E-85 fuelE-85 fuel is a mixture of approximately 85% fuel
ethanol and 15% unleaded gasoline. E-85 can
only be used in a Flexible Fuel Vehicle (FFV). Do
not use E-85 fuel in your vehicle. U.S. govern-
ment regulations require fuel ethanol dispensing
pumps to be identified by a small, square, or-
ange and black label with the common abbre-
viation or the appropriate percentage for that
region.Aftermarket fuel additivesNISSAN does not recommend the use of any
aftermarket fuel additives (for example, fuel in-
jector cleaner, octane booster, intake valve de-
posit removers, etc.) which are sold commer-
cially. Many of these additives intended for gum,
varnish or deposit removal may contain active
solvent or similar ingredients that can be harmful
to the fuel system and engine.Octane rating tipsUsing unleaded gasoline with an octane
rating lower than recommended can cause
persistent, heavy spark knock. (Spark
knock is a metallic rapping noise.) If se-
vere, this can lead to engine damage. If you
detect a persistent heavy spark knock even
when using gasoline of the stated octane
rating, or if you hear steady spark knockwhile holding a steady speed on level
roads, have your dealer correct the condi-
tion. Failure to correct the condition is
misuse of the vehicle, for which NISSAN is
not responsible.
Incorrect ignition timing will result in knocking,
after-run or overheating. This in turn may cause
excessive fuel consumption or damage to the
engine. If any of the above symptoms are en-
countered, have your vehicle checked at a
NISSAN dealer or other competent service fa-
cility.
However, now and then you may notice
light spark knock for a short time while
accelerating or driving up hills. This is no
cause for concern, because you get the
greatest fuel benefit when there is light
spark knock for a short time under heavy
engine load.9-4
Technical and consumer information
06.4.14/T30-J/V5.0
Page 252 of 281
1
API certification mark
2
API service symbol
ENGINE OIL AND OIL FILTER
RECOMMENDATION
Selecting the correct oilIt is essential to choose the correct quality, and
viscosity oil to ensure satisfactory engine life and
performance. NISSAN recommends the use of a
low friction oil (energy conserving oil) in order to
improve fuel economy and conserve energy. Oils
which do not have the specified quality labelshould not be used as they could cause engine
damage.
Only those engine oils with the American Petro-
leum Institute (API) certification mark on the front
of the container should be used. This type of oil
supersedes the existing API SG, SH, or SJ and
Energy ConservingI&IIcategories.
If you cannot find engine oil with the API certifi-
cation mark, use an API grade SG, Energy
Conserving II or API grade SH, SJ or SL, Energy
conserving oil. An oil with a single designation
SG or SH, or in combination with other catego-
ries (for example, SG/CC or SG/CD) may also
be used if one with the API certification markcannot be found. An ILSAC grade, GF-II or
GF-III oil can also be used.
NISSAN recommends mineral based oils. These
oils must however, meet the API quality and SAE
viscosity ratings specified for your vehicle.
Oil additivesNISSAN does not recommend the use of oil
additives. The use of an oil additive is not
necessary when the proper oil type is used and
maintenance intervals are followed.
Oil which may contain foreign matter or has
been previously used should not be used.Oil viscosityThe engine oil viscosity or thickness changes
with temperature. Because of this, it is important
that the engine oil viscosity be selected based
on the temperatures at which the vehicle will be
operated before the next oil change. The recom-
mended SAE viscosity number chart shows the
recommended oil viscosities for the expected
ambient temperatures. Choosing an oil viscosity
other than that recommended could cause seri-
ous engine damage.Selecting the correct oil filterYour new vehicle is equipped with a high-quality
genuine NISSAN oil filter. When replacing, use
STI0367A
Technical and consumer information
9-5
06.4.14/T30-J/V5.0
Page 253 of 281
the genuine oil filter or its equivalent for the
reason described in change intervals.Change intervalsThe oil and oil filter change intervals for your
engine are based on the use of the specified
quality oils and filters. Oil and filter other than the
specified quality, or oil and filter change intervals
longer than recommended could reduce engine
life. Damage to engines caused by improper
maintenance or use of incorrect oil and filter
quality and/or viscosity is not covered by the
new NISSAN vehicle warranties.
Your engine was filled with a high quality engine
oil when it was built. You do not have to change
the oil before the first recommended change
interval. Oil and filter change intervals depend
upon how you use your vehicle. Operation under
the following conditions may require more fre-
quent oil and filter changes.
repeated short distance driving at cold out-
side temperatures,
driving in dusty conditions,
extensive idling,
towing a trailer,
stop and go “rush hour” traffic,
aggressive driving.
RECOMMENDED SAE VISCOSITY
NUMBERSAE 5W-30 viscosity oil is preferred for all
ambient temperatures. SAE 10W-30,
10W-40 viscosity oil may be used if the
ambient temperature is above −18°C (0°F).
AIR CONDITIONING SYSTEM
REFRIGERANT AND LUBRICANT
RECOMMENDATIONSThe air conditioning system in this NISSAN
vehicle must be charged with the refriger-
ant HFC-134a (R-134a) and the lubricant,
NISSAN A/C System Oil Type S or the
exact equivalents.
CAUTION
The use of any other refrigerant or lubri-
cant will cause severe damage to the air
conditioning system and will require the
replacement of all air conditioner sys-
tem components.
The refrigerant HFC-134a (R-134a) in your
NISSAN vehicle will not harm the earth’s ozone
layer. Although this refrigerant does not affect
the earth’s atmosphere, certain governmental
regulations require the recovery and recycling of
any refrigerant during automotive air condition-
ing system service. Your NISSAN dealer has the
trained technicians and equipment needed to
recover and recycle your air conditioning system
refrigerant.
TI1028-C
9-6
Technical and consumer information
06.4.14/T30-J/V5.0
Page 254 of 281
Contact a NISSAN dealer when servicing your
air conditioning system.
ENGINE
Model QR25DE
Type Gasoline, 4-cycle
Cylinder arrangement 4-cylinder, inline
Bore x Stroke mm (in) 89.0 x 100.0 (3.504 x 3.937)
Displacement cm
3(cu in) 2,488 (151.82)
Firing order 1-3-4-2
Idle speed rpm
See the emission control label on
the underside of the hood.
Ignition timing (B.T.D.C.) degree
Spark plugStandard PLFR5A-11
Service option PLFR4A-11, PLFR6A-11
Spark plug gap (Normal) mm (in) 0.043 (1.1)
Camshaft operation Timing chain
The spark ignition system of this vehicle meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
SPECIFICATIONS
Technical and consumer information
9-7
06.4.14/T30-J/V5.0
Page 255 of 281
WHEELS AND TIRES
Road wheelType Size Offset mm (in)
Steel 16 x 6-1/2JJ 40 (1.57)
Aluminum16 x 6-1/2JJ 40 (1.57)
17 x 6-1/2JJ 40 (1.57)TireType Size Pressure (COLD)
ConventionalP215/65R16 220 kPa (32 psi)
P215/60R17 200 kPa (29 psi)
Spare Conventional —
DIMENSIONS AND WEIGHTSOverall length mm (in) 4,455 (175.4)
Overall width mm (in) 1,765 (69.5)
Overall heightmm (in) 1,675 (65.9)
mm (in) 1,750 (68.9)*
Front tread mm (in) 1,530 (60.2)
Rear tread mm (in) 1,530 (60.2)
Wheelbase mm (in) 2,625 (103.3)
Gross vehicle weight rating kg (lb)
See the C.M.V.S.S. certifica-
tion label on the driver’s side
lock pillar. Gross axle weight rating
Front kg (lb)
Rear kg (lb)
*: Rear air spoiler or roof rail with driving lights equipped model
9-8
Technical and consumer information
06.4.14/T30-J/V5.0
Page 256 of 281
When planning to travel in another country,
you should first find out if the fuel available is
suitable for your vehicle’s engine.
Using fuel with too low an octane rating may
cause engine damage. All gasoline vehicles
must be operated with unleaded engine gaso-
line. Therefore, avoid taking your vehicle to areas
where appropriate fuel is not available.
When transferring the registration of your
vehicle to another country, state, province
or district,it may be necessary to modify the
vehicle to meet local laws and regulations.
The laws and regulations for motor vehicle emis-
sion control and safety standards vary according
to the country, state, province or district; there-
fore, vehicle specifications may differ.
When any vehicle is to be taken into an-
other country, state, province or district
and registered, its modifications, transpor-
tation, and registration are the responsibil-
ity of the user. NISSAN is not responsible
for any inconvenience that may result.
VEHICLE IDENTIFICATION NUMBER
(VIN) PLATEThe vehicle identification number plate
1
is
attached as shown. This number is the identifi-
cation for your vehicle and is used in the vehicle
registration.
VEHICLE IDENTIFICATION NUMBER
(Chassis number)The number
1
is stamped under the passen-
ger’s seat as shown.
STI0301A
STI0371A
WHENTRAVELING OR
REGISTERING YOUR VEHICLE IN
ANOTHER COUNTRYVEHICLE IDENTIFICATION
Technical and consumer information
9-9
06.4.14/T30-J/V5.0
Page 257 of 281
ENGINE SERIAL NUMBERThe number is stamped on the engine as shown.
C.M.V.S.S. CERTIFICATION LABELThe Canadian Motor Vehicle Safety Standards
(C.M.V.S.S.) certification label is affixed as
shown. This label contains valuable vehicle in-
formation, such as: Gross Vehicle Weight Rat-
ings (GVWR), Gross Axle Weight Rating
(GAWR), month and year of manufacture, Ve-
hicle Identification Number (VIN), etc. Review it
carefully.
EMISSION CONTROL
INFORMATION LABELThe emission control information label is at-
tached as shown.
STI0286C
QR engine
STI0336
STI0393
9-10
Technical and consumer information
06.4.14/T30-J/V5.0
Page 258 of 281
TIRE AND LOADING INFORMATION
LABELThe cold tire pressure are shown on the Tire and
Loading Information label affixed to the driver’s
door center pillar.
AIR CONDITIONER SPECIFICATION
LABELThe air conditioner specification label is affixed
inside of the hood as shown.
WARNING
It is extremely dangerous to
ride in a cargo area inside of a
vehicle. In a collision, people
riding in these areas are more
likely to be seriously injured or
killed
Do not allow people to ride in
any area of your vehicle that is
not equipped with seats and
seat belts.
Be sure everyone in your ve-
hicle is in a seat and using a
seat belt properly.TERMSIt is important to familiarize yourself with
the following terms before loading your
vehicle:
CurbWeight (actual weight of your
vehicle) - vehicle weight including:
standard and optional equipment, flu-
STI0394
STI0395
VEHICLE LOADING
INFORMATIONTechnical and consumer information
9-11
06.4.14/T30-J/V5.0
Page 259 of 281
ids, emergency tools, and spare tire
assembly. This weightdoes notin-
clude passengers and cargo.
GVW (Gross Vehicle Weight) - curb
weight plus the combined weight of
passengers and cargo.
GVWR (Gross Vehicle Weight Rat-
ing) - maximum total combined weight
of the unloaded vehicle, passengers,
luggage, hitch, trailer tongue load and
any other optional equipment. This in-
formation is located on the
F.M.V.S.S./C.M.V.S.S. label.
GAWR (Gross Axle Weight Rating) -
maximum weight (load) limit specified
for the front or rear axle. This informa-
tion is located on the
F.M.V.S.S./C.M.V.S.S. label.
GCWR (Gross Combined Weight
Rating) - maximum total weight rating
of the vehicle, passengers, cargo, and
trailer.
Vehicle Capacity Weight, Load limit,Total load capacity - maximum total
weight limit specified of the load (pas-
sengers and cargo) for the vehicle.
This is the maximum combined weight
of occupants and cargo that can be
loaded into the vehicle. If the vehicle is
used to tow a trailer, the trailer tongue
weight must be included as part of the
cargo load. This information is located
on the Tire and Loading Information
label (if so equipped).
Cargo capacity - permissible weight of
cargo, the subtracted weight of occu-
pants from the load limit.
VEHICLE LOAD CAPACITYDo not exceed the load limit of your
vehicle shown as “The combined weight
of occupants and cargo” on the Tire and
Loading Information label. Do not exceed
the number of occupants shown as
“Seating Capacity” on the Tire and Load-
ing Information label.
To get “the combined weight of occu-
pants and cargo”, add the weight of alloccupants, then add the total luggage
weight. Examples are shown below.
9-12
Technical and consumer information
06.4.14/T30-J/V5.0
Page 260 of 281
Steps for determining correct load
limit1. Locate the statement “The combined
weight of occupants and cargo should
never exceed XXX kg or XXX lbs” on
your vehicle’s placard.
2. Determine the combined weight of the
driver and passengers that will be
riding in your vehicle.
3. Subtract the combined weight of the
driver and passengers from XXX kg or
XXX lbs.
4. The resulting figure equals the avail-
able amount of cargo and luggage
load capacity. For example, if the XXX
amount equals 1400 lbs. and there will
be five 150 lb. passengers in your
vehicle, the amount of available cargo
and luggage load capacity is 650 lbs.
(1400 − 750 (5 x 150) = 650 lbs.) or
(640 − 340 (5 x 70) = 300 kg.)
5. Determine the combined weight of
luggage and cargo being loaded on
STI0445
Technical and consumer information
9-13
06.4.14/T30-J/V5.0
