THE ALARM* This provides two types of protec- tion: Ðexterior protection: when this is
set, the alarm sounds if a door, the boot or the bonnet is opened.
Ð interior protection: when this is
set, the alarm sounds if the sen-sors detect a variation in the airmovement inside the vehicle(breaking of a window or move-ment inside the vehicle).
Setting the alarm Switch off the ignition and get out of the vehicle.
Set the alarm within five minutesof getting out of the vehicle, bylocking or deadlocking using theremote control (button Aindica-
tor light flashes once persecond).
Note: if you wish to lock your vehicle
without setting the alarm, use thedoor lock. When the alarm is triggered, thesiren sounds and the direction indi-cators flash for thirty seconds. After triggering, the alarm remains set.
Warning:
if the alarm has been trig-
gered ten times in succession, on the eleventh time it becomes inactive. Note: if button Aflashes rapidly, the
alarm has been triggered while you
were away from your car. Disarming Unlock the vehicle with the remote control key (button Aindicator light
goes out). Note: if the alarm has been triggered
while you were away from your car, the rapid flashing of the indicatorlight will stop when you switch on theignition.
To set the alarm with exterior protection only If, while you are away from the vehicle, you wish to leave a windowpartially open or a pet inside thevehicle, you should choose exterior
protection only. Switch off the ignition.
In the next ten seconds, press button Auntil the indicator light
is on continuously.
Get out of the vehicle.
Set the alarm by locking or dead-locking using the remote control(button Aindicator light flashes
once a second).
Note: when the alarm is set but the
remote control does not operate: Unlock the doors with the key
and open the door. The alarm istriggered.
Switch on the ignition in the next
ten seconds. The alarm is disarmed.
Incorrect operation When the ignition is switched on, if button Alights for ten seconds, there
is a fault in the siren connection.
Contact a PEUGEOT dealer to have the system checked. Automatic activation** The alarm is activated automatically two minutes after the last opening(door or boot) is closed. In order to avoid accidental triggering of the alarm when a door or the bootis opened, it is essential to first pressthe remote control opening button.
* According to specification
** According to country
YOUR 307 IN DETAIL
68

Locking / Unlocking from the inside Press button A.
This allows locking or unlocking of the doors and the tailgate. Note: if the vehicle is deadlocked,
button Adoes not function. In this
case use the remote control for unlocking. "Door open" alert With the engine running or the vehicle moving, the flashing of thecentral "STOP" warning light,
accompanied by an audible signaland a diagram locating the problem
on the multifunction display, warnsyou that a door is not properly clo-sed.
THE DOORS Opening the doors from outside Opening the doors from inside The front door unlocking controls permit complete unlocking of thevehicle.
However, the rear door unlocking controls only unlock the door concerned. Note:
the door opening switches do
not function when the vehicle is deadlocked.
Child safety This prevents either of the rear doors being opened from inside. Turn the red plastic switch a quarter of a turn using the ignition
key.
YOUR 307 IN DETAIL 69

TAILGATE Simultaneous locking or unlocking of the tailgate andthe doors The tailgate is locked or unlocked by the remote control or the driver's door lock.
To open, pull handle Aand lift the
tailgate.Note: the tailgate locks automatical-
ly when the vehicle is being driven at 6 mph (10 km/h) and unlocks whenone of the doors is opened or at aspeed below 6 mph (10 km/h).
"Tailgate open" warning When the engine is running or if the vehicle is being driven, the flashingof the central "STOP"warning light
accompanied by an audible signaland a diagram on the multifunctiondisplay warns you that the tailgate isnot properly closed. Tailgate release This enables the tailgate to be unloc- ked in the event of a central lockingfault.
- Fold back the rear seats to gain
access to the lock from inside the boot,
- Insert a small screwdriver into hole A of the lock to unlock the tailgate. THE SUNROOF* -
to partially open the roof: Turn
the switch to the right (three pos- sible settings).
- to close: Turn the switch back to
position "O".
- to open the roof completely:
Turn the switch to the left (six pos-sible settings).
- to close it completely: Turn the
switch back to position "O".
- safety auto-reverse: When the
sunroof is closing and meets anobstacle, it stops then opensagain.
- After a safety auto-reverse manoeuvre, to synchronise theposition of the switch with the roofposition, press and hold the switch.
Note: the sunroof shutter is manual.
* According to specification.
YOUR 307 IN DETAIL
70

FILLING WITH FUEL Low fuel levelWhen the minimum fuel level in the tank is rea-ched, this warning lightcomes on.
You can still drive
approximately 30 miles (50 km). Flashing of the warning light indi- cates a malfunction of the fuelgauge.
Contact a PEUGEOT dealer.The engine must be switched off when filling with fuel.
OPENING THE BONNET From inside: push the handle on the
driver's side under the fascia. From outside: lift the catch and
raise the bonnet. Bonnet strut Secure the strut to hold the bonnet open. Before closing the bonnet, replace the strut in its housing.
To close Lower the bonnet and release it at the end of its travel. Check that thebonnet is properly locked. "Bonnet open" warning* With the engine running or the vehicle moving, flashing of the central
"STOP" warning light accompanied by an audible signal and a diagram
on the multifunction display, warnsyou that the bonnet is not properlyclosed.

Open the fuel filler flap.
Insert the key then turn it to theleft.
Remove the cap and hang it onthe hook located on the inside ofthe flap.
A label affixed inside the fuel fillerflap indicates which type of fuel touse. When you fill your tank, do not conti-
nue after the third cut-off of the
pump. This could cause your vehicleto malfunction. The capacity of the tank is approxi- mately 12 gallons (60 litres). After filling the tank, lock the cap and close the fuel filler flap.
* According to specification.
YOUR 307 IN DETAIL 71

Dipped/Main beam change Pull the stalk towards you. Note:with the ignition off, if the dri-
ver's door is opened, a buzzer sounds if you have left your lights on. Front fog lamps* and rear fog lamp Rotate the ring forwards to switch on
and backwards to switch off. The statusis confirmed by the light on the instru-ment panel.
Vehicles fitted with a rear fog lamp (ring B)
Rear fog lamp
This operates with the dipped/main beam headlamps.
Vehicles fitted with front fog lamps and a rear fog lamp (ring C)* Front fog lamps (first rota- tion of the ring forwards)
These operate with the side lightsand the dipped beam lamps.
THE LIGHTS STALK Front and rear lights Selection is by turning ring
A.
Lights off Side lights on Dipped/Main beam headlamps Automatic switching on of lights* Front and rear foglamps (2nd rotation ofthe ring forwards). These operate with the
side lights and the dipped/main beam headlamps. Note: to switch off the rear fog lamp
and the front fog lamps, turn the ring backwards twice in succession.
Direction indicators (flashers) Left : downwards.
Right : upwards.
YOUR 307 IN DETAIL
72
In good or rainy weather, both day and night, therear fog lamp is dazzlingand is prohibited. Do not forget to switch
the fog lamp off when it is no lon- ger needed.
* According tospecification

AUTOMATIC SWITCHING ON OF LIGHTS* Side lights and dipped beam head- lamps switch on automatically if the
light is poor, or during operation of
the windscreen wipers. They switch
off as soon as the light becomesbright enough or the windscreenwipers stop. Note :In foggy weather the bright-
ness sensor can detect sufficient
light. As a consequence, the lights
wil not come on automatically. This function is active when the
vehicle is supplied to the customer.
To disarm or activate the function: Start with the key in the accesso- ries position (1st notch),
Press the end of the stalk formore than two seconds.
Note: after the ignition is switched
off and depending on the brightness,the lights remain on for 45 secondsor until the vehicle is locked. Do not cover the brightness sen- sor located in the centre of thefascia. It is used for automaticswitching on of the lights. Operating check
Triggering of the sensorAcivation of this function is accom- panied by an audible signal"Automatic lighting''
on the multi-
function display. The light also comes on as soon as the driver changes the stalk positionto 0. Disarming Disarming of the function is accom- panied by an audible signal Note: the function is temporarily
disarmed when the driver uses the manual lighting controls. If the brightness sensor does not function correctly , the system acti-
vates the function (the lights comeon). The driver is alerted by an audible signal, accompanied by the messa-ge "Automatic switching on of
lights faulty" .
Contact a PEUGEOT dealer to havethe system checked.
*According to specification
YOUR 307 IN DETAIL 73

Automatic timed windscreen wipers* In the AUTOposition, the wind-
screen wipers operate automatically and adapt their speed to the intensi-ty of the rainfall.
Operating check ActivationWhen the function is activated, the message "Automatic windscreen
wiping active" appears on the mul-
tifunction display. Switching off
Switching off the function is accom- panied by an audible signal. In the event of malfunction, the driver is informed by an audible signal andthe message "Auto windscreen
wiper faulty" on the multifunction
display. In the event of malfunction in the
AUTO position, the windscreen
wiper will operate in intermittentmode.
Contact a PEUGEOT dealer to have the system checked.
* According to specification
WINDSCREEN WIPER STALK Front windscreen wipers
2 Fast wipe (heavy rain)
1 Normal wipe (moderately heavy rain)
AUTO Automatic wipe*
0 Off
Single wipe (press downwards) Operation In position
1or 2, when the vehicle
stops, the windscreen wiper changes to a lower wiping speed, then resumesits initial speed when the vehicle startsagain. When the ignition has been swit- ched off for more than a minute with
the control in the AUTO* position, itis necesary to reactivate this func-tion. To do this, move the control to any
position, then move it back to the
AUTO* position.
Screenwash and headlamp wash* Pull the windscreen wiper stalk towards you. The windscreen wash then the wind- screen wipers operate for a fixed
period. The headlamp wash ope-rates simultaneously for a fewseconds, only if the dipped beam
or main beam headlamps are on.
YOUR 307 IN DETAIL
74

Maintenance position This position enables the wiper blade to be removed.
In the minute following switching off of the ignition, any action on the stalkpositions the wipers in the centre ofthe windscreen (winter parking, clea-ning, replacing the blades).
To reposition the wipers after this has been done, switch on the ignitionand operate the stalk.
* According to specification
YOUR 307 IN DETAIL75
When using an automatic car wash, switch off theignition or check that thewiper control is not in theautomatic position.
In winter it is advisable to wait forthe windscreen to completelyclear of ice before operating theautomatic wipe. Rear windscreen wiper
Turn ring
Ato the first notch for inter-
mittent wiping. Rear windscreen wash
Turn ring Apast the first notch; the
windscreen wash then the wind- screen wiper operate for a specifiedtime.

TRIP COMPUTER*Each successive press on the end of the wash/wipe stalk displays in turn:
Display B
- the date,
- the remaining range,
- the distance travelled,
- the average consumption,
- the current consumption,
- the average speed. Zero reset Press the stalk for more than two seconds.
* According to specification.
YOUR 307 IN DETAIL
76

Range The display shows the distance which can still be covered with thefuel remaining in the tank. Note :this figure may rise if there is
a change in driving style or road sur- face, accompanied by a significantdrop in current fuel consumption. If there are less than 3 litres of fuel in the tank, only three segments will bedisplayed. Current consumption This gives the fuel consumption recorded during the last two
seconds. This function is displayedonly when the vehicle is travelling atapproximately 15 mph (20 km/h). The display stops at 10 mpg (30 l/100km). Average consumption This is the ratio between the amount of fuel consumed and the distancetravelled since the computer was lastreset to zero. The display stops at 10 mpg (30 l/100km).
Distance travelled This shows the distance travelled since the computer was last reset tozero. After the trip computer has been reset to zero, the range databecomes meaningful only after thevehicle has been in use for a certainperiod. If horizontal segments are displayed instead of figures when driving,
contact a PEUGEOT dealer.
YOUR 307 IN DETAIL
77
Average speed This is obtained by dividing the dis- tance travelled by the period of timethe vehicle has been in use (with theignition on), since the computer waslast reset to zero.
