fold seats Peugeot 206 CC 2001.5 Owner's Manual

10YOUR AT A GLANCE
FRONT SEATS1 - Forwards/backwards
adjustment
Lift the control and slide the seat forwards or backwards.
2 - Access to rear seats Place your fingers in one ofthe handles and pushforwards to fold down the seatback and move the seatforwards. On repositioning,the seat returns to its originalposition.
3 - Head restraint Height adjustment:
- to lift the head restraint,push it upwards;
- to lower it, press the lug and slide downwards.
The setting is correct whenthe upper edge of the headrestraint is level with the topof the head.
To remove the head restraint, press the lug.
4 - Seat back angle adjustment Push the control towards the
rear.
5 - Driver's seat height adjustment
Pull the control upwards. Remove your weight from the seat to raise, or press on the
seat to lower.
62

YOUR 206 CC IN DETAIL63
1 - Forwards/backwards adjustment
Lift the lever and slide the seat forwards or backwards.
2 - Access to the rear seats Place your fingers in one of the twohandles and push towards the frontto fold down the seat backt andmove the seat forwards. When putback, the seat returns to its initialposition.It is impossible to access the rearseats if the front seat is in areclining position.
No person nor object mustprevent the seat from returningto its initial position. Returning tothis position is necessary for it tobe locked.
3 - Adjusting the height of the head restraint
To raise the head restraint, push it upwards.
The setting is correct when theupper edge of the head restraintis level with the top of the head.
The head restraint has a frame withnotches which prevents the headrestraint from dropping down (safetydevice in case of impact).
To lower the head restraint you must simultaneously:- press the knob on the left-hand side at its base,
- press downwards. The angle of the head restraint can also be adjusted.
To remove the head restraint, press the tab.
4 - Adjusting the seat back angle Push one of the two controls
towards the rear.
5 - Driver's seat height adjustment Pull the handle upwards. Remove your weight from the seat to raise, or press on the seat to
lower.
Never drive with the head restraints removed. Theseshould be correctly fittedand adjusted.
