AT-348
REPAIR FOR COMPONENT PARTS
Revision: June 20062007 Versa
10. Install OD servo piston assembly (2) to transaxle case (1).
11. Push in OD servo piston assembly using a puller A (commercial
service tool) and a suitable drift B, and install snap ring (1) to
transaxle case using a flat-bladed screwdriver C.
SCIA6010J
SCIA7050E

REPAIR FOR COMPONENT PARTS
AT-349
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
Final DriveUCS005W F
COMPONENTS
DISASSEMBLY
1. Remove final gear (1) from differential case (2).
2. Press out differential side bearings.
CAUTION:
Be careful not to mix up the right and left bearings.
1. Pinion mate gear 2. Pinion mate gear thrust washer 3. Pinion mate shaft
4. Lock pin 5. Side gear 6. Side gear thrust washer
7. Differential side bearing 8. Speedometer drive gear 9. Differential case
10. Final gear 11. Differential side bearing 12. Differential side bearing adjusting
shim
Refer to GI section to make sure icons (symbol marks) in the figure. Refer to GI-10, "
Components" .
SCIA7962E
SCIA8003E
Tool number: ST3306S001 (J-22888-D)
SAT3 1 2D

AT-350
REPAIR FOR COMPONENT PARTS
Revision: June 20062007 Versa
3. Remove speedometer drive gear from differential case.
4. Drive out lock pin from differential case (1) using Tool (A).
5. Draw out pinion mate shaft.
6. Remove pinion mate gears, pinion mate gear thrust washers,
side gears and side gear thrust washers.
INSPECTION
Gears, Washers, Pinion Mate Shaft and Differential Case

Check mating surfaces of differential case, side gears, pinion
mate gears and pinion mate shaft. Replace if necessary.

Check washers for wear. Replace if necessary.
SAT3 1 3D
Tool number: KV32101000 (J-25689-A)
SCIA7034E
SAT3 1 6D
SAT5 4 4F

REPAIR FOR COMPONENT PARTS
AT-351
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
Bearings

Make sure bearings roll freely and are free from noise, cracks,
pitting or wear. Replace if necessary.
CAUTION:
When replacing taper roller bearing, replace outer and inner
race as a set.
ASSEMBLY
1. Attach side gear thrust washers to side gears, then install pinion
mate thrust washers and pinion mate gears in place.
CAUTION:
Apply ATF to any parts.
2. Insert pinion mate shaft.
CAUTION:

When inserting, be careful not to damage pinion mate
gear thrust washers.

Apply ATF to pinion mate shaft.
3. Select side gear thrust washers according to the following procedures.
a. Place differential case in the upright position so that the side
gear to be measured is at the top.
(A): Location for inserting feeler gauge
(B): Side gear tooth
(C): The center line of differential case
b. In order to maximize the back clearance, rotate side gears so
that a tooth on side gears at the top and bottom will align at the
same position as shown in the figure.
SPD7 15
SMT839
SMT087A
SCIA7064E

AT-352
REPAIR FOR COMPONENT PARTS
Revision: June 20062007 Versa
c. Adjust the back clearance of side gear according to the following
procedures.
i. Insert feeler gauges A of the same thickness to the back of side
gear from both sides, preventing side gear from falling, to mea-
sure the clearance.

Measure clearance 3 times by rotating side gears and take
the average.
CAUTION:
In all 3 measurements, maximize the clearance by aligning
teeth on side gears at the top and bottom at the same posi-
tion.
ii. Select side gear thrust washer so that the clearance will fall
within the standard.
iii. Turn differential case upside down, and measure the back clear-
ance of the other side gear in the same manner.
NOTE:
Adjust the clearance to approx. 0.1 mm (0.004 in) for used differ-
ential [driven approx. 3,000 km (1864 mile) or more].
4. Install lock pin (1) to pinion mate shaft using the pin punch A.
CAUTION:

Do not reuse lock pin.

Make sure that lock pin is flush with differential case.
5. Install speedometer drive gear on differential case.
6. Set drift A [commercial service tool] on differential side bearing
inner race, and press differential side bearing inner race into dif-
ferential case.
CAUTION:
Apply ATF to differential side bearings.
7. Install differential side bearing outer race and differential side
bearing adjusting shim on transaxle case. Refer to AT-354,
"Assembly (1)" . Differential side gear clearance:
Refer to AT-382, "
Final Drive" .
SCIA7061E
Tool number: KV32101000 (J-25689-A)
SCIA7228E
SAT3 1 3D
SCIA8005E

REPAIR FOR COMPONENT PARTS
AT-353
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
8. Tighten final gear and tighten fixing bolts to the specified torque
in numerical order as shown in the figure after temporarily tight-
ening them. Refer to AT- 3 4 9 , "
COMPONENTS" .
SCIA8004E

AT-354
ASSEMBLY
Revision: June 20062007 Versa
ASSEMBLYPFP:00000
Assembly (1)UCS005WG
1. Drive each differential side oil seal evenly using a drift (SST and
commercial service tool) so that differential side oil seal pro-
trudes by the dimension “C” or “D” respectively.
(1): LH differential side oil seal
(2): RH differential side oil seal
(A): Transaxle case side
(B): Converter housing side
Unit: mm (in)
NOTE:
Differential side oil seal pulling direction is used as the reference.
Drift to be used:
2. Install O-ring on governor cap.
CAUTION:

Do not reuse O-ring.

Apply ATF to O-ring.
3. Install governor cap in transaxle case.
4. Install snap ring in transaxle case.
5. Install parking actuator support (1) on transaxle case.
(A): Inside
(B): Outside
CAUTION:
Be careful with the direction of parking actuator support (1).
6. Tighten parking actuator support fitting bolts to the specified
torque. Refer to AT-257, "
Components" .
7. Install parking pawl (2) on transaxle case, and fix it with parking
shaft (1).
Dimension “C” 0 ± 0.5 (0 ± 0.020)
Dimension “D” 6 ± 0.5 (0.043 ± 0.020)
SCIA7226E
Location Tool number
Transaxle case side (A)ST35325000 ( – )
KV31103000 (J-38982)
Converter housing side (B)Commercial service tool [Inner diameter: 47 mm (1.85 in), outer
diameter: 54 mm (2.13 in)]
SCIA5910J
SCIA6997E

ASSEMBLY
AT-355
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
8. Install return spring (2) on parking shaft (3) and parking pawl (1)
using a flat-bladed screwdriver.
Adjustment (1)UCS005WH
DIFFERENTIAL SIDE BEARING PRELOAD
1. Select proper thickness of differential side bearing adjusting shim using the following procedures.
a. Install differential side bearing outer race without differential side
bearing adjusting shim on transaxle case.
CAUTION:
Apply ATF to differential side bearing outer race.
b. Install differential side bearing outer race on converter housing.
CAUTION:
Apply ATF to differential side bearing outer race.
c. Place final drive assembly on transaxle case.
d. Tighten converter housing fitting bolts (1) and (2) to the specified
torque. Refer to AT-349, "
Final Drive" .
SCIA6996E
SAT9 4 7DA
Bolt 1 2
Bolt length
[mm (in)]
32.8 (1.291) 40 (1.57)
Number of bolts 10 10
SCIA7970E

AT-356
ASSEMBLY
Revision: June 20062007 Versa
e. Attach dial indicator on differential case at converter housing
side.
f. Insert SST into differential side gear from transaxle case side.
g. Move SST up and down and measure dial indicator deflection.
h. Select proper thickness of differential side bearing adjusting
shim. Refer to “Parts Information” for differential side bearing
adjusting shim selection.
Suitable shim thickness = Dial indicator deflection + Speci-
fied bearing preload
i. Remove converter housing from transaxle case.
j. Remove final drive assembly from transaxle case.
k. Remove differential side bearing outer race from transaxle case.
l. Reinstall differential side bearing outer race and differential side
bearing adjusting shim selected from “Parts Information” on
transaxle case.
m. Reinstall converter housing on transaxle case and tighten con-
verter housing mounting bolts to the specified torque. Refer to
AT-257, "
Components" .
n. Insert SST and measure turning torque of final drive assembly.

Turn final drive assembly in both directions several times
to seat bearing rollers correctly.

When old bearing is used again, turning torque will be
slightly less than the above.

Make sure torque is close to the specified range.Suitable shim thickness = Dial indicator deflection +
Specified bearing preload
Bearing preload: Refer to AT- 3 8 2 , "
Final Drive" .
SCIA8006E
SCIA5378E
Turning torque of final drive assembly
(New bearing):
Refer to AT- 3 8 2 , "
Final Drive" .
SCIA8012E

ASSEMBLY
AT-357
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
REDUCTION PINION GEAR BEARING PRELOAD
1. Select proper thickness of reduction pinion gear adjusting shim using the following procedures.
a. Place reduction pinion gear on transaxle case as shown in the
figure.
b. Install idler gear bearing outer race on transaxle case. Refer to
AT-336, "
COMPONENTS" .
c. Place idler gear bearing inner race on outer race.
d. Measure dimensions “B”, “C” and “D”, and calculate dimension
“A”.

Measure dimension “B” between the end of reduction pinion
gear and the surface of transaxle case.

Measure dimension “B” in at least two places, and take
the average.

Measure dimension “C” between the surface of idler gear
bearing inner race and the surface of transaxle case.

Measure dimension “C” in at least two places, and take
the average.
SCIA3623E
“A”: Distance between the surface of idler gear
bearing inner race and the adjusting shim mat-
ing surface of reduction pinion gear.
A = D − (B + C)
SCIA3624E
SCIA3625E
SCIA3626E
