QUICK REFERENCE GUIDE
2 015
VERSA SEDAN
1804921_15c_Versa_Sedan_QRG_080714.indd 38/7/14 2:22 PM
Page 2 of 24
*See your Owner’s Manual for information.
13
2
4
5
9
15
12
13
6
14
11
7
8
1 Trip Computer2 Low Tire Pressure Warning Light3 Instrument Brightness Control*4 Headlight and Turn Signal Control
5 Windshield Wiper
and Washer Switch6 Outside Mirror Control Switc h7 Steering Wheel Switches for
Audio Control/Bluetooth
®
8 Cruise Control9 Steering W heel Tilt Adjustment*10 Vehicle Dynamic Control (VDC)
Off Switch*11 Fuel-filler Door Release
12 Hood Release*
13 Front Passenger Air B ag
Status Light*14 Audio and Navigation System
15 Climate Controls
10
1804921_15c_Versa_Sedan_QRG_080714.indd 48/7/14 2:22 PM
Page 3 of 24
![NISSAN VERSA SEDAN 2015 2.G Quick Reference Guide NEW SYSTEM FEATURES
RearView Monitor (if so equipped) ........................................................................\
....................................2
T rip Computer .................](/img/5/454/w960_454-2.png "NISSAN VERSA SEDAN 2015 2.G Quick Reference Guide NEW SYSTEM FEATURES
RearView Monitor (if so equipped) ........................................................................\
....................................2
T rip Computer .................")
NEW SYSTEM FEATURES
RearView Monitor (if so equipped) ........................................................................\
....................................2
T rip Computer ........................................................................\
......................................................................... 2
USB (Universal Serial Bus) Connection Port/Aux Jack and iPod
® Interface (if so equipped) .... 2
T
ext Messaging (if so equipped)
........................................................................\
........................................ 3
SiriusX
M Travel Link and SiriusXM Traffic (if so equipped)
................................................................. 3
ESSENTIAL INFORMATION
Tire Pressure Monitoring System (TPMS) with Easy Fill Tire Alert (if so equipped) ......................4
Loose Fuel Cap ........................................................................\
..................................................................... 4
Fuel-filler Door
........................................................................\
....................................................................... 5
Clock Set/Adjustment
........................................................................\
........................................................... 5
FIRST DRIVE FEATURES
NISSAN Intelligent Key® System (if so equipped) ........................................................................\
.........6
Rear T
runk Release (if so equipped) ........................................................................\
................................. 7
Seat Adjustments
........................................................................\
................................................................... 7
Power Outside Mirror Control Switch (if so equipped)
....................................................................... 7
Starting/Stopping the Engine
........................................................................\
............................................. 8
Headlight Control Switc
h
........................................................................\
..................................................... 8
W
indshield Wiper and Washer Switch ........................................................................\
........................... 9
Manual Climate Controls
........................................................................\
.................................................... 10
F
M/AM/SiriusXM
® Satellite Radio with CD Player (if so equipped) ............................................... 11
Cruise Control (if so equipped)
........................................................................\
........................................ 12
SYSTEM GUIDE
NissanConnectsm with Mobile Apps Smartphone Integration (if so equipped) .............................13
Bluetooth® Hands-free Phone System ........................................................................\
........................... 13
•
System Operating T
ips
........................................................................\
.................................................. 13
Bluetooth® System without Navigation (if so equipped) .................................................................... 14
Bluetooth® System with Navigation (if so equipped) ........................................................................\
.. 16
Navigation System (if so equipped) ........................................................................\
................................. 18
Please see your Owner’s Manual for important safety information and system operation limitations.
•
A cellular telephone should not be used for any purpose while driving
so full attention may be given to vehicle operation.
•
Always wear your seat belt.
•
Supplement
al air bags do not replace proper seat belt usage.
•
Children 12 and under should always ride in the rear seat properly secur\
ed
in c
hild restraints or seat belts according to their age and weight.
•
Do not drink and drive.
F
or more information, refer to the “Safety — Seats, seat belts and supplemental restraint system (se\
ction 1)”,
“Monitor, climate, audio, phone and voice recognition systems (section 4)” \
and “Starting and driving
(section 5)” of your Owner’s Manual.
TAB LE OF CONTE NTS
Additional information about your vehicle is also available in your Owne\
r’s Manual, Navigation System
Owner’s Manual and at www.nissanusa.com.
1804921_15c_Versa_Sedan_QRG_080714.indd 58/7/14 2:22 PM
Page 4 of 24
2
REARVIEW MONITOR (if so equipped)
When the shift lever is moved to the
R ( REVERSE ) position, the front display shows
the view to the rear of the vehicle.
The colored lines on the display screen indicate approximate distances to objects.
•
Red 1.5 ft (0.5 m); Y
ellow 3 ft (1 m);
Green 7 ft (2 m) and 10 ft (3 m).
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of
your Owner’s Manual.
NEW SYSTEM FEATURES
USB ( Universal Serial Bus) CONNECTION PORT/AUX JACK AND
i POD® INTERFACE (if so equipped)
The USB port/Aux jack
1 is located on the
center console.
When a compatible USB memory device, iPod® or
auxiliary device is plugged into the USB port/Aux
jack, compatible audio files stored on the device
can be played through the vehicle’s audio system.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of
your Owner’s Manual.
1
TRIP COMPUTER
With the ignition switch in the ON position,
modes of the trip computer
1 can be selected
by pushing the trip computer change button 2
on the instrument panel.
The following modes can be selected in the display:
•
OD
O – records the total distance the vehicle
has been driven.
•
T
rip A – measures the distance of one
specific trip.
•
T
rip B – measures the distance of a second specific trip.
• mpg
– displays the instant fuel consumption.
• mpg A
VG – displays the average fuel consumption since the last reset.
•
mls
– displays the estimated distance that can be driven before refueling.
• Outside A
ir Temperature (if so equipped) – displays the outside air temperature
in °F or °C.
To reset TR IP A, TRIP B, mpg or mpg AVG, go to the desired mode on the trip
computer and hold the change button
2 for more than 3 seconds.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
1
2
1804921_15c_Versa_Sedan_QRG_080714.indd 28/7/14 2:22 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 5 of 24
3
TEXT MESSAGING* (if so equipped)
This system allows for sending and receiving text
messages through the vehicle interface.
Using predefined or custom mess ages, send a
text to a name or phone number stored in your
Bluetooth
® Hands-free Phone System.
Once enabled, the text mess age, sender and
delivery time are shown on the control panel
display screen.
Text messages have the option of being read aloud.
Text messages are only displayed on the control panel if the vehicle speed is les\
s than 5 mph (8 km/h).
This feature is not supported by all phones. See your cellular phone’s Owner’s Manual for details and also visit www.nissanusa.com/bluetooth.
*Laws in some jurisdictions may restrict the use of “Text-to-Speech.” Some of the applications and features, such as social
networking and texting may also be restricted. Check local regulations for any requirements before using these features.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4) ” of
your Owner’s Manual.
SiriusXM TRAVEL LINK* AND SiriusXM TRAFFIC*
(if so equipped)
Your vehicle’s Navigation System is equipped with SiriusXM Travel Link and SiriusXM
Traffic capabilities.
SiriusXM Travel Link provides access to real-time weather information and forecasts, nearby fuel
prices, movie listings and stock quotes.
SiriusXM Traffic provides information that may help to avoid delays due to traffic incidents.
Traffic jams, roadwork, road closures around the
current location, etc., are represented graphically
on the map by icons depicting the nature of the
event. Incidents on the route are automatically
displayed when they are approached.
*These features, SiriusXM® Satellite Radio, Travel Link and Traffic require an active subscription. Multiple subscriptions
may be necessary to activate the various features.
For more information, refer to the “Navigation (section 4)” and the “General system information (section 6)” of
your Navigation System Owner’s Manual.
1804921_15c_Versa_Sedan_QRG_080714.indd 38/7/14 2:22 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 6 of 24
4
ESSE NTIAL I N FOR MATION
TIRE PRESSURE MONITORING SYSTEM (TPMS)
WITH EASY FILL TIRE ALERT (if so equipped)
A CHECK TIRE PRES warning message will
appear in the trip computer 1 and the low tire
pressure warning light 2 will illuminate when one
or more tires are low on pressure and air is needed.
•
T
he tire pressures should be checked when the
tires are cold. The tires are considered cold after
the vehicle has been parked for 3 hours or more or
driven less than 1 mi (1.6 km) at moderate speeds.
After the tire pressures are adjusted, drive the
vehicle at speeds above 16 mph (25 km/h). T he CHECK TIRE PRES
warning message and low tire pressure warning light will extinguish.
When adding air to an under-inflated tire, the TPMS with Easy Fill Tire Alert (if so equipped) provides visual and audible signals to help you inflate the\
tires to the
recommended COLD tire pressure.
T
o use the Easy Fill Tire Alert (if so equipped):
1.
Move the shift lever to the
P (PARK) position and apply the parking brake.
2.
Place the ignition switc
h in the ON position. Do not start the engine.
3.
Add air to the under-inflated tire, and within a few seconds the hazar\
d warning
lights will st
art flashing.
4.
W
hen the designated tire pressure is reached, the horn will beep once and the
hazard warning flashers will stop flashing.
5.
Repeat this procedure for any additional under-inflated tires.
When the low tire pressure warning light flashes for 1 minute and then \
remains on, the TPMS is not functioning properly. Have the system checked by a NISSAN dealer.
Tire pressure rises and falls depending on the heat caused by the vehicle\
’s operation and the outside temperature. Low outside temperature can lower the tempe\
rature of
the air inside the tire, which can cause a lower tire inflation pressure. This may cause
the low tire pressure warning light to illuminate. If the warning light \
illuminates, check
the tire pressure in your tires.
•
Chec
k the tire pressure (including the spare tire) often and always prior \
to long
distance trips.
The Tire and Loading Information label contains valuable information. Please refer to “Technical and consumer information (section 9)”, in your Owner’s Manual for the
location of the Tire and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)” , the “Starting and driving (section 5)”
and the “Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
1
2
LOOSE FUEL CAP
A LOOSE FUEL CAP warning message will
display in the odometer
1 when the fuel-filler
cap is not tightened correctly.
To tighten, turn the cap clockwise until a single click is heard.
1
2
1804921_15c_Versa_Sedan_QRG_080714.indd 48/7/14 2:22 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 7 of 24
5
CLOCK SET/ADJUSTMENT
To adjust the time and the appearance of the clock on the display:
1. Press the button 1.
2. T
ouch the “Settings” key.
3. T
ouch the “System” key.
4. T
ouch the “Clock” key.
The following settings can be adjusted:
•
T
ime Format: The clock can be set to 12 hours
or 24 hours.
•
Date F
ormat: The date can be changed to one
of five different formats.
• Cloc
k Mode: From here, the clock mode options are:
·
Manual
: Allows for the option “Set Clock Manually”. Touch this to begin setting
the clock manually using the “+” or “–” key to adjust the hours, \
minutes, day and
month up or down.
·
Time Zone: Touch the “Time Zone” key
2
to choose from the applicable time zone list
and/or touch the “Daylight Savings Time” key
to switch between on and off.
·
A
uto: Automatically sets the clock to the
vehicle’s current location.
Press the BAC K button 3 to return to the
previous screen.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4) ” of
your Owner’s Manual.
FUEL-FILLER DOOR
The fuel-filler door release 1 is located to
the left of the steering wheel and below the
instrument panel.
To open the fuel-filler door, pull the release. To lock, close the fuel-filler door securely.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
3
1
2
1
The warning message will disappear when the vehicle detects the fuel-filler cap is properly tightened and the reset button
2 is pressed for more than 1 second.
If the cap is not fully tightened, the Malfunction Indicator light
may also illuminate.
For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks and
adjustments (section 3)” of your Owner’s Manual.
1804921_15c_Versa_Sedan_QRG_080714.indd 58/7/14 2:22 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 8 of 24
6
NISSAN INTELLIGENT KEY® SYSTEM (if so equipped)
The NISSAN Intelligent Key® system allows you
to lock or unlock your vehicle, open your trunk
and start the engine.
It is import ant to make sure the Intelligent Key is
with you (that is, in your pocket or purse).
The operating range of the Intelligent K ey is
within 31.5 in (80 cm) from each request switch.
To lock the vehicle, push either door handle request switch
1 once or press the
button
2 on the key fob.
To unlock the vehicle, perform one of the
following procedures:
•
Push either door handle request switch
1 once; the corresponding door will
unlock. Push the door handle request switch 1 again within 5 seconds; all other
doors will unlock, or
•
Press the button
3 on the key fob to unlock the driver’s side door. Press the
button again; all other doors will unlock.
To open the trunk, press the button
4 for more than 1 second.
The Intelligent Key can also be used to activate the panic alarm by pressing and
holding the
button
5 for more than 1 second. Once activated, the panic alarm
and headlights will stay on for a period of time.
INTELLIGENT KEY BATTERY DISCHARGE
If the battery of the Intelligent K ey is discharged
or environmental conditions interfere with
the Intelligent Key operation, start the engine
according to the following procedure:
1.
Move the shift lever to the P (P
ARK) position.
2.
Firmly apply the foot brake.
3.
Touc
h the ignition switch with the Intelligent
Key and a chime will sound.
4.
W
ithin 10 seconds after the chime sounds, push the ignition switch while
depressing the brake pedal and the engine will start.
For more information, refer to the “Pre-driving checks and adjustments (section 3)”, “Starting and driving
(section 5)” and the “Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
23
4
5
1
FIRST DRIVE FEATURES
1804921_15c_Versa_Sedan_QRG_080714.indd 68/7/14 2:22 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 9 of 24
7
REAR TRUNK RELEASE
(if so equipped)
Use one of the following methods to
open the trunk:
•
Push the trunk opener request switc
h
1,
located under the center of the trunk handle, for
more than 1 second while carrying the NISSAN
Intelligent Key
® (if so equipped) with you.
•
Press the trunk release button 2 on
the Intelligent Key (if so equipped) for more than
1 second.
For more information, refer to the “Pre-driving checks and
adjustments (section 3)” of your Owner’s Manual.
SEAT ADJUSTMENTS
To slide the front seat forward or backward, pull
up on the lever
1 under the front of the seat
and slide forward or backward. Release the lever
to lock the seat in position.
To recline the seatback, pull up on the lever
2
and lean back. To bring the seatback forward,
pull the lever up and lean your body forward.
Release the lever to lock the seatback in position.
SEAT LIFTER (if so equipped for driver’s seat)
To adjust the seat height, pull up or push down
on the adjusting lever
3 repeatedly.
For more information, refer to the “Safety — Seats, seat belts and
supplemental restraint system (section 1)” of your Owner’s Manual.
1
23
2
1
POWER OUTSIDE MIRROR CONTROL SWITCH (if so equipped)
Move the switc
h
1 right or left to select the
right or left mirror.
Adjust eac h mirror to the desired position using
the switch
2.
Move the switc h
1 to the middle (neutral)
position to prevent accidentally moving the mirrors.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
1
2
1804921_15c_Versa_Sedan_QRG_080714.indd 78/7/14 2:22 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
Page 10 of 24
8
HEADLIGHT CONTROL SWITCH
HEADLIGHT CONTROL
Turn the headlight control switch to the
position 1 to turn on the front parking, tail,
license plate and instrument panel lights. Turn
the switch to the
position
2 to turn on
the headlights.
1
2
STARTING/STOPPING THE ENGINE
STARTING THE ENGINE
It is import ant to make sure the Intelligent Key is
with you (that is, in your pocket or purse).
CONTINUOUSLY VARIABLE TRANSMISSION
(NISSAN Intelligent Key
® models only - if so equipped)
Depress the brake pedal.
•
If the brake pedal is not depressed, pushing the
ignition switc
h once enters the ACC mode.
•
If the ignition is pushed a second time, the vehicle will enter the O
N mode.
Move the shift lever to the P (PARK) position.
Push the ignition switch to start or stop the engine.
CONTINUOUSLY VARIABLE TRANSMISSION/ AUTOMATIC/MANUAL TRANSMISSION
(if so equipped)
Depress the brake pedal.
Move the shift lever to the N (NEUTRAL)
position (manual transmission only).
Depress the clutc h (manual transmission only)
pedal to the floor.
Turn the ignition switch to START.
TURNING THE ENGINE OFF
For a Continuously Variable Transmission (NISSAN Intelligent Key® models only - if so
equipped), apply the brake pedal, move the shift lever to the P (PARK) position, apply
the parking brake and push the ignition START/STOP switch to turn the engine off.
For a manual transmission, apply the brake pedal, place the vehicle in 1s\
t gear, apply the parking brake and turn the ignition switch to the LOCK position.
For automatic transmission and Continuously Variable Transmission, apply the brake pedal, move the shift lever to P (PARK) position, apply the parking brake and turn the
ignition switch to the LOCK position.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
FIRST DRIVE FEATURES
1804921_15c_Versa_Sedan_QRG_080714.indd 88/7/14 2:22 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
