152 Driving and Operating
Fuel
Fuel (for Petrol Engines)
Only use unleaded fuel that
complies with European standard
EN 228 or E DIN 51626-1 or
equivalent.
Your engine is capable of running
with E10 fuel that fulfils these
standards. E10 fuel contains up to
10% bioethanol.
Use fuel with the recommended
octane rating
0Engine Data0202.
Use of fuel with too low an octane
rating can reduce engine power and
torque and slightly increases fuel
consumption.
Caution
Do not use fuel or fuel additives
that contain metallic compounds
such as manganese-based
additives. This may cause engine
damage.
Caution
Use of fuel that does not comply
to EN 228 or E DIN 51626-1 or
equivalent can lead to deposits or
engine damage and loss of
warranty.
Caution
Use of fuel with too low an octane
rating could lead to uncontrolled
combustion and engine damage.
Filling the Tank
{Danger
Before refuelling, switch off
engine and any external heaters
with combustion chambers.
Switch off any mobile phones.
Follow the operating and safety
instructions of the filling station
when refuelling.

OPEL Karl Owner Manual (GMK-Localizing-EU RHD-9231168) - 2016 - crc -
5/7/15
202 Technical Data
Vehicle Data
Engine Data
Sales designation1.0
Engine identifier code L5Q
Number of cylinders 3
Piston displacements [cm³] 999
Engine Power [kW] at rpm 55
Torque [Nm] at rpm 95
Octane rating RON
recommended 95
possible 98
possible 91
Fuel type Petrol
Performance
Engine 1.0
Top speed [km/h] ([mph])
Manual gearbox 170 km/h
Automatic transmission -
