Peugeot 206 CC Dag 2003 User Guide

30-06-2003
11YOUR AT A GLANCE
9367
FRONT AIR BAGS Disarming the passenger air bag* Insert the ignition key into switch 1 and turn it to:
- the passenger air bag ON
position,
- the passenger air bag OFF
position.
Operating check
With the ignition on (2nd notchon the key), switching on of thiswarning light, accompanied byan audible signal and the mes-sage ''Passenger air bag
deactivated'' on the multifunc-
tion screen, indicates that the
passenger air bag is switched off( ''OFF'' position on the switch).
The warning lightremains switched onthroughout the dura-tion of the disarmingprocess. "ISOFIX" MOUNTINGS
Available on the front passenger seat, Isofix mountings allow fit-ting of a
special child seat , sold
by PEUGEOT dealers. The locks incorporated in the child seat fit onto the "Isofix"mountings, ensuring reliable,
safe and fast assembly. The child
seat must be fitted in the rearwards-facing position for children weighingless than 29 lbs or 13 kg (to do
this it is essential to disarmthe passenger air bag) .
Follow the instructions for fitting the child seat in themanufacturer's installationbrochure.
Precautions concerning thepassenger air bag
Vehicle fitted with a passenger air bag disarming switch:
- disarm the air
bag if you install a rearwards-fac-ing child seat
- arm the air bag when you trans-port an adult.
Vehicle not fitted with a passen-ger air bag disarming switch:
- do not install a rear- wards-facing child seat on the frontpassenger seat.
Never place your feet or anyobject on the fascia.
* According to destination.

30-06-2003
12YOUR AT A GLANCE
No. Symbol Function
1 Air distribution adjustment.
2 Air intake control.
3 Temperature adjustment.
4 Demisting the rearscreen and the mirrors.
5 Air flow adjustment.
6 Air conditioningcontrol.
HEATING/AIR CONDITIONING
58
60

30-06-2003
13
No. Symbol Function1 Air flow adjustment.
2 Air distribution adjustment.
3 Air intake control.
4 Air conditioningcontrol.
5 Demisting the rearscreen and themirrors.
6 Stopping the system.
7
Temperatureadjustment.
8 Automatic comfort programme.
9 Automatic visibilityprogramme.
Note: in the cabriolet version, system performance may be
reduced.
62
AUTOMATIC AIR CONDITIONING
YOUR AT A GLANCE

30-06-2003
THE AUTOMATIC AUTOADAPTIVE GEARBOX Starting
To start the vehicle, position the gear lever at Nor P.
Press the brake pedal to change fromposition P and when selecting forwards or
reverse gears.
P. Parking.
R. Reverse.
N. Neutral.
D. Driving: automatic changing of the four gears in this position.
3. Automatic changing of the first three gears only.
2. Automatic changing of the first two gears only.
A. Sport programme.
B. Snow programme.
YOUR AT A GLANCE
89
14

30-06-2003
PEUGEOT SERVICING
18
PEUGEOT SERVICING
Your vehicle benefits from extended service intervals, every 20,000 miles (30,000 km) or every two years. The extension of the service intervals means that the engine oil level must be checked regularly: topping up of the oil between oil changes is normal.
It is for this reason that the PEUGEOT network invites you to an intermediate visit between each regular Service. The service indicator does not show when this service is due. It must be carried out every 10,000 miles (15,000 km) maximum.
A PEUGEOT dealer will carry out a quick check, and will top up the levels if necessary (oil, coolant, screen-wash up to 2 litres). If the oil level is too low there is a risk of serious damage to the engine: check the engine oil level at least every 2,000 to 3,000 miles (3,000 to 5,000 km), depending on the conditions of use. This extended servicing has been made possible by modifications to our vehicles and to the lubricants:
THUS IT IS ESSENTIAL TO ONLY USE LUBRICANTS WHICH ARE SUITED TO YOUR ENGINE AND RECOMMENDED
BY THE MANUFACTURER (see "Lubricants" pages).

30-06-2003
PEUGEOT SERVICING19
SPECIAL FEATURES Some of your vehicle's vital components have specific servicing schedules. The brake fluid must be replaced every 40,000 miles (60,000 km) or every 2 years.
The passenger compartment filter must be checked at each visitto the PEUGEOT dealer (intermediate visits and
regular services).The timing belt: contact a PEUGEOT dealer.
Note: The engine coolant does not need to be replaced.
Arduous conditions of use If the vehicle is used under certain particularly arduous conditions: - Continuous door-to-door use.
- Town use.- Repeated short journeys, with the engine cold in low temperatures.
Or prolonged stay under the following conditions: - Countries with temperatures often above +30 ¡C.- Countries with temperatures often below minus 15 ¡C.- Countries with a dusty atmosphere.- Countries whose lubricants or fuels do not conform to our recommendations.
It is necessary to follow an "Arduous conditions" service schedule which includes shorter service intervals: - Every 12,000 miles (20,000 km) or every year.

30-06-2003
PEUGEOT SERVICING19
SPECIAL FEATURES Some of your vehicle's vital components have specific servicing schedules. The brake fluid must be replaced every 40,000 miles (60,000 km) or every 2 years.
The passenger compartment filter must be checked at each visitto the PEUGEOT dealer (intermediate visits and
regular services).The timing belt: contact a PEUGEOT dealer.
Note: The engine coolant does not need to be replaced.
Arduous conditions of use If the vehicle is used under certain particularly arduous conditions: - Continuous door-to-door use.
- Town use.- Repeated short journeys, with the engine cold in low temperatures.
Or prolonged stay under the following conditions: - Countries with temperatures often above +30 ¡C.- Countries with temperatures often below minus 15 ¡C.- Countries with a dusty atmosphere.- Countries whose lubricants or fuels do not conform to our recommendations.
It is necessary to follow an "Arduous conditions" service schedule which includes shorter service intervals: - Every 12,000 miles (20,000 km) or every year.

30-06-2003
PEUGEOT SERVICING
20
SERVICE INDICATOR This is a visual reminder of when the
next service is due. This service is tobe carried out according to the man-ufacturer's servicing schedule. Operation As soon as the ignition is switched on and for 5 seconds, the spannersymbolising ''service operation'' is lit.The trip recorder display shows thedistance remaining (in round figures)before the next service. Example: 4,800 km remain before
the next service is due. When the ignition comes on and for 5 secondsthe display indicates: 5 seconds after the ignition is switched on, the total distancerecorder resumes normal operationand the display shows the total or tripdistances. The distance remaining before thenext service is less than 1,000 km. Example:
900 km remain before the
next service is due.When switching on the ignition and for 5 seconds, the display shows: 5 seconds after the ignition is switched on, the total distancerecorder resumes normal operationand the symbol remains lit. This indicates that a service should
be carried out shortly. The displayshows the total or trip distances. The service is overdue. Each time the ignition is switched on and for 5 seconds, the symbol andthe excess distance flash. Example:
the service is overdue by
300 km. The service should be car-
ried out very shortly. When the ignition is switched on and for 5 seconds, the display shows: 5 seconds after the ignition is switched on, the total distance recorderresumes normal operation and the
symbol remains lit. The display showsthe total or trip distances.

30-06-2003
PEUGEOT SERVICING21
Resetting the service indicator
Your PEUGEOT dealer carries out this operation after each service.
However, if you carry out the service yourself, the reset procedure is asfollows:
- Switch off the ignition. - Press and hold button 1.
- Switch on the ignition. The display begins a 10 second countdown.
- Keep button 1pressed for
10 seconds.
The display shows [=0]and the
service symbol disappears.

30-06-2003
PEUGEOT SERVICING
22
TYPES OF SERVICE Each vehicle has its own servicing cycle, based upon the engine type.
This cycle consists of alternating two types of service, A and C, intermediate visits and a few additional operations depend- ing on your vehicle; these correspond to key stages in the life of your vehicle. When the first service is carried out and at each subsequent service, your dealer will advise you of the type and content of the next service due.
Intermediate top-up visitincorporated in the ServicingSchedule.
These services are to be carried out with
10W40 synthetically based oil
minimum. They can also be carried out with 5W30 Fuel Economy oilor with 5W40
synthetic oil .
Arduous conditions of use (see corresponding section).
* Whichever comes first. THE MAINTENANCE CYCLE FOR YOUR 206 CC
Service every 20,000 miles (30,000 km) or 2 years
80,000 (120,000) 100,000 (150,000) 120,000 (180, 000) 140,000 (210,000) 160,000 (240,000) MILES (KM) 20,000 (30,000) 40,000 (60,000) 60,000 (90,000)
1st service at 6,000 miles (10,000 km) or 6 months*.
This is necessary in order to benefit from the warranty
