NISSAN X-TRAIL 2003 Service Repair Manual

INDEX FOR DTC
EC-483
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by ISO 15031-5.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: When engine is running.
*5: The troubleshooting for this DTC needs CONSULT-II.
*6: For models with ESP system.
*7: Except QR20DE with A/T models.
*8: For QR20DE with A/T models.P-N POS SW/CIRCUIT*
7P1706 1706 2 —EC-725
SENSOR POWER/CIRC P1229 1229 1×EC-720
TCS C/U FUNCTN*6P1211 1211 2 —EC-698
TCS/CIRC*6P1212 1212 2 —EC-699
TP SEN 1/CIRC P0222 0222 1×EC-625
TP SEN 1/CIRC P0223 0223 1×EC-625
TP SEN 2/CIRC P0122 0122 1×EC-603
TP SEN 2/CIRC P0123 0123 1×EC-603
TP SENSOR P2135 2135 1×EC-755
VEH SPEED SEN/CIRC P0500 0500 2×EC-654
V/SP SEN (A/T OUT) P1720 1720 2 —EC-730
Items
(CONSULT-II screen terms)DTC*1
TripMI lighting
upReference page
CONSULT-II*2ECM*3

EC-484
[QR (WITHOUT EURO-OBD)]
INDEX FOR DTC

DTC No. IndexEBS010WF
NOTE:
If DTC U1000 or U1001 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000,
U1001. Refer to EC-579, "
DTC U1000, U1001 CAN COMMUNICATION LINE" .
DTC*1Items
(CONSULT-II screen terms)TripMI lighting
upReference page
CONSULT-II*
2ECM*3
No DTC
Flashing*4NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.—
Flashing*4EC-517
U1000
1000*5CAN COMM CIRCUIT 2 —EC-579
U1001
1001*5CAN COMM CIRCUIT 2 —EC-579
P0000 0000NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.———
P0011 0011 INT/V TIM CONT-B1 2 —EC-582
P0102 0102 MAF SEN/CIRCUIT 1×EC-590
P0103 0103 MAF SEN/CIRCUIT 1×EC-590
P0117 0117 ECT SEN/CIRCUIT 2×EC-597
P0118 0118 ECT SEN/CIRCUIT 2×EC-597
P0122 0122 TP SEN 2/CIRC 1×EC-603
P0123 0123 TP SEN 2/CIRC 1×EC-603
P0132 0132 HO2S1 (B1) 2
×*8 or —*7EC-611
P0134 0134 HO2S1 (B1) 2×EC-618
P0222 0222 TP SEN 1/CIRC 1×EC-625
P0223 0223 TP SEN 1/CIRC 1×EC-625
P0327 0327 KNOCK SEN/CIRC-B1 2 —EC-633
P0328 0328 KNOCK SEN/CIRC-B1 2 —EC-633
P0335 0335 CKP SEN/CIRCUIT 2×EC-638
P0340 0340 CMP SEN/CIRC-B1 2×EC-646
P0500 0500 VEH SPEED SEN/CIRC 2×EC-654
P0550 0550 PW ST P SEN/CIRC 2 —EC-656
P0605 0605 ECM 1 or 2× or —EC-661
P1065 1065 ECM BACK UP/CIRC 2×EC-664
P1121 1121 ETC ACTR 1×EC-668
P1122 1122 ETC FUNCTION/CIRC 1×EC-671
P1124 1124 ETC MOT PWR 1×EC-682
P1126 1126 ETC MOT PWR 1×EC-682
P1128 1128 ETC MOT 1×EC-690
P1211 1211
TCS CU FUNCTN*62—EC-698
P1212 1212
TCS/CIRC*62—EC-699
P1217 1217 ENG OVER TEMP 1×EC-700
P1225 1225 CTP LEARNING 2 —EC-716
P1226 1226 CTP LEARNING 2 —EC-718
P1229 1229 SENSOR POWER/CIRC 1×EC-720
P1610 - P1615 1610 - 1615 NATS MALFUNCTION 2 —EC-515
P1706 1706
P-N POS SW/CIRCUIT*72—EC-725

INDEX FOR DTC
EC-485
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by ISO 15031-5.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: When engine is running.
*5: The troubleshooting for this DTC needs CONSULT-II.
*6: For models with ESP system.
*7: Except QR20DE with A/T models.
*8: For QR20DE with A/T models.P1720 1720 V/SP SEN (A/T OUT) 2 —EC-730
P1805 1805 BRAKE SW/CIRCUIT 1×EC-733
P2122 2122 APP SEN 1/CIRC 1×EC-740
P2123 2123 APP SEN 1/CIRC 1×EC-740
P2127 2127 APP SEN 2/CIRC 1×EC-747
P2128 2128 APP SEN 2/CIRC 1×EC-747
P2135 2135 TP SENSOR 1×EC-755
P2138 2138 APP SENSOR 1×EC-763
DTC*1Items
(CONSULT-II screen terms)TripMI lighting
upReference page
CONSULT-II*
2ECM*3

EC-486
[QR (WITHOUT EURO-OBD)]
PRECAUTIONS

PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EBS010WG
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SRS and SB section of
this Service Manual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
On Board Diagnostic (OBD) System of EngineEBS010WH
The ECM has an on board diagnostic system. It will light up the malfunction indicator (MI) to warn the driver of
a malfunction causing emission deterioration.
CAUTION:

Be sure to turn the ignition switch OFF and disconnect the battery ground cable before any repair
or inspection work. The open/short circuit of related switches, sensors, solenoid valves, etc. will
cause the MI to light up.

Be sure to connect and lock the connectors securely after work. A loose (unlocked) connector will
cause the MI to light up due to the open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)

Certain systems and components, especially those related to OBD, may use a new style slide-
locking type harness connector. For description and how to disconnect, refer to PG-70, "
HAR-
NESS CONNECTOR" .

Be sure to route and secure the harnesses properly after work. The interference of the harness
with a bracket, etc. may cause the MI to light up due to the short circuit.

Be sure to erase the unnecessary malfunction information (repairs completed) from the ECM.
PrecautionEBS010WI

Always use a 12 volt battery as power source.

Do not attempt to disconnect battery cables while engine is
running.

Before connecting or disconnecting the ECM harness con-
nector, turn ignition switch OFF and disconnect battery
ground cable. Failure to do so may damage the ECM
because battery voltage is applied to ECM even if ignition
switch is turned OFF.

Before removing parts, turn ignition switch OFF and then
disconnect battery ground cable.
SEF289H

PRECAUTIONS
EC-487
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC


Do not disassemble ECM.

If battery cable is disconnected, the memory will return to
the initial ECM values.
The ECM will now start to self-control at its initial values.
Engine operation can vary slightly when the cable is dis-
connected. However, this is not an indication of a malfunc-
tion. Do not replace parts because of a slight variation.

When connecting ECM harness connector, fasten it
securely with levers as far as they will go as shown in the
figure.

When connecting or disconnecting pin connectors into or
from ECM, take care not to damage pin terminals (bend or
break).
Make sure that there are not any bends or breaks on ECM
pin terminal, when connecting pin connectors.

Securely connect ECM harness connectors.
A poor connection can cause an extremely high (surge)
voltage to develop in coil and condenser, thus resulting in
damage to ICs.

Keep engine control system harness at least 10 cm (4 in)
away from adjacent harness, to prevent engine control sys-
tem malfunctions due to receiving external noise, degraded
operation of ICs, etc.

Keep engine control system parts and harness dry.

Before replacing ECM, perform ECM Terminals and Refer-
ence Value inspection and make sure ECM functions prop-
erly. Refer to EC-543
.

Handle mass air flow sensor carefully to avoid damage.

Do not disassemble mass air flow sensor.

Do not clean mass air flow sensor with any type of deter-
gent.

Do not disassemble electric throttle control actuator.

Even a slight leak in the air intake system can cause seri-
ous incidents.

Do not shock or jar the camshaft position sensor (PHASE),
crankshaft position sensor (POS).
PBIB1164E
PBIB1512E
PBIB0090E
MEF040D

EC-488
[QR (WITHOUT EURO-OBD)]
PRECAUTIONS


After performing each TROUBLE DIAGNOSIS, perform DTC
Confirmation Procedure or Overall Function Check.
The DTC should not be displayed in the DTC Confirmation
Procedure if the repair is completed. The Overall Function
Check should be a good result if the repair is completed.

When measuring ECM signal with a circuit tester, connect
break-out box (SST) and Y-cable adapter (SST) between the
ECM and ECM harness connector.

When measuring ECM signals with a circuit tester, never
allow the two tester probes to contact.
Accidental contact of probes will cause a short circuit and
damage the ECM power transistor.

Do not use ECM ground terminals when measuring input/
output voltage. Doing so may result in damage to the ECM's
transistor. Use a ground other than ECM terminals, such as
the ground.

Do not operate fuel pump when there is no fuel in lines.

Tighten fuel hose clamps to the specified torque.
SAT652J
SEF348N
PBIB0513E

PRECAUTIONS
EC-489
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC


Do not depress accelerator pedal when starting.

Immediately after starting, do not rev up engine unneces-
sarily.

Do not rev up engine just prior to shutdown.

When installing C.B. ham radio or a mobile phone, be sure
to observe the following as it may adversely affect elec-
tronic control systems depending on installation location.
–Keep the antenna as far as possible from the electronic
control units.
–Keep the antenna feeder line more than 20 cm (8 in) away
from the harness of electronic controls.
Do not let them run parallel for a long distance.
–Adjust the antenna and feeder line so that the standing-
wave radio can be kept smaller.
–Be sure to ground the radio to vehicle body.
Wiring Diagrams and Trouble DiagnosisEBS010WJ
When you read wiring diagrams, refer to the following:

GI-14, "How to Read Wiring Diagrams"

PG-2, "POWER SUPPLY ROUTING" for power distribution circuit
When you perform trouble diagnosis, refer to the following:

GI-10, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES"

GI-23, "How to Perform Efficient Diagnosis for an Electrical Incident"
SEF709Y
SEF708Y

EC-490
[QR (WITHOUT EURO-OBD)]
PREPARATION

PREPARATIONPFP:00002
Special Service ToolsEBS010WK
Tool number
Tool nameDescription
KV10117100
Heated oxygen
sensor wrenchLoosening or tightening heated oxygen sensor
with 22 mm (0.87 in) hexagon nut
KV10114400
Heated oxygen
sensor wrenchLoosening or tightening heated oxygen sensor
a: 22 mm (0.87 in)
EG17650301
Radiator cap tester
adapterAdapting radiator cap tester to radiator cap and
radiator filler neck
a: 28 (1.10) dia.
b: 31.4 (1.236) dia.
c: 41.3 (1.626) dia.
Unit: mm (in)
KV109E0010
Break-out boxMeasuring ECM signals with a circuit tester
KV109E0080
Y-cable adapterMeasuring ECM signals with a circuit tester
S-NT379
S-NT636
S-NT564
NT825
NT826

PREPARATION
EC-491
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC

Commercial Service ToolsEBS010WL
Tool name Description Description
Quick connector
releaseRemoving fuel tube quick connectors in engine
room
(Available in SEC. 164 of PARTS CATALOG: Part
No. 16441 6N210)
Fuel filler cap adapter Checking fuel tank vacuum relief valve opening
pressure
Socket wrench Removing and installing engine coolant
temperature sensor
Oxygen sensor thread
cleaner
ie: (J-43897-18)
(J-43897-12)Reconditioning the exhaust system threads
before installing a new oxygen sensor. Use with
anti-seize lubricant shown below.
a: 18 mm diameter with pitch 1.5 mm for
Zirconia Oxygen Sensor
b: 12 mm diameter with pitch 1.25 mm for
Titania Oxygen Sensor
Anti-seize lubricant
i.e.: (Permatex
TM
133AR or equivalent
meeting MIL
specification MIL-A-
907)Lubricating oxygen sensor thread cleaning tool
when reconditioning exhaust system threads.
PBIC0198E
S-NT653
S-NT705
AEM488
S-NT779

EC-492
[QR (WITHOUT EURO-OBD)]
ENGINE CONTROL SYSTEM

ENGINE CONTROL SYSTEMPFP:23710
System DiagramEBS010WM
QR20DE ENGINE MODELS
PBIB2455E
