Seats, restraints41Armrest
Base armrest
The armrest can be slid forwards.
FlexConsole armrest
The armrest can be moved in a centre
console. Pull the handle to slide the
armrest.
There are two storages, a storage
drawer and a movable cupholder in
the armrest console.
Armrest storage 3 65.
Removing the armrest
Flex console armrest can be
removed.
Press fastenings inward and fold down locking mechanism at the rear
end of the armrest.

42Seats, restraintsPull the handle in front of the armrest
and slide armrest rearwards out of the console.
Installation in reverse order.
Heating
Adjust heating to the desired setting
by pressing ß for the respective seat
one or more times. The control
indicator in the button indicates the
setting.
Prolonged use of the highest setting
for people with sensitive skin is not
recommended.
Seat heating is operational when
engine is running and during an
Autostop.
Stop-start system 3 185.Rear seats
Second row seats9 Warning
When seats or backrests of
second and third seat row are
being adjusted or folded, keep
hands and feet away from the
moving area.
Never store objects under the
seats.
Never adjust seats while driving as they could move uncontrollably.
Drive only with engaged seats and
backrests.
Base seats
Seat positioning
Each seat of the second seat row can be individually moved forward or
backward.

Seats, restraints43
Pull handle, slide seat, release
handle and allow seat to engage.
The seats can be engaged in
intermediate positions.
Seat backrests
The backrest inclination of each seat can be individually adjusted in three
positions.Pull the loop, adjust inclination,
release strap and allow backrest to
engage.
9 Warning
Use vertical position of the
backrest only for increased
luggage volume and not as
seating position.
Load compartment, folding down the
backrests 3 66.
Easy entry function
To permit an easy entrance to the
seats of the third row, the outer seats
of the second row can be tilted.
Pull release lever, fold backrest and
move the seat to the front.Folding back easy entry
First move seat to desired position
and then raise backrest.9 Warning
When folding up, ensure that the
seat is securely locked in position
before driving. Failure to do so
may result in personal injury in the event of hard braking or a collision.

44Seats, restraintsThird row seats9Warning
When seats or backrests of
second and third seat row are
being adjusted or folded, keep
hands and feet away from the
moving area.
Never store objects under the
seats.
Never adjust seats while driving as they could move uncontrollably.
Drive only with engaged seats and
backrests.
Caution
Before setting up or folding down
seats, all components must be
removed from the side rails and
from the lashing eyes.
Lashing eyes must be in stored
position.
The seats in the third row can be folded down to the vehicle floor if they
are not required, or for increasing the
size of the load compartment.
The seats in the third row can only be
used if the second seat row is not in
the lounge position.
Setting up the seats ● Fold in interior protection mat 3 70 and remove load
compartment cover 3 68.
● Insert the latch plate of the seat
belt on each side into the pocket
that is mounted at the belt.

Seats, restraints45● Pull up the seat by the upperloop, fold out and allow seat to
engage in upright position.
Folding down the seats in the vehicle floor
● Push down head restraint by pressing the catch 3 36.
● Insert the latch plate of the seat belt on each side into the pocket
that is mounted at the belt.● Pull the lower loop, simultaneously swing the
backrest forwards until the seat is
lowered into the vehicle floor.
● Install the interior protection mat 3 70 and load compartment
cover 3 68.Seat belts
The seat belts are locked during
heavy acceleration or deceleration of
the vehicle, holding the occupants in
the seat position. Therefore the risk of injury is considerably reduced.
9 Warning
Fasten seat belt before each trip.
In the event of an accident, people
not wearing seat belts endanger their fellow occupants and
themselves.

48Seats, restraintsUnfasten
To release belt, press red button on
belt buckle.
Centre seat belt of the secondseat row
The centre seat is equipped with a particular three-point seat belt.
Pull latch plates with the belt out of
belt holder in the roof.
Remove lower latch plate from
retainer and click it into left-hand
buckle ( 1) at the centre seat. Guide
the upper latch plate with the belt over
the lap area and the shoulder (do not twist) and click into right-hand buckle
( 2 ) at centre seat.
To unfasten the seat belt, first press
the button on the right-hand buckle
( 2 ) and remove upper latch plate.
Then press the button on the left-
hand buckle ( 1) and remove lower
latch plate. The seat belt retracts
automatically.Push the top latch plate into the
retainer. Fold over locked together
latch plates against the seat belt.

Seats, restraints49Insert in the seat belt holder in the roof
with the lower latch plate pointing
forward.
Seat belts on the third seat row
The seat belts on the third seat row
are equipped with three point seat
belts.
When seat belts are not used or when
folding the seats, insert the latch plate of the seat belt on each side into the
pocket that is mounted at the belt.
If the centre seat of the second seat
row is occupied and the seat belt is
fastened, only persons with a body
height up to max. 150 cm are allowed
to use the left seat of the third seat
row.
There is a warning label on the rear
side of the centre belt, when it is
pulled out, to inform the passenger on the left seat of the third seat row.
Using seat belts while pregnant9 Warning
The lap belt must be positioned as
low as possible across the pelvis
to prevent pressure on the
abdomen.
Airbag system
The airbag system consists of a
number of individual systems
depending on the scope of
equipment.
When triggered the airbags inflate
within milliseconds. They also deflate
so quickly that it is often unnoticeable
during the collision.9 Warning
The airbag system deploys in an
explosive manner, repairs must be performed by skilled personnel
only.
9 Warning
Adding accessories that change
the vehicle's frame, bumper
system, height, front end or side
sheet metal, may keep the airbag
system from working properly. The operation of the airbag system can
also be affected by changing any
parts of the front seats, seat belts,

62StorageStorageStorage compartments................62
Glovebox ................................... 62
Cupholders ................................ 62
Front storage ............................. 64
Door panel storage ....................64
Overhead console .....................64
Underseat storage .....................64
Armrest storage .........................65
Centre console storage .............65
Load compartment .......................66
Rear storage .............................. 68
Load compartment cover ...........68
Rear floor storage cover ............70
Load rails and hooks .................75
Lashing eyes ............................. 75
Cargo management system ......75
Safety net .................................. 77
Folding tray ................................ 79
Warning triangle ........................79
First aid kit ................................. 79
Roof rack system .........................80
Roof rack ................................... 80
Loading information .....................81Storage compartments9Warning
Do not store heavy or sharp
objects in the storage
compartments. Otherwise, the
storage compartment lid could
open and vehicle occupants could be injured by objects being thrown
around in the event of hard
braking, a sudden change in
direction or an accident.
Glovebox
To open the glovebox pull the handle.
The glovebox features an adapter for the locking wheel nuts.
The glovebox should be closed whilst
driving.
Cupholders
Front cupholder
Cupholders are located in the centre
console between the front seats.

66StorageLoad compartmentThe seats in the third row can befolded down separately into the
vehicle floor. The seat backrests of the second row can be folded forward separately.
Rear floor storage cover 3 70.9 Warning
When seats or backrests are being
adjusted or folded, keep hands
and feet away from the moving
area.
Never store objects under the
seats.
Drive only with engaged seats and
backrests.
Caution
Before setting up or folding down
seats, all components must be
removed from the side rails and
from the lashing eyes.
Lashing eyes must be in stored
position.
Folding down the seats of the third
row
● Push down head restraint by pressing the catch 3 36.
● Insert the latch plate of the seat
belt on each side into the pocket
that is mounted at the belt.

Storage67● Pull the lower loop andsimultaneously swing the
backrest forwards until the seat is lowered into the vehicle floor.
● Install interior floor mat 3 70
and load compartment cover
3 68 if necessary.
Setting up the seats
Pull up the seat by the upper loop, fold out and allow seat to engage in
upright position.
Folding the seat backrests of the
second row
● Remove the load compartment cover if necessary 3 68.
● Push down head restraints by pressing the catch 3 36.
● Move front passenger seat to a position that avoids contact with
the head restraints of the folded
backrests.
● Pull the loop and fold down the backrest onto the seat cushion.
Caution
●Do not fold the outer seatbacks
while the seats are in the
lounge seat position 3 42.
● Do not pull release lever of the easy entry function when the
backrest is folded down.
The seats could be damaged.
● Alternatively pull the loop and adjust backrest to vertical
position as cargo position.
9 Warning
Use vertical position of the
backrest only for increased
luggage volume and not as a
seating position.
Folding up backrest
Raise backrest to vertical position.
Adjust inclination by pulling the loop.
Ensure that all positions are engaged
correctly.
