SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00100
General SpecificationsEBS011GJ
Mass Air Flow SensorEBS011GK
Engine Coolant Temperature SensorEBS011GL
Fuel Rail Pressure SensorEBS011GM
Glow PlugEBS011GN
EGR Volume Control ValveEBS011GO
Crankshaft Position Sensor EBS011GP
Refer to EC-1049, "Component Inspection" .
Camshaft Position Sensor EBS011GQ
Refer to EC-1061, "Component Inspection" .
EngineYD22DDTi
Idle speed725 ± 25 rpm
Maximum engine speed 4,900 rpm
Supply voltageBattery voltage (11 - 14V)
Ignition switch ON (Engine stopped.) Approx. 0.4V
Idle (Engine is warmed up to normal operating temperature.) 1.5 - 2.0V
2,000 rpm (Engine is warmed up to normal operating tempera-
ture.)2.2 - 2.7V
Temperature °C (°F)Resistance kΩ
20 (68)2.1 - 2.9
50 (122)0.68 - 1.00
90 (194)0.236 - 0.260
Supply voltageApproximately 5V
Idle (Engine is warmed up to normal operating temperature.) 1.7 - 2.0V
2,000 rpm (Engine is warmed up to normal operating tempera-
ture.)2.0 - 2.3V
Resistance [at 25°C (77°F)] Ω Approximately 0.8
Resistance [at 25°C (77°F)] Ω13 - 17

INDEX FOR DTC
EC-1205
[YD (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

[YD (WITHOUT EURO-OBD)]INDEX FOR DTCPFP:00024
Alphabetical IndexEBS011WP
Check if the vehicle is a model with Euro-OBD (E-OBD) system or not by the “Type approval number” on the
identification plate. Refer to GI-44, "
IDENTIFICATION PLATE" .
NOTE:
If DTC U1000 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000. Refer to
EC-1268, "
DTC U1000 CAN COMMUNICATION LINE" .
X: Applicable —: Not applicable
Items
(CONSULT-II screen terms) DTC* MI lighting up Reference page
APP SEN 1/CIRCUIT P0122 —EC-1297
APP SEN 1/CIRCUIT P0123 —EC-1297
APP SEN 2/CIRCUIT P0222 —EC-1332
APP SEN 2/CIRCUIT P0223 —EC-1332
APP SENSOR P2135 —EC-1437
BARO SEN/CIRC P2228 —EC-1455
BARO SEN/CIRC P2229 —EC-1455
BATTERY VOLTAGE P0563 —EC-1376
CAN COMM CIRCUIT U1000 —EC-1268
CKP SEN/CIRCUIT P0335×EC-1351
CKP SENSOR P0336×EC-1357
CMP SEN/CIRCUIT P0340×EC-1363
CMP SENSOR P0341×EC-1369
CMP/CKP RELATION P0016 —EC-1271
CYL1 INJECTOR P0201 —EC-1314
CYL2 INJECTOR P0202 —EC-1314
CYL3 INJECTOR P0203 —EC-1314
CYL4 INJECTOR P0204 —EC-1314
ECM P0605×EC-1378
ECM P0606×EC-1380
ECM RELAY P0686 —EC-1399
ECT SEN/CIRCUIT P0117 —EC-1291
ECT SEN/CIRCUIT P0118 —EC-1291
ENG OVER TEMP P0217×EC-1320
FRP RELIEF VALVE P1272 —EC-1416
FRP SEN/CIRC P0192 —EC-1307
FRP SEN/CIRC P0193 —EC-1307
FUEL LEAK P0093×EC-1277
FUEL PUMP P0089 —EC-1275
FUEL PUMP P1273 —EC-1422
FUEL PUMP P1274×EC-1427
FUEL PUMP P1275×EC-1432
FUEL PUMP/CIRC P0628×EC-1382
FUEL PUMP/CIRC P0629×EC-1382
FUEL TEMP SEN/CIRC P0182 —EC-1303
FUEL TEMP SEN/CIRC P0183 —EC-1303

EC-1206
[YD (WITHOUT EURO-OBD)]
INDEX FOR DTC

*: This number is prescribed by ISO 15031-6.
DTC No. IndexEBS011WQ
Check if the vehicle is a model with Euro-OBD (E-OBD) system or not by the “Type approval number” on the
identification plate. Refer to GI-44, "
IDENTIFICATION PLATE" .
NOTE:
If DTC U1000 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000. Refer to
EC-1268, "
DTC U1000 CAN COMMUNICATION LINE" .
HIGH FUEL PRESS P0088×EC-1273
IAT SEN/CIRCUIT P0112 —EC-1286
IAT SEN/CIRCUIT P0113 —EC-1286
INJ ADJ RES/CIRC1 P1260 —EC-1404
INJ ADJ RES/CIRC1 P1261 —EC-1404
INJ ADJ RES/CIRC2 P1262 —EC-1404
INJ ADJ RES/CIRC2 P1263 —EC-1404
INJ ADJ RES/CIRC3 P1264 —EC-1404
INJ ADJ RES/CIRC3 P1265 —EC-1404
INJ ADJ RES/CIRC4 P1266 —EC-1404
INJ ADJ RES/CIRC4 P1267 —EC-1404
INJ PWR/CIRC P2146×EC-1443
INJ PWR/CIRC P2149×EC-1443
INJECTOR P0200×EC-1313
INJECTOR/CIRC P2147×EC-1448
INJECTOR/CIRC P2148×EC-1448
INJECTOR 1 P1268 —EC-1410
INJECTOR 2 P1269 —EC-1410
INJECTOR 3 P1270 —EC-1410
INJECTOR 4 P1271 —EC-1410
MAF SEN/CIRCUIT P0102 —EC-1280
MAF SEN/CIRCUIT P0103 —EC-1280
NATS MALFUNCTION P1610 - P1617 —EC-1224
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000——
SENSOR PWR/CIRC1 P0642 —EC-1387
SENSOR PWR/CIRC1 P0643 —EC-1387
SENSOR PWR/CIRC2 P0652 —EC-1393
SENSOR PWR/CIRC2 P0653 —EC-1393
TC BOOST SEN/CIRC P0237 —EC-1345
TC BOOST SEN/CIRC P0238 —EC-1345
TC SYSTEM P0234 —EC-1338
TCS/CIRC P1212×EC-1403
TCS C/U FUNCTN P1211×EC-1402
Items
(CONSULT-II screen terms) DTC* MI lighting up Reference page

INDEX FOR DTC
EC-1207
[YD (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

X: Applicable —: Not applicable
DTC*Items
(CONSULT-II screen item) MI lighting up Reference page
U1000 CAN COMM CIRCUIT —EC-1268
P0000NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.——
P0016 CMP/CKP RELATION —EC-1271
P0088 HIGH FUEL PRESS×EC-1273
P0089 FUEL PUMP —EC-1275
P0093 FUEL LEAK×EC-1277
P0102 MAF SEN/CIRCUIT —EC-1280
P0103 MAF SEN/CIRCUIT —EC-1280
P0112 IAT SEN/CIRCUIT —EC-1286
P0113 IAT SEN/CIRCUIT —EC-1286
P0117 ECT SEN/CIRCUIT —EC-1291
P0118 ECT SEN/CIRCUIT —EC-1291
P0122 APP SEN 1/CIRCUIT —EC-1297
P0123 APP SEN 1/CIRCUIT —EC-1297
P0182 FUEL TEMP SEN/CIRC —EC-1303
P0183 FUEL TEMP SEN/CIRC —EC-1303
P0192 FRP SEN/CIRC —EC-1307
P0193 FRP SEN/CIRC —EC-1307
P0200 INJECTOR×EC-1313
P0201 CYL1 INJECTOR —EC-1314
P0202 CYL2 INJECTOR —EC-1314
P0203 CYL3 INJECTOR —EC-1314
P0204 CYL4 INJECTOR —EC-1314
P0217 ENG OVER TEMP×EC-1320
P0222 APP SEN 2/CIRCUIT —EC-1332
P0223 APP SEN 2/CIRCUIT —EC-1332
P0234 TC SYSTEM —EC-1338
P0237 TC BOOST SEN/CIRC —EC-1345
P0238 TC BOOST SEN/CIRC —EC-1345
P0335 CKP SEN/CIRCUIT×EC-1351
P0336 CKP SENSOR×EC-1357
P0340 CMP SEN/CIRCUIT×EC-1363
P0341 CMP SENSOR×EC-1369
P0563 BATTERY VOLTAGE —EC-1376
P0605 ECM×EC-1378
P0606 ECM×EC-1380
P0628 FUEL PUMP/CIRC×EC-1382
P0629 FUEL PUMP/CIRC×EC-1382
P0642 SENSOR PWR/CIRC1 —EC-1387
P0643 SENSOR PWR/CIRC1 —EC-1387
P0652 SENSOR PWR/CIRC2 —EC-1393

EC-1208
[YD (WITHOUT EURO-OBD)]
INDEX FOR DTC

*: This number is prescribed by ISO 15031-6.P0653 SENSOR PWR/CIRC2 —EC-1393
P0686 ECM RELAY —EC-1399
P1211 TCS C/U FUNCTN —EC-1402
P1212 TCS/CIRC —EC-1403
P1260 INJ ADJ RES/CIRC1 —EC-1404
P1261 INJ ADJ RES/CIRC1 —EC-1404
P1262 INJ ADJ RES/CIRC2 —EC-1404
P1263 INJ ADJ RES/CIRC2 —EC-1404
P1264 INJ ADJ RES/CIRC3 —EC-1404
P1265 INJ ADJ RES/CIRC3 —EC-1404
P1266 INJ ADJ RES/CIRC4 —EC-1404
P1267 INJ ADJ RES/CIRC4 —EC-1404
P1268 INJECTOR 1 —EC-1410
P1269 INJECTOR 2 —EC-1410
P1270 INJECTOR 3 —EC-1410
P1271 INJECTOR 4 —EC-1410
P1272 FRP RELIEF VALVE —EC-1416
P1273 FUEL PUMP —EC-1422
P1274 FUEL PUMP×EC-1427
P1275 FUEL PUMP×EC-1432
P1610 - P1617 NATS MALFUNTION —EC-1224
P2135 APP SENSOR —EC-1437
P2146 INJ PWR/CIRC×EC-1443
P2147 INJECTOR/CIRC×EC-1448
P2148 INJECTOR/CIRC×EC-1448
P2149 INJ PWR/CIRC×EC-1443
P2228 BARO SEN/CIRC —EC-1455
P2229 BARO SEN/CIRC —EC-1455
DTC*Items
(CONSULT-II screen item) MI lighting up Reference page

PRECAUTIONS
EC-1209
[YD (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EBS011WR
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SRS and SB section of
this Service Manual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
On Board Diagnostic (OBD) System of EngineEBS011WS
The ECM has an on board diagnostic system. It will light up the malfunction indicator (MI) to warn the driver of
a malfunction causing emission deterioration.
CAUTION:

Be sure to turn the ignition switch OFF and disconnect the battery ground cable before any repair
or inspection work. The open/short circuit of related switches, sensors, solenoid valves, etc. will
cause the MI to light up.

Be sure to connect and lock the connectors securely after work. A loose (unlocked) connector will
cause the MI to light up due to the open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)

Certain systems and components, especially those related to OBD, may use a new style slide-
locking type harness connector. For description and how to disconnect, refer to PG-70, "
HAR-
NESS CONNECTOR" .

Be sure to route and secure the harnesses properly after work. The interference of the harness
with a bracket, etc. may cause the MI to light up due to the short circuit.

Be sure to connect rubber tubes properly after work. A misconnected or disconnected rubber tube
may cause the MI to light up due to the malfunction of the fuel system, etc.

Be sure to erase the unnecessary malfunction information (repairs completed) from the ECM
before returning the vehicle to the customer.
PrecautionsEBS011WT

Always use a 12 volt battery as power source.

Do not attempt to disconnect battery cables while engine is
running.

Before connecting or disconnecting the ECM harness con-
nector, turn ignition switch OFF and disconnect battery
ground cable. Failure to do so may damage the ECM
because battery voltage is applied to ECM even if ignition
switch is turned off.

Before removing parts, turn ignition switch OFF and then
disconnect battery ground cable.
SEF289H

EC-1210
[YD (WITHOUT EURO-OBD)]
PRECAUTIONS


Do not disassemble ECM.

When connecting ECM harness connector, fasten it
securely with levers as far as they will go as shown in the
figure.

When connecting or disconnecting pin connectors into or
from ECM, take care not to damage pin terminals (bend or
break).
Make sure that there are not any bends or breaks on ECM
pin terminal, when connecting pin connectors.

Securely connect ECM harness connectors.
A poor connection can cause an extremely high (surge)
voltage to develop in coil and condenser, thus resulting in
damage to IC's.

Keep engine control system harness at least 10cm (4 in)
away from adjacent harness, to prevent engine control sys-
tem malfunctions due to receiving external noise, degraded
operation of IC's, etc.

Keep engine control system parts and harness dry.

Before replacing ECM, perform ECM Terminals and Refer-
ence Value inspection and make sure ECM functions prop-
erly. Refer to EC-1245, "
ECM Terminals And Reference
Va l u e" .

Handle mass air flow sensor carefully to avoid damage.

Do not disassemble mass air flow sensor.

Do not clean mass air flow sensor with any type of deter-
gent.

Even a slight leak in the air intake system can cause seri-
ous incidents.

Do not shock or jar the camshaft position sensor, crank-
shaft position sensor.
MBIB0625E
PBIB1512E
SEF291H
MEF040D

PRECAUTIONS
EC-1211
[YD (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC


After performing each TROUBLE DIAGNOSIS, perform DTC
Confirmation Procedure or Overall Function Check.
The DTC should not be displayed in the DTC Confirmation
Procedure if the repair is completed. The Overall Function
Check should be a good result if the repair is completed.

When measuring ECM signals with a circuit tester, never
allow the two tester probes to contact.
Accidental contact of probes will cause a short circuit and
damage the ECM power transistor.

Do not use ECM ground terminals when measuring input/
output voltage. Doing so may result in damage to the ECM's
transistor. Use a ground other than ECM terminals, such as
the ground.

Do not disassemble fuel pump.
If NG, take proper action.

Do not disassemble fuel injector.
If NG, replace fuel injector.

Do not depress accelerator pedal when staring.

Immediately after staring, do not rev up engine unnecessar-
ily.

Do not rev up engine just prior to shutdown.

When installing C.B. ham radio or a mobile phone, be sure
to observe the following as it may adversely affect elec-
tronic control systems depending on installation location.
–Keep the antenna as far as possible from the electronic
control units.
–Keep the antenna feeder line more than 20 cm (8 in) away
from the harness of electronic controls.
Do not let them run parallel for a long distance.
–Adjust the antenna and feeder line so that the standingwave
radio can be kept smaller.
–Be sure to ground the radio to vehicle body.
SAT652J
SEF348N
SEF709Y
SEF708Y

EC-1212
[YD (WITHOUT EURO-OBD)]
PRECAUTIONS

Wiring Diagrams and Trouble DiagnosisEBS011WU
When you read Wiring diagrams, refer to the following:

GI-14, "How to Read Wiring Diagrams".

PG-2, "POWER SUPPLY ROUTING" for power distribution circuit
When you perform trouble diagnosis, refer to the following:

GI-10, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES".

GI-23, "How to Perform Efficient Diagnosis for an Electrical Incident".
