner and squeaking
Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these
incidents. Repairs usually consist of insulating with felt cloth tape.
OVERHEAD CONSOLE (FRONT AND REAR)
Overhead console noises are often caused by the console panel clips not being engaged correctly. Most of
these incidents are repaired by pushing up on the console at the clip locations until the clips engage.
In addition look for:
1. Loose harness or harness connectors.
2. Front console map/reading lamp lense loose.
3. Loose screws at console attachment points.
SEATS
When isolating seat noise it's important to note the position the seat is in and the load placed on the seat when
the noise is present. These conditions should be duplicated when verifying and isolating the cause of the
noise.
Cause of seat noise include:
1. Headrest rods and holder
2. A squeak between the seat pad cushion and frame
3. The rear seatback lock and bracket
These noises can be isolated by moving or pressing on the suspected components while duplicating the con-
ditions under which the noise occurs. Most of these incidents can be repaired by repositioning the component
or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then
transmitted into the passenger compartment.
Causes of transmitted underhood noise include:
1. Any component mounted to the engine wall
2. Components that pass through the engine wall
3. Engine wall mounts and connectors
4. Loose radiator mounting pins
5. Hood bumpers out of adjustment
6. Hood striker out of adjustment
These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best
method is to secure, move or insulate one component at a time and test drive the vehicle. Also, engine RPM
or load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or
insulating the component causing the noise.

POWER WINDOW SYSTEM
GW-29
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: June 20062007 Versa
ACTIVE TEST
WORK SUPPORT
DATA MONITOR
Trouble Diagnoses Symptom ChartEIS0099B
Check that other systems using the signal of the following systems operate normally.
Te s t I t e m D e s c r i p t i o n
RETAINED PWRThis test is able to supply RAP signal (power) from BCM (body control module) to power window
system and power sunroof system (if equipped). Those systems can be operated when turning on
“RETAINED PWR” on CONSULT-II screen even if the ignition switch is turned OFF.
NOTE:
During this test, CONSULT-II can be operated with ignition switch in OFF position. “RETAINED
PWR” should be turned “ON” or “OFF” on CONSULT-II screen when ignition switch is ON. Then
turn ignition switch OFF to check retained power operation. CONSULT-II might be stuck if
“RETAINED PWR” is turned “ON” or “OFF” on CONSULT-II screen when ignition switch is OFF.
Work item Description
RETAINED PWRRAP signal’s power supply period can be changed by mode setting. Selects RAP signal’s power
supply period between three steps

MODE1 (45 sec.)/MODE2 (OFF)/MODE3 (2 min.).
Work item Description
IGN ON SW Indicates (ON/OFF) condition of ignition switch
DOOR SW-DR Indicates (ON/OFF) condition of front door switch LH
DOOR SW-AS Indicates (ON/OFF) condition of front door switch RH
Symptom Repair order Refer to page
None of the power windows can be operated using any switch1. BCM power supply and ground circuit checkBCS-16
2. Main power window and door lock/unlock
power supply and ground circuit checkGW-30
3. Replace main power window and door lock/
unlock switchEI-27
Front power window LH alone does not operate1. Front power window motor LH circuit checkGW-322. Replace main power window and door lock/
unlock switchEI-27, "FRONT
DOOR"
Front power window RH does not operate from power window and
door lock/unlock switch RH only1. Front power window RH circuit check (power
window and door lock/unlock switch RH opera-
tion)GW-33
Front power window RH does not operate from main power win-
dow and door lock/unlock switch only1. Replace main power window and door lock/
unlock switchEI-27
Front power window RH does not operate from any switch 1. Front power window motor RH circuit checkGW-33
Anti-pinch system does not operate normally (Front LH)1. Door window sliding part malfunction

A foreign material adheres to window glass
or glass run rubber.

Glass run rubber wear or deformation.

Sash is tilted too much, or not enough.—
2. Encoder circuit checkGW-34
Rear power window LH does not operate from rear power window
switch LH only1. Rear power window LH circuit check (rear
power window switch LH operation)GW-38
Rear power window LH does not operate from main power window
and door lock/unlock switch only1. Replace main power window and door lock/
unlock switchEI-27
Rear power window LH does not operate from any switch 1. Rear power window motor LH circuit checkGW-39

IDX-3
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
Collision diagnosis .......................................... SRS-54
Combination lamp, rear, removal and installation LT-87
Combination meter ................................................ DI-5
Combination meter removal and installation - See Instru-
ment panel .......................................................... IP-11
COMBSW - Wiring diagram ............................... LT-67
Component Location (manual A/C) ................ MTC-25
Compression pressure ...................................... EM-62
Compressor mounting .................................... MTC-84
Compressor special service tool .................... MTC-12
Condenser ...................................................... MTC-88
Connecting rod .................................................. EM-97
Connecting rod bearing clearance .................. EM-101
Connecting rod bushing clearance .................... EM-97
CONSULT for ABS .......................................... BRC-20
CONSULT general information .......................... GI-37
CONSULT-II for engine ................................... EC-113
CONSULT-II function (EPS) ............................ STC-13
CONSULT-II Reference value (CVT) .............. CVT-57
Control lever (M/T) ............................................ MT-12
Control units (terminal arrangement) ................ PG-72
Control valve (CVT) ......................................... CVT-29
Converter housing installation ............ AT-254, AT-369
COOL/F - Wiring diagram ............................... EC-448
Coolant mixture ratio ......................................... MA-12
Cooling circuit (engine) ....................................... CO-7
Cooling fan ........................................................ CO-15
Cooling fan motor ............................................ EC-443
Corrosion protection ......................................... BL-237
Coupling sleeve (M/T) ....................................... MT-18
Crankcase ventilation system - See Positive crankcase
ventilation .......................................................... EC-44
Crankshaft ......................................................... EM-77
Crankshaft position sensor (POS) ................... EC-319
Crash zone sensor .......................................... SRS-49
CVT air breather hose ................................... CVT-205
CVT control system ......................................... CVT-22
CVT cross-sectional view ................................ CVT-21
CVT Electrical parts location ........................... CVT-40
CVT fluid checking ............... CVT-16, CVT-43, MA-20
CVT fluid cooler cleaning ................................ CVT-18
CVT fluid replacement ........................ CVT-17, MA-21
CVT fluid temparature sensor ......................... CVT-85
CVT hydraulic control system ......................... CVT-23
CVT indicator ...................................................... DI-42
CVT self-diagnoses ........................... CVT-60, CVT-67
CVT shift lock system .................................... CVT-197
CVT trouble diagnoses .................................... CVT-34
CVTIND - Wiring diagram ................................... DI-43
Cylinder block .................................................... EM-77
Cylinder head .................................................... EM-62
Cylinder head bolt tightening ............................. EM-65
D
D/LOCK - Wiring diagram ...................... BL-26
, BL-31
Data link connector ............. EC-115, EC-127, EC-592
DEF - Wiring diagram ....................................... GW-52
Diagnosis sensor unit ...................................... SRS-52
Diagnostic trouble code (DTC) for OBD system . EC-8,
EC-48
Diagnostic trouble code (DTC) inspection priority chart
EC-89
, CVT-34
Differential gear (FF M/T) .................................. MT-22
Differentil side oil seal .................................... CVT-206
DLC - Wiring diagram ...................................... EC-592
Door glass .......................................... GW-43, GW-47
Door glass Fitting Adjustment(Front) ................ GW-46
Door glass Fitting Adjustment(Rear) ................ GW-49
Door mirror ....................................................... GW-65
Door trim .............................................................. EI-27
Door, front ......................................................... GW-43
Door, rear ......................................................... GW-47
Drive shaft ......................................................... MA-27
Driver air bag ................................................... SRS-41
Dropping resistor (A/T) .................................... AT-150
DTC work support ............................................ EC-122
DTRL - Wiring diagram ....................................... LT-31
Duct and grilles ............................................... MTC-75
E
ECM input/output signal .................................. EC-105
ECM power supply .......................................... EC-144
ECTS - Wiring diagram .................................... EC-202
Electric sunroof .................................................. RF-10
Electric throttle control actuator .. EM-18, EC-499, EC-
506, EC-511
Electrical load signal circuit ............................. EC-562
Electrical unit ..................................................... PG-72
Electrical units location ...................................... PG-64
Electronic ignition (EI) system ........................... EC-25
Electronic key ..................................................... BL-80
ENG SS - Wiring diagram ................................ AT-114
Engine control circuit diagram ......................... EC-103
Engine control component parts location .......... EC-96
Engine control module (ECM) ......................... EC-427
Engine control system diagram ......................... EC-22
Engine coolant ..................................................... CO-8
Engine coolant temperature sensor (ECTS) ... EC-200,
EC-212
Engine fail-safe system ..................................... EC-91
Engine oil ............................................................. LU-5
Engine oil precautions .......................................... GI-7
Engine removal .................................................. EM-73
EPS - Wiring diagram ........................................ STC-9
EPS control unit input/output signal reference values ..
STC-11
EPS system description ..................................... STC-5
EPS system diagram ......................................... STC-6
ETC1 - Wiring diagram .................................... EC-500
ETC2 - Wiring diagram .................................... EC-495
ETC3 - Wiring diagram .................................... EC-507
EVAP canister ................................................... EC-34
EVAP canister purge volume control solenoid valve ....
EC-354
, EC-362
EVAP canister vent control valve ...... EC-369, EC-376
EVAP control system (small leak) diagnosis .. EC-346,
