remote control OLDSMOBILE AURORA 2002 Owners Manual

1-4 Power Lumbar Control (Option)
If your vehicle has this
option, the power lumbar
controls are located on
the outboard side of each
front seat.
Use the power seat control first to get the proper
position, then continue with the lumbar adjustment.
To reshape the lower seatback, press the lumbar control
forward to increase support and rearward to decrease
support. Press the control up or down to raise or lower
the support mechanism.
Keep in mind that as your seating position changes,
as it may during long trips, so should the position of
your lumbar support. Adjust the seat as needed.
If you have the independent front cushion moved down
as far as it will go, you may feel the lumbar support
higher in your back. Readjust the location of the cushion
until you are comfortable. You may also want to adjust
the seatback for maximum comfort.
Memory Seat and Mirrors (If Equipped)
If your vehicle has this
feature, the controls are
located on the driver's
door panel, and are used to
program and recall memory
settings for the driver's
seating, outside mirror
positions and comfort
controls. See ªComfort
Controlsº in the Index for
more information.
To save your seat and mirror positions into memory,
use the following procedure:
1. First identify the DRIVER # on the Driver
Information Center (DIC) by pressing the memory
button (1 or 2) or by pressing the button with
the unlock symbol on the remote keyless entry
transmitter. See ªDriver Information Center (DIC)º
in the Index.
2. Adjust the driver's seat and lumbar position to a safe
and comfortable driving position. Adjust both outside
mirrors to suit you. See ªMirrorsº in the Index.
ProCarManuals.com

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-10 Remote Keyless Entry System
2
-15 Trunk
2
-17 Theft
2
-18 Universal Theft-Deterrent
2
-20 PASS-Key
III
2
-22 New Vehicle ªBreak-Inº
2
-22 Ignition Positions
2
-24 Starting Your Engine
2
-25 Engine Coolant Heater (If Equipped)
2
-26 Automatic Transaxle Operation
2
-29 Parking Brake
2
-30 Shifting Into PARK (P)
2
-32 Shifting Out of PARK (P)2
-32 Parking Over Things That Burn
2
-33 Engine Exhaust
2
-34 Tilt Wheel
2
-35 Turn Signal/Multifunction Lever
2
-43 Exterior Lamps
2
-47 Interior Lamps
2
-51 Mirrors
2
-55 Storage Compartments
2
-57 Accessory Power Outlet
2
-58 OnStar
System (If Equipped)
2
-62 Sunroof (Option)
2
-63 HomeLink
Transmitter (If Equipped)
2
-66 The Instrument Panel - Your
Information System
2
-70 Warning Lights, Gages and Indicators
2
-83 Driver Information Center (DIC)
ProCarManuals.com

2-6
Door Locks
CAUTION:
Unlocked doors can be dangerous.

Passengers -- especially children -- can
easily open the doors and fall out of a
moving vehicle. When a door is locked,
the handle won't open it. You increase the
chance of being thrown out of the vehicle in
a crash if the doors aren't locked. So, wear
safety belts properly and lock the doors
whenever you drive.

Young children who get into unlocked
vehicles may be unable to get out. A child
can be overcome by extreme heat and can
suffer permanent injuries or even death
from heat stroke. Always lock your vehicle
whenever you leave it.

Outsiders can easily enter through an
unlocked door when you slow down or stop
your vehicle. Locking your doors can help
prevent this from happening.
There are several ways to lock and unlock your vehicle.
From the outside, use your key or remote keyless
entry transmitter.
To unlock the door from the inside, move the manual
door lock control located above the door handle
rearward. To lock the door, move the manual door
lock control forward.
ProCarManuals.com

2-15
Trunk
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk lid open or if
electrical wiring or other cable connections must
pass through the seal between the body and the
trunk lid:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on any airflow selection except RECIRC.
That will force outside air into your vehicle.
See ªComfort Controlsº in the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
Trunk Lock Release
To unlock the trunk from the outside, insert the master
key and turn it.
Remote Trunk Release
Press the trunk release
button located on the lower
portion of the driver's door
to release the trunk lid.
The trunk release lockout
switch must be OFF for
this button to work.
The system also works with the remote keyless entry
transmitter. The trunk will unlock when the trunk
symbol is pressed while the vehicle is in PARK (P) or
NEUTRAL (N) and the trunk release lockout switch is
in OFF.
ProCarManuals.com

2-49 Parade Dimming
To activate the instrument panel backlighting during the
day, turn the exterior lamps control to the parking lamp
position. Dimming of the instrument panel display is not
possible during daylight hours. The instrument panel
display can only be adjusted when the parking lamps are
on and it is dark outside.
Perimeter Lighting
When the unlock symbol on the remote keyless entry
transmitter is pressed, the DRL headlamps, parking
lamps and back
-up lamps will turn on for approximately
25 seconds if it is dark enough outside.
This feature can be programmed to be on or off for each
transmitter. You can also program how long the exterior
lamps will stay on after unlocking the vehicle.
You must program this feature through the DIC. See
ªDIC Personalization Programmingº in the Index.
Front Reading Lamps
These lamps and the interior courtesy lamps will come
on when you open a door. They will turn off when you
turn on the ignition. If a door is left open, they will turn
off after about 10 minutes.
To turn on the reading lamps when the doors are closed,
press the button under the lamp you want on. Press it
again to turn the lamp off.
These lamps work even when the ignition is off. To avoid
draining your vehicle's battery, be sure to turn off all
front and rear reading lamps when leaving your vehicle.
ProCarManuals.com

2-53
3. Once the zone number appears in the display, press
the COMPASS (or the on/off button for mirrors
equipped with OnStar controls) button quickly until
the correct zone number appears in the display.
Stop pressing the button and the mirror will return
to normal operation. If C appears in the compass
window, the compass may need calibration. See
ªCompass Calibrationº explained previously.
Power Remote Control Rearview Mirrors
The controls for the power remote rearview mirrors are
located on the driver's door armrest.
Press the left or right side of the L/R selector switch
located beneath the control pad to choose the left or
right mirror.
ProCarManuals.com

2-89
The DIC is used to program the personal choices of
two drivers. The drivers are recognized as DRIVER 1
and DRIVER 2. You will let the DIC and the vehicle
know which driver you are by using your remote keyless
entry transmitter or by pressing the appropriate memory
seat button located on the driver's door or choosing
the driver with the DIC. Each remote keyless entry
transmitter was pre
-programmed to belong to
DRIVER 1 or DRIVER 2. The personalization
features may be programmed differently for each driver.
When you press the unlock symbol on the transmitter,
the DIC will automatically change driver numbers
and the vehicle will recall the personal choice settings
that were last made to correspond to your transmitter,
including your radio and comfort control settings.
See ªComfort Controls, Personalizationº in the Index.
If you unlock the vehicle using the door key instead
of the transmitter, the personal choice settings will
correspond to the previous driver of the vehicle as
identified by the transmitter, the memory seat control
or the DIC. If this happens and you were not the last
driver of the vehicle, press the correct driver number
on the door panel for the memory seats, press the
unlock symbol on the transmitter or select the
personalization programming mode and choose
the correct driver number.After you have the correct driver number on the display
use the SELECT down arrow button to scroll through
the following messages and feature options:

DOORS LOCK IN GEAR
-- YES/NO

DOORS UNLOCK
-- YES/NO

ALL DOORS IN PARK
-- YES/NO

ALL DOORS AT KEY OFF
-- YES/NO

DRIVERS DOOR IN PARK
-- YES/NO

DRIVERS DOOR KEY OFF
-- YES/NO

PASS WINDOW LOCKOUT
-- YES/NO

KEY FOB FLASH LIGHTS
-- YES/NO

KEY FOB CHIRP HORN
-- YES/NO

DELAY LOCK OF DOORS
-- YES/NO

PERIMETER LIGHTS
-- YES/NO

EXT LIGHT TIMEOUT
-- 5 to 30 Seconds

DISPLAY DRIVER ID
-- YES/NO

KEY FOB MEMORY SEAT
-- YES/NO

DRIVING POSITION
-- YES

EXIT POSITION
-- YES

TILT MIRROR REVERSE
-- YES/NO
ProCarManuals.com

2-93
If you would like to program your vehicle to Mode 2,
do the following:
1. Select YES for KEY FOB LIGHTS FLASH.
2. Select NO for KEY FOB HORN CHIRP.
If you would like to program your vehicle to Mode 3,
do the following:
1. Select NO for KEY FOB LIGHTS FLASH.
2. Select YES for KEY FOB HORN CHIRP.
If you would like to program your vehicle to Mode 4,
do the following:
1. Select YES for KEY FOB LIGHTS FLASH.
2. Select YES for KEY FOB HORN CHIRP.
For more information on this feature, see ªSecurity
Feedbackº in the Index.Delayed Locking
The delayed locking feature, which delays the actual
locking of the vehicle, can be made active or inactive
through the DIC. When DELAY LOCK OF DOORS
appears on the display, use the SELECT right arrow
button to toggle between YES and NO. When you have
made your choice, press the SELECT down arrow
button to record your selection and move on to the
next choice.
For more information on this feature, see ªDelayed
Lockingº in the Index.
Perimeter Lighting Personalization
When the unlock symbol on the remote keyless entry
transmitter is pressed, the DRL, parking lamps and
back
-up lamps will turn on if it is dark enough outside.
You can control activation of this feature by choosing
YES or NO when the PERIMETER LIGHTS choice is
displayed on the DIC. Make your choice by pressing the
SELECT right arrow button and record your choice by
pressing the SELECT down arrow button. You will then
be prompted to choose a TIMEOUT period.
ProCarManuals.com

3-6 Comfort Controls Personalization
(If Equipped)
This feature enables up to two drivers to store and recall
comfort control settings for temperature, air delivery
mode and fan speed.
The memory buttons (1 or 2) for this feature are located
on the driver's door panel and correspond to the
numbers (1 or 2) found on the back of each remote
keyless entry transmitter.
To recall comfort settings, press the unlock button
on the remote keyless entry transmitter and put the
ignition in ACC (Accessory) or ON. The climate
control setting last chosen by the identified
driver (1 or 2) will be recalled.
To program a personal climate control setting, do
the following:
1. Choose a climate control setting for the driver
and if desired, for the passenger. See ªAutomatic
Electronic Climate Controlº and ªPassenger
Temperature Control (Option)º earlier in this section.
2. Adjust the direction of the airflow.3. Locate the memory buttons on the driver's
door panel.
4. Press a memory button (1 or 2) until you hear two
beeps. The beeps confirm that your selection has
been saved and can now be recalled.
Follow these steps each time you want to change the
stored settings. For more information on the memory
feature, see ªMemory Seat and Mirrorsº in the Index.
Air Conditioning
The air conditioner cools and dehumidifies the air inside
of the vehicle.
The air conditioning compressor is enabled in all
modes unless the air conditioning button is not selected
(the indicator light will not be illuminated). However,
the air conditioning compressor will not operate when
the outside temperature is below 34
F (1
C). When the
air conditioner is on, you may sometimes notice slight
changes in your vehicle's engine speed and power. This
is normal, because the system is designed to cycle the
compressor on and off to maintain the desired
temperature and to help with fuel economy.
ProCarManuals.com

3-25 Personal Choice Radio Controls
(If Equipped)
This feature enables up to two drivers to store and
recall personal settings for AM and FM presets, last
tuned station, volume, tone and audio source (radio,
cassette or CD).
The memory buttons (1 or 2) for this feature are
located on the driver's door panel and correspond to
the numbers (1 or 2) found on the back of each remote
keyless entry transmitter.
To recall audio sources, press the unlock button on the
remote keyless entry transmitter and put the ignition in
RUN. The source last listened to will be recalled for the
identified driver (1 or 2).
To program this feature, do the following:
1. Set all radio preferences. For more information see
ªSetting Preset Stationsº and ªSetting the Toneº
listed for your particular radio.
2. Locate the memory buttons on the driver's
door panel.
3. Press one of the memory buttons (1 or 2) until you
hear two beeps. The beeps confirm that your
selection has been saved and can now be recalled.
Follow these steps each time you want to change the
stored settings.
Theft-Deterrent Feature
THEFTLOCK
is designed to discourage theft of your
radio. It works by using a secret code to disable all radio
functions whenever battery power is removed and the
radio is placed in a different vehicle. This feature
requires no user input to be activated. It is automatically
armed when it is put into the vehicle for the first time.
When the radio is turned off, the blinking red light
indicates that THEFTLOCK is armed.
If THEFTLOCK is activated, your radio will not
operate if stolen. The radio will display LOCKED
and a red LED indicator light will come on above the
THEFTLOCK logo to indicate a locked condition.
If this occurs, the radio will have to be returned to
the dealer.
ProCarManuals.com
