Page 61 of 324
60
Manual operation
If you wish, you can make a different
choice from that offered by the system
by changing a setting. The other func-
tions will still be controlled automati-
cally.
Pressing the "AUTO" button returns
the system to completely automatic
operation.
Press this button to switch
off the air conditioning. 6 . A i r d i s t r i b u t i o n a d j u s t m e n t
Press one or more buttons to
d i r e c t t h e a i r fl o w t o w a r d s :
7 . A i r fl o w a d j u s t m e n t
Turn this control to the left
t o d e c r e a s e t h e a i r fl o w o r
to the right to increase the
a i r fl o w .
5. Air conditioning On/Off
- the windscreen and side windows ( d e m i s t i n g o r d e f r o s t i n g ) ,
- the windscreen, the side windows and the vents,
- the windscreen, the side windows, the vents and the footwells,
- the vents and the footwells,
- the vents,
- the footwells,
- the windscreen, the side windows and the footwells.
T h e a i r fl o w i n d i c a t o r l a m p s , b e t w e e n
the two fans, come on progressively in
relation to the value requested.
For maximum cooling or heat-
ing of the passenger compart-
ment, it is possible to exceed
the minimum value 14 or the maxi-
mum value 28.
Turn control 2 or 3 to the left until
"LO" ( l o w ) i s d i s p l a y e d o r t o t h e
right until "HI" ( h i g h ) i s d i s p l a y e d . Switching the system off could result in
s o m e d i s c o m f o r t ( h u m i d i t y , c o n d e n s a t i o n ) .
Press this button again to return
to automatic operation of the air
conditioning. The indicator lamp in
the "A/C" button comes on.
Page 62 of 324
61
9. Mono-zone/Dual-zone
Press this button to equalise
the comfort value on the pas-
senger side with that on the
d r i v e r ' s s i d e ( m o n o - z o n e ) .
The indicator lamp in the
button comes on.
8. Air recirculation
Press this button to recir-
culate the interior air. The
indicator lamp comes on.
Air recirculation enables the passenger
compartment to be isolated from exte-
rior odours and smoke.
As soon as possible, press this
button again to allow the intake of
exterior air and avoid misting. The
indicator lamp in the button goes off.
S w i t c h i n g t h e s y s t e m o f f
T u r n t h e a i r fl o w c o n t r o l t o t h e l e f t
until all of the indicator lamps go
off.
This action switches off all of the func-
tions of the system.
Temperature related comfort is no lon-
g e r g u a r a n t e e d b u t a s l i g h t fl o w o f a i r ,
due to the movement of the vehicle, can
still be felt.
T u r n t h e a i r fl o w d i a l t o t h e r i g h t o r
press the "AUTO" button to reacti-
vate the system with the values set
before it was switched off.
Avoid driving for prolonged
periods with the system off.
Page 63 of 324
62
FRONT SEATS
Seat consisting of a seat cushion, a seat
back and a head restraint which can all
be adjusted to adapt your position for
ease of driving and comfort.
F o r w a r d s - b a c k w a r d s a d j u s t m e n t
Raise the control and slide the seat
forwards or backwards. D r i v e r ' s o r p a s s e n g e r ' s s e a t h e i g h t
a d j u s t m e n t
Pull the control upwards to raise
or push it downwards to lower, as
many times as necessary, to obtain
the position required. S e a t b a c k a n g l e a d j u s t m e n t
Push the control rearwards.
M a n u a l a d j u s t m e n t s
Page 64 of 324
63
DRIVER'S ELECTRIC SEAT
Seat consisting of a seat cushion, a seat
back and a head restraint which can all
be adjusted to adapt your position for
ease of driving and comfort.
F o r w a r d s - b a c k w a r d s a d j u s t m e n t
Push the control forwards or rear-
wards to slide the seat. S e a t c u s h i o n h e i g h t a n d a n g l e
a d j u s t m e n t
Tilt the rear part of the control up-
wards or downwards to obtain the
required height.
Tilt the front part of the control up-
wards or downwards to obtain the
required angle. S e a t b a c k a n g l e a d j u s t m e n t
Tilt the control forwards or rearwards
to adjust the angle of the seat back.
The electrical functions of the
driver's seat are active approxi-
mately one minute after opening
the front door. They are deactivated ap-
proximately one minute after the ignition
is switched off and in economy mode.
To reactivate them, switch on the ignition.
Page 65 of 324
64
Heated seats control
With the engine running, the front seats
can be heated separately.
Use the adjustment dial, placed on
the side of each front seat, to switch
on and select the level of heating re-
quired:
0
: Off.
1
: Low.
2
: Medium.
3
: High.
H e a d r e s t r a i n t h e i g h t a n d a n g l e
a d j u s t m e n t
To raise the head restraint, pull it for-
wards and upwards at the same time.
To remove the head restraint, press
the lug A and pull the head restraint
upwards.
To put the head restraint back in
place, engage the head restraint
stems in the openings keeping them
in line with the seat back.
To lower the head restraint, press
the lug A and the head restraint at
the same time.
To adjust the angle of the head re-
straint, tilt its lower part forwards or
rearwards. T h e h e a d r e s t r a i n t i s fi t t e d w i t h
a frame with notches which
prevents it from lowering; this
is a safety device in case of
impact.
T h e a d j u s t m e n t i s c o r r e c t w h e n t h e u p p e r e d g e o f t h e h e a d r e s t r a i n t i s
l e v e l w i t h t h e t o p o f t h e h e a d .
Never drive with the head restraints
removed; they must be in place and
adjusted correctly.
M a n u a l l u m b a r a d j u s t m e n t
Turn the knob to obtain the desired
level of lumbar support.
Page 66 of 324
65
F o l d i n g t h e s e a t b a c k r e s t
Check that no object, either on or
underneath the seat, could hinder
its movement.
To make the operation easier, place
the head restraint in the low position
( i f t h e s e a t i s i n t h e f u l l y f o r w a r d p o -
s i t i o n ) .
I f y o u r v e h i c l e i s fi t t e d w i t h t h e v i d e o
pack, place the protective cover on
the head restraint.
Lift the control, located behind the
seat, then guide the seat backrest
forwards. When the seat backrest is in this posi-
tion, the seat behind it and the centre
rear seat must not be occupied.
This position, associated with that of the
rear seats, allows you to transport long
objects inside the vehicle.
The maximum weight on the seat is 30 kg.
Table position, front passenger seat
R e t u r n i n g t h e s e a t t o t h e n o r m a l
position
Guide the seat backrest rearwards
until it locks in place.
Page 67 of 324
66
F o l d i n g t h e s e a t f r o m t h e b o o t
E a c h s e c t i o n o f t h e b e n c h s e a t ( 1 / 3 o r
2 / 3 ) h a s i t s o w n c o n t r o l t o r e l e a s e t h e
seat back and its seat cushion from the
boot.
Check that nothing is preventing
t h e s e a t b a c k f r o m f o l d i n g ( h e a d r e -
s t r a i n t , s e a t b e l t s , . . . ) ,
check also that no object on or un-
der the seat could hinder its move-
ment,
pull the control from the boot.
REAR SEATS
Never drive with rear passen-
gers when the head restraints
are removed; the head re-
straints must be in place and in the
high position.
R e a r h e a d r e s t r a i n t s
T h e s e h a v e a h i g h p o s i t i o n ( c o m f o r t a n d
s a f e t y ) a n d a l o w p o s i t i o n ( r e a r v i s i b i l i t y ) .
They can also be removed.
To remove a head restraint:
pull the head restraint fully upwards,
then, press the lug A .
B e n c h s e a t t h e l e f t - h a n d ( 2 / 3 ) o r r i g h t -
h a n d ( 1 / 3 ) s e c t i o n o f w h i c h c a n b e f o l d -
ed to adapt the boot load space.
Page 68 of 324
67
The seat cushion lowers to be
covered by the seat back; this
l e a v e s a fl a t b o o t fl o o r , i f t h e
a d j u s t a b l e fl o o r i s i n t h e i n t e r m e d i a t e
position.
F o l d i n g t h e s e a t f r o m t h e r e a r
Check that no object, either on or un-
derneath the seat, could hinder its
movement.
Move the corresponding front seat
forwards if necessary,
check that the seat belt is positioned
correctly on the side of the seat
back,
place the head restraints in the low
position or remove them if necessary,
pull the control 1 forwards to release
the seat back 2 which tilts easily
onto the seat cushion 3 .
R e t u r n i n g t h e s e a t b a c k t o i t s original position
Put the seat back in the upright posi-
tion and secure it, the seat cushion
also returns to its original position,
check that the red indicator, located
at the control 1 , is no longer visible,
r e fi t t h e h e a d r e s t r a i n t s o r p u t t h e m
back in place.
When returning the rear seat back to
its original position, take care not to
trap the seat belts and ensure that their
buckles are positioned correctly.
Page 69 of 324
68
The objects observed are, in
reality, closer than they ap-
pear.
Take this into account in order to cor-
rectly judge the distance of vehicles
approaching from behind.
MIRRORS
Door mirrors
E a c h fi t t e d w i t h a n a d j u s t a b l e m i r r o r
glass permitting the lateral rearward vi-
sion necessary for overtaking or park-
ing. They can also be folded for parking
i n c o n fi n e d s p a c e s . Folding
- Automatic: lock the vehicle using
the remote control or the key.
- Manual: with the ignition on, pull control A rearwards.
The folding and unfolding of
the door mirrors using the re-
mote control can be deactivat-
ed by a PEUGEOT dealer.
Fold the mirrors when putting your
vehicle through an automatic car
wash.
A d j u s t m e n t
Unfolding
- Automatic: unlock the vehicle using the remote control or the key.
- Manual: with the ignition on, pull control A rearwards.
If the mirrors are folded using
control
A , they will not unfold
when the vehicle is unlocked.
Pull again on control A .
Move control A to the right or to
the left to select the corresponding
mirror.
Move control B in all four directions
to adjust.
Return control A to the central
position.
Demisting - Defrosting
I f y o u r v e h i c l e i s fi t t e d w i t h h e a t e d m i r -
rors, the demisting-defrosting operates
with the engine running, by switching
o n t h e h e a t e d r e a r s c r e e n ( r e f e r t o t h e
" R e a r s c r e e n d e m i s t - d e f r o s t " p a g e ) .
Page 70 of 324
69
A d j u s t m e n t
Adjust the mirror so that the glass
i s d i r e c t e d c o r r e c t l y i n t h e " d a y "
position.
As a safety precaution, the
mirrors must be adjusted to
r e d u c e t h e " b l i n d s p o t " .
M a n u a l d a y / n i g h t m o d e l
D a y / n i g h t p o s i t i o n
P u l l t h e l e v e r t o c h a n g e t o t h e " n i g h t "
anti-dazzle position.
Push the lever to change to the nor-
m a l " d a y " p o s i t i o n .
R e a r v i e w m i r r o r
Adjustable mirror providing a central
rearward view.
Equipped with an anti-dazzle system,
useful in poor light. In order to ensure optimum
visibility during your manoeu-
vres, the mirror lightens au-
tomatically when reverse gear is
engaged.
A u t o m a t i c d a y / n i g h t m o d e l
By means of a sensor, which measures
the light from the rear of the vehicle, this
system automatically and progressively
changes between the day and night
uses.
It has an anti-dazzle system which dark-
ens the mirror glass: this reduces any
driver discomfort caused by the light
beams of following vehicles, the sun...
