Oldsmobile Intrigue 2002 Owner's Manuals
Manufacturer: OLDSMOBILE, Model Year: 2002, Model line: Intrigue, Model: Oldsmobile Intrigue 2002Pages: 363, PDF Size: 2.53 MB
Page 1 of 363
Page 2 of 363
i
2002 Oldsmobile Intrigue
Owner's Manual
Litho in U.S.A.Copyright General Motors Corporation 06/13/01
Part Number 10315412 A First Edition All Rights Reserved
Page 3 of 363
ii
GENERAL MOTORS, GM, the GM Emblem,
OLDSMOBILE, the OLDSMOBILE Rocket Emblem
and the name INTRIGUE are registered trademarks of
General Motors Corporation.
This manual includes the latest information at the time
it was printed. We reserve the right to make changes
after that time without further notice. For vehicles first
sold in Canada, substitute the name ªGeneral Motors
of Canada Limitedº for Oldsmobile Division whenever
it appears in this manual.
Please keep this manual in your vehicle, so it will
be there if you ever need it when you're on the road.
If you sell the vehicle, please leave this manual in it
so the new owner can use it.
We support voluntary
technician certification.
For Canadian Owners Who Prefer a
French Language Manual:
Aux propri‡taires canadiens: Vous pouvez vous
procurer un exemplaire de ce guide en fran†ais chez
votre concessionaire ou au:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
Page 4 of 363
iii
CAUTION:
These mean there is something that could hurt
In the caution area, we tell you what the hazard is.
Y ou will also find a circle
Page 5 of 363
iv
Vehicle Damage Warnings
Also in this book you will find these notices:
NOTICE:
These mean there is something that could damage
your vehicle.
In the notice area, we tell you about something that can
damage your vehicle. Many times, this damage would
not be covered by your warranty, and it could be costly.
But the notice will tell you what to do to help avoid
the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different colors
or in different words.
You'll also see warning labels on your vehicle.
They use the same words, CAUTION or NOTICE.
Vehicle Symbols
Your vehicle may be equipped with components and
labels that use symbols instead of text. Symbols,
used on your vehicle, are shown along with the text
describing the operation or information relating to a
specific component, control, message, gage or indicator.
If you need help figuring out a specific name of a
component, gage or indicator reference the following
topics in the Index:
ªEngine Compartment Overviewº
ªInstrument Panelº
ªComfort Controlsº
ªAudio Systemsº
Also see ªWarning Lights and Gagesº in the Index.
Page 6 of 363
v
These are some examples of vehicle symbols you may find on your vehicle:
Page 7 of 363
1-
1-1
Section 1 Seats and Restraint Systems
Here you'll find information about the seats in your vehicle and how to use your safety belts properly. You can also
learn about some things you should not do with air bags and safety belts.
1
-2 Seats and Seat Controls
1
-7 Safety Belts: They're for Everyone
1
-11 Here Are Questions Many People Ask About
Safety Belts
-- and the Answers
1
-12 How to Wear Safety Belts Properly
1
-13 Driver Position
1
-20 Safety Belt Use During Pregnancy
1
-21 Right Front Passenger Position
1
-21 Supplemental Restraint System (SRS)
1
-28 Rear Seat Passengers1
-32 Rear Safety Belt Comfort Guides for Children
and Small Adults
1
-34 Center Passenger Position
1
-36 Children
1
-39 Restraint Systems for Children
1
-55 Older Children
1
-58 Safety Belt Extender
1
-58 Checking Your Restraint Systems
1
-58 Replacing Restraint System Parts
After a Crash
Page 8 of 363
1-2
Seats and Seat Controls
This section tells you how to adjust the seats and
explains reclining seatbacks, folding rear seats and
head restraints.
Manual Front Seat
CAUTION:
You can lose control of the vehicle if you try to
adjust a manual driver's seat while the vehicle is
moving. The sudden movement could startle and
confuse you, or make you push a pedal when you
don't want to. Adjust the driver's seat only when
the vehicle is not moving.
Lift the lever, located under the front of the seat, using a
twisting motion. This will unlock the seat. Slide the seat
to where you want it and release the lever. Try to move
the seat back and forth to make sure the seat is locked
into place.
Page 9 of 363
1-3 Six-Way Power Seat (If Equipped)
If your vehicle is equipped
with this feature, the
controls are located on the
outboard sides of both the
driver's and the passenger's
seat cushions.
To adjust the front seat cushions do any of
the following:
Move the seat forward or rearward by sliding the
control toward the front or the rear of the vehicle.
Raise or lower the seat cushion by sliding the control
up or down.
Raise or lower the front portion of the seat cushion
by sliding the front of the control up or down.
Raise or lower the rear portion of the seat cushion by
sliding the rear of the control up or down.
Four-Way Power Lumbar Driver's
Seat (Option)
If the vehicle has this option, there is a control located
on the outboard side of the driver's seat cushion, in front
of the reclining seatback lever. To increase or decrease
lumbar support, push the control forward or rearward.
To adjust the lumbar support up or down, push the
control up or down.
Page 10 of 363
1-4 Heated Front Seat (If Equipped)
If your vehicle has this
feature, the driver's and
passenger's heated seat
switches are located on the
instrument panel near the
comfort controls.
The driver's switch is on the left, and the passenger's
switch is on the right.
There are two settings, LO and HI. To choose the LO
setting, press the top part of the switch twice. The circle
next to LO on the switch will light, indicating the LO
setting has been selected.
To choose the HI setting, press the top part of the switch
once. The circle next to HI on the switch will light,
indicating the HI setting has been selected.
To turn the system off, press the lower part of the switch
once. The light should go out when the system is not in
use. The heated seats will turn off when the ignition is
turned off.
Reclining Front Seatbacks
The release levers for the driver's and passenger's front
seatbacks are located on the outboard sides of each front
seat cushion.
Lift the lever to release the seatback, then move the
seatback to where you want it. Release the lever to lock
the seatback in place. Pull up on the lever without pushing
on the seatback and the seatback will move forward.
