Remove reduction pinion gear from transaxle case.

Measure dimension “D” between the end of reduction pinion
gear and the adjusting shim mating surface of reduction pin-
ion gear.

Measure dimension “D” in at least two places, and take
the average.

Calculate dimension “A”.
e. Measure dimension “E” between the end of idler gear and idler
gear bearing inner race mating surface of idler gear.

Measure dimension “E” in at least two places, and take
the average.
f. Select proper thickness of reduction pinion gear adjusting shim.
Refer to “Parts Information” for reduction pinion gear adjusting
shim selection.
2. Install reduction pinion gear and reduction pinion gear adjusting
shim selected in step 1-f on transaxle case.
CAUTION:
Apply ATF to reduction pinion gear bearing.
3. Press idler gear bearing inner race on idler gear. Refer to AT-
336, "COMPONENTS" .
4. Press idler gear on reduction pinion gear.
CAUTION:

Apply ATF to idler gear bearing.

Press idler gear until idler gear fully contacts reduction
pinion gear bearing adjusting shim.
5. Set manual shaft in “P” position to fix idler gear.
6. Tighten lock nut of idler gear to the specified torque. Refer to AT-257, "
Components" .
CAUTION:
Lock idler gear with parking pawl when tightening lock nut.
7. Measure turning torque of reduction pinion gear.

When measuring turning torque, turn reduction pinion
gear in both directions several times to seat bearing roll-
ers correctly.

If turning torque is out of specification, decrease or
increase thickness of reduction pinion gear adjusting
shim.A = D − (B + C)
SAT3 3 6DA
Proper shim thickness = A − E − 0.05 mm (0.0020 in)*
(*: Bearing preload)
SAT3 3 7D
Turning torque of reduction pinion gear:
Refer to AT-382, "
Reduction Pinion Gear" .
SCIA5651E
SCIA5514E

ASSEMBLY
AT-359
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
8. After properly adjusting turning torque, clinch idler gear lock nut
as shown.
CAUTION:
Do not reuse idler gear lock nut.
OUTPUT SHAFT END PLAY
1. Select proper thickness of output shaft adjusting shim using the
following procedures.
a. Install bearing retainer (1) in transaxle case. Refer to AT-336,
"COMPONENTS" .
b. Install needle bearing on bearing retainer.
CAUTION:
Be careful to direction of needle bearing.
SCIA4915E
SCIA8013E
SCIA5909J
SCIA4917E

AT-360
ASSEMBLY
Revision: June 20062007 Versa
c. Install output shaft on transaxle case.
d. Measure dimensions “
1 ” and “2 ” at side cover and then cal-
culate dimension “A”.

Measure dimension “ 1” and “ 2” in at least two places.
e. Measure dimensions “
2 ” and “3 ” and then calculate dimen-
sion “B”.

Measure dimension “ 2” and “ 3” in at least two places.
f. Select proper thickness of output shaft adjusting shim so that
output shaft end play (clearance between side cover and output
shaft bearing) is within specifications. Refer to “Parts Informa-
tion” for output shaft adjusting shim selection.
g. Install output shaft adjusting shim on output shaft bearing.
2. Apply recommended sealant (Genuine Anaerobic Liquid Gasket
or equivalent.) to transaxle case as shown in figure.
: Inside of side cover
CAUTION:

Apply the sealant on the center between the bolt holes.
SAT0 3 5F
“A”: Distance between transaxle case fitting sur-
face and adjusting shim mating surface.
A =
1 − 2
2
:Height of gauge
SAT3 7 4F
“B”: Distance between the end of output shaft
bearing outer race and the side cover fitting
surface of transaxle case.
B =
2 − 3
2
:Height of gauge
SAT3 7 5F
Output shaft end play (A − B):
Refer to AT-382, "
Output Shaft" .
SCIA4918E
“A”: 3 - 5 mm (0.12 - 0.20 in)
“B”: 8 mm (0.31 in) R
“C”: 1.5 mm (0.059 in) dia.
“D”: 4 mm (0.16 in)
SCIA7089E

ASSEMBLY
AT-361
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa

Completely remove all moisture, oil and old sealant, etc. from the transaxle case and side cover
mounting surfaces.
3. Fit mounting part of output shaft bearing on side cover to output
shaft bearing, and after adjusting knock pin position, install it
with light taps of a soft hammer and things like that.
CAUTION:
When installing, to avoid getting damaged and deformed,
set mounting part straight to parallel with the mounting sur-
face.
4. Tighten side cover fitting bolts to specified torque. Refer to AT-
257, "Components" .
CAUTION:

Do not mix bolts A and B.

Always replace bolts A as they are self-sealing bolts.
Assembly (2)UCS005WI
1. Remove paper rolled around bearing retainer.
2. Install thrust washer on bearing retainer.
CAUTION:
Align pawls of thrust washer with holes of bearing retainer.
3. Install forward clutch assembly and overrun clutch assembly (1)
into transaxle case.
CAUTION:

Align teeth of low & reverse brake drive plates before
installing.

Make sure that bearing retainer seal rings are not spread.
SAT4 4 2D
SCIA7939E
SAT3 5 4D
SCIA5900J

AT-362
ASSEMBLY
Revision: June 20062007 Versa
4. Install needle bearing (1) on bearing retainer.
CAUTION:
Be careful with the direction of needle bearing.
5. Install thrust washer (1) on overrun clutch hub (2).
CAUTION:
Align pawls of thrust washer (1) with holes of overrun
clutch hub (2).
6. Install overrun clutch hub (1) into forward clutch drum.
CAUTION:
Align teeth of overrun clutch drive plates before installing.
7. Hold forward clutch hub, and check that rear internal gear locks
when tried to rotate counterclockwise.
CAUTION:
If rear internal gear rotates counterclockwise, check instal-
lation direction of forward one-way clutch.
8. Install needle bearing (1) on rear internal gear (2).
CAUTION:
Be careful with the direction of needle bearing (1).
SCIA8014E
SCIA5899J
SCIA5898J
SCIA7078E
SCIA6041J

ASSEMBLY
AT-363
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
9. Install rear internal gear (1) and forward clutch hub (2) as a set
into forward clutch drum.
CAUTION:
Align teeth of forward clutch drive plates before installing.
10. Install needle bearing (1) on rear planetary carrier (2).
CAUTION:
Be careful with the direction of needle bearing (1).
11. Install rear sun gear on rear planetary carrier.
CAUTION:
Be careful with the direction of rear sun gear.
12. Install rear planetary carrier in transaxle case.
13. Install needle bearing (1) on front planetary carrier (2).
CAUTION:
Be careful with the direction of needle bearing (1).
SCIA5897J
SCIA5927J
SAT0 5 2D
SAT0 5 1D
SCIA6047J

AT-364
ASSEMBLY
Revision: June 20062007 Versa
14. Install low one-way clutch to front planetary carrier by turning it
in the direction of unlock.
15. Check that low one-way clutch rotates counterclockwise around
front planetary carrier. Then try to turn it clockwise and check
that it is locked.
16. Install front planetary carrier (2) and low one-way clutch (1) as a
set into transaxle case.
17. Install snap ring into transaxle case using a flat-bladed screw-
driver.
18. Install needle bearing (1) on front sun gear (2).
CAUTION:
Be careful with the direction of needle bearing (1).
19. Install front sun gear on front planetary carrier.
SAT0 4 8D
SCIA5896J
SCIA3633E
SCIA6960E
SAT3 6 8D

ASSEMBLY
AT-365
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
20. Install needle bearing on front sun gear.
CAUTION:
Be careful with the direction of needle bearing.
21. Install high clutch hub on front sun gear.
22. Install needle bearing on high clutch hub.
CAUTION:
Be careful with the direction of needle bearing.
23. Remove paper rolled around input shaft assembly (high clutch
drum).
24. Install input shaft assembly (high clutch assembly) (1).
CAUTION:
Align teeth of high clutch drive plates before installing.
25. Install reverse clutch assembly.
CAUTION:
Align teeth of reverse clutch drive plates before installing.
SAT3 6 9D
SAT3 7 0D
SAT3 7 1D
SCIA7079E
SAT3 7 3D

AT-366
ASSEMBLY
Revision: June 20062007 Versa
Adjustment (2)UCS005W J
When any parts listed below are replaced, adjust total end play and reverse clutch end play.
TOTAL END PLAY

Measure clearance between reverse clutch drum and needle
bearing for oil pump cover.

Select proper thickness of bearing race so that end play is within
specifications.
1. Measure dimensions “K” and “L”, and then calculate dimension
“J”.
a. Measure dimension “K”.
Part name Total end play Reverse clutch end play
Transaxle case


Overrun clutch hub


Rear internal gear


Rear planetary carrier


Rear sun gear


Front planetary carrier


Front sun gear


High clutch hub


Input shaft assembly (high clutch drum)


Oil pump cover


Reverse clutch drum —

SCIA3661E
SCIA3662E
SCIA3663E

ASSEMBLY
AT-367
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
b. Measure dimension “L”.
c. Calculate dimension “J”.
2. Measure dimension “M”.
a. Place bearing race and needle bearing on oil pump assembly.
b. Measure dimension “M”.
c. Measure thickness of straightedge “t”.
3. Adjust total end play “T
1 ”.

Select proper thickness of bearing race so that total end play
is within specifications. Refer to “Parts Information” for bear-
ing race selection.“J”: Distance between oil pump fitting surface of
transaxle case and needle bearing mating sur-
face of input shaft assembly (high clutch
drum).
J = K – L
SCIA3664E
SAT3 7 8D
“M”: Distance between transaxle case fitting sur-
face of oil pump cover and needle bearing on
oil pump cover.
“M
1 ”: Indication of gauge
SAT3 7 9D
M = M1 – t
T
1 = J – M
Total end play “T
1 ”:
Refer to AT-383, "
To ta l E n d P l a y" .
SAT4 4 3D
