REPAIR FOR COMPONENT PARTS
9. Remove spring retainer (1), OD servo return spring (2), bandservo piston (3) and band servo thrust washer (4) from band
servo piston stem (5).
10. Remove O-ring from servo piston retainer.
a. HR16DE engine models (1): O-ring (small diameter)
(2): O-ring (large diameter)
(3): Servo piston retainer
b. MR18DE engine models (1): O-ring
(2): Servo piston retainer
11. Remove D-rings from band servo piston.
INSPECTION
Pistons, Retainers and Piston Stem
Check the sliding surfaces for damage or excessive wear. Replace if necessary.
Return Springs
SCIA7054E
JPDIA0258ZZ
SCIA7967E
SCIA3688E
Revision: January 20102010 Versa

REPAIR FOR COMPONENT PARTSAT-335
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
• Check each return spring for damage or deformation. Also mea- sure free length. Refer to AT-378, "
Band Servo".
• Replace springs if deformed or fatigued.
ASSEMBLY
1. Install D-rings to band servo piston.
2. Install band servo thrust washer (4), band servo piston (3), OD servo return spring (2) and spring retainer (1) to band servo pis-
ton stem (5).
3. Place band servo piston stem (1) on a wooden block, and install E-ring (2) to band servo piston stem (1) while pressing spring
retainer (3) downward.
4. Install O-ring to servo piston retainer.
SAT138D
SCIA3688E
SCIA7054E
SCIA7056E
Revision: January 20102010 Versa

AT-336
< SERVICE INFORMATION >
REPAIR FOR COMPONENT PARTS
• HR16DE engine models
(1): O-ring (small diameter)
(2): O-ring (large diameter)
(3): Servo piston retainer
• MR18DE engine models(1): O-ring
(2): Servo piston retainer
5. Install band servo piston assembly to servo piston retainer by pushing it inward.
6. Install D-ring (1) to OD servo piston (2).
7. Install O-rings and to OD servo piston retainer. (1): O-ring (small diameter)
(2): O-ring (medium diameter)
(3): O-ring (large diameter)
(4): OD servo piston retainer
JPDIA0258ZZ
SCIA7967E
SAT303D
SCIA7053E
SCIA6492J
Revision: January 20102010 Versa

REPAIR FOR COMPONENT PARTSAT-337
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
8. Install OD servo piston (1) to OD servo piston retainer (2) in the direction shown.
9. Install 2nd servo return spring (2) and band servo piston assem- bly (3) to transaxle case (1).
10. Install OD servo piston assembly (2) to transaxle case (1).
11. Push in OD servo piston assembly using a suitable tool (A) and a suitable tool (B), and install snap ring (1) to transaxle case
using a suitable tool (C).
Final DriveINFOID:0000000005397448
COMPONENTS
SCIA7057E
SCIA6310J
SCIA6010J
SCIA7050E
Revision: January 20102010 Versa

AT-338
< SERVICE INFORMATION >
REPAIR FOR COMPONENT PARTS
HR16DE engine modelsMR18DE models
DISASSEMBLY
SCIA7486E
1. Pinion mate gear thrust washer 2. Pinion mate gear 3. Pinion mate shaft
4. Side gear 5. Side gear thrust washer 6. Lock pin
7. Differential side bearing 8. Speedometer drive gear 9. Differential case
10. Final gear 11. Differential side bearing adjusting shim
SCIA7962E
1. Pinion mate gear 2. Pinion mate gear thrust washer 3. Pinion mate shaft
4. Lock pin 5. Side gear 6. Side gear thrust washer
7. Differential side bearing 8. Speedometer drive gear 9. Differential case
10. Final gear 11. Differential side bearing 12. Differential side bearing adjusting shim
Revision: January 20102010 Versa

REPAIR FOR COMPONENT PARTSAT-339
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
1. Remove final gear (1) from differential case (2).
2. Remove differential side bearings according to the following procedures.
a. HR16DE engine models
i. Set a suitable tool (A) on differential case (1), and remove differ- ential side bearing (RH side) (2) from differential case with suit-
able tool (B) and suitable tool (C).
ii. Set a suitable tool (A) on differential case (1), and remove differ- ential side bearing (LH side) (2) from differential case with suit-
able tool (B).
CAUTION:
Be careful not to mix up the right and left bearings.
b. MR18DE engine models
i. Set Tool on differential case, and remove differential side bear- ings from differential case using a suitable tool.
CAUTION:
Be careful not to mix up the right and left bearings.
SCIA8003E
SCIA7059E
SCIA7060E
Tool number : ST3306S001 (J-22888-D)
SAT312D
Revision: January 20102010 Versa

AT-340
< SERVICE INFORMATION >
REPAIR FOR COMPONENT PARTS
3. Remove speedometer drive gear from differential case.
4. Drive out lock pin from differential case (1) using Tool (A).
5. Draw out pinion mate shaft.
6. Remove pinion mate gears, pinion mate gear thrust washers,side gears and side gear thrust washers.
INSPECTION
Gears, Washers, Pinion Mate Shaft and Differential Case
• Check mating surfaces of differential case, side gears, pinion mate
gears and pinion mate shaft. Replace if necessary.
• Check washers for wear. Replace if necessary.
Bearings
SAT313D
Tool number : KV32101000 (J-25689-A)
SCIA7034E
SAT316D
SAT544F
Revision: January 20102010 Versa

REPAIR FOR COMPONENT PARTSAT-341
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
• Make sure bearings roll freely and are free from noise, cracks, pit- ting or wear. Replace if necessary.
CAUTION:
When replacing taper roller bearing, replace outer and inner
race as a set.
ASSEMBLY
1. Attach side gear thrust washers to side gears, then install pinion mate thrust washers and pinion mate gears in place.
CAUTION:
Apply ATF to any parts.
2. Insert pinion mate shaft. CAUTION:
• When inserting, be careful not to damage pinion mate
gear thrust washers.
• Apply ATF to pinion mate shaft.
3. Select side gear thrust washers according to the following procedures.
a. Place differential case in the upright position so that the side gear to be measured is at the top.
(A): Location for inserting feeler gauge
(B): Side gear tooth
(C): The center line of differential case
b. In order to maximize the back clearance, rotate side gears so that a tooth on side gears at the top and bottom will align at the
same position as shown.
SPD715
SMT839
SMT087A
SCIA7064E
Revision: January 20102010 Versa

AT-342
< SERVICE INFORMATION >
REPAIR FOR COMPONENT PARTS
c. Adjust the back clearance of side gear according to the followingprocedures.
i. Insert feeler gauges (A) of the same thickness to the back of side gear from both sides, preventing side gear from falling, to
measure the clearance.
• Measure clearance 3 times by rotating side gears and take theaverage.
CAUTION:
In all 3 measurements, maximi ze the clearance by aligning
teeth on side gears at the top and bottom at the same posi-
tion.
ii. Select side gear thrust washer so that the clearance will fall within the standard.
iii. Turn differential case upside down, and measure the back clear- ance of the other side gear in the same manner.
NOTE:
Adjust the clearance to approx. 0.1 mm (0.004 in) for used differ-
ential [driven approx. 3,000 km (1864 mile) or more].
4. Install lock pin (1) to pinion mate shaft using suitable tool (A).
CAUTION:
• Do not reuse lock pin.
• Make sure that lock pin is flush with differential case.
5. Install speedometer drive gear on differential case.
6. Install output gear bearing (HR16DE engine models) or radial needle bearing (MR18DE engine models) according to the following procedures.
a. HR16DE engine models Differential side gear clearance:
Refer to AT-378, "
Final Drive".
SCIA7061E
Tool number A: KV32101000 (J-25689-A)
SCIA7228E
SAT313D
Revision: January 20102010 Versa

REPAIR FOR COMPONENT PARTSAT-343
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
i. Set Tool (A) on differential side bearing (RH side) (1), and press differential side bearing (RH side) to differential case (2)
CAUTION:
Set Tool (A) on differential side bearing inner race.
Apply ATF to differential side bearings.
ii. Set Tool (A) on differential side bearing (LH side) (1), and press differential side bearing (LH side) to differential case (2)
CAUTION:
Set Tool (A) on differential side bearing inner race.
Apply ATF to differential side bearings.
b. MR18DE engine models
i. Set suitable tool (A) on differential side bearing inner race, and press differential side bearing inner race into differential case.
CAUTION:
Set Tool on differential side bearing inner race.
Apply ATF to differential side bearings.
7. Install final gear and tighten bolts to the specified torque in numerical order as shown after temporarily tightening them.
Refer to AT-378, "
Final Drive".
Tool number A: ST33200000 (J-26082)
SCIA8005E
Tool number A: ST33200000 (J-26082)
SCIA8005E
SCIA8005E
SCIA8004E
